CH-507TXWPBD & RXWPBD

HDMI over Single CAT5e/6/7

Wall-plate Transmitter and Receiver

Operation Manual

DISCLAIMERS

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes no

commitment to update or to keep current the information contained

in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer le, in any form or by any means—

electronic, mechanical, magnetic, optical, chemical, manual, or

otherwise—without express written permission and consent from

Cypress Technology.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufcient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE

RDV1 25/04/13 Preliminary Release

VS0 21/03/14 Updated text/diagrams

CONTENTS

1. Introduction............................................ 1

2. Applications........................................... 1

3. Package Contents ................................ 1

4. System Requirements............................ 1

5. Features.................................................. 2

6. Operation Controls and Functions....... 3

6.1 Transmitter Front and Rear Panels..3

6.2 Receiver Front and Rear Panels .....4

6.3 IR Cable Pin Assignment..................6

6.4 RS-232 Cable Pin Denitions............6

7. Connection Diagrams........................... 7

7.1 Option 1: Point to Point....................7

7.2 Option 2: Matrix System...................8

8. Specications ........................................ 9

8.1 Technical Specications .................9

8.2 CAT5e/6/7 Cable Specications..10

9. Acronyms ............................................. 10

1. INTRODUCTION

The HDMI over Single CAT5e/6/7 Wall-plate Transmitter and Receiver

set can send uncompressed video/audio and IP data over a single

run of CAT5e/6/7 cable up to 100 meters. It has the added benet of

control through the built-in RS-232 pass-through and 2-way IR control

and a LAN serving connection. Additionally, it has bi-directional Power

over Ethernet (PoE) functionality that allows for greater exibility in

installations.

2. APPLICATIONS

• Household entertainment sharing and control

• Lecture room display and control

• Showroom display and control

• Meeting room presentation and control

• Classroom display and control

3. PACKAGE CONTENTS

• HDMI over Single CAT5e/6/7 Transmitter

• HDMI over Single CAT5e/6/7 Receiver

• IR Blaster

• IR Extender

• 24 V/1.25 A DC Power Adaptor

• Operation Manual

4. SYSTEM REQUIREMENTS

HDMI source device such as a DVD/Blu-ray player and an HDMI

equipped display (TV or monitor).

5. FEATURES

• HDMI (with 3D format and 4K2K resolution support), HDCP and DVI

compliant

• Supports HDCP repeater and CEC bypass functions

• Simultaneous transmission of uncompressed video/audio and data

over a single CAT5e/6/7 cable up to 100m/328ft

• HDBaseT™ 5Play convergence: uncompressed high-denition Video

and Audio, LAN serving, bi-directional Power over Ethernet (PoE)

and IR/RS-232 Control pass-through

• Supports uncompressed video up to 4K2K resolution

(3840×2160@30 Hz or 4096×2160@24 Hz)

• Supports pass-through of high-denition audio formats - LPCM 7.1CH,

Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio

• Wall-plate design and installation friendly

Note:

1. This system was tested with CAT6/23AWG and CAT5e/24AWG

cables, results may vary with cables of a different specication.

2. The PoE function is designed for powering compatible Transmitter

and Receiver units only—non-PoE units will need their own power

supply. Transmitters/Receivers from other brands may not be

compatible.

3. For playback of 4K×2K HDMI source signals, a 4K×2K capable

display and High Speed HDMI cables are required.

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Transmitter Front and Rear Panels

HDMI INLAN

POWER

LINK

IR 2

EXTENDER

IR 1

BLASTER

DC 24V

RS-232

1 2 3 4 5 6 7 8 9

1IR 2 EXTENDER: Connect an IR Extender cable for IR signal

reception. Signals received will be transmitted from any IR blaster

connected to the receiver unit. Ensure that the remote being used

is within the direct line-of-sight of the IR Extender.

2IR 1 BLASTER: Connect an IR Blaster cable for IR signal transmission.

IR signals received by an IR extender connected to the receiver

unit will be transmitted by this blaster. Place the IR Blaster in direct

line-of-sight of the equipment to be controlled.

3RS-232 IN: Connect to a PC or laptop with D-sub 9-pin male cable

for the transmission of RS-232 commands.

4LAN: Connect to an active network for LAN serving and Telnet/

Web GUI control.

When the transmitter or any compatible LAN equipped receivers

are connected to a network, this allows the network access

(including internet access if available) to be shared between the

transmitter and all connected receivers. Connect any Ethernet

equipped device e.g. a Smart TV or games console to the LAN

port of a receiver for that device to share the network/internet

access.

5DC 24V: Connect the 24 V DC power supply to the transmitter and

plug the adaptor into an AC outlet.

6HDMI IN: Connect to HDMI source equipment such as a DVD or

Blu-ray player.

7POWER LED: This LED will illuminate when the transmitter is

connected to a power supply or powered by another unit via PoE.

8LINK LED: This LED will illuminate when both the source connected

to the transmitter and the display connected to the receiver are

connected.

9CAT5e/6/7 OUT: Connect to the receiver unit with a single

CAT5e/6/7 cable for transmission of all data signals.

6.2 Receiver Front and Rear Panels

HDMI OUTLAN

POWER

LINK

IR 1

EXTENDER

IR 2

BLASTER

DC 24V

RS-232

OUT

1 2 3 4 5 6 7 8 9

1IR 1 EXTENDER: Connect an IR Extender cable for IR signal

reception. Signals received will be transmitted from any IR blaster

connected to the transmitter unit. Ensure that the remote being

used is within the direct line-of-sight of the IR Extender.

2IR 2 BLASTER: Connect an IR Blaster cable for IR signal transmission.

IR signals received by an IR extender connected to the transmitter

unit will be transmitted by this blaster. Place the IR Blaster in direct

line-of-sight of the equipment to be controlled.

3RS-232 OUT: Connect to the device that is to be controlled (via

D-sub 9-pin female cable) by RS-232 commands.

4LAN: Connect to an active network for LAN serving and Telnet/

Web GUI control.

When the transmitter or any compatible LAN equipped receivers

are connected to a network, this allows the network access

(including internet access if available) to be shared between the

transmitter and all connected receivers. Connect any Ethernet

equipped device e.g. a Smart TV or games console to the LAN

port of a receiver for that device to share the network/internet

access.

5DC 24V: Connect the 24 V DC power supply to the transmitter and

Plug the adaptor into an AC outlet.

6HDMI OUT: Connect to a HDMI equipped TV/monitor for display of

the HDMI input source signal.

7POWER LED: This LED will illuminate when the receiver is connected

to a power supply or powered by another unit via PoE.

8LINK LED: This LED will illuminate when both the source connected

to the transmitter and the display connected to the receiver are

connected.

9CAT5e/6/7 IN: Connect to the transmitter unit with a single

CAT5e/6/7 cable for transmission of all data signals.
