Coffee Queen Empire Hot & Cold Manual de usuario
User manual
Rev. 090914
U / EN
Empire Hot & Cold
Din återförsäljare / Your retail dealer
...............................................................................
...............................................................................
1. Table (list) of contents.
1. Table of contents sid. 2
2. General 3
3. Overview of components front 4
3. Overview of components mixing system 5
3. Overview of components cooling system 6
4. SERVICE; Installation and start
Place the brewer 7
Connectings: Electricity/Water 7
Starting up machine 7
Fylla behållare med ingredienser 8
5. Operation
Making a drink 9
6. CLEANING
Weekly cleaning
Dismantle mixing system 10
Washing parts 10
Reassemble mixing system 11
7. CLEANING programs:
Automatic cleaning of mixing bowl (only): 12
Automatic cleaning of mixing bowl 1 or 2 13
Automatic cleaning of In/Outlet valves: 14
8. Cleaning and maintenance 15
outside cleaning
cleaning of condenser
9. Cup counter and Easy access 16
10. Safety functions 17
11. Failure messages 17
12. Storage / Transporting 17
13. Dimension sketch 18
2.
2. General. Empire hot & cold
We congratulate to your choice of a Empire coffee machine.
Please read this manual before you take the machine into operation
for the first time.
Themanualcontainsimportantinstructionsforasafeandproperuseofthemachine.
Alwayskeepthismanualwithinreachfortheuser!
Empire Hot & Cold
- making coffee cup by cup
- 8 choices of drinks,
- 2 - 4 ingredients canisters,
- electronicallytemperaturecontrolled
- adjustablecoffeestrength
- clockfunctions
Facts:
Height 622 mm
Width 311 mm
Depth 475 mm
Electricity 230V/2370W Chillerunit
Refrigerator HFC-134a
Water connection ½”outside thread
3.
Outlet
drinks
Strength of drinks
++ or - -
Choices of
drinks
Drip tray
insert
Drip tray
Keyswitch
cupandjug
choice)
Display
Door
lock
4.
3. Overview of components , front Empire hot & cold
Chillerunit
3. Overview of components , mixer system Empire hot & cold
5.
Canister: Width Depth Height Volume/litre; Cups/filling
Instantcoffee 67 225 200 1,15
Topping 67 225 200 1,15
Icechocolate 67 225 200 1,15
Frappe 67 225 200 1,15
Chute
Ingredients
canister
ON/OFF-
switch
Steam trap
Mixing bowl
Outlet
drinks
Service
opening
emptyingof
watertank
3. Overview of components , cooling water Empire hot & cold
6.
Fan
Cooling unit
Compressor Starting capacitor Thermostat
Condenser
Dryer
Water IN
Water
OUT
4. Service. Installation and start Empire hot & cold
1. Place the brewer on a flat Connect the electrical plug to a separate
levelandwaterproofsurface. groundedwallsocket
Grounded wall socket
230V 10A
OBSERVE!
Make sure there is a space
behind the machine for free
flow of air.( minimum 10cm ).
2. Connect attached water tube to cold water with an R 1/2”.
Makesurethatthewaterhosenotarekinkedanywherewhenmachineis
pushedintoplace.
Pleaseflushthewatertubebeforeconnectingtomachine,thistoavoidany
particlestodamagetheinletvalve.
3. Openthewaterinlet.
4. TurnontheON-OFFswitchinsidethedoor.
Waterisbeenfilledintothe tankautomatically,
with2,0litresofwater.
Theheatingwillnotstartbeforethewaterlevel
reachesthelevelsensor.
Set temp. is approx. 85ºC.
5. Close door.
6. Whenthewater is heated up torighttemperature.Thetext”pleasewait” will disappear.
NOTE! Machine must be heated up before chilled water can be in use.
7. Pushbuttonforchilledwateruntilwateriscominginaevenflow.
8. Afterapproximately 10 minutes machineisready to use.
(Inthemeantimewaterisgettingcold).
7.
ON / OFF
switch
”Pleasewait”
8.
4. Service. Installation and start Empire hot & cold
9. Fill canisters with ingredients.
Takeout(thistoavoidunnecessaryspillage
inthemachine)ingredientcanistersandfill
them withingredients.
1. Loosencanister.
2. Removelid and fillcanisterwith
ingredients.
Reassemblecanisters.
10. When placing the ingredient canisters;
Makesurethattheoutletpipesontheingredientcanistersare touching the
steam traps (A).
(A).
(A).
9.
5. Operation; Making coffee in a cup Empire hot & cold
1. Place a cup in the centre of the cup holder
2. The strength has a standard setting,
ifyou wish to increase or decrease it, do as
follows ifnot continue to point 3.
Stronger drink;
Increase by pushing + or ++ for 5% or 10%
alternative
Weaker drink;
Decrease by pushing - or -- for 5% or 10%
(the indication lamp will go up or down
depending of choice).
3. Choosedrinkbypushingonthebuttontothe
rightofeachmenu
The display will show; ”Please wait”
Wait untilthetext”Pleasewait”hasbeen
turnedoffbeforeyoutakeyour cup.
Enjoyyourdrink.
2.
3.
(D)
Dismantle : Mixer system
1.
Loosenoutlethose(A) and
turnlockknob(B)
anti-clockwise.
3.
Loosen whipper (D) pull
whipperstraightout from
themachine.
(E)
(A)
(B) (C)
Cleaning
Wash these parts:
6.
A. Mixerbowl
B. Steam trap
C. Whipper
D. Assembly plate
NOTE!
Make sure this parts are dry
before use
2.
Loosenmixerbowl.
Pullapart(C).
4.
Turnlockknobanti-
clockwise.(E) untilit stops
5. Clean with a wet rag and
droughtdrily.
10.
6. CLEANING: Weekly cleaning Empire hot & cold
