Clarke TIGER 2600A Manual de instrucciones

WARNING: Read these instructions before using the machine

OPERATION & MAINTENANCE

INSTRUCTIONS

LS0120 - ISS 1

ORIGINAL INSTRUCTIONS

PETROL DRIVEN POWER WASHER

MODEL NO: TIGER 2600A

PART NO: 7320206

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

INTRODUCTION

Thank you for purchasing this CLARKE Petrol driven power washer.

Before attempting to use this product, please read this manual thoroughly and

follow the instructions carefully. In doing so you will ensure the safety of yourself

and that of others around you, and you can look forward to your purchase

giving you long and satisfactory service.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt which will be

required as proof of purchase. This guarantee is invalid if the product is found

to have been abused or tampered with in any way, or not used for the

purpose for which it was intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission.

This guarantee does not effect your statutory rights.

ACCESSORIES

The range of accessories listed below are available from your CLARKE dealer.

ITEM PAR T NUM B E R

5 Litres Detergent (Traffic Film Remover) 3050821

25 Litres Detergent (Traffic Film Remover) 3050820

5 Litres Wash ‘n’ Wax 3050815

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

GENERAL SAFETY RULES

1. DO NOT point the spray at other people, animals, electrical equipment or the

machine itself.

2. DO NOT hold your finger over the high pressure nozzle.

3. DO NOT let children or untrained personnel use this machine.

4. DO NOT operate the machine with any of the covers removed.

5. DO NOT try to repair this machine. Always refer to your CLARKE service

department for all repairs.

6. DO NOT supply any liquid other than water to the water inlet.

7. DO NOT use the detergent pickup facility to introduce flammable liquids/

solvents, e.g. paint thinners, petrol, oil as there is a risk of explosion.

8. ALWAYS release the remaining pressure in the system turn off the water supply

and operate the trigger before you remove hoses or accessories.

9. ALWAYS keep the machine dry and away from the water spray.

10. ALWAYS use protective clothing and safety glasses. Loose particles and other

items can be propelled at high speed by the water spray.

11. ALWAYS hold the gun securely and expect it to ‘kick’ when you pull the

trigger.

12. ALWAYS respect the requirements of the local water company. Pressure

washers may only be connected to the mains water supply if a system

separator (also known as a backflow preventer) is installed in the supply hose.

13. ALWAYS disconnect from the water supply, and make sure that you drain the

system when not in use. Keep in a cool dry location.

14. ONLY use detergents that are suitable for pressure washers, we recommend

that you use CLARKE Traffic Film Remover or CLARKE Wash and WAX

(available from your dealer).

15. WARN ING High pressure hoses, fittings and couplings are important for the

safety of the machine. Use only hoses, fittings and couplings recommended

by the manufacturer.

16. WARN ING Water that passes through a system separator (also known as a

backflow preventer) is not safe to drink.

17. DO NOT use the pressure washer if there is damage to the inlet/outlet hose or

the machine.

WARNING: Water at high pressure can be dangerous and can cause

damage if the operator is careless. Never allow anyone to operate this

pressure washer unless they are familiar with the safety precautions.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

SAFETY SYMBOLS

WARNIN G: Do not direct discharge

stream at persons or animals. Keep

clear of nozzle.

WARNIN G: Never direct spray toward

any electrical device or electrical

outlet.

General Warning, indicates

that failing to follow these

instruction could result in

injury or damage to the

machine.

To reduce the risk of injury,

read the manual before

use.

ALWAYS wear safety glasses

when using this machine.

WARNING: No open flame,

open ignition source and

smoking is prohibited

WARNING: No smoking

DANGER: Risk to

breathing. Engine

exhaust fumes can kill.

For outdoor use only. Work

in a well ventilated area.

WARNIN G: Risk of injection

or severe injury. Do not

direct discharge stream at

persons or animals. Keep

clear of nozzle. This

machine is to be used

only by qualified operators.

WARNIN G: Risk of spray

injury. Spray can propel

objects. Always wear ANSI

approved Z87.1 Safety

Glasses.

WARNIN G: Risk of

chemical burn. Never

spray acids, corrosive or

toxic chemicals. Use only

cleaners formulated for

pressure washers.

WARNIN G: Risk of

electrocution. Never

direct spray toward any

electrical device or

electrical outlet.

