FOR SMARTPHONE

CVM-WS50

USER MANUAL

6-channels Smartphone Wireless Microphone

Foreword

Thank you for purchasing Comica WS50 6-channels smartphone wireless microphone.

WS50 is a creative wireless microphone for smartphone with built-in mobile phones

holders. With built-in lithium polymer batteries, it uses UHF wireless technology and

high-resolution LCD code screen, comes with six channels in total, stepless adjustable

volume at receiving end, and integrated into power monitoring, audio dynamic display

bar, real-time monitoring and other functions; the working distance is up to 60 meters

(30 meters in barrier area), it can assist your phone for video recording and achieve

professional sound effects.

To ensure the smooth use and safety of the products, please read this user manual

carefully before using and properly assemble and operate.

Main Features

. 6 Channels, Working Distance Up to 60m (In Open Area, 30m in Barrier Area) ；

. Built-in Metal Material Smartphone Holder；

. LCD Screen for Displaying Channels and Audio Status；

. Stepless Volume Adjustment；

. Real-time Audio Monitor；

. Extendable for Connection with LED Light, Grip, Tripod, Cold-shoe, etc；

. Built-in Rechargeable Lithium Batteries；

. Portable and Light；

WS50A Additional Features: Detachable Electronic Grip, Intelligent Video Operation;

WS50B Additional Features: Detachable Ordinary Grip

WS50C Additional Features: Can be used for live video on table for wireless audio 　

　　　　　　　　　　　　　transmission

6 Channels Working Distance

Up to 60m

Built-in

Smartphone Holder

Stepless Volume

Adjustment

Real-time

Audio Monitor

Lithium Batteries LCD Screen

60M

. This product is compatible with both IOS and Android system, and when used with the

iphone 7 or above, you need to use the original adapter cable;

. For smart phones with IOS system (Iphones), this Mic works well either in Audio or

Video mode;

. For the smart phones with Android system, this Mic works well in audio mode, it may not

be compatible with partial smart phones in video mode (Then we suggest you to try the

3rd party APP);

. To avoid signal interference during usage, please set the phone to flight mode;

. The working distance will be affected by the surrounding environment. In the process,

please try to make sure the environment is barrier free and turn off the WIFI of your

smart phone;

. During usage, the receiver should not be close to other UHF transmitters, radio stations

and other devices which may cause interference;

. Please keep this product in dry environment;

. Do not expose the device in rain or humid environment, or there will be a danger of

short circuit;

Notice

Packing List

Main Body:

Accessories:

Transmitter Receiver Ordinary Grip

(Only for WS50B)

Electronic Grip

(Only for WS50A)

Tripod on Table

(Only for WS50C)

1. 3.5mm Audio Mic

2.TRRS Audio Output Cable

3. USB Charging Cable

4. Belt Clip

5. Wind Muff

6. Portable Case

7. User Manual

8. Warranty Card

1 2 3 4

5 6 7 8

Components

Transmitter

1.Set Button for Channel Selection

2.On-off/Muting Button

3.Working Status Indicator Light

4.Mic Audio Input Socket/ Reset Hole

5.Micro USB Charging Socket

6.Belt Clip Hole

7.1/4 Thread at the Back

Components and Instruction

The function of reset hole：When function

program of the product is disorganized and

unable to make normal adjustment or even

shutdown, you can use an appropriate

taper tool to insert the reset hole to realize

the function reset.

Receiver

1.Set Button for Channel Selection

2.Adjusting Screw

3.On/Off Button

4.Working Status Indicator Light

5.3.5mm Audio Output Socket/ Reset Hole

6.Micro USB Charging Socket

7.3.5mm Monitoring Socket

8.Smartphone Clamp

9.1/4 Thread at the bottom

10.1/4 Thread at the top

11.Volume Adjusting Button

External light and other equipment can be

used on 1/4 thread at the top; Grip can be

used for 1/4 thread at the bottom.

The function of reset hole：When function

program of the product is disorganized and

unable to make normal adjustment or even

shutdown, you can use an appropriate

taper tool to insert the reset hole to realize

the function reset.

Ordinary Grip

1. 1/4 Screw Thread

2. 1/4 Thread at the Bottom

Electronic Grip

1. 1/4 Screw Thread

2. Adjustable Screw

3. 1/4 Thread at the Bottom

4. Bluetooth Remote Controller

5. On-off/Function Button of the Remote Controller

The bluetooth remote controller can be taken down for remote control；

Bluetooth remote controller supports both IOS and Android system；
