Cochlear Wireless phone clip Manual de usuario
Cochlear™
Wireless Phone Clip
Quick guide for Baha®users
Benefits of your Cochlear Wireless Phone Clip
Enjoy hands-free calling direct to your Baha 4 Sound Processor.
Hear your Bluetooth-enabled navigation system directly in your
Baha 4 Sound Processor.
Discreetly adjust your Baha 4 Sound Processor by using the
Phone Clip as a remote control.
Stream music from a Bluetooth-enabled device.
The Phone Clip can be easily attached to clothing. The built-in
microphone will pick up and transmit your voice, even if your phone
is several metres away.
Product overview Getting Started
Check with your hearing healthcare professional whether your sound processor has been
paired with your Phone Clip. Pre-paired sound processors do not need to be paired again.
If your sound processor is not pre-paired, instructions on how to easily pair it with your
Phone Clip are on the last page of this guide.
Tip! Make sure that your sound processor volume is comfortably adjusted before you change
the settings with the volume control on the Phone Clip.
Call pick-up/
hang-up button
Micro-USB connector
for charging
Sound processor
program button
Sound processor
microphone
mute button
Microphone
inlet
Volume
control
10-30cm between mouth
and Phone Clip
Charging the battery
Plug one end of the included micro-USB charging cable into the Phone Clip and the other
into a computer, or into a power outlet via the supplied adapter.
When the red LED indicator on top of the Phone Clip turns green with a red blink every 2
seconds charging is complete.
The first time you charge your Phone Clip allow it to charge for at least 3 hours, even if the
indicator light shows a full charge. The battery cannot be overcharged.
Note: The Phone Clip provides 6 hours of talk time or 80 hours of standby time from a full
charge.
ON/OFF
switch
OFF
ON
Support
For full details about the Cochlear Wireless Phone Clip, please refer to the User Manual.
For full details about the Cochlear Baha 4 Sound Processor, please refer to the User Manual part A.
For further support and videos, visit the Cochlear website: www.cochlear.com
Cochlear™
Wireless Phone Clip
Quick guide for Baha®users
Light indicators (LED) Connecting with your mobile phone
Using the Phone Clip
To receive or place phone calls with the Phone Clip, the Bluetooth®
functionality must be activated in your mobile phone. Your phone
might ask you to confirm whether you would like to connect with the
Phone Clip after it is successfully paired.
If you have to connect manually, locate a list of “Paired Devices” in
your phone’s Bluetooth®menu. From this list, highlight “Hearing Aid
Phone” and select “Connect.”
You are now ready to use your Phone Clip.
On some phones you can also enable “Automatic Reconnection.”
Refer to your mobile phone’s user guide for instructions on how to
do this.
Tip! In most instances, a headset symbol on the main screen of your
mobile phone will confirm that you have successfully connected.
Managing calls with the call pick-up / hang-up button
Incoming calls:
To answer a call, press once.
To decline a call, double-click.
During a call:
To transfer a call started on your phone to the
phone clip, press once.
To put a call on hold, press and hold for 2
seconds.
To make a call:
To redial the last number, double-click.
To activate voice dialling, press and hold for 2
seconds.
Using the Phone Clip as a remote control
Adjust the sound
processor’s volume
Press once to mute
and unmute the sound
processor’s microphones.
Press one or more times to
toggle through the sound
processor’s programs
When you’re not on the phone, the Phone Clip can also be used as a simple
remote control for your sound processor(s).
The LED indicator at the top of your Phone Clip functions as a
multi-purpose user interface, providing information on the status
of the device.
Blinks Meaning
Normal operation (green)
Battery low (yellow)
Charging (red)
Fully charged – still connected to charger (red/green)
Ready for pairing with sound processor (yellow)
Ready for pairing with Bluetooth device (blue)
Bluetooth call active (blue)
Cochlear™
Wireless Phone Clip
Quick guide for Baha®users
Pairing with your Baha 4 Sound Processor
ASwitch off your Baha 4 Sound Processor:
BSwitch on your Phone Clip and remove
the silver cap.
E
Press the white pairing button on the
Phone Clip once using the tip of a pen
or similar object.
C
By opening the
battery door and
removing the battery.
By pressing the
“off/volume down”
button.
OR
While pairing mode is active, switch on your sound processor:
By inserting the
battery and closing
the battery door.
By pressing the
“on/volume up” button.
OR
DThe LED will flash yellow every two
seconds and the Phone Clip will now
be in pairing mode for 20 seconds.
FSuccessful pairing will be indicated by an audible melody
played in the sound processor.
Switch on
Remove cap
Cochlear™
Wireless Phone Clip
Quick guide for Baha®users
Pairing with your mobile phone
ASwitch on your Phone Clip and remove the silver cap.
BMake sure your mobile phone’s Bluetooth function is switched on.
Refer to your mobile phone user guide or visit www.jabra.com
for instructions.
Press the blue Bluetooth pairing button on the Phone Clip once
to activate the pairing mode for 2 minutes. During pairing the LED
will turn blue.
C
A
DOn your mobile phone search for new Bluetooth devices and select
“Hearing Aid Phone” from the list.
EIf your mobile phone asks for a passcode, enter “0000” (four zeros).
FYour Phone Clip should now be paired with your mobile phone.
If your mobile phone asks which Bluetooth service you wish to
enable, select “Headset”.
Ardium, Baha, Baha Divino, Baha Intenso, Baha PureSound, Baha SoftWear, DermaLock, Vistafix and WindShield are either trademarks or registered trademarks of Cochlear Bone Anchored Solutions AB. Cochlear, Hear Now. And
always and the elliptical logo are either trademarks or registered trademarks of Cochlear Limited. © Cochlear Bone Anchored Solutions AB 2014. All rights reserved. JAN14.
Manufacturer:
Cochlear Bone Anchored Solutions AB
Konstruktionsvägen 14, SE - 435 33 Mölnlycke, Sweden
Tel: +46 31 792 44 00 Fax: +46 31 792 46 95
www.cochlear.com
C
E82989A
Switch on
Remove cap
