CHAPTER
Overview of the Router 1-1
1
Overview of the Router
Table 1-1 lists the router models discussed in this publication and provides a summary of
the interfaces supported on each model. These router models are similar in functionality,
but differ in the number of interfaces supported.
Table 1-1 Summary of Router Interfaces
Model Ethernet
AUI1(DB-15)
1. AUI = attachment unit interface.
Token Ring
(DB-9) Serial
(DB-60) ISDN2BRI3
(RJ-45)
2. ISDN = Integrated Services Digital Network.
3. BRI = Basic Rate Interface.
Cisco 2501/
CPA2501 1–2–
Cisco 2502/
CPA2502 –12–
Cisco 2503/
CPA2503 1–21
Cisco 2504/
CPA2504 –121
Cisco 2513/
CPA2513 112–
Cisco 2514/
CPA2514 2–2–
Cisco 25154
4. A CPA2515 model is not available.
–22–
1-2 Router Installation and Configuration Guide
Hardware Features
Note Throughout the remainder of the publication, one model number will be used in text
references. For example, references to the model 2501 router will apply to both the
Cisco 2501 and CPA2501 routers.
Hardware Features
In addition to the interfaces listed in Table 1-1, the routers include the following hardware
features:
•Dynamic random-access memory (DRAM) for main memory and shared memory
•Nonvolatile random-access memory (NVRAM) for storing configuration information
•Flash memory for running the Cisco IOS software
•EIA/TIA-232 console port for local system access using a console terminal
•EIA/TIA-232 auxiliary port for remote system access using a modem
Note EIA/TIA-232 and EIA/TIA-449 were known as recommended standards RS-232
and RS-449 before their acceptance as standards by the Electronic Industries Association
(EIA) and Telecommunications Industry Association (TIA).
Figure 1-1 to Figure 1-7 show the rear panels of the router models discussed in this
publication.
Overview of the Router 1-3
Hardware Features
Figure 1-1 Model 2501 Router Rear Panel
Figure 1-2 Model 2502 Router Rear Panel
H4262
Ethernet
AUI LED
Ethernet
AUI port
(DB-15)
Console
port (RJ-45)
Auxiliary port
(RJ-45)
On/off
switch Power
Synchronous
serial LEDs
Synchronous
serial ports
(DB-60)
System
OK LED
H6585
Token Ring
port (DB-9) Console
port (RJ-45)
Auxiliary port
(RJ-45)
On/off
switch Power
Synchronous
serial ports
(DB-60)
Token Ring
LED Synchronous
serial LEDs System
OK LED
1-4 Router Installation and Configuration Guide
Hardware Features
Figure 1-3 Model 2503 Router Rear Panel
Figure 1-4 Model 2504 Router Rear Panel
H6586
Ethernet
AUI port
(DB-15)
PowerSynchronous
serial ports
(DB-60)
Console
port
(RJ-45)
ISDN
BRI port
(RJ-45)
Auxiliary port
(RJ-45)
Ethernet
AUI LED Synchronous
serial LEDs ISDN
BRI LED System
OK LED
On/off
switch
Power
On/off
switch
H6587
Token Ring
port (DB-9) Synchronous
serial ports
(DB-60)
Token Ring
LED
Synchronous
serial LEDs
System
OK LED
ISDN
BRI LED
Console
port
(RJ-45)
ISDN
BRI port
(RJ-45)
Auxiliary port
(RJ-45)
Overview of the Router 1-5
Hardware Features
Figure 1-5 Model 2513 Router Rear Panel
Figure 1-6 Model 2514 Router Rear Panel
H6588
TOKEN RING
Token Ring
port (DB-9) Ethernet
AUI port
(DB-15)
Synchronous
serial ports
(DB-60)
Token Ring
LED
Power
On/off
switch
Ethernet
AUI LED Synchronous
serial LEDs
System
OK LED
Console port
(RJ-45)
Auxiliary port
(RJ-45)
Synchronous
serial ports
(DB-60)
On/off
switch Power
H6589
Ethernet
AUI ports
(DB-15)
Ethernet
AUI LEDs Synchronous
serial LEDs System
OK LED
Console
port (RJ-45)
Auxiliary port
(RJ-45)
1-6 Router Installation and Configuration Guide
System Specifications
Figure 1-7 Model 2515 Router Rear Panel
System Specifications
The system specifications of the routers are listed in Table 1-2.
