Cisco NCS 4216 Manual de instrucciones

Installing the Cisco NCS 4216

This chapter describes how to install the Cisco NCS 4216.

•Prerequisites, page 1

•Installing the Router in a Rack, page 1

•Installing the Chassis Ground Connection, page 12

•Installing the Fan Tray, page 15

•RSP Installation, page 24

•Interface Module Installation, page 28

•Installing the Power Supply, page 31

•Connecting the Cisco NCS 4216 Router to the Network, page 40

Prerequisites

Before installing the Cisco NCS 4216, it is important to prepare for the installation by:

•Preparing the site (site planning) and reviewing the installation plans or method of procedures (MOP)

•Unpacking and inspecting the Cisco NCS 4216

•Gathering the tools and test equipment required to properly install the Cisco NCS 4216

For more instructions on how to prepare for the installation of the Cisco NCS 4216, see the Preparing for

Installation section.

Installing the Router in a Rack

The sections describe how to install the Cisco NCS 4216 in a rack.

Cisco NCS 4216 Hardware Installation Guide

The Cisco NCS 4216 Door is not displayed in the figures below. It is only displayed in the Installing the

Cisco NCS 4216 Door figure.

Note

Installing the Chassis Brackets

The chassis is shipped with mounting brackets that can be installed on the front or rear of the chassis. To

install the brackets on the front of the chassis, perform these steps:

SUMMARY STEPS

1. Remove the rack-mount brackets from the accessory kit and position them beside the router chassis.

2. Position one of the brackets against the chassis side, and align the screw holes.

3. Secure the bracket to the chassis with the screws removed when performing Step 1 . The recommended

maximum torque is 28 in.-lb (3.16 N-m).

DETAILED STEPS

Step 1 Remove the rack-mount brackets from the accessory kit and position them beside the router chassis.

Figure 1: Attaching Mounting Brackets for a 23-inch Rack

Cisco NCS 4216 Hardware Installation Guide

Installing the Cisco NCS 4216

Installing the Chassis Brackets

Step 2 Position one of the brackets against the chassis side, and align the screw holes.

Step 3 Secure the bracket to the chassis with the screws removed when performing Step 1 . The recommended maximum torque

is 28 in.-lb (3.16 N-m).

The A907-FAN-E fan tray with filter (A907-FAN-F) cannot be mounted using the mounting screws that are supported

for fan tray. This is not an issue with the FAN tray filter blank panel (A907-FAN-F-B). We recommend that you use the

short screws provided in the following rack mount kits to avoid interference of the air filter during rack mounting and

while replacing the fan tray with the fan tray filter (A907-FAN-E):

•23" rack mount kit (A907-RCKMT-23IN)

What to Do Next

Repeat Step 2 and Step 3 for the other bracket.

Installing the Air Plenum (A907-F2B-AIR) in the Rack

This procedure installs the air plenum to orient the air flow in front-to- back direction in the NCS 4216 router.

Before performing any of the following procedures, ensure that power is removed from the DC circuit.

Statement 1074

Warning

This equipment is intended to be grounded. Ensure that the host is connected to earth ground during normal

use. Statement 39

Warning

For nominal voltage of -60 VDC, the input voltage range is from -40 to -72 VDC.Note

Use only the fastening hardware provided with the NCS 4216 to prevent loosening, deterioration, and

electromechanical corrosion of the hardware and joined material.

Note

When installing or replacing the unit, the ground connection must always be made first and disconnected

last. Statement 1046

Warning

The Air Plenum is installed on a rack or a cabinet using thread-forming screws that remove any paint or

non-conductive coatings inside the hole threads, and establish a metal-to-metal contact. Also, clean both

surfaces outside the screw points that come in contact, so that they are free of paint and other nonconductive

coating. Apply an appropriate antioxidant compound to the surfaces.

Warning

Cisco NCS 4216 Hardware Installation Guide

Installing the Cisco NCS 4216

Installing the Air Plenum (A907-F2B-AIR) in the Rack

Installing Air Plenum in NCS 4216 Shelf for ANSI 23-inch Configuration

To install the Air Plenum in NCS 4216 Shelf for ANSI 23-inch configuration, follow the steps below:

SUMMARY STEPS

1. Install the ANSI 23-inch adapter plates on the horizontal air plenums.

2. Align the screws to fix the adapter plates to the shelf. Insert the screws and tighten them to a torque value

of 11.5 in-lb (1.3 N-m).

3. Place a horizontal air plenum as the base.

4. Install the vertical air plenum to the left of the bottom horizontal plenum.

5. Install the wing head screws from the internal side of the horizontal plenum and tighten the screws to a

torque value of 11.5 in-lb (1.3 N-m).

6. Install the vertical air plenum to the right of the horizontal air plenum. Follow step 5.

7. Install the horizontal air plenum above the vertical air plenums. Follow step 5.

8. Install the pre-assembled air plenum for ANSI 23-inch configuration.

9. Install the pre-assembled air plenums in the ANSI 23-inch rack or cabinet.

10. Check the length between the top and bottom horizontal air plenums where the chassis will be installed.

The length must be not less than 10.5 inches (267 mm). If the length is less, adjust the position of the top

horizontal plenum.

11. Install the empty NCS 4216 chassis between the horizontal plenums.

Cisco NCS 4216 Hardware Installation Guide

Installing the Cisco NCS 4216

Installing the Air Plenum (A907-F2B-AIR) in the Rack

DETAILED STEPS

Step 1 Install the ANSI 23-inch adapter plates on the horizontal air plenums.

