Quick Installation Guide

DVG-5102S

VoIP Telephone Adapter

Check Your Package Contents

DVG-5102S

VoIP TA

Ether CAT5 UTP)

Cable

12VDC, 1A Power

Adapter

Using a power

adapter with a different

voltage rating will

damage this product

and void the warranty.

Front Panel

1. Power Indicator: Solid green light indicates a normal power supply.

2. Alarm Indicator: Red light indicates abnormal status, such as

failed to register or provision or not obtained IP address.

3. Register Indicator: The Register LED will turn on when the VoIP

Router is connected to a VoIP service provider. The LED will blink if

not connected to a service provider.

4. LAN indicator: When a connection is established the LED will light

up solid. The LEDs will blink to indicate activity. If the LED does not

light up when a cable is connected, verify the cable connections and

make sure your devices are powered on.

5. WAN indicator: When a connection is established the LED will light

up solid. The LED will blink to indicate activity. If the LED does not

light up when a cable is connected, verify the cable connections and

make sure your devices are powered on.

6. Phone Indicator: Phone LED will light up solid if a phone

connected to a phone port is off the hook or in use. When a phone

is ringing, the indicator will blink.

Hardware Overview

Rear Panel

1. Phone : Connect to your phones using standard phone cabling (RJ-

11).

2. WAN: Connect to your broadband modem or router using an

Ethernet cable.

3. LAN: Connect to your Ethernet enabled computers using Ethernet

cabling.

4. Power receptor: Receptor for the provided power adapter.

5. Reset Button: Press this button to restore factory default settings.

Hardware Overview (continued)

A. Insert one end of the Ethernet cable into the Ethernet (LAN) port on

the back panel of the DVG-5102S and the other end of the cable to

an Ethernet Adapter or available Ethernet port on your computer.

B. Insert one end of the Ethernet cable into the WAN port on the back of

the DVG-5102S and the LAN port of your router.

C. Insert a telephone cable into the Phone port, and then connect the

cable to your telephone.

Installing the Hardware

D. Connect the power adapter to the power input at the back panel of

the DVG-5102S and then plug the other end of the power adapter to

a wall outlet or power strip. On the front of the device, the Power LED

will turn on to indicate proper operation.

E. Check the LED display on the front of the VoIP TA to confirm that the

connections have been made.

Installing the Hardware (continued)

After the installations are completed, your network should look similar to

the diagram below.

Hardware configuration is complete! If your VoIP service is already activated, you

can make phone calls now.

Installing the Hardware (continued)

Configuration

To access the web-based configuration utility, set a statics IP on the LAN

adapter, open a web browser such as Internet Explorer and enter the IP

address of the DVG-5102S.

*Statics IP: 192.168.8.XXX, the “XXX” can be any number from 1~253 except 254 cannot

be used*

If the DVG-5102S is connected behind a router, the IP address of the

router is determine by the router’s DHCP Server.

Open your Web browser and

type http://192.168.8.254 into

the URL address box. Press

the Enter or Return Key.

User name: User

Password: [leave this blank]

Click Login to enter Web Site.

Configuration (continued)

The username of USER have been

defined and locked by default. It is

highly recommended to create a

secure at “Maintenance Device

Management User”.

Click “Apply” “Save and Reboot”

Select your Internet connection type:

DHCP –Connecting the DVG-

5102S behind a router.

Static IP –Select if your ISP

supplied you with your IP settings.

PPPoE –Most DSL ISPs.

Select Manual to manually enter IP

address of DNS or select Auto if

DNS is assigned by ISP.

Technical Support

You can find software updates and user documentation on the D-Link

website.

Tech Support for customers within Singapore:

D-Link Technical Support over the Telephone:

Service Centre Hotline: (65) 6774 6233 [Press 1]

24x7 Technical Support Hotline: (65) 6501 4200

D-Link Technical Support over the Internet:

www.dlink.com.sg/support/

email:[email protected]
