D-Link DWR-961 Manual de usuario

Wireless AC1200 4G lTe rouTer

DWr-961

QUICK

INSTALLATION

GUIDE

DWr-961

PACKAGE CONTENTS

CoNTeNTs

WirElESS AC1200 4G lTE rOuTEr

DWR-961

12V 1.5A POWEr ADAPTEr

If any of these items are missing or damaged, please contact

your reseller.

ETHErNET CABlE

2X 4G BlADE ANTENNAS

DWr-961 3

PrODuCT

SETuP

BAsiC seTuP

Ensure that your DWR-961 Wireless AC1200 4G LTE Router is powered off before performing the

steps below.

1. Verify that your SIM/UICC card is installed and has been activated by your carrier.

2. Attach the included antennas to the back of the router, screwing them in clockwise.

Arrange them so that they point upward.

3. Connect the power adapter to the socket on the back panel of your DWR-961. Plug the other

end of the power adapter into a wall outlet or power strip. Make sure the power button is in the

"On" position

a. The Power LED will light up to indicate that power is being supplied to the router and the

router is turned on.

 b.ThenetworkLEDonthefrontpanelwillashonandoffastheDWR-961performs

initialization and Internet connection processes.

c. After a few moments, if a connection has been established, the following LEDs will turn solid

green: Power, Internet, 2.4 GHz or 5 GHz (if enabled), 4G (if connected), LAN (if connected),

WAN (if connected), and Signal Strength.

Note: By default, the DWR-961 uses the mobile network as the sole Internet connection. If you

wish to use your mobile connection as a backup to a wired connection, or you wish to use a

wired connection exclusively, you must use the Optional Advanced Setup procedure.

4. Connect via Wi-Fi using the SSID and password printed on the bottom of the router, or through

Ethernet via one of the LAN ports on the back of your DWR-961.

SIM/UICC card

oPTioNAl ADVANCeD seTuP (ACCess ViA iP ADDress)

1. Once connected to your router, open a web browser and enter the IP address below into the

browseraddresseld.Loginusingtheusernameandpasswordbelow.

IP ADDRESS: http://192.168.0.1

USERNAME: admin

PASSWORD: [leave this blank]

2. After logging in, you can access the setup wizard which will guide you through the rest of the

setup process. To reach the wizard, click the Internet tab on the bar along the top, then click

Wizard on the left hand side. Follow the on-screen instructions.

For additional information, see the user manual.

TrOuBlESHOOTiNG

seTuP AND CoNFiGurATioN ProBleMs

1. HOW DO i CONFiGurE MY DWr-961 rOuTEr Or CHECK MY WirElESS NETWOrK

NAME (SSiD) AND WirElESS ENCrYPTiON KEY?

- Connect your PC to the router using an Ethernet cable.

- Open a web browser and enter the router's IP address: http://192.168.0.1 into the address bar.

- Log into the router using the default username admin. By default, the password is left blank.

-Onceloggedin,youcanusethewizardtoconguretherouter,ormakechangesmanually.

Note: If you have changed the password and cannot remember it, you will need to reset the

router to factory defaults. The default SSID and password are printed on the bottom of your

router.

2. HOW DO i rESET MY DWr-961 rOuTEr TO FACTOrY DEFAulT SETTiNGS?

- If you cannot remember your router administrator password, you may use an implement such as

a straightened paperclip to press and hold the reset button on the left-hand side of the router for

about 10 seconds.

Note:Resettingtheroutertofactorydefaultsettingswillerasethecurrentconguration.To

 recongureyourrouter,loginasoutlinedinquestion1,thenruntheSetupWizard.

3. HOW DO i ADD A NEW WirElESS CliENT Or PC iF i HAVE FOrGOTTEN MY

WirElESS NETWOrK NAME (SSiD) Or WirElESS ENCrYPTiON KEY?

- For every PC that needs to connect to the router wirelessly, you will need to ensure you use the

correct Wireless Network Name (SSID) and encryption key.

 -Usetheweb-baseduserinterface(asdescribedinquestion1above)tocheckorchooseyour

wireless settings.

- Make sure you write down the SSID and password so that you can enter them into each

wirelesslyconnectedPC.Youwillndadedicatedareaonthebackofthisdocumenttorecord

this important information for future use.

4. WHY AM i uNABlE TO ESTABliSH AN iNTErNET CONNECTiON?

- If connecting using a 4G LTE mobile connection, make sure that you are within range of the

mobileserviceprovider,andthattheservicehasbeencorrectlycongured.

Important: Due to variances in 4G LTE signal saturation, it may be necessary to try setting

up the D-Link High-Speed Internet Router in various rooms and locations to obtain the signal

strength necessary for a strong mobile connection.

- If connecting using the WAN via ADSL/Cable service, make sure the modem has been enabled,

connected, and is operational, and that the service is correctly congured.

Technical Support

Please contact with your eld sales team for any technical inquiries

Ver.1.00(US)_130x183 2018/08/31 29072600D961D10