Table 1-2 System Specifications
Description Specification
Dimensions (H x W x D) 1.75 x 17.5 x 10.56 in. (4.44 x 44.45 x 26.82 cm),
one rack unit
Weight 10 lb (4.5 kg)
Input voltage, AC power supply
Current
Frequency
Power dissipation
100 to 240 VAC
1.2 to 0.6A
50/60 Hz
40W (maximum), 135.5 Btus1/hr
Input voltage, DC power supply
Current
Power dissipation
40W, 40 to 72 VDC
1.5 to 1.0A
40W (maximum), 135.5 Btus/hr
Processor 20-MHz Motorola 68EC030
On/off
switch Power
H6590
System
OK LED
Token Ring
LEDs Synchronous
serial LEDs
Synchronous
serial ports
(DB-60)
Token Ring
ports (DB-9) Console
port (RJ-45)
Auxiliary port
(RJ-45)
Overview of the Router 1-7
Obtaining Service and Support
Obtaining Service and Support
For service and support for a product purchased from a reseller, contact the reseller.
Resellers offer a wide variety of Cisco service and support programs, which are described
in the information packet that shipped with your chassis.
Interfaces See Table 1-1 for a list of interfaces supported on each
router model.
• Ethernet AUI (IEEE2802.3) (DB-15)
• Token Ring (IEEE 802.5) (DB-9)
• Synchronous serial3(DB-60)
• ISDN BRI (RJ-45)4
• Console (RJ-45)
• Auxiliary (RJ-45)
Operating environment 32 to 104°F (0 to 40°C)
Nonoperating temperature –40 to 185°F (–40 to 85°C)
Operating humidity 5 to 95%, noncondensing
Noise level 34 dBa @ 3 ft (0.914 m)
Regulatory compliance FCC Class A and Canadian DOC Class A
For more regulatory information, refer to the
Regulatory Compliance and Safety Information
document that accompanied your router.
1. Btus = British thermal units.
2. IEEE = Institute of Electrical and Electronic Engineers.
3. The synchronous serial interface supports the following standards in data terminal equipment (DTE) and
data communications equipment (DCE) mode: EIA/TIA-232, EIA/TIA-449, V.35, and X.21. The
EIA-530 standard is supported in DTE mode only.
4. External network terminal 1 (NT1) device required.
Table 1-2 System Specifications (Continued)
Description Specification
1-8 Router Installation and Configuration Guide
Cisco Connection Online
Note If you purchased your product from a reseller, you can access Cisco Connection
Online (CCO) as a guest. CCO is Cisco Systems’ primary, real-time support channel.Your
reseller offers programs that include direct access to CCO’s services.
For service and support for a product purchased directly from Cisco, use CCO.
Cisco Connection Online
CCO is Cisco Systems’ primary, real-time support channel. SMARTnet customers and
partners can self-register on CCO to obtain additional content and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and
value-added services to Cisco’s customers and business partners. CCO services include
product information, software updates, release notes, technical tips, the Bug Navigator,
configuration notes, brochures, descriptions of service offerings, and download access to
public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced
simultaneously—a character-based version and a multimedia version that resides on the
World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit,
Xmodem, FTP, and Internet e-mail, and is excellent for quick access to information over
lower bandwidths. The WWW version of CCO provides richly formatted documents with
photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can access CCO in the following ways:
•WWW: http://www.cisco.com.
•WWW: http://www-europe.cisco.com.
•WWW: http://www-china.cisco.com.
•Telnet: cco.cisco.com.
•Modem: From North America, 408 526-8070; from Europe, 33164464082.Usethe
following terminal settings: VT100 emulation; databits: 8; parity: none; stop bits: 1; and
baud rates up to 14.4 kbps.
Overview of the Router 1-9
Ordering Documentation
Note If you need technical assistance with a Cisco product that is under warranty or
covered by a Cisco maintenance contract, contact Cisco’s Technical Assistance Center
Please use CCO to obtain general information about Cisco Systems, Cisco products, or
upgrades. If CCO is not accessible, contact 800 553-6387, 408 526-7208, or
Ordering Documentation
Documentation for Cisco products is available in three forms: on a CD-ROM, printed
books, and on the World Wide Web. You have the option of subscribing to the
documentation CD through an update service. Or you can order printed documentation at
an additional cost. Refer to the information packet included with the router for detailed
ordering information. You can also access Cisco documentation on the World Wide Web
URL http://www.cisco.com.
1-10 Router Installation and Configuration Guide
Ordering Documentation
