D-Link DHP-342 Manual de usuario

2D-Link DHP-342 User Manual

Table of Contents

Product Overview ........................................................ 3

Package Contents ................................................... 3

System Requirements ............................................. 3

Introduction .............................................................. 4

Features .................................................................. 4

Hardware Overview ................................................. 5

LEDs .................................................................. 5

Connection......................................................... 6

Hardware Installation .................................................. 7

Push Button Security ...............................................8

Using the Setup Wizard .............................................. 9

Conguration.............................................................11

Setup ..................................................................... 13

Security.................................................................. 15

Application QoS ..................................................... 16

Advanced QoS ...................................................... 17

Reset ..................................................................... 18

Troubleshooting ........................................................ 19

Technical Specications........................................... 20

Table of Contents

3D-Link DHP-342 User Manual

Section 1 - Product Overview

• D-Link DHP-342 Powerline HD 4-Port Switch

• CAT5 Ethernet Cable

• Power Cord

• CD-ROM with Software and User Manual

• Quick Install Guide

System Requirements

• Windows Vista®, XP (with Service Pack 2) or 2000 (with Service Pack 4)

• PC with 233MHz Processor, 64MB Memory

• Ethernet Adapter (100MBit/s)

Product Overview

Package Contents

4D-Link DHP-342 User Manual

Section 1 - Product Overview

Introduction

D-Link announces a fast, 200Mbps* Powerline HD 4-Port Switch which allows you to connect your home computers,

networking devices and gaming devices through the most pervasive medium in your house - the electric powerlines

- and share Internet connections, printers, transfer les, play games, and more. This adapter can be used to network

multiple Ethernet-enabled devices with a 10/100Base-T adapter through powerlines.

Features

• Provides Ethernet to Powerline Connection

• Fast Data Transfer Rate of Up to 200Mbps*

• Four 10/100 Ethernet ports

• Plug & Play, Easy Installation

• Easy to use Management Utility

• Congurable QoS for video streaming, VoIP and Gaming

• Firmware Upgrade Support

• Push button security

• Throughput LED

• Power Saving mode

• LLTD Support (Windows Vista®)

* Maximum throughput based on theoretical transmission PHY rate. Actual date throughput will vary. Network conditions and environmental factors, including volume

of trafc and network overhead, may lower actual data throughput rate. Interference from devices that emit electrical noise, such as vacuum cleaners and hair dryers,

may adversely affect the performance of this product. This product may interfere with devices such as lighting systems that have a dimmer switch, short wave radios,

or other powerline devices that do not follow the Universal Powerline Association (UPA) standard.

5D-Link DHP-342 User Manual

Section 1 - Product Overview

Hardware Overview

LEDs

Power LED

A solid light indicates that the

device is receiving power.

AP LED

A solid light indicates that the device

is the master unit in the powerline

network.

Ethernet LED (1-4)

A solid light indicates a connection on the

Ethernet port. The LED blinks during data

transmission.

Throughput LED

A solid light indicates that the Powerline device has connected to another

Powerline device on the network.

Green LED: Power Line speed > 20Mbps (non master unit)

Amber LED: Power Line speed < 20Mbps or > 6Mbps (non master unit)

Red LED: Power Line speed < 6Mbps or link is down. (non master unit)

6D-Link DHP-342 User Manual

Section 1 - Product Overview

Hardware Overview

Connection

Ethernet Ports (1-4)

Connect Ethernet-enabled devices to

the DHP-342 Ethernet ports.

Push Button Security

Press to secure your network. Refer

to page 8 for more information.

Power Receptor

Connect the supplied power

cord to the power receptor.

7D-Link DHP-342 User Manual

Section 2 - Installation

Hardware Installation

Power

Plug in the DHP-342 into an AC wall outlet or power strip.

Note: Power source is conrmed when the green LED Power Indicator on the DHP-342 is illuminated.

Connect the Ethernet Cable

Connect the included Ethernet cable to the network cable connector located on the DHP-342 and attach the

other end of the Ethernet cable to the network or PC. Network Connectivity is conrmed when the Throughput

and Ethernet LED Indicators on the DHP-342 are illuminated.

8D-Link DHP-342 User Manual

Section 2 - Installation

1. All Adapters

Plug in all the adapters to be congured.

2. First Adapter

Select the rst adapter to be congured as the AP(Access Point). Press and hold the button until the AP LED starts ashing.

Note: It is recommended to choose a Powerline adapter directly connected to a router or a Media Center PC to be the master unit. There

must be only one master unit in the network.

The adapters memorize their security settings even after power is removed from the units. The security settings of any adapter can be

cleared by pressing the button until its AP LED is off. This will reset the unit back to the factory default settings.

3. First Adapter

Wait until the AP LED stops ashing (up to 30 seconds).

4. First Adapter

The AP LED remains on and is now ready to start registering new adapters.

5. First Adapter

Press the button until its AP LED starts ashing and continue to the new adapter.

6. New Adapter

Press and hold the button in the new adapter until the AP LED starts ashing.

7. New Adapter

The new adapter’s AP LED will turn off indicating that it is securely congured and its throughput LED will indicate the link quality.

8. First Adapter

After registering the new adapter, the AP LED of the rst adapter remains on and its throughput LED will indicate the link quality.

Note: When adding more adapters, repeat steps 5 to 8. At the end of this process, only one adapter should have the AP LED on.

Push Button Security

9D-Link DHP-342 User Manual

Section 2 - Installation

Follow the simple steps below to run the Setup Wizard to guide you quickly through the installation process.

Insert the D-Link DHP-342 CD into your CD-ROM drive. If the CD Autorun function does not automatically start on

your computer, click Start > Run.

In the Run command box type “D:\DHP342.exe”, where D: represents the drive letter of your CD-ROM. If it does start,

proceed to the next screen.

Click on Install Utility

Using the Setup Wizard

Click Next

The InstallShield Wizard will begin the DHP-342 software

installation.

10D-Link DHP-342 User Manual

Section 2 - Installation

Click Next

Click Finish
