CH-501TX & RX
HDMI over Single CAT5e/6/7
Transmitter and Receiver
Operation Manual
Operation Manual
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VS1 08/12/11 First Release
VR2 16/04/12 Add IR Distance
VS3 12/06/14 Updated texts/diagrams
CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Transmitter Front and Rear Panels..3
6.2 Receiver Front and Rear Panels .....4
6.3 IR Cable Pin Assignment..................5
6.4 RS-232 Cable Pin Denitions............5
7. Connection Diagram ............................ 6
8. Specications ........................................ 7
9. Acronyms ............................................... 8
1
1. INTRODUCTION
The HDMI over Single CAT5e/6/7 Transmitter and Receiver set can
send uncompressed video/audio and IP data over a single run of
CAT5e/6/7 cable up to 100m at 1080p and 70m at 4K. It has the
added benet of control through the built-in RS-232 pass-through and
2-way IR control. It also features a HDMI bypass function that allows for
local testing of the HDMI source.
2. APPLICATIONS
• Home entertainment sharing and control
• Lecture room display and control
• Showroom display and control
• Meeting room presentation and control
• Classroom display and control
• Any Smart AV Installation System
3. PACKAGE CONTENTS
• 1×HDMI over Single CAT5e/CAT6 Transmitter
• 1×HDMI over Single CAT5e/CAT6 Receiver
• 1× IR Blaster
• 1× IR Extender
• 2× 5 V/2.6 A DC Power Adaptor
• 1×Operation Manual
4. SYSTEM REQUIREMENTS
HDMI source device such as a DVD/Blu-ray player and an HDMI
equipped display (TV or monitor).
2
5. FEATURES
• HDMI (with 3D format and 4K2K resolution support), HDCP and DVI
compliant
• Supports CEC bypass function
• Simultaneous transmission of uncompressed video/audio and data
over a single CAT5e or CAT6 cable up to 100m/328ft at 1080p and
70m/229ft at 4K
• Supports uncompressed video up to 4K@60Hz (YUV 4:2:0, 8-bit) and
WUXGA@60Hz (RB)
• Supports pass-through of high-denition audio formats: LPCM 7.1CH,
Dolby TrueHD and DTS-HD Mater Audio
• HDBaseT™ 3Play convergence: uncompressed high-denition Video
and Audio and IR/RS-232 Control pass-through
• Installation friendly
Note:
1. This system was tested with CAT6/23AWG cables, results may vary
with cables of a different specification.
2. For playback of 4K×2K HDMI source signals, a 4K×2K capable
display and High Speed HDMI cables are required.
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Transmitter Front and Rear Panels
HDMI Bypass HDMI In RS 232 In
TransmitterHDMI to CAT5e/6 with IR CH-501TX
Front
2 31
Power DC 5V IR 1
Blaster
IR 2
Extender
HDCP
Link
Mode
CAT5e/6 Out
Rear
5 6 7 1098 114
1
HDMI Bypass: Connect to a HDTV/monitor to test the HDMI input
source signal. When the HDMI Bypass output is connected, signal
transmission from the CAT5e/6 output is disabled. Ensure that it is
not connected during normal use.
2
HDMI In: Connect to an HDMI source device such as DVD or Blu-
ray player.
3
RS-232 In: Connect to a PC/laptop or RS-232 control system with
D-sub 9-pin male cable for the transmission of RS-232 commands.
4
Power LED: This LED will illuminate when the transmitter is connected
to a power supply.
5
DC 5V: Connect the 5V DC power supply to the transmitter and
plug the adaptor into an AC outlet.
6
IR 1 Blaster: Connect to the supplied IR Blaster cable for IR signal
transmission. Place the IR blaster in direct line-of-sight of the
equipment to be controlled.
7
IR 2 Extender: Connect to the supplied IR Extender cable for IR
signal reception. Ensure that remote being used is within the direct
line-of-sight of the IR extender.
8
HDCP LED: This LED will illuminate when the input source signal
contains HDCP data and when it blink it means the input source
signal is without HDCP data.
9
Link LED: This LED will illuminate when both the CAT5e/6 input and
output signals are connected.
10
Mode LED: This LED will blink when the unit is processing data.
11
CAT5e/6 Out: Connect to the receiver unit with a single CAT5e/6
cable for all data transmission.
4
6.2 Receiver Front and Rear Panels
HDMI Out RS 232 Out
Receiver
CAT5e/6 to HDMI with IR CH-501RX
Front
1 2
Rear
4 5 6 987 10
Power DC 5V IR 2
Blaster
IR 1
Extender
HDCP
Link
Mode
CAT5e/6 In
3
1
HDMI Out: Connect to an HDMI equipped TV/monitor of display
the HDMI input source signal.
2
RS-232 Out: Connect to the device that is to be controlled (via
D-sub 9-pin female cable) by RS-232 commands.
3
Power LED: This LED will illuminate when the receiver is connected
to a power supply.
4
DC 5V: Connect the 5V DC power supply to the transmitter and
plug the adaptor into an AC outlet.
5
IR 2 Blaster: Connect to the supplied IR Blaster cable for IR signal
transmission. Place the IR blaster in direct line-of-sight of the
equipment to be controlled.
6
IR 1 Extender: Connect to the supplied IR Extender cable for IR
signal reception. Ensure that remote being used is within the direct
line-of-sight of the IR extender.
7
HDCP LED: This LED will illuminate when the input source signal
contains HDCP data and when it blink it means the input source
signal is without HDCP data.
8
Link LED: This LED will illuminate when the both CAT5e/6 input and
output signals are connected.
9
Mode LED: This LED will blinking when the unit is processing data.
10
CAT5e/6 In: Connect to the transmitter unit with a single CAT5e/6
cable for all data transmission.
5
6.3 IR Cable Pin Assignment
3
1
2
3
1
2
Power 5 V
IR Blaster Signal
NC
IR Signal
Power 5 V
Grounding
IR Extender
IR Blaster
6.4 RS-232 Cable Pin Denitions
PIN DEFINE (TX / RX)
1N/C
2TxD / RxD
3RxD / TxD
4N/C
5GND
6N/C
7N/C
8N/C
9N/C
