dallmeier DDF5 00HDV-DN-IM Series Guía
005316 / 1.0.5 / 2018-12-19
IM
DDF5(X)00HDV-DN
Commissioning
English
2www.dallmeier.com
DDF5(X)00HDV-DN-IM Commissioning
Informaon about Copyright, Trademarks, Design Patents
© 2018 Dallmeier electronic
The reproducon, distribuon and ulizaon of this document as well as the communicaon of its contents to
others without express authorizaon is prohibited. Oenders will be held liable for the payment of damages.
All rights reserved in the event of the grant of a patent, ulity model or design.
We reserve the right to make technical modicaons.
The manufacturer accepts no liability for damage to property or pecuniary damages arising due to minor de-
fects of the product or documentaon, e.g. print or spelling errors, and for those not caused by intenon or
gross negligence of the manufacturer.
All trademarks idened by ® are registered trademarks of Dallmeier electronic.
All trademarks idened by *) are trademarks or registered trademarks of the following owners:
Google and Google Chrome of Google Inc. headquartered in Mountain View, California, USA;
HDMI of HDMI Licensing, LLC headquartered in Sunnyvale, California, USA;
JavaScript of Oracle Corporaon (and/or its aliates) headquartered in Redwood Shores, California, USA;
microSDHC of SD-3C, LLC headquartered in North Hollywood, California, USA;
Microso, Internet Explorer, Microso Edge and Windows of Microso Corporaon headquartered in Red-
mond, Washington, USA;
Mozilla and Firefox of Mozilla Foundaon headquartered in Mountain View, California, USA.
Third-party trademarks are named for informaon purposes only.
Dallmeier electronic respects the intellectual property of third pares and always aempts to ensure the com-
plete idencaon of third-party trademarks and indicaon of the respecve holder of rights.
In case that protected rights are not indicated separately, this circumstance is no reason to assume that the
respecve trademark is unprotected.
This product includes soware developed by the OpenSSL Project for use in the OpenSSL Toolkit
(hp://www.openssl.org) and cryptographic soware wrien by Eric Young (eay@cryptso.com).
www.dallmeier.com 3
Commissioning DDF5(X)00HDV-DN-IM
Contents
1 Validity 4
2 Documents 4
This Document 5
Other Applicable Documents 5
3 Typographical Convenons 6
4 Safety Instrucons 8
5 General Notes 11
Scope of Delivery 11
Transportaon and Packaging 11
Warranty 12
Approvals/Cercaons 12
Appropriate Use 12
Operaon 13
6 Requirements 14
Ambient Condions 14
Power Supply 15
7 Maintenance 16
8 Installaon 18
9 Pin Assignment 38
10 Connecon and Login 40
Connecon 41
Login 42
11 Technical Specicaons 44
12 Dimensions 46
4www.dallmeier.com
DDF5(X)00HDV-DN-IM Commissioning
1 Validity
This document applies to the following devices:
• DDF5200HDV-DN-IM
• DDF5300HDV-DN-IM
• DDF5400HDV-DN-IM
Figures in this document may dier from the actual product.
2 Documents
The product documentaon contains several documents which are included in the
scope of delivery in a printed form and/or on a digital medium.
Read all documents included in the scope of delivery carefully and thoroughly
before using the device.
Always follow the instrucons, notes and warnings and observe the technical
specicaons in the product data sheet.
Keep all documents in legible condion and in a suitable locaon for future refer-
ence.
Regularly check the website www.dallmeier.com for the latest updates on product
documentaon.
www.dallmeier.com 5
Commissioning DDF5(X)00HDV-DN-IM
This Document
Commissioning
The document “Commissioning” (this document) contains detailed descripons on
installaon, connecon and commissioning of the device as well as safety instruc-
ons and general notes.
The target audience of this document is trained system integrators.
Other Applicable Documents
Data Sheet
The document “Data Sheet” contains detailed technical specicaons, features
and characteriscs of the device.
The target audience of the document is trained system integrators.
Conguraon
The document “Conguraon” contains detailed descripons on the conguraon
of the device.
The target audience of the document is trained system integrators.
6www.dallmeier.com
DDF5(X)00HDV-DN-IM Commissioning
3 Typographical Convenons
This document may contain various warning words and symbols that indicate
potenal sources of danger:
DANGER
DANGER indicates a hazardous situaon which, if not avoided, will
result in death or serious injury.
