Cognex MX-1000 Manual de usuario

MX-1000 Series

Quick Reference Guide

2021 June 14

Revision:6.3.0.21

Precautions

To reduce the risk of injury or equipment damage, observe the following precautions

when you install the Cognex product:

lRoute cables and wires away from high-current wiring or high-voltage

power sources to reduce the risk of damage or malfunction from the

following causes: over-voltage, line noise, electrostatic discharge (ESD),

power surges, or other irregularities in the power supply.

lChanges or modifications not expressly approved by the party responsible

for regulatory compliance could void the user’s authority to operate the

equipment.

lEnsure that the cable bend radius begins at least six inches from the

connector. Cable shielding can be degraded or cables can be damaged or

wear out faster if a service loop or bend radius is tighter than 10X the cable

diameter.

lThisdevice should be used in accordance with the instructions in this

manual.

lAll specifications are for reference purposes only and can change without

notice.

lThe safety of any system incorporating this product is the responsibility of

the assembler of the system.

lThis product is intended for industrial use in automated manufacturing or

similar applications.

lThisproduct does not contain user-serviceable parts. Do not make

electrical or mechanical modifications to product components.

Unauthorized modifications can void your warranty.

Symbols

The following symbols indicate safety precautions and supplemental information:

WARNING:This symbol indicates a hazard that could cause death, serious personal injury or electrical

shock.

CAUTION:This symbol indicates a hazard that could result in property damage.

Note: This symbol indicates additional information about a subject.

Tip: This symbol indicates suggestions and shortcuts that might not otherwise be apparent.

MX-1000 Layout

Layout

1 Scanner head (rotatable by 45°)

2 Indicator LEDs

3 Side trigger buttons

4 Power button

5 Touch screen

6 Home button

7 Speaker vents

8 Recessed area for mobile camera

9 Slider to lock battery cover

10 Battery cover

11 Lanyard hook

12 End cap of pistol grip*

13 Trigger button on the pistol grip*

*Pistol grip is optional

MX-1000 Series Accessories

Accessory

Battery for reader (3120 mAh) DMA-MTBATTERY-01

Battery for pistol grip accessory (3070 mAh) DMA-HHBATTERY-01

Pistol grip

Note: The grip features its own

trigger button and an additional

battery which can be charged via the

charging station.

DMA-GRIP-01

Belt holster DMA-HOLSTER-01

DMA-HOLSTER-02

Charging station (inductive) DMA-MTBASE-US

DMA-MTBASE-EU

Charging station (non-inductive) DMA-MTBASEP-US

DMA-MTBASEP-EU

Multi-device charger DMA-MTBASE4-US

DMA-MTBASE4-EU

DMA-MTBASE4BKT-US

DMA-MTBASE4BKT-EU

Multi-battery charger DMA-MBC-US

DMA-MBC-EU

Wireless car charger DMA-VMCHARGER-00

Accessory

Power supply for charging station 24V/24W DMA-24VPWR-US

DMA-24VPWR-EU

USB Type-C battery charger kits

1. USB Type-C Battery Cover

(DMA-MXUSB-00) + USB

Type-C 3Amp Car Charger

(DMA-MXUSB-CHARGER)

2. USB Type-C Battery Cover

(DMA-MXUSB-00) + Handstrap

(DMA-MXSTRAP-00)

3. USB Type-C Battery Cover

(DMA-MXUSB-00) + USB

Type-C 3Amp Car Charger

(DMA-MXUSB-CHARGER) +

Handstrap (DMA-MXSTRAP-

00)

1. DMA-MXUSB-01

2. DMA-MXUSB-02

3. DMA-MXUSB-03

Passive car holder1DMA-VMHOLDER-00

1Using or storing the device outside of the recommended temperature ranges may damage or reduce the lifespan of

the battery. Leaving the MX Series Mobile Terminal with a mobile device in direct sunlight for an extended amount

of time can raise the temperature above the recommended limit.

Accessory

Top Cover DMA-COVERKIT-S6

DMA-COVERKIT-S7

DMA-COVERKIT-S8

DMA-COVERKIT-S9

DMA-COVERKIT-I5

DMA-COVERKIT-I6

DMA-COVERKIT-S4

DMA-COVERKIT-S5

DMA-COVERKIT-J3

DMA-COVERKIT-J327

DMA-COVERKIT-J330

DMA-COVERKIT-A3

DMA-COVERKIT-X4

DMA-COVERKIT-N42

DMA-COVERKIT-s10e

DMA-COVERKIT-iX

Dimensional Drawings

Field of View and Reading Distances

Note: Due to tolerances, ranges can vary by +/- 5 mm for small codes to +/- a couple of centimeters for

large codes.
