Compaq Presario X1000 - Notebook PC Manual de instrucciones

Modem Command Guidelines

Compaq Notebook Series

Document Part Number: 316654-001

February 2003

This document provides instructions for selecting, accessing, and

using the AT command set supported by the modem in your

notebook.

316654-001.book Page i Wednesday, December 11, 2002 5:09 PM

Compaq and the Compaq logo are trademarks of Compaq Information

Technologies Group, L.P. in the U.S. and/or other countries.

Compaq shall not be liable for technical or editorial errors or omissions

contained herein or for incidental or consequential damages in connection

with the furnishing, performance, or use of this material. The information

in this document is provided “as is” without warranty of any kind,

including, but not limited to, the implied warranties of merchantability and

fitness for a particular purpose, and is subject to change without notice. The

warranties for Compaq products are set forth in the express limited

warranty statements accompanying such products. Nothing herein should

be construed as constituting an additional warranty.

Modem Command Guidelines

Compaq Notebook Series

First Edition February 2003

Document Part Number: 316654-001

316654-001.book Page ii Wednesday, December 11, 2002 5:09 PM

Modem Command Guidelines iii

Contents

Modem Command Guidelines

Accessing HyperTerminal . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Selecting a Command Set . . . . . . . . . . . . . . . . . . . . . . . 1

Identifying Your Modem. . . . . . . . . . . . . . . . . . . . . . . . 2

Accessing Your Command Set . . . . . . . . . . . . . . . . . . . 2

Using Commands on the Notebook . . . . . . . . . . . . . . . . . . . 2

Entering a Command . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Editing a Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Executing a Command. . . . . . . . . . . . . . . . . . . . . . . . . . 3

Repeating a Command. . . . . . . . . . . . . . . . . . . . . . . . . . 3

Omitting a Parameter in a Command Line . . . . . . . . . . 3

Setting the Result Code Format. . . . . . . . . . . . . . . . . . . 4

Setting Local Character Echo . . . . . . . . . . . . . . . . . . . . 4

Using Online Mode and Online Command Mode . . . . . . . . 5

Switching to Online Command Mode . . . . . . . . . . . . . . 5

Switching to Online Mode. . . . . . . . . . . . . . . . . . . . . . . 5

Creating a Command Mode Shortcut Icon . . . . . . . . . . 6

316654-001.book Page iii Wednesday, December 11, 2002 5:09 PM

Modem Command Guidelines 1

Modem Command Guidelines

This guide provides instructions for selecting, accessing, and

using the AT command set supported by the modem in your

notebook.

For help with specific modem problems, go to the modem

manufacturer’s Web site, or refer to the Worldwide Telephone

Numbers booklet to contact a Compaq authorized dealer, reseller,

or service provider.

Accessing HyperTerminal

Modem commands can be entered in HyperTerminal, which is

included with all Microsoft Windows operating systems.

To access HyperTerminal:

■In Windows XP Professional, select Start > All Programs >

Accessories > Communications > HyperTerminal.

■In Windows 2000 Professional, select Start > Programs >

Accessories > Communications > HyperTerminal.

Selecting a Command Set

Command sets are modem-specific. To use modem commands

successfully, you must use the command set supported by the

modem in your notebook.

316654-001.book Page 1 Wednesday, December 11, 2002 5:09 PM

2 Modem Command Guidelines

Modem Command Guidelines

Identifying Your Modem

To display the model name of the modem in your notebook:

1. Select Start.

2. Right-click My Computer > Properties > Hardware tab >

Device Manager button.

3. Double-click Modems. (An icon and name for your modem

is displayed.)

4. Double-click the modem name icon. (The modem model

name is displayed.)

Accessing Your Command Set

After you identify the model name of your notebook, refer to

the modem manufacturer’s Web site to obtain an updated

command set.

Using Commands on the Notebook

Entering a Command

When entering modem commands on the notebook:

■You must start every AT command line (except the A/ and

+++ commands) with the attention (AT) code characters. If

you do not begin the command line with the attention (AT)

code characters, the modem will not execute the command.

