D-Link DHN-520 Manual de usuario

DHN-520

10Mb Home Phoneline Network Adapter

User’s Guide

Rev. 02 (June, 2001)

6DHN520…01

Printed in Taiwan

D-Link DHN-520 10Mb Home Phoneline Network Adapter for the PCI Bus

RECYCLABLE

D-Link DHN-520 10Mb Home Phoneline Network Adapter for the PCI Bus

FCC Certifications

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

Shielded interface cables must be used in order to comply with emission limits.

You are cautioned that changes or modifications not expressly approved by the party responsible for

compliance could void your authority to operate the equipment.

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) This device must accept any interference

received, including interference that may cause undesired operation.

D-Link DHN-520 10Mb Home Phoneline Network Adapter for the PCI Bus

Table of Contents

INTRODUCTION ..........................................................................................1

ABOUT PHONELINE NETWORKING...................................................................1

FEATURES ......................................................................................................2

INSTALLATION............................................................................................3

UNPACK AND INSPECT....................................................................................3

SOFTWARE INSTALLATION.............................................................................4

INSTALL THE ADAPTER...................................................................................5

CONNECT THE PHONELINE CABLE...................................................................5

TROUBLESHOOTING..................................................................................6

SPECIFICATIONS.........................................................................................7

D-LINK OFFICES..........................................................................................9

LIMITED WARRANTY..............................................................................10

D-Link DHN-520 10Mb Home Phoneline Network Adapter for the PCI Bus

Introduction

Thank you for choosing the D-Link DHN-520. As a leading network

manufacturer, D-Link is dedicated to making the best cost/performance adapter on

the market. This Introduction chapter will be useful if you are new to phoneline-

based networking and other new technologies featured in the D-link DHN-520.

Otherwise, skip ahead to the Installation chapter.

For more information on D-Link go to www.dlink.com.

About Phoneline Networking

HomePNA 1.0 is a standard as defined and ratified by the Home Phoneline

Networking Association (HomePNA). Currently The DHN-520 was designed

around the proposed iLine10standard as accepted by the HomePNA on July

27, 1999 as the basis for HomePNA 2.0.

Home Phoneline Networking allows a home user to build a network utilizing their

standard home phone lines. It removes the need to install separate hardware or

specialty cables as is required by other networking technologies. With a full 10Mb

of bandwidth, the data throughput speed is effectively 150-200 times faster than a

V.90 modem.

This technology will allow a Microsoft Window 95 OSR2, Windows 98, Windows

Me, Windows NT 4.0 and Windows 2000 user to quickly share files and printers.

With additional software a user may also play multi-player network games and

share Internet access.

D-Link DHN-520 10Mb Home Phoneline Network Adapter for the PCI Bus

Features

Designed for versatility and performance, the D-Link DHN-520 provides the

following features:

•Backwards compatibility with older 1 Mb HomePNA 1.0 certified hardware

•Operates in a PCI Bus Master slot of a Pentium/Pentium-Pro/Pentium-II

computer, independent of CPU speed.

•PCI Bus Master memory access for high throughput and low CPU demand.

•Plug and Play installation.

•10 Mbps throughput over standard home phone lines.

•Two LED indicators: Link and Activity.

D-Link DHN-520 10Mb Home Phoneline Network Adapter for the PCI Bus

Installation

Installation of a D-Link DHN-520 10Mb Home Phoneline Network Adapter

requires that the software be installed first, then hardware.

Unpack and Inspect

CAUTION:Under ordinary circumstances, a D-Link DHN-520 card will not be affected

by static charge as may be received through your body during handling of

the unit. In special circumstances where you may carry an extraordinarily

high static charge, it is good practice to reduce the charge by touching a

ground before handling the adapter card.

Open the shipping carton and carefully remove all items. In addition to this User's

Guide, ascertain that you have:

•One DHN-520 Ethernet Adapter Card.

•DHN-520 Software CD.

•Phoneline Cable.

•DHN-520 Quick Install Guide

D-Link DHN-520 10Mb Home Phoneline Network Adapter for the PCI Bus

Software Installation

Note for Microsoft Windows 98, 98SE, Me and 2000 users:

Please follow the instructions in the printed Quick Install Guide for

your version of Windows to install the software correctly.

Due to the great variety of network environments and system configurations in

which the DHN-520 may be used, and revisions of those network systems, the

instructions for software installation in Microsoft Windows 98, 98SE, Me and 2000

are provided in the printed Quick Install Guide. HTML versions of the same QIG

are provided on the Software CD. Instructions for Windows 95 and NT 4.0 are

given as TEXT (*.txt) files on the DHN-520 Software CD. Review the root

directory README.TXT for overview information, and for full installation details,

see the TEXT reference instruction files in the sub-directory appropriate to your

network operating system.

We have provided an HTML Quick Install Guide on the Software CD designed for

our DHN-520 10Mb Home Phoneline PCI adapter. Simply insert the DHN-520

Software CD and click on the appropriate button.

By clicking the “Install Drivers” button on the Autorun.exe screen, the drivers for

your version of Windows will be copied to the appropriate system directories

making it easier to load the drivers once the hardware is installed. Make sure that

you follow then instructions in the Quick Install Guides to install the DHN-520

correctly.
