CYP CPLUS-VHHE Manual de usuario
CPLUS-VHHE
4K2K HDMI to HDMI Enhancer
Operation Manual
Operation Manual
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2015 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
RDV1 17/08/15 Preliminary release
CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front and Rear Panels .....................3
6.2 Top Panel ..........................................4
6.3 Side Panel .........................................5
7. Connection Diagram ............................ 6
8. Specications ........................................ 7
9. Acronyms ............................................... 8
1
1. INTRODUCTION
The 4K2K HDMI to HDMI Enhancer is a handy device for your HDMI
signal extension. With bandwidth, HDCP analyzing, EDID and YUV420
selections this device allows you with fast and clear viewing on the
HDMI signal status. Further, this device allows user to upload EDID for
selection which create alternative EDID selection for specic usage.
Moreover, with hot keys and LEDs design which allow fast switching on
various selection and quick viewing on the status.
2. APPLICATIONS
• HDMI signal extension
• Source and display signal status display
• EDID selection
• HDCP verication
• 4K2K YUV444 down sampling to 4K2K YUV420
3. PACKAGE CONTENTS
• 1×4K2K HDMI to HDMI Enhancer
• 1×5 V/2.6 A Power Adaptor
• 1×Operation Manual
4. SYSTEM REQUIREMENTS
Input HDMI source a signals with output HDMI display and connection
cables.
2
5. FEATURES
• HDMI with 4K2K 6G supported, HDCP 2.2/1.4 and DVI compliant
• Supports video source and output display signal analysis up to 6G
4K2K
• Supports HDMI 2.0
• Supports HDCP v1.4 & v2.2 a
• Supports EDID selection from internal, external and user’s EDID to be
insert
• Supports application control via USB
• Supports LEDs display with fast viewing on current selection status
• Supports USB rmware update
• Supports 6G bandwidth down sampling to 3G
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front and Rear Panels
HDMI IN
DC
5V
HDMI OUT
SERVICE
1 2 3 4
Front Rear
1HDMI IN: Connect with HDMI source equipment such as Blue-ray/
PS4 player with HDMI cable.
2DC 5V: Plug the 5V DC power supply into the unit and connect the
adaptor to an AC outlet.
3SERVICE: This slot is for rmware update use and customer EDID le
upload.
4HDMI OUT: Connect with display/amplier for both video and
audio output with HDMI cable.
4
6.2 Top Panel
PWR
YUV
420
USB
LINK
SYNC
HDCP
EDID
3G
6G
1.4
2.2
INT
EXT
USER
2
3
4
1
5
6
1PWR LED: This LED will illuminate when the device is connected with
power supply from the AC outlet.
2SYNC LEDs: These LEDs will illuminate according to both HDMI input
and output signal’s current bandwidth.
3HDCP LEDs: These LEDs will illuminate according to both HDMI input
and output’s HDCP encrypted signal.
4EDID LEDs: These LEDs will illuminate according to the selected EDID
setting.
5YUV420 LED: This LED will illuminate according to YUV420’s selection.
6USB LINK LED: This LED will illuminate when the connected USB
device is valid for PC control.
5
6.3 Side Panel
YUV420 EDID
ACTIVE SRC
1 2 3
1YUV420: Press this button to allows HDMI input 6G signal to be
subsampling to YUV420 from YUV444.
2EDID: Press this button to select EDID of INTernal/EXTernal or USER
where internal EDID is 1080p at 2CH, external EDID is depending on
the connected HDMI output display and USER is for upload EDID.
3ACTIVE SRC: Press this button to force the connected HDMI output
display to output image always.
Note: Output display must support CEC in order to perform this
function.
