CHAPTER

2-1

Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0

78-18663-01

Alarm Troubleshooting

Note The terms "Unidirectional Path Switched Ring" and "UPSR" may appear in Cisco literature. These terms

do not refer to using Cisco ONS 15xxx products in a unidirectional path switched ring configuration.

Rather, these terms, as well as "Path Protected Mesh Network" and "PPMN," refer generally to Cisco's

path protection feature, which may be used in any topological network configuration. Cisco does not

recommend using its path protection feature in any particular topological network configuration.

This chapter gives a description, severity, and troubleshooting procedure for each commonly

encountered Cisco ONS 15310-MA SDH alarm and condition. Tables 2-1 through 2-5 list the alarms of

both platforms, organized by severity. Table 2-6 on page 2-6 provides a list of alarms organized

alphabetically. Table 2-7 gives definitions of all ONS 15310-MA SDH alarm logical objects, which are

the basis of the alarm profile list in Table 2-8 on page 2-11. For a comprehensive list of all conditions,

refer to the Cisco SDH TL1 Command Guide. For further information about Transaction Language One

(TL1), refer to the Cisco ONS SDH TL1 Reference Guide.

An alarm’s troubleshooting procedure applies to both the Cisco Transport Controller (CTC) and the TL1

version of that alarm. If the troubleshooting procedure does not clear the alarm, log into the Technical

Support Website at http://www.cisco.com/cisco/web/support/index.html for more information or call the

Cisco Technical Assistance Center (1-800-553-2447).

More information about alarm profile information modification and downloads is located in the “Manage

Alarms” chapter in the Cisco ONS15310-MA SDH Procedure Guide.

2.1 Alarm Index by Default Severity

The following tables group alarms and conditions by their default severities in the ONS 15310-MA SDH

systems. These severities are the same whether they are reported in the CTC Alarms window severity

(SEV) column or in TL1.

Note The CTC default alarm profile contains some alarms or conditions that are not currently implemented

but are reserved for future use.

2-2

Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0

78-18663-01

Chapter 2 Alarm Troubleshooting

Alarm Index by Default Severity

Note The CTC default alarm profile in some cases contains two severities for one alarm (for example,

Major/Minor [MJ/MN]). The default severity comes first (in this example, MJ), but the alarm can be

demoted to the second severity in the presence of a higher-ranking alarm. This is in accordance with

Telcordia GR-474-CORE.

2.1.1 Critical Alarms (CR)

Table 2-1 alphabetically lists ONS 15310-MA SDH Critical (CR) alarms.

2.1.2 Major Alarms (MJ)

Table 2-2 alphabetically lists ONS 15310-MA SDH Major (MJ) alarms.

Table 2-1 ONS 15310-MA SDH Critical Alarm List

AUTOLSROFF (STM) LINK-KEEPALIVE (ML100T) MEA (PPM)

BKUPMEMP (EQPT) LOA (VCG) MFGMEM (BPLANE)

COMIOXC (EQPT) LOF (DS3) MFGMEM (FAN)

CONTBUS-DISABLED (EQPT) LOF (E3) MFGMEM (PPM)

CTNEQPT-PBPROT (EQPT) LOF (STM) LP-PLM (VCMON-HP)

CTNEQPT-PBWORK (EQPT) LOF (VCTRM-HP) LP-PLM (VCTRM-HP)

ENCAP-MISMATCH-P (VCTRM-HP) LOM (VCMON-HP) SQM (VCTRM-HP)

EQPT (EQPT) LOM (VCTRM-HP) SWMTXMOD-PROT (EQPT)

EQPT (PPM) AU-LOP (VCMON-HP) SWMTXMOD-WORK (EQPT)

EQPT-MISS (FAN) AU-LOP (VCTRM-HP) TIM (STM)

FAN (FAN) LOS (DS3) HP-TIM (VCTRM-HP)

HITEMP (NE) LOS (E3) RS-TIM (E3)

I-HITEMP (NE) LOS (STM) RS-TIM (STM)

IMPROPRMVL (EQPT) MEA (EQPT) HP-UNEQ (VCMON-HP)

IMPROPRMVL (PPM) MEA (FAN) HP-UNEQ (VCTRM-HP)

Table 2-2 ONS 15310-MA SDH Major Alarm List

APSCNMIS (STM) GFP-CSF (ML100T) HP-PLM (VCMON-LP)

