CHDBT-1H7CL

1×8 HDMI over HDMI and CAT5e/6/7 Splitter

Operation Manual

DISCLAIMERS

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes no

commitment to update or to keep current the information contained

in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer le, in any form or by any means—

electronic, mechanical, magnetic, optical, chemical, manual, or

otherwise—without express written permission and consent from

Cypress Technology.

Version 1.0 September 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufcient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE

RDV1 27/06/13 Preliminary Release

VS1 23/12/13 Updated Text & Diagrams

CONTENTS

1. Introduction............................................ 1

2. Applications........................................... 1

3. Package Contents ................................ 1

4. System Requirements............................ 1

5. Features.................................................. 2

6. Operation Controls and Functions....... 3

6.1 Front Panel.........................................3

6.2 Rear Panel .........................................3

6.3 IR Cable Pin Assignment ..................5

7. Connection Diagram ............................ 6

8. Specications ........................................ 7

8.1 Technical Specications ..................7

8.2 CAT5e/6/7 Cable Specication ......8

9. Acronyms ............................................... 8

1. INTRODUCTION

The HDMI over HDMI and CAT5e/6/7 Splitter can support resolutions

up to 1080p Full HD, 4K×2K timing, 3D and multi-channel digital audio

formats to one HDTV and seven CAT5e/6/7 outputs. The HDMI can

be connected to HDMI display for instant nearby display and the

CAT5e/6/7 can be connected to CAT5e/6/7 to HDMI Receivers for

distance up to 60 meters.

2. APPLICATIONS

• Household entertainment sharing and control

• Lecture room display and control

• Showroom display and control

• Meeting room presentation and control

• Classroom display and control

3. PACKAGE CONTENTS

• 1×1 by 8 HDMI over HDMI and CAT5e/6/7 Splitter

• 1×IR Receiver

• 1×IR Blaster

• 24V DC Power Adaptor

• Power Cord

• Operation Manual

4. SYSTEM REQUIREMENTS

• HDMI equipped source devices, connect with HDMI cables

• HDMI equipped displays (TVs or monitors) or HDMI equipped AV

receivers, connect with HDMI cables

• Certied CAT5e/6/7 cables

• HDBaseT™ Receivers (e.g. CH-506RXL or CH-514RXL)

5. FEATURES

• HDMI with 3D and 4K×2K supported, HDCP and DVI compliant

• Simultaneous HDMI and CAT5e/6/7 outputs

• Supports one HDTV and seven CAT5e/6/7 outputs

• Supports data rate from 250Mbps up to 3Gbps

• Supports wide range of PC resolutions from VGA to WUXGA and

HDTV resolutions up to 4K×2K (3840×2160@30 Hz and 4096×2160@24

Hz)

• Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD

Master Audio transmission (32-192 kHz sample rate)

• Supports distances up to 60 meters through CAT5e/6/7 cables

• Supports selection of Standard or TV EDID settings

• Supports USB service port

• Supports Bi-directional IR control

• The 3D signal display follow by display TV’s EDID

Note:

1. This system was tested with CAT6/23AWG cables, results may vary

with cables of a different specication.

2. For playback of 4k×2k HDMI source signals, a 4K×2K capable

display and High Speed HDMI cables are required.

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

POWER SYNC

HDMI

LINK LINK 1LINK 2LINK 3LINK 4LINK 5LINK 6LINK 7

CAT5e/6/7 OUT

1 2 3 4

1POWER LED: The LED will illuminate when connected to an active

power supply.

2SYNC LED: This LED will illuminate when the HDMI input is connected

to a HDMI source and receiving a signal.

3HDMI OUT LINK LED: This LED will illuminate when HDMI output is

connected to TV or display monitor and receiving a signal.

4CAT5e/6/7 OUT LINK 1~7 LEDs: The link LEDs will illuminate when the

receivers are connected to the CAT 5e/6/7 outputs are connected

to TVs or displays and displaying a signal.

6.2 Rear Panel

1HDMI OUTHDMI IN 234567

SERVICE

CAT5e/6/7 OUT

STDTV

DC 24V

IR IN IR OUT

EDID

421 3 5 6 7 8

1HDMI IN: Connect to HDMI equipped source equipment such as a

DVD/Blu-ray player or games console.

2HDMI OUT: Connect to a HDMI display for local monitoring of the

HDMI signal or cascade to another Splitter.

3CAT5e/6/7 OUT 1~7: Connect to CAT5e/6/7 to HDMI Receivers (with

or without PoE) with a single CAT5e/6/7 cable each to extend the

HDMI signal up to 60 m.

4IR IN: Connect the supplied IR Receiver cable for IR signal

reception. Ensure that remote being used is within the direct line-

of-sight of the IR Extender.

5IR OUT: Connect the supplied IR Blaster cable for IR signal

transmission. Place the IR Blaster in direct line-of-sight of the

equipment to be controlled.

6EDID STD/TV: The default setting is TV, when in this mode, the unit

will detect the EDID settings of the display device connected to

the CAT 5e/6/7 Output 1. If it detects a 4K×2K capable EDID setting

it will transmit the signal in that format to the output port. If no 4K×2K

capable EDID is detected then the unit will detect the EDID settings

and send out the signal that all outputs can accept.

This device has a last memory function and will retain the EDID

settings of the last device connected via the CAT5e/6/7 output

port when it is not connected to a display after power cycling.

Switch to the STD setting to use the unit's built-in EDID if there are

display problems. In this mode, the video output will be set to

1080p@60Hz and the audio at LPCM 2CH Stereo.

7SERVICE: Reserved for manufacturer use only.

8DC 24V: Connect the 24V DC power supply to the unit and plug

the adaptor into an AC outlet.

6.3 IR Cable Pin Assignment

Power 3.3 V

IR Blaster Signal

IR Signal

Power 3.3 V

Ground

IR Extender

IR Blaster
