CYP CDPS-U10H2HFS Manual de usuario
DRAFT
CDPS-U10H2HFS
10 By 2 HDMI Matrix Fast Switch
Operation Manual
Operation Manual
DRAFT
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means
- electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise - without express written permission and consent from
Cypress Technology.
© Copyright 2014 by Cypress Technology.
All Rights Reserved.
Version 1.0 November 2014
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
DRAFT
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack or install or
operate this equipment, and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through
module openings or empty slots, as you may damage parts.
• Do not attach the power supply cabling to building surfaces.
• Do not allow anything to rest on the power cabling or allow it to
be abused by persons walking on it.
• To protect the equipment from overheating, do not block the slots
and openings in the module housing that provide ventilation.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 05/11/14 Preliminary Release
RDV2 09/12/14 Add Power Supply
RDV3 17/12/14 Add IR Frequency
DRAFT
CONTENTS
1. Introduction............................................1
2. Applications...........................................1
3. Package Contents ................................1
4. System Requirements............................1
5. Features..................................................2
6. Operation Controls and Functions.......3
6.1 Front Panel........................................3
6.2 Rear Panel.........................................5
6.3 Remote Control................................6
6.4 OSD Menu.........................................8
6.5 RS-232 Protocols .............................13
6.6 IR Pin Denitions..............................14
6.7 Telnet & RS-232 Commands..........14
6.8 Telnet Control.................................17
6.9 Web GUI Control............................18
8. Specications ......................................23
9. Acronyms.............................................25
DRAFT
1
1. INTRODUCTION
This 10 by 2 HDMI UHD Matrix is an advanced solution for switching up
to 10 HDMI inputs to two HDMI outputs. It provides high performance
pass-through of video/audio and is capable of receiving and
transmitting 340MHz/10.2Gbps bandwidth rate with no data loss.
It’s Fast Switching technology can greatly reduce the time required
to swap between inputs. Supporting the latest features you can be
assured of reliable and high quality HDMI distribution.
2. APPLICATIONS
• Showroom display & control
• Educational demo
• Installation usage
• Advertising display
3. PACKAGE CONTENTS
• 10 By 2 HDMI Matrix Fast Switch
• 1 x IR Extender
• 1 x Remote Control
• 1 x 5V/2.6A Power Adaptor
• Operational Manual
4. SYSTEM REQUIREMENTS
Input source equipment such as DVD/Blu-ray player and output HD
display/Monitor with HDMI cables.
DRAFT
2
5. FEATURES
• Supports UHD resolutions up to 4K2K@24/25/30Hz & 4K2K
YUV420@60Hz
• Supports HDTV resolutions up to 1080@60Hz, ‘Deep Color’ 36/30/24-
bit and PC resolutions up to WUXGA@60Hz(RB)
• Supports 3D
• Supports pass-through of audio formats: LPCM 2/5.1/7.1CH, Dolby
Digital 2~5.1CH, DTS 2~5.1CH, Dolby Digital Plus, Dolby TrueHD and
DTS-HD Master Audio
• Supports EDID selection function
• Supports control via IR, RS-232, Telnet and Web GUI controls
• Input port HDCP support Standard and Apple mode. The Apple
mode selection to guarantees the use of Apple devices.
• Compliant with DVI source
Note: Supporting HDMI to DVI conversion that HDMI sources is non-
deep color and color space RGB.
Not supporting HDMI to DVI conversion when that HDMI
source is deep color and color space YCbCr 444/422
DRAFT
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER
10X2 HDMI MATRIX FAST SWITCH
IN 6 IN 7IN 8IN 9IN 10 OUT BTAKE
IN 1 IN 2IN 3IN 4IN 5OUTACANCEL
ENTER
MENU
PRESET
ALL
MUTE
LOCK
+
-
4K UHD
7
6
9
8
11
12
13
14
10 1554321
1POWER Button
Press this button to switch On or set the device to standby mode.
2POWER LED
This LED will illuminate in green when the device is power On and if
it is switched to standby mode the LED will turn red.
3IR Window
This IR Receiver receives the remote control signal from the
package included remote control only.
4IN 1~10
Press these IN buttons to select an input from the 10 input sources.
5OUT A/B
Press these buttons once a time along with an IN buttons to select
an input source for an output display. i.e. OUTA → IN1 → TAKE or
OUTB → IN10 → TAKE.
6CANCLE
Press this button to cancel the IN/OUT selection and during any
selection under MENU.
7TAKE
Press this button to conrm the selection of an IN and an OUT
button. If this button is not pressed the IN & OUT selection will not
be executed.
8MENU
Press to enter into the menu selection.
DRAFT
4
9ENTER
Press to conrm the selection.
10 +/-
Press these buttons to move up/down under menu selection.
11 PRESET
Press this button to recall the preset setting from 1~10. Press and
select from IN1~10 then press TAKE to conrm the recall selection or
press CANCEL to exit the selection. To reset the Preset setting, enter
into menu and select Preset setting from IN1~10 then press OUTA
and select an input from IN1~10 then press OUTB and select an
input from IN1~10 again and press ENTER to conrm the selection.
eg. To preset 2’s gure, MENU → ENTER → Matrix Preset → Enter→
Preset2 → IN2 → OUTA → IN8 → OUTB → IN7 → ENTER
12 ALL
Press this button to select all outputs to display with an input
source. e.g. To select all output with input source 3. ALL → IN3
13 MUTE
Press this button to mute video and audio on OUT A or B or on all
output. e.g. To mute output A OUTA → MUTE
14 LOCK
Press this button to lock all button functions on the panel to unlock,
press the button and hold for 3 seconds.
15 LCM
Displaying Input and Outputs selection and menu selection.
DRAFT
5
6.2 Rear Panel
CONTROLSERV.
HDMI IN HDMI OUT
12345678910ABRS232 IR IN DC 5V
7654321
1HDMI IN
Connect from source equipment such as Blu-ray/DVD/PS3 players,
Set-Top-Box or any HDMI equipped source device for input signal
sending.
2HDMI OUT
Connect to HDMI TV/display or HD Amplier for output image and
or audio display.
3SERV.
This slot is reserved for rmware update use only.
4CONTROL
Connect from PC/Laptop with active internet service for Telnet or
Web GUI control with RJ-45 terminated cable.
5RS-232
Connect from PC/Laptop for RS-232 command sending to control
the device.
6IR IN
Connect the IR Receiver included in the package for IR signal
receive from the included remote control.
7DC 5V
Connect the adaptor included in the package and connect to
AC wall outlet for power supply.
DRAFT
6
6.3 Remote Control
1POWER
Press this button to switch On or
set the device to standby mode.
2MUTE
Press this button to mute video
and audio on OUT A or B or on
all output. e.g. To mute output A
OUTA → MUTE
3OUT A/B
Press these buttons once a time
along with an IN buttons to select
an input source for an output
display. i.e. OUTA → IN1 → TAKE or
OUTB → IN10 → TAKE.
4IN 1~10
Press these IN buttons to select an
input from the 10 input sources.
5+/-
Press these buttons to move up/
down under menu selection.
6OK
Press to conrm the selection.
7CANCEL
Press this button to cancel the IN/OUT selection and during any
selection under MENU.
8MENU
Press to enter into the menu selection.
9TAKE
Press this button to conrm the selection of an IN and an OUT
button. If this button is not pressed the IN & OUT selection will not
be executed.
OK
+
-
A
OUT
B1
IN
POWER MUTE
CANCEL MENU
TAKE PRESET
LOCK ALL
CR-151
234
567
8910
1
3
5
7
9
11
2
4
8
12
6
10
