Comica STA-X2D Manual de usuario

User Manual

STA-X2D

Cardioid Condenser XLR Microphone Kit

Foreword

Main Features

Notice

Thanks for purchasing Comica STA-X2D cardioid condenser XLR

microphone kit

· 25mm Cardioid Condenser Mic for Professional Studio Quality

· Super Low Self-noise and Distortion for Ideal Recording

· Excellent Dynamic Range and High SPL to Deliver Detailed Sound

· XLR Interface Output, Support 48V Phantom Power

· Support 75/150Hz Two-stage Low-cut Filter

· Internal Pop Filter and Capsule Shock Mounting

· Equipped with Desktop Mic Stand, Flexible Extension and Combination

· Professional Shock Mount and Metal Pop Filter for Double Denoise

· Robust All-metal Construction for Excellent Shielding

Please aim the front of the microphone at the sound source to get an

excellent recording.

Do not use this equipment in the vicinity of a heat source or interference

source, such as radiator, oven, refrigerator or air conditioner.

This product is a high-precision instrument, please avoid falling, collision or

pounding.

Do not use the equipment in rain or in a damp environment to avoid

short-circuit danger.

1

Packing List

Main Part:

Accessories:

Microphone

XLR-XLR Audio CableShock Mount Pop Filter

User ManualDesk Stand Warranty Card

UserManual

STA-X2

CardioidCondenser XLR Microphone

2

Components Introduction

Mic Capsule

Low-cut Button

(Switch between three recording

modes 150Hz low-cut/normal

recording/75Hz low-cut)

Working Indicator Light

(Green light is always on

when working)

XLR Output Interface

3

Installation and Use

1. Install the shock mount to the 3/8 threaded head of the desk stand

2.Install the microphone to the shock mount

4

3. Fix the pop ﬁlter to the shock mount

4. Connect the microphone to the output device through the XLR-XLR

audio cable

5

Technical Parameters

Polar Pattern

Sensitivity

Frequency Response

Maximum SPL

Signal/Noise

Equivalent Noise

Dynamic Range

Output

Phantom Power

Weight

Dimension

Working Temperature

Storage Temperature

Cardioid

-40dB±2dB

20Hz ~ 20kHz

130dB

70dB

24dBA

106dB

XLR

48V±2V

253g

55 x 55 x 170mm

0℃~+50℃

-20℃~+60℃

6
