Dallmeier DDF5(X)00HDV-DN Manual de usuario

005318 / 1.0.0 / 2015-01-29

DDF5(X)00HDV-DN

Commissioning

English

www.dallmeier.com

DDF5(X)00HDV-DN-SM Commissioning

Informaon about Copyright, Trademarks, Design Patents

The reproducon, distribuon and ulizaon of this document as well as the communicaon of

its contents to others without express authorizaon is prohibited. Oenders will be held liable

for the payment of damages.

We reserve the right to make technical modicaons.

The manufacturer accepts no liability for damage to property or pecuniary damages arising due

to minor defects of the product or documentaon, e.g. print or spelling errors, and for those not

caused by intenon or gross negligence of the manufacturer.

All trademarks idened by ® are registered trademarks of Dallmeier electronic.

All trademarks idened by *) are trademarks or registered trademarks of the following owners:

AMD and AMD Athlon of Advanced Micro Devices, Inc. headquartered in Sunnyvale, California, USA;

Intel and Penum or Intel Penum of Intel Corporaon headquartered in Santa Clara, California, USA;

JavaScript of Oracle Corporaon (and/or its aliates) headquartered in Redwood Shores, California, USA;

microSDXC of SD-3C, LLC headquartered in North Hollywood, California, USA;

Microso, AcveX, DirectX, Internet Explorer, Windows and Windows Vista of Microso Corporaon headquar-

tered in Redmond, Washington, USA.

Third-party trademarks are named for informaon purposes only.

Dallmeier electronic respects the intellectual property of third pares and always aempts to ensure the com-

plete idencaon of third-party trademarks and indicaon of the respecve holder of rights.

In case that protected rights are not indicated separately, this circumstance is no reason to assume that the

respecve trademark is unprotected.

www.dallmeier.com 3

Commissioning DDF5(X)00HDV-DN-SM

Contents

1 Validity 4

2 Documents 4

This Document 5

Other Applicable Documents

Data Sheet

The document “Data Sheet” contains detailed technical specicaons, features

and characteriscs of the device.

The target audience of the document is trained system integrators.

Conguraon

The document “Conguraon” contains detailed descripons on the conguraon

of the device.

The target audience of the document is trained system integrators.

www.dallmeier.com

DDF5(X)00HDV-DN-SM Commissioning

3 Typographical Convenons

This document may contain various warning words and symbols that indicate

potenal sources of danger:

DANGER

DANGER indicates a hazardous situaon which, if not avoided, will

result in death or serious injury.

WARNING

WARNING indicates a hazardous situaon which, if not avoided,

could result in death or serious injury.

CAUTION

CAUTION indicates a hazardous situaon which, if not avoided,

could result in minor or moderate injury.

NOTICE

NOTICE is used to address pracces not related to physical injury.

www.dallmeier.com 7

Commissioning DDF5(X)00HDV-DN-SM

For reasons of clarity and readability, various text formang elements and types

of emphasis are used in this documentaon:

Instrucons are indicated by arrows (➡).

➡Always carry out instrucons one aer the other in the sequence described.

“Expressions” in quotaon marks generally indicate a control element on the

device (switches or labels) or on its user interface (buons, menu items).

Paragraphs in italics provide informaon on basic principles, special features

and ecient procedure as well as general recommendaons.

www.dallmeier.com

DDF5(X)00HDV-DN-SM Commissioning

4 Safety Instrucons

Only use the device if it is technically in proper working condion and for the

intended purpose while keeping safety and potenal dangers in mind.

• Qualied Personnel

The installaon, mounng, connecon, commissioning and conguraon of the

device may only be carried out by qualied personnel.

This also applies to the maintenance, tesng and repair, whereat the regula-

ons of the DIN VDE 0701 series of standards (repair, modicaon and inspec-

on of electrical appliances) must be followed.

• Regulaons

The use of video and audio surveillance systems is, in general, strictly regulated.

Inform yourself about the currently valid laws and regulaons regarding data,

worker and environmental protecon before using the device and ensure

compliance with them.

• System Components

Only use internal components that have been tested and approved by Dallmeier.

Inappropriate internal components may cause malfuncons, damages and data

loss and may result in the loss of warranty.

• Modicaons

Do not make any modicaons to the hardware or soware that have not been

tested and approved by Dallmeier.

Inappropriate modicaons may cause malfuncons, damages and data loss

and may result in the loss of warranty.

www.dallmeier.com 9

Commissioning DDF5(X)00HDV-DN-SM

• Documentaon

Read the documents included in the delivery carefully and thoroughly.

Always observe the contained instrucons, notes and warnings.

The product documentaon contains several documents which are included in

the scope of delivery in a printed form and/or on a digital medium.

Keep all documents in legible condion and in a suitable locaon for future

reference.

• Condensaon Water

If the device is brought from a cold to a warm environment, resulng conden-

saon water may cause malfuncons and damages.

In this case, wait (up to 8 hours) unl the device has reached room tempera-

ture before commissioning.

• Earthing & Equipotenal Bonding

For the safety of persons (protecon against dangerous contact voltages) and

devices (protecon against over-voltages) and the immunity of informaon and

communicaon technology equipment to electromagnec interferences (EMI),

all protecve measures, which are specied by the currently valid DIN, VDE and

ISO standards and which provide for a standard-compliant earthing and a cor-

rect equipotenal bonding of electrical and electronic devices, are mandatory

and must be fullled by all means.

• Lightning Storms

To avoid damage to the device by electrical surge during lightning storms, all

protecve measures, which are specied by the currently valid DIN, VDE and

ISO standards and which provide for a standard-compliant lightning protecon

equipotenal bonding, are mandatory and must be fullled by all means.

www.dallmeier.com

DDF5(X)00HDV-DN-SM Commissioning

• Operang Condions

Unfavorable operang condions may shorten the life of the device and may

cause malfuncons, damages and data loss and may result in the loss of war-

ranty.

Observe the specicaons given in the technical data, the operang condion

requirements and the maintenance instrucons.

• Foreign Bodies

If objects or liquids get into the device, immediately disconnect it from the

power supply (pull out the power plug).

Contact the sales partner responsible for your area.

• Burnt Smell

If you noce burnt smell or a formaon of smoke coming from the device, im-

mediately disconnect it from the power supply (pull out the power plug).

Contact the sales partner responsible for your area.

• Opening

The device may only be opened by qualied personnel for commissioning,

inspecon, maintenance and repair.

• Disposal

Do not dispose waste electrical and electronic equipment into the household

trash.

Disconnect the device from the power supply.

Remove all connected devices.

Return the device to your respecve sales partner.