WARNIN G: Risk of unsafe

operation. Keep

children away from this

equipment. Gun kicks

back. Hold with both hands.

WARNIN G: Risk of hot

surfaces.

Recycle unwanted

materials instead of

disposing of them as waste.

All tools, accessories and

packaging should be

sorted, taken to a recycling

centre and disposed of in a

manner which is compatible

with the environment.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

OVERVIEW

NO DESCRIPTION NO DESCRIPTION

1 Fuel Tank Cap 11 Engine On/Off Switch

2 Fuel Tank 12 Oil Filler Cap

3 Spark Plug 13 Water Outlet

4 Choke 14 Detergent Tank

5 Gun Assembly 15 Water Inlet

6 Lance 16 Bypass Drain Hose

7 Air Filter Cover 17 Hose Holder

8 Recoil Pull Start 18 Lance Holder

9 Fuel Valve 19 Priming Bottle

10 Throttle

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

ASSEMBLY

Unpack your pressure washer and check to ensure the following items are

present.

Contact your CLARKE dealer immediately if any parts are missing or

damaged.

CONNECTING THE WHEELS

1. Slide the axles into the locating

tube as shown.

• Make sure the ball catch locks

into the small hole on the

bottom of the locating tube.

2. Add the 2 axle covers as shown.

•1 x Petrol Power Washer •1 x Gun Assembly

•2 x Wheel c/w Axle •1 x Lance / Nozzle Assembly

•1 x Upper Handle c/w fixings •1 x Spark Plug Box Spanner

•1 x Hose Bracket c/w fixings •1 x Tommy bar

•1 x Lance Bracket c/w fixings •1 x Engine Manual

•1 x Primer Bottle •1 x Primer Bottle Holder

•1 x Primer Bottle Bracket •2 x Rubber feet and fixings

•1 x Hose •1 x 3m Inlet water hose

•1 x Water Filter (may be supplied already fitted)

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

FITTING THE RUBBER FEET

1. Fit the rubber feet to the legs as

shown.

CONNECTING THE HANDLE

1. Slide the upper handle into

position as shown.

2. Secure using a bolt and

handwheel.

• The handwheel should be on

the outside.

FITTING THE WATER BOTTLE

NOTE: The water bottle is only used when using the drawing water from an

unpresurrised source such as a water butt. See page 16.

1. Fit the bracket to the frame as

shown using the bolts, nuts and

washers supplied.

2. Slide the bottle holder over the

bracket and place the bottle in

the holder.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

FITTING THE LANCE/HOSE HOLDER

Fit the holders into the positions

shown and secure using the washers

and nuts provided.

CONNECTING THE HIGH PRESSURE HOSE

CONNECT THE HOSE TO THE GUN

1. Screw the high pressure hose onto

the gun assembly.

• Tighten the connector, hand

tight only. Do not use a

spanner.

NOTE: Make sure the connection is

secure.

CONNECT THE HOSE TO THE PRESSURE WASHER

1. Screw the hose on to the pressure

washer.

• Tighten the connector, hand

tight only, Do not use a

spanner.

NOTE: Make sure the connection is

secure.

ASSEMBLING THE LANCE

Connect the spray lance to the gun

assembly and tighten securely by

turning the locking ring.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

CONNECTING THE WATER SUPPLY

Always follow the regulations of your local water supplier. The pressure washer

must never be connected to the drinking water supply without using a system

separator (also known as a backflow preventer) available from most

hardware stores.

NOTE: Water that has flowed through a system separator is considered non-

drinkable.

1. Connect a water supply hose (not

supplied) to the water inlet.

• Make sure that the water filter is

installed behind the hose

connector on the water inlet

NOTE: Use a good quality fibre-

reinforced water hose with a

standard coupling.

NOTE: This machine has the ability to

draw its own water, meaning

you can use water not under pressure such as rainwater collected in a

water butt. See page 16.

BEFORE USE

IMPORTANT: The engine is supplied without any oil in it and must be filled to

the correct level before use, see below.

ENGINE OIL

1. Turn the oil filler cap anticlockwise

and remove it from the engine,

wipe the integral dipstick with a

clean cloth.

WARNING: STAND THE PRESSURE WASHER ON LEVEL GROUND WITH THE

ENGINE SWITCHED OFF.

