Cognex DataMan 280 Series Manual de usuario

DataMan®280 Series

Quick Reference Guide

2022 February 21

Revision: 6.3.1.51

Precautions

To reduce the risk of injury or equipment damage, observe the following precautions

when you install the Cognex product:

lConnectivity is possible through the following options:

l24 VDC (+/- 10%) output connection using a UL or NTRL listed

power supply

lPower over Ethernet (PoE) 13 W power supply

Any other voltage creates a risk of fire or shock and can damage the

components. Applicable national and local wiring standards and rules must

be followed.

lThis product is intended for industrial use in automated manufacturing or

similar applications.

lThe safety of any system incorporating this product is the responsibility of

the assembler of the system.

lDo not install Cognex products where they are exposed to environmental

hazards such as excessive heat, dust, moisture, humidity, impact, vibration,

corrosive substances, flammable substances, or static electricity.

lRoute cables and wires away from high-current wiring or high-voltage

power sources to reduce the risk of damage or malfunction from the

following causes: over-voltage, line noise, electrostatic discharge (ESD),

power surges, or other irregularities in the power supply.

lDo not expose the image sensor to laser light. Image sensors can be

damaged by direct, or reflected, laser light. If your application requires laser

light that might strike the image sensor, use a lens filter at the corresponding

laser wavelength. For suggestions, contact your local integrator or

application engineer.

lThisproduct does not contain user-serviceable parts. Do not make

electrical or mechanical modifications to product components.

Unauthorized modifications can void your warranty.

lChanges or modifications not expressly approved by the party responsible

for regulatory compliance could void the user’s authority to operate the

equipment.

lInclude service loops with cable connections.

lEnsure that the cable bend radius begins at least six inches from the

connector. Cable shielding can be degraded or cables can be damaged or

wear out faster if a service loop or bend radius is tighter than 10X the cable

diameter.

lThisdevice should be used in accordance with the instructions in this

manual.

lAll specifications are for reference purposes only and can change without

notice.

Symbols

The following symbols indicate safety precautions and supplemental information:

WARNING:This symbol indicates a hazard that could cause death, serious personal injury or electrical

shock.

CAUTION:This symbol indicates a hazard that could result in property damage.

Note: This symbol indicates additional information about a subject.

Tip: This symbol indicates suggestions and shortcuts that might not otherwise be apparent.

Accessories

You can purchase the following components separately. For a list of options and

accessories, contact your local Cognex sales representative.

Lenses

Accessory Product Number Illustration

6.2 mm lens kit that includes:

l6.2 mm optics mount

l6.2 mm lens

lManual lens cap (assembled)

lScrews

DM280-LENS-62

16 mm lens kit with extended optics mount (requires the use of an

extended front cover and high-powered red LED). The kit includes:

l16 mm optics mount

l16 mm lens

lManual lens cap (assembled)

lScrews

DM260-LENS-16

IR 6.2 mm lens kit, 3-position with IR LED includes:

l6.2 mm optics mount

l6.2 mm lens (IR)

lIR Light for 6.2mm (Risk Group Exempt acc. IEC62471)

lManual lens cap (not assembled)

lScrews

DM280-KIT-IR-62

Accessory Product Number Illustration

IR16 mm lens kit that includes:

l16 mm optics mount

l16 mm lens (IR)

lIR Light for 16mm (Risk Group Exempt acc. IEC62471)

lManual lens cap (assembled)

lScrews

DMA-KIT-IR-16

High Speed Liquid Lens Module (HSLL) to be used with 6.2 mm lens or

16 mm lens

DMA-HSLL-280

16 mm lens with ImageMax kit that includes:

l16 mm optics mount

l16 mm lens

lHigh Speed Liquid Lens Module (DMA-HSLL-280)

lHigh Powered red LED illumination (DM280-LED-RED-HP)

(Risk Group Exempt acc. IEC62471)

l2-LED half-polarized extended cover (DM260-LENS-16CVR-

P) (Risk Group Exempt acc. IEC62471)

DM280-KIT-IMGMAX

Blue bandpass filter DM150-BP470

Red bandpass filter DM150-BP635

Lens Covers and Internal Illumination

Accessory Product Number Illustration

Red LED Light for 6.2 mm Lens (Risk Group Exempt acc. IEC 62471) DM150-LED-RED

White LED Light for 6.2 mm Lens (Risk Group Exempt acc. IEC 62471) DM150-LED-WHT

Blue LED Light for 6.2 mm Lens (Risk Group Exempt acc. IEC 62471) DM150-LED-BLU

High-Powered Red LED Light for 16 mm Lens (Risk Group Exempt acc.

IEC 62471)*

DM280-LED-RED-

High-Powered White LED Light for 16 mm Lens (Risk Group Exempt acc.

IEC 62471)*

DM280-LED-WHT-

Front cover. Use with a 6.2 mm lens only. DM280-CVR-62

Polarized front cover. Use with a 6.2 mm lens only. DM280-LENS-

62CVR-F

Half-Polarized front cover. Use with a 6.2 mm lens only. DM280-LENS-

62CVR-P

Accessory Product Number Illustration

Extended front cover. Use with a 16 mm lens only. DM260-LENS-

16CVR

Extended front cover, half-polarized. Use with a 16 mm lens only. DM260-LENS-

16CVR-P

Extended front cover, fully-polarized.Use with a 16 mm lens only. DM260-LENS-

16CVR-F

C-mount adapter, IP40 DM280-CMNT-00

C-mount cover, IP65 DM280-CMNT-CVR

Note: *For maximum light power 24VDC supply is recommended. For more

information, see Illumination Options on page1.

Cables

Note: Cables are sold separately.

Accessory Product Number Illustration

Ethernet Cable, X-coded M12-8 to RJ-45 CCB-84901-2001-xx (straight, xx specifies length:

2m, 5m, 10m, 15m, 30m)

Ethernet Cable, X-coded M12-8 to RJ-45 CCB-84901-2002-xx (right-angled, xx specifies

length: 2m, 5m, 10m)

Ethernet Cable, Robotic X-Coded M12-8

to RJ-45

CCB-84901-2RBT-xx (straight, xx specifies length:

2m, 5m, 10m)

X-Coded to A-Coded Ethernet cable

adapter, 0.5 m

CCB-M12X8MS-XCAC

Power and I/O Breakout Cable, M12-12 to

Flying Lead, 5m

CCB-M12x12Fy-05 (y = straight/angled)

Power and I/O Breakout Cable, M12-12 to

Flying Lead, 5m

CCBL-05-01

Power and I/O Breakout Cable, M12-12 to

Flying Lead

CCB-PWRIO- xx (straight, xx specifies length: 5m,

10m, 15m)

Accessory Product Number Illustration

Power and I/O Breakout Cable, M12-12 to

Flying Lead

CCB-PWRIO-xxR (right-angled, xx specifies length:

5m, 10m, 15m)

I/O Module Cable M12-12 to DB15 CCB-PWRIO-MOD-xx (xx specifies length: 2m, 5m)

RS-232 Connection Cable CCB-M12xDB9Y-05

I/O Extension Cable CKR-200-CBL-EXT
