D-Link PersonalAir DBT-120 Manual de usuario

2D-Link DBT-120 User Manual

Table of Contents

Product Overview .........................................................................................................3

Package Contents ....................................................................................................3

System Requirements ..............................................................................................3

Introduction ...............................................................................................................4

Uninstalling a Previous Version of the Bluetooth Software .......................................5

Installing the Bluetooth Software ..............................................................................6

Using the Add New Connection Wizard ..................................................................12

Introduction to the Bluetooth Software ....................................................................17

Bluetooth Tray ...................................................................................................17

Bluetooth Information Exchanger .....................................................................17

Using Bluetooth Information Exchanger .................................................................18

Bluetooth Software Basic Operations .....................................................................18

Start or Stop Bluetooth .....................................................................................18

Create a Conection From the Bluetooth Icon in the System Tray .....................20

Create a Connection Using the Bluetooth Setup Wizard ..................................20

View Connection Details Using Bluetooth Settings ...........................................20

Delete a Connection Using Bluetooth Settings .................................................22

Contacting Technical Support ...................................................................................23

Warranty ......................................................................................................................24

Registration .................................................................................................................29

Table of Contents

3D-Link DBT-120 User Manual

Section 1 - Product Overview

• D-Link DBT-120 USB Bluetooth Adapter

• USB Extension Cable

• Installation CD with Driver, Manual, & Bluetooth Software

• Installation Guide

If any of the above items are missing, please contact your reseller.

System Requirements

• Windows® XP SP2 or 2000 SP4 / Macintosh® OSX 10.4.3 or higher

• A CD-ROM drive

• One Available USB Port

Product Overview

Package Contents

4D-Link DBT-120 User Manual

Section 1 - Product Overview

Introduction

The term “Bluetooth” refers to a worldwide standard for the wireless exchange of data between two devices within

a Personal Area Network. In order to exchange data, two Bluetooth devices must establish a connection. Before a

connection is established, one device must request a connection with another, where the second device accepts (or

rejects) the connection. The originator of the request is known as the client. The device that accepts (or rejects) the

request is known as the server. Many Bluetooth devices can act as both client and server. A client Bluetooth device

runs a software program that requests a connection to another device as part of its normal operation. For example,

the program may request a connection to a remote computer, a printer, or a modem.

Becoming a Bluetooth client normally requires an action by the device operator, such as an attempt to browse a

remote computer, print a ﬁle, or dial out on a modem. Every Bluetooth device that provides a service must be prepared

to respond to a connection request. Bluetooth software is always running in the background on the server, ready to

respond to connection requests.

The D-Link Bluetooth USB Adapter is the perfect wireless solution for quick and easy access to Bluetooth enabled

devices. It is a class 2/3 low power device and is bundled with Bluetooth Software which allows you to connect to

several Bluetooth devices at once. The wireless transmission range of the D-Link DBT-120 Bluetooth USB Adapter is

about 30 feet. A PC conﬁgured as the Bluetooth server can support up to 7 Bluetooth client devices with IP addresses

being automatically assigned upon a successful connection. The Bluetooth Software also provides Internet sharing

and security access between the server and clients.

After ﬁnishing the steps outlined in this manual, you will have the ability to share information, obtain network access,

and take full advantage of a wireless connected environment.

5D-Link DBT-120 User Manual

Section 2 - Installation

Uninstalling a Previous Version of the Bluetooth Software

If you are installing the Bluetooth software for the ﬁrst time, please skip this section.

Any previous versions of the Bluetooth software must be uninstalled before installing an upgraded version.

Please uninstall the software by completing these steps:

1) Close any open programs and insert the Driver CD into your CD-ROM Drive.

2) The Autorun screen will appear. Click on Install Bluetooth Software.

3) The Welcome screen will indicate the previous version of BTW that is currently installed. Click on the Next

button to continue.

4) Click on the Remove button from the Remove the Program screen.

5) When the ﬁles have been removed, you will be presented with a screen informing of its completion.

a.Click on the Finish button

b.Click on the Yes button when the pop-up dialog box appears on the screen to reboot your PC.

You have now removed the previous version of the Bluetooth software.

6D-Link DBT-120 User Manual

Section 2 - Installation

Installing the Bluetooth Software

Insert the D-Link PersonalAir DBT-120 Driver CD into your

CD-ROM drive.

Click Install the Bluetooth Utility

If this Autorun screen does not automatically appear, click on

Start > Run, enter “D:\Autorun.exe” and click OK. “D” represents

the letter of your CD-ROM drive.

Warning: Install the driver and software located on the D-Link CD that came with your purchase BEFORE installing the

DBT-120 USB Bluetooth Adapter into your computer.

7D-Link DBT-120 User Manual

Section 2 - Installation

Click Next

Click Accept

Click Next

8D-Link DBT-120 User Manual

Section 2 - Installation

Click Install

9D-Link DBT-120 User Manual

Section 2 - Installation

Click Yes

10D-Link DBT-120 User Manual

Section 2 - Installation

Click Ok

When this screen appears, connect the DBT-120 to an available

USB port on your USB host adapter or USB hub.