WARNING
WARNING indicates a hazardous situaon which, if not avoided,
could result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situaon which, if not avoided,
could result in minor or moderate injury.
NOTICE
NOTICE is used to address pracces not related to physical injury.
www.dallmeier.com 7
Commissioning DDF5(X)00HDV-DN-IM
For reasons of clarity and readability, various text formang elements and types
of emphasis are used in this documentaon:
Instrucons are indicated by arrows (➡).
➡Always carry out instrucons one aer the other in the sequence described.
“Expressions” in quotaon marks generally indicate a control element on the
device (switches or labels) or on its user interface (buons, menu items).
Paragraphs in italics provide informaon on basic principles, special features
and ecient procedure as well as general recommendaons.
8www.dallmeier.com
DDF5(X)00HDV-DN-IM Commissioning
4 Safety Instrucons
Only use the device if it is technically in proper working condion and for the
intended purpose while keeping safety and potenal dangers in mind.
• Qualied Personnel
The installaon, mounng, connecon, commissioning and conguraon of the
device may only be carried out by qualied personnel.
This also applies to the maintenance, tesng and repair, whereat the regula-
ons of the DIN VDE 0701 series of standards (repair, modicaon and inspec-
on of electrical appliances) must be followed.
• Regulaons
The use of video and audio surveillance systems is, in general, strictly regulated.
Inform yourself about the currently valid laws and regulaons regarding data,
worker and environmental protecon before using the device and ensure
compliance with them.
• System Components
Only use internal components that have been tested and approved by Dallmeier.
Inappropriate internal components may cause malfuncons, damages and data
loss and may result in the loss of warranty.
• Modicaons
Do not make any modicaons to the hardware or soware that have not been
tested and approved by Dallmeier.
Inappropriate modicaons may cause malfuncons, damages and data loss
and may result in the loss of warranty.
www.dallmeier.com 9
Commissioning DDF5(X)00HDV-DN-IM
• Documentaon
Read the documents included in the delivery carefully and thoroughly.
Always observe the contained instrucons, notes and warnings.
The product documentaon contains several documents which are included in
the scope of delivery in a printed form and/or on a digital medium.
Keep all documents in legible condion and in a suitable locaon for future
reference.
• Condensaon Water
If the device is brought from a cold to a warm environment, resulng conden-
saon water may cause malfuncons and damages.
In this case, wait (up to 8 hours) unl the device has reached room tempera-
ture before commissioning.
• Earthing & Equipotenal Bonding
For the safety of persons (protecon against dangerous contact voltages) and
devices (protecon against over-voltages) as well as for the immunity of infor-
maon and communicaon technology equipment to electromagnec interfer-
ences (EMI), all protecve measures, which are specied by the currently valid
DIN, VDE and ISO standards and which provide for a standard-compliant earth-
ing and a correct equipotenal bonding of electrical and electronic devices, are
mandatory and must be fullled by all means.
• Lightning Storms
To avoid damage to the device by electrical surge during lightning storms, all
protecve measures, which are specied by the currently valid DIN, VDE and
ISO standards and which provide for a standard-compliant lightning protecon
equipotenal bonding, are mandatory and must be fullled by all means.
10 www.dallmeier.com
DDF5(X)00HDV-DN-IM Commissioning
• Operang Condions
Unfavorable operang condions may shorten the life of the device and may
cause malfuncons, damages and data loss and may result in the loss of war-
ranty.
Observe the specicaons given in the technical data, the operang condion
requirements and the maintenance instrucons.
• Foreign Bodies
If objects or liquids get into the device, immediately disconnect it from the
power supply (pull out the power plug).
Contact the sales partner responsible for your area.
• Burnt Smell
If you noce burnt smell or a formaon of smoke coming from the device, im-
mediately disconnect it from the power supply (pull out the power plug).
Contact the sales partner responsible for your area.
• Opening
The device may only be opened by qualied personnel for commissioning,
inspecon, maintenance and repair.
• Disposal
Do not dispose waste electrical and electronic equipment into the household
trash.
Disconnect the device from the power supply.
Remove all connected devices.
Return the device to your respecve sales partner.