■You must type the AT prefix in the same case (AT or at, not At

or aT).

■You may type commands following the AT prefix in all

uppercase, all lowercase, or any combination of uppercase

and lowercase letters.

■You may enter telephone numbers with or without

punctuation, for example, (123) 456-7890 or 1234567890.

316654-001.book Page 2 Wednesday, December 11, 2002 5:09 PM

Modem Command Guidelines

Modem Command Guidelines 3

Editing a Command

If you make an error while typing a command, backspace over the

error, then retype. You cannot backspace over the AT prefix

because it is interpreted immediately after it is typed.

Executing a Command

To execute a command line, press enter. (Pressing enter instructs

the modem to process the command line.)

Repeating a Command

To repeat the last command line issued, enter the A/ command.

When repeating the A/ command, it is not necessary to enter the

AT prefix or press enter, because issuing the A/ command repeats

the AT prefix and enter function.

The last command entered remains in the command buffer until

the modem is reset or power to the modem is turned off. Both

actions clear the buffer. The A/ command is invalid while the

buffer is clear.

Omitting a Parameter in a Command Line

If you enter a command that normally includes a numeric

parameter, such as ATHn, without entering the numeric parameter,

the value of the numeric parameter is assumed to be the default

parameter.

For example, the Hn (hang-up) command can have a numeric

parameter of zero (H0), which is the default, or of one (H1). If

neither parameter is entered, ATH plus enter is the equivalent of

ATH0 plus enter.

This rule does not apply to the D(dial) command.

316654-001.book Page 3 Wednesday, December 11, 2002 5:09 PM

4 Modem Command Guidelines

Modem Command Guidelines

Setting the Result Code Format

A result code is the response of the modem to a command. It may

be issued in either of two formats: words (the long form, also

known as verbose) or numeric characters (the short form,

represented by digits).

The result code format is set using the Vn command:

■Use V1 for words (default).

■Use V0 for numeric characters.

Setting Local Character Echo

Local echo is a process that transmits received data back to the

sending station and allows you to see what data was received.

If your typing is not displayed on the screen, local echo is

turned off.

Local echo preferences are set using the En command:

■Use EO for no local echo.

■Use E1 to enable local echo.

316654-001.book Page 4 Wednesday, December 11, 2002 5:09 PM

Modem Command Guidelines

Modem Command Guidelines 5

Using Online Mode and

Online Command Mode

Online mode is used for data transfer; online command mode is

used for entering commands.

Switching to Online Command Mode

To escape from online mode and enter online command mode,

press and hold shift as you type +++.

When you have correctly entered this escape command:

■An OK result code is displayed.

■The established connection is maintained, but input is

interpreted locally and not transmitted to the remote

connection.

Switching to Online Mode

To escape from online command mode and enter online mode,

use either of the following methods:

■Enter the ATO (letter “O”) command.

■Terminate the connection with the ATH0 (digit “0”) command.

316654-001.book Page 5 Wednesday, December 11, 2002 5:09 PM

6 Modem Command Guidelines

Modem Command Guidelines

Creating a Command Mode Shortcut Icon

You can create a Windows shortcut icon for accessing

HyperTerminal in online command mode. To place a Command

shortcut icon on the Windows desktop:

1. Create a Command icon in HyperTerminal.

✎To access HyperTerminal:

■In Windows XP Professional, select Start > All

Programs > Accessories > Communications >

HyperTerminal.

■In Windows 2000 Professional, select Start > Programs >

Accessories > Communications > HyperTerminal.

a. In the Name field, type:

Command

b. Select OK. (The Connect To dialog box is displayed.)

c. In the Connect Using field, select the COM port used by

your modem.

✎To identify the COM port used by your modem:

■In Windows XP Professional, select Start > Control

Panel > Printers and Other Hardware icon > Phone and

Modem Options icon > Modems tab.

