Coffee Queen CAFE ELITE Manual de usuario

Your retail dealer

Rev. 110202

TECHNICAL MANUAL

CAFÉ ELITE

1. Table of contents. Technical manual CAFÉ ELITE

1. Contents sid. 2

2. General 3

3. Overview User card 4

4. Warning message shown in display 5 - 6

5. Error code description 7

6. Circuit diagram 8

6. Circuit diagram UC and IO Pay card 9

7. Spare part list 10-11

8. Exploded view 12 - 16

9. Dimension sketch 17

10. Serviceintervals 18

2. General. CAFÉ ELITE

Function description:

Café Elite has three nozzles, one for hot water and two for a choice of other drinks.

Café Elite has eight buttons, one of which is generally reserved for hot water only and

the others are programmable for dispensing a choice of other drinks.

Café Elite can be programmed to dispense a set volume or for continuous ow from

any dispenser nozzle or self-closing faucet.

First start up

Turn ON the main switch behind the door, display will show: “water level low”

“Press Enter”

Press the E button to conrm.

Energy Saving Mode:

Hold the stop button for 5 seconds. Display will show standby.

When the machine goes into standby mode, drinks cannot be dispensed and the

water temperature falls to the block ambient temperature.

To return to operation mode, press the stop button for 5 seconds.

Fact:

Height 735 mm

Width 310 mm

Depth 515 mm

Electrical connection. 1-phase 230V/2200W

Cold water connection: ½” Radius external thread

Ambient temperatures for correct operation +5ºC - +50ºC

Note: All options must be connected and installed by a qualied electrician.

4 Canisters

Canister: Width Depth Height volume/litre;

coffee 67 225 335 2,7

espresso 67 225 335 2,7

chocolate 67 225 335 2,7

topping 67 225 335 2,7

3 Canisters

Canister: Width Depth Height volume/litre;

coffee 137 225 335 2,7

chocolate 67 225 335 2,7

topping 67 225 335 2,7

5. Overview of components, function buttons AC12

3. Overview of components, User Card CAFÉ ELITE

TECHNICAL SERVICE CARD.

Insert the user card, according to the illustration.

The display will show the Service Menu, Counters and you can now browse

forwards through the menu.

(TECHNICAL SERVICE CARD) Item number:

1602693.is used for adjusting drinks and

counters.

The user card is supplied by your dealer.

Service Menu

Counters

To use the machine again. Remove the card and keep it in a safe place.

4. Warning message shown on display CAFÉ ELITE

Message on display:

Display shows

Hardware Error: Hardware error

Not available Drink cannot be selected as pot.

Heating Water Low temperature in the water tank, the machine

is heating up (blocked)

Please Wait...

Low Water Level Low water level in water tank.

Press Enter Key

Filling Water The machine is lling water.

Please wait

Select drink

Temperature Shows actual temp. in water tank

Strength + / - to increase concentrate

Jug Mode

Energy saving mode Machine is in Energy saving mode

Warning The temperature is low, it is still possible to dispense drink.

Low Temperature

Low Temperature The temperature is low, the machine is blocked.

Blocked

Empty Drip Tray The drip tray is full of water

Overcurrent Overcurrent

Message on display:

Display shows

Error: The water has not reached the correct level in the water tank.

Water Supply Check the water tap, restart the machine.

Error: Check the level sensor, cable failure, level pins connected incorrect

Water level pins

Place Cup If the cup sensor has been activated, this is

shown if no cup has been placed on the drip tray.

Bev. Disabled The drink has been disabled

Please wait Shows when drink dispens

Door open

Error: Tempsensor damaged, faults in cables

Temp.sensor

Error: Solid state defect, heater defect. Output I/0 card is defect.

Check Heater

4. Warning message shown on display CAFÉ ELITE

Felkodsbeskrivning:

Error code description:

Overcurrent

Group 1:2 = Other components (Fan, Valves, Relays Etc..) (1,5A limit)

Group 1:3 = Mixer 1 (3,5A limit)

Group 1:5 = Mixer 2 (3,5A limit)

Message is shown if one of the software fuses have been trigged. Caused by a component

using too much current (A). You can run each component in the “Hardware Test” menu and

the message will show when you turn on the component that is using too much current.

ERROR: Water Supply

Message will show if the inlet valve has been open for more than 3 minutes and the

machine still have not acquired correct water level

Action: Check that the water to the machine is turned on, Check the levelsensor, test

function of the inlet valve in “Hardware Test”

ERROR: Tempsensor

Message will show if the NTC sensor is broken or is out of range of its resistance curve,

also if cables have loosened from its connectors.

Action: Replace NTC sensor, check cable connection on the NTC and PCB board.

ERROR: Levelpins

Message will show if the cables to the water level high & low have been connected to the

wrong levelpin.

Action: Swap cables to the levelsensor

ERROR: Check Heater

Message will show if the machine have not reached working temperature within

14 minutes from startup.

Action: Check Overheating protection, cables to the element, solid state relay, signal from

IO-board to solid state when you know the machine should heat, you can also force the

element to run in “Hardware Test”.

5. Error code description. CAFÉ ELITE

6. Circuit diagram. CAFÉ ELITE

6. Circuit diagram. UC Pay

7. Spare part list. CAFÉ ELITE

Pos. Amount/unitArticle . no. Description

Valid for page 12 Door

1 1 1202551 Key switch

2 1 1665009 Left Overlay

3 1 1665002 Middle Printing Film

4 1 1665001 Membrane Switch

5 1 1604112 Display Board complete

6 1 180115 guide pin, Door

7 1 1602697 Card Reader

8 1 1605401 Grommet

9 1 260067-02 Spill Grid

10 1 1264007 Drip Tray Cafe Elite Black

Valid for page 13 Machine 1

1 1 120250 Key Lock

2 1 160841 Microswitch Instant

3 1 1206123 Non Return Valve complete

4 1 1604111 Main PCB

5 4 1205626 Canister W67 H350

6 1 1505076 Rubber Plug,10mm

7 2 120465 Rubber TPG 20.5

8 1 NA 01 Air Flow Pipe

9 1 160536 Rubber Trp 30.0 Shore45

10 1 1602414 Terminal Block for 4mm” Wire

11 1 1031652 Power Supply 150W

12 1 1604203 Solid State 25A

13 1 1206581 Seal Solid State

14 2 1604836 Hose Adapter for Mixing System

15 1 160801 Rocket switch single orange

16 1 120498 Bulkhead Adaptor

17 1 1205500 Spring Level Sensor

Valid for page 14 Machine 2

1 1 1561015 Over Flow Pipe

2 3 1206289 Outlet Valve Deltrol 24VDC

3 4 1604612 Motor gear 145rpm

4 4 1604614 Drive Shaft 16mm

5 1 1604351 Fuse Assembly

- 1 1604381 Fuse 4 Amp (slow 5x20)

6 1 1604173 Fan Connection Complete Black

7 1 1505042 Inlet hose with connect

8 1 160565 Power Cord European

9 1 160570 Power Socket

10 1 220220 High limit Switch

11 1 260141 Water tank 5L Assy deep draw

12 1 160841 Microswitch Instant

13 1 1403401 Inlet Valve Plug with Silicon Seal White

14 1 1604171 Fan 24VDC

15 1 1206371 Single Valve 2.5L 24VDC

10.