Figure 2: Installing the Air Plenum in the Rack

Cisco NCS 4216 Hardware Installation Guide

Installing the Cisco NCS 4216

Installing the Air Plenum (A907-F2B-AIR) in the Rack

Step 2 Align the screws to fix the adapter plates to the shelf. Insert the screws and tighten them to a torque value of 11.5 in-lb

(1.3 N-m).

Step 3 Place a horizontal air plenum as the base.

Step 4 Install the vertical air plenum to the left of the bottom horizontal plenum.

Step 5 Install the wing head screws from the internal side of the horizontal plenum and tighten the screws to a torque value of

11.5 in-lb (1.3 N-m).

Step 6 Install the vertical air plenum to the right of the horizontal air plenum. Follow step 5.

Step 7 Install the horizontal air plenum above the vertical air plenums. Follow step 5.

Step 8 Install the pre-assembled air plenum for ANSI 23-inch configuration.

Step 9 Install the pre-assembled air plenums in the ANSI 23-inch rack or cabinet.

Step 10 Check the length between the top and bottom horizontal air plenums where the chassis will be installed. The length must

be not less than 10.5 inches (267 mm). If the length is less, adjust the position of the top horizontal plenum.

Step 11 Install the empty NCS 4216 chassis between the horizontal plenums.

Cisco NCS 4216 Hardware Installation Guide

Installing the Cisco NCS 4216

Installing the Air Plenum (A907-F2B-AIR) in the Rack

Installing the Router Chassis in the Rack

The procedures in this section apply to both horizontal and vertical mounting of the router in a rack.

Figure 3: Installing the Router Chassis in the Rack

To install the router chassis in the equipment rack, perform these steps:

Cisco NCS 4216 Hardware Installation Guide

Installing the Cisco NCS 4216

Installing the Router Chassis in the Rack

SUMMARY STEPS

1. Position the chassis in the rack as follows:

2. Align the mounting holes in the bracket (and optional cable guide) with the mounting holes in the equipment

rack.

3. Install the 8 or 12 (4 or 6 per side) rack mount screws through the holes in the bracket and into the threaded

holes in the equipment rack posts.

4. Use a tape measure and level to verify that the chassis is installed straight and level.

DETAILED STEPS

Step 1 Position the chassis in the rack as follows:

•If the front of the chassis (front panel) is at the front of the rack, insert the rear of the chassis between the mounting

posts.

•If the rear of the chassis is at the front of the rack, insert the front of the chassis between the mounting posts.

Step 2 Align the mounting holes in the bracket (and optional cable guide) with the mounting holes in the equipment rack.

Do not use interface module and power supply ejector handles to lift the chassis; using the handles to lift the

chassis can deform or damage the handles.

Caution

Step 3 Install the 8 or 12 (4 or 6 per side) rack mount screws through the holes in the bracket and into the threaded holes in the

equipment rack posts.

Step 4 Use a tape measure and level to verify that the chassis is installed straight and level.

Installing the Cisco NCS 4216 Door

This section describes how to install the NCS 4216 door.

Cisco NCS 4216 Hardware Installation Guide

Installing the Cisco NCS 4216

Installing the Cisco NCS 4216 Door

You cannot install the 19-inch Rack Door.Note

Figure 4: Installing the Cisco NCS 4216 Door

To install the door of NCS 4216 shelf, follow the steps below:

Cisco NCS 4216 Hardware Installation Guide

Installing the Cisco NCS 4216

Installing the Cisco NCS 4216 Door

SUMMARY STEPS

1. Align the left door bracket screw holes against the shelf screw holes.

2. Insert the fasteners provided along with the packaging (three screws on the side and two screws on the

bottom of the door bracket) and tighten them to a torque value of 11.5 in-lb (1.3 N-m).

3. Place a safety washer on the front bottom of the door bracket and fasten it with a fastener.

4. Repeat steps 1 and 2 for the door bracket on the opposite side.

5. Pull the top hinge pin down on the door.

6. Align the door hinges with the bracket hinges.

7. Slide the bottom hinge pin into the bracket hinge and move the top hinge pin in the upward direction.

8. Connect the other end of the ground strap cable to a grounding point on the door bracket using a fastener.

DETAILED STEPS

Step 1 Align the left door bracket screw holes against the shelf screw holes.

Step 2 Insert the fasteners provided along with the packaging (three screws on the side and two screws on the bottom of the

door bracket) and tighten them to a torque value of 11.5 in-lb (1.3 N-m).

Step 3 Place a safety washer on the front bottom of the door bracket and fasten it with a fastener.

Step 4 Repeat steps 1 and 2 for the door bracket on the opposite side.

Step 5 Pull the top hinge pin down on the door.

The bottom hinge pin is

fixed.

Note

Step 6 Align the door hinges with the bracket hinges.

Step 7 Slide the bottom hinge pin into the bracket hinge and move the top hinge pin in the upward direction.

The ground strap cable is pre-installed on the

door.

Note

Step 8 Connect the other end of the ground strap cable to a grounding point on the door bracket using a fastener.

Opening and Removing the Door of the NCS 4216 Shelf

This procedure opens and removes the door of the NCS 4216 shelf.

The NCS 4216 shelf has an ESD plug input and is shipped with an ESD wrist strap. The ESD plug input

is located on the outside of the shelf on the right side. It is labeled “ESD”on the top and bottom. Always

wear an ESD wrist strap and connect the strap to the ESD plug when working on the NCS shelf.

Note

To open and remove the door of the NCS 4216 router, follow the steps below:

Cisco NCS 4216 Hardware Installation Guide

Installing the Cisco NCS 4216

Installing the Cisco NCS 4216 Door