■In Windows 2000 Professional, select Start > Settings >

Control Panel > Phone and Modem Options > Modems.

d. Select OK. (The Port Settings tab is displayed.)

e. Select OK. (The command mode screen is displayed with

a flashing cursor in the upper left corner. The modem can

now receive a command and respond to the command

with a result code.)

316654-001.book Page 6 Wednesday, December 11, 2002 5:09 PM

Modem Command Guidelines

Modem Command Guidelines 7

f. Select File > Save. (A Command icon is created, but is

not visible until you exit HyperTerminal.)

g. To exit HyperTerminal, select File > Exit.

2. To access the Command icon:

h. In Windows XP Professional, select Start > All

Programs > Accessories > Communications >

HyperTerminal.

i. In Windows 2000 Professional, select Start > Programs >

Accessories > Communications > HyperTerminal.

3. To create a shortcut to the Command icon, select the

Command icon, then select File > Create Shortcut. (The

shortcut to the Command icon is displayed in the

HyperTerminal window.)

4. To place the shortcut icon on the desktop, select the shortcut

icon, then drag it to the desktop.

5. To exit and close HyperTerminal, select File > Exit.

316654-001.book Page 7 Wednesday, December 11, 2002 5:09 PM

Otros manuales para Presario X1000 - Notebook PC

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Computadora portátil de Compaq

Compaq

Compaq Presario R3000 - Notebook PC Manual de usuario

Compaq

Compaq nx7300 - Notebook PC Instrucciones de uso

Compaq

Compaq Armada 7800 Guía de referencia rápida

Compaq

Compaq Presario X1000 - Notebook PC Manual de usuario

Compaq

Compaq Presario 1800T Manual

Compaq

Compaq Armada 1500C series Manual de operación y mantenimiento

Compaq

Compaq Presario X1100 - Notebook PC Manual de instrucciones y seguridad

Compaq

Compaq Armada 7300 - Notebook PC Instrucciones de instalación

Compaq

Compaq 3000 Series Manual de operación y mantenimiento

Compaq

Compaq Evo Notebook N800v Instrucciones de instalación

Compaq

Compaq Presario CQ35-100 - Notebook PC Manual

Compaq

Compaq Armada 1500C series Manual de usuario

Compaq

Compaq Evo Notebook N400c Series Manual

Compaq

Compaq Armada E500 Series Manual

Compaq

Compaq Compaq 311245-001 Manual de usuario

Compaq

Compaq Compaq Presario Manual

Compaq

Compaq 6710b Instrucciones de uso

Compaq

Compaq EVO M800c Manual

Compaq

Compaq Prosignia 170 Series Manual de usuario

Compaq

Compaq AMC20493-KT5 Manual de usuario

Compaq

Compaq Evo Notebook N800v Guía de inicio rápido

Compaq

Compaq Evo Notebook N800c Manual de usuario

Compaq

Compaq Presario CQ62-300 - Notebook PC Manual de uso y mantenimiento

Compaq

Compaq Presario 1246 Manual de usuario

Manuales populares de Computadora portátil de otras marcas

HP ze2401xt - Pavilion Notebook PC Manual de usuario

Velocity

Velocity NoteMagix M10 Manual de usuario

Dell

Dell Alienware 17 R2 Manual de usuario

Toshiba

Toshiba A105-S2236 Manual de usuario

HP ENVY 17 Manual

Winbook

Winbook LM Manual de usuario

Dell

Dell Inspiron 1464 Manual de usuario

Dell

Dell Inspiron 15R 5537 Manual de usuario

HP PROBOOK 4520S Manual

Dell

Dell Latitude ATG D620 Manual de usuario

Sony

Sony VAIO PCG-FX270 Manual de usuario

Dell

Dell Latitude 7310 Manual de usuario

Dell

Dell Precision GU806 Manual de usuario

Sony

Sony VAIO PCG-R505JLK Manual de usuario

Lenovo

Lenovo THINKPAD X32 Manual de usuario

HP Compaq tc4200 Guía de inicio rápido

Toshiba

Toshiba mini NB300 Manual de usuario

Lenovo

Lenovo ThinkPad X201 Tablet Manual
