D-Link DIR-825/AC Manual de usuario

Quick Installation Guide

DIR-825/AC

Wireless AC1200 Dual Band Gigabit Router

with G/LTE Support and USB Port

DIR-825/AC Quick Installation Guide

BEFORE YOU BEGI

Delivery Package

•Router DIR-825/AC

•Power adapter DC 12V/1.5A

•Ethernet cable (CA 5E)

•“Quick Installation Guide” (brochure).

If any of the items are missing, please contact your reseller.

he “User Manual” and “Quick Installation Guide” documents are available

on D-Link website (see www.dlink.ru).

!Using a power supply with a different voltage rating than the one

included will cause damage and void the warranty for this product.

DIR-825/AC Quick Installation Guide

Default Settings

IP address of wireless router 192.168.0.1

Username (login) admin

Password admin

ame of wireless network (SSID)

2.4GHz DIR-825

5GHz DIR-825-5G

etwork key (PSK password)

see WPS PIN on the

barcode label on the

bottom panel of the

device

Router DIR-825/AC with default settings cannot connect to the

Internet. o get started, please set your own password for access to the

web-based interface and change the WLAN name (SSID); then, if

needed, configure other settings recommended by your ISP.

DIR-825/AC Quick Installation Guide

System Requirements and Equipment

•A computer with any operating system that supports a web browser.

•A web browser to access the web-based interface of the router:

◦Apple Safari 8 and later

◦Google Chrome 48 and later

◦Microsoft Internet Explorer 10 and later

◦Microsoft Edge 20.10240 and later

◦Mozilla Firefox 44 and later

◦Opera 35 and later.

•A NIC (Ethernet or Wi-Fi adapter) to connect to the router.

•An 802.11a, b, g, n, or ac Wi-Fi adapter to create a wireless network.

•A USB modem (when it is necessary to connect to the Internet via mobile

operators' networks)1.

Your USB modem should be equipped with an active SIM card of your

operator.

Some operators require subscribers to activate their USB modems prior

to using them. Please, refer to connection guidelines provided by your

operator when concluding the agreement or placed on its website.

For some models of L E USB modems, it is required to disable the PIN

code check on the SIM card prior to connecting the USB modem to the

router.

1 Contact your operator to get information on the service coverage and fees.

DIR-825/AC Quick Installation Guide

CO ECTI G TO PC

PC with Ethernet Adapter

1. Make sure that your PC is powered off.

2. Connect an Ethernet cable between any of LAN ports located on the back

panel of the router and the Ethernet port of your PC.

3. To connect via USB modem: connect your USB modem to the USB port2

located on the back panel of the router.

!In some cases you will need to reboot the router after connection of the

USB modem.

4. Connect the power cord to the power connector port on the back panel of

the router, then plug the power adapter into an electrical outlet or power

strip.

5. urn on the router by pressing the POWER button on its back panel.

6. urn on your PC and wait until your operating system is completely

loaded.

Now you should configure your PC to obtain an IP address automatically (as

DHCP client).

2 It is recommended to use a USB extension cable to connect a USB modem to the

router.

DIR-825/AC Quick Installation Guide

Obtaining P Address Automatically

in OS Windows XP

1. Click the Start button and proceed to the Control Panel > etwork

and Internet Connections > etwork Connections window.

2. In the etwork Connections window, right-click the relevant Local

Area Connection icon and select the Properties line in the menu

displayed.

3. In the Local Area Connection Properties window, on the General

tab, select the Internet Protocol (TCP/IP) line. Click the Properties

button.

DIR-825/AC Quick Installation Guide

4. Select the Obtain an IP address automatically and Obtain D S

server address automatically radio buttons. Click the OK button.

5. Click the ОК button in the connection properties window.

Now your computer is configured to obtain an IP address automatically.

DIR-825/AC Quick Installation Guide

Obtaining P Address Automatically

in OS Windows 7

1. Click the Start button and proceed to the Control Panel window.

2. Select the etwork and Sharing Center section. (If the Control Panel

has the category view (the Category value is selected from the View by

drop-down list in the top right corner of the window), choose the View

network status and tasks line under the etwork and Internet

section.)

3. In the menu located on the left part of the window, select the Change

adapter settings line.

4. In the opened window, right-click the relevant Local Area Connection

icon and select the Properties line in the menu displayed.

5. In the Local Area Connection Properties window, on the

etworking tab, select the Internet Protocol Version 4 (TCP/IPv4)

line. Click the Properties button.

DIR-825/AC Quick Installation Guide

6. Select the Obtain an IP address automatically and Obtain D S

server address automatically radio buttons. Click the OK button.

7. Click the OK button in the connection properties window.

Now your computer is configured to obtain an IP address automatically.

DIR-825/AC Quick Installation Guide

PC with Wi-Fi Adapter

1. To connect via USB modem: connect your USB modem to the USB port3

located on the back panel of the router.

!In some cases you will need to reboot the router after connection of the

USB modem.

2. Connect the power cord to the power connector port on the back panel of

the router, then plug the power adapter into an electrical outlet or power

strip.

3. urn on the router by pressing the POWER button on its back panel.

4. urn on your PC and wait until your operating system is completely

loaded.

5. urn on your Wi-Fi adapter. As a rule, modern notebooks with built-in

wireless NICs are equipped with a button or switch that turns on/off the

wireless adapter (refer to your PC documents). If your PC is equipped

with a pluggable wireless NIC, install the software provided with your

Wi-Fi adapter.

Now you should configure your Wi-Fi adapter.

3 It is recommended to use a USB extension cable to connect a USB modem to the

router.