WARNING: TAKE CARE NOT TO TOUCH ANY HOT PARTS OF THE PRESSURE

WASHER WHEN CHECKING THE OIL LEVEL.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

2. Insert the oil filler cap back into

place and then remove it again.

3. If the oil reads low on the dipstick,

add oil to the oil reservoir (Max

0.6L).

• We recommend the use of

SAE10W-30 oil.

• Do not overfill the oil reservoir.

4. Replace the oil filler cap.

NOTE: Running the engine with

insufficient oil will cause

engine damage.

FUEL

1. Remove the fuel tank cap.

• Just inside the fuel tank is a fuel

strainer, which should be

checked periodically and any

contaminants which have

accumulated must be

removed.

2. Pour unleaded petrol through the

fuel strainer and into the fuel tank.

• Do not fill above the fuel

strainer shoulder.

• Use unleaded petrol with a

pump octane rating of 86 or

higher.

3. Replace the fuel filler cap

securely.

WARNING: REFUEL IN A WELL-VENTILATED AREA, AWAY FROM ANY

SOURCES OF IGNITION.

WARNING: IF THE ENGINE HAS BEEN RUNNING, ALLOW IT TO COOL

BEFORE REFUELING.

WARNING: DO NOT LEAVE FUEL WITHIN THE REACH OF CHILDREN.

WARNING: REFUEL CAREFULLY TO AVOID SPILLING FUEL.

Tabla de contenidos

Otros manuales de Hidrolavadora de Clarke

Clarke

Clarke JetKing 2000 Manual de instalación y operación

Clarke

Clarke KING150 Manual de instrucciones

Clarke

Clarke JET 9500B Manual de instrucciones

Clarke

Clarke JETSTAR 1600 Manual de instalación y operación

Clarke

Clarke JETSTAR 1800 Manual de instalación y operación

Clarke

Clarke KING 145 Guía de solución de problemas

Clarke

Clarke JETSTAR 1900 Manual de instalación y operación

Clarke

Clarke PLS130AH Manual de instalación y operación

Clarke

Clarke TIGER 2600 Manual de instrucciones

Clarke

Clarke Power Wash PLS195A Manual de instrucciones

Clarke

Clarke JET 9500 Manual de instrucciones

Clarke

Clarke JET 8500 Manual de instrucciones

Clarke

Clarke Tiger 3000B Manual de instrucciones

Clarke

Clarke JETSTAR 1950 Manual de instrucciones

Clarke

Clarke JET 7500 Manual de instrucciones

Clarke

Clarke ELS140 Manual de instalación y operación

Clarke

Clarke Power Wash PLS190 Manual de instrucciones

Clarke

Clarke Power Wash EHD130 Manual de instalación y operación

Clarke

Clarke TIGER1700 Manual de instrucciones

Clarke

Clarke POWER WASH JET 7000 Manual de instrucciones

Clarke

Clarke TIGER 3000A Manual de instrucciones

Clarke

Clarke HLS160 Manual de instrucciones

Clarke

Clarke PLS100FH Manual

Clarke

Clarke JETSTAR 1700 Manual de instalación y operación

Manuales populares de Hidrolavadora de otras marcas

Shark

Shark RG-232637 Manual de usuario

Shakti Technology

Shakti Technology S3 Manual de usuario

Kärcher

Kärcher K 4 Pure Manual de usuario

Porter-Cable

Porter-Cable D25806-025-2 Manual de usuario

REM POWER

REM POWER HDEm 662 Manual de usuario

Landa

Landa HS-3000 Manual de usuario

Craftsman

Craftsman 580.752270 Manual de usuario

HIKOKI

HIKOKI AW 100 Manual de usuario

Delco

Delco DC 1302 Manual de usuario

Kärcher

Kärcher K 3 Full Control Manual de usuario

BIEMMEDUE

BIEMMEDUE 120/10 - 170/13 Manual de usuario

ARKSEN

ARKSEN 014-HG-14141-HR Manual de usuario

Black & Decker

Black & Decker PW1700SPX Manual de usuario

Kärcher

Kärcher 595 - SPARE Guía

Kranzle

Kranzle B 10 200 Manual de usuario

Stihl

Stihl RE 90 Manual de usuario

Husky

Husky HU80911 Manual de usuario

PowR-Quip

PowR-Quip PQ-2600 Manual de usuario