BAT-FAIL (PWR) GFP-LFD (CE100T) HP-PLM (VCTRM-LP)

BLSROSYNC (STM) GFP-LFD (CEMR) PRC-DUPID (STM)

CARLOSS (CE100T) GFP-LFD (ML100T) SHELF-COMM-FAIL (SHELF)

CARLOSS (CEMR) GFP-UP-MISMATCH (CE100T) SQM (VCTRM-LP)

CARLOSS (EQPT) GFP-UP-MISMATCH (CEMR) SYNCPRI (NE-SREF)

CARLOSS (ML100T) GFP-UP-MISMATCH (ML100T) SYSBOOT (NE)

DATA-CRC (CE100T) INVMACADR (BPLANE) LP-TIM (VCMON-LP)

2-3

Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0

78-18663-01

Chapter 2 Alarm Troubleshooting

Alarm Index by Default Severity

2.1.3 Minor Alarms (MN)

Table 2-3 alphabetically lists ONS 15310-MA SDH Minor (MN) alarms.

2.1.4 Not Alarmed Conditions

Table 2-4 alphabetically lists ONS 15310-MA SDH Not Alarmed (NA) conditions.

DATA-CRC (ML100T) LOF (E1) LP-TIM (VCTRM-LP)

DUP-SHELF-ID (SHELF) LOM (VCTRM-LP) TPTFAIL (CE100T)

EHIBATVG (PWR) TU-LOP (VCMON-LP) TPTFAIL (CEMR)

ELWBATVG (PWR) TU-LOP (VCTRM-LP) TPTFAIL (ML100T)

FANDEGRADE (FAN) LOS (E1) LP-UNEQ (VCMON-LP)

GFP-CSF (CE100T) MEA (SHELF) LP-UNEQ (VCTRM-LP)

GFP-CSF (CEMR) MEM-GONE (EQPT) —

Table 2-2 ONS 15310-MA SDH Major Alarm List (continued)

Table 2-3 ONS 15310-MA SDH Minor Alarm List

APSB (STM) HELLO (STM) LO-TXPOWER (PPM)

APSCDFLTK (STM) HI-LASERBIAS (STM) MATECLK (EQPT)

APSCINCON (STM) HI-LASERBIAS (PPM) MEM-LOW (EQPT)

APSCM (STM) HI-LASERTEMP (STM) PROTNA (EQPT)

APSIMP (STM) HI-LASERTEMP (PPM) PROV-MISMATCH (PPM)

AUTORESET (EQPT) HI-RXPOWER (STM) PWR-FAIL-A (EQPT)

CONTBUS-CLK-A (EQPT) HITEMP (EQPT) PWR-FAIL-B (EQPT)

CONTBUS-CLK-B (EQPT) HI-TXPOWER (STM) ROUTE-OVERFLOW (NSA)

CONTBUS-IO-A (EQPT) HI-TXPOWER (PPM) SFTWDOWN (EQPT)

CONTBUS-IO-B (EQPT) ISIS-ADJ-FAIL (STM) SNTP-HOST (NE)

DATAFLT (NE) LASEREOL (STM) SSM-FAIL (BITS)

DUP-IPADDR (NE) LOF (BITS) SSM-FAIL (E1)

DUP-NODENAME (NE) LO-LASERBIAS (STM) SSM-FAIL (STM)

EOC (STM) LO-LASERBIAS (PPM) SYNCPRI (EXT-SREF)

MS-EOC (STM) LO-LASERTEMP (STM) SYNCSEC (EXT-SREF)

ERROR-CONFIG (EQPT) LO-LASERTEMP (PPM) SYNCSEC (NE-SREF)

EXCCOL (EQPT) LO-RXPOWER (STM) SYNCTHIRD (EXT-SREF)

EXT (ENVALRM) LOS (BITS) SYNCTHIRD (NE-SREF)

FEPRLF (STM) LOS (FUDC) HP-TIM (VCMON-HP)

FP-LINK-LOSS (EQPT) LO-TXPOWER (STM) —

2-4

Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0

78-18663-01

Chapter 2 Alarm Troubleshooting

Alarm Index by Default Severity

Table 2-4 ONS 15310-MA SDH NA Conditions List

ALS (STM) IDLE (E1) SD (DS3)

APC-END (NE) INTRUSION-PSWD (NE) SD-L (E3)

AS-CMD (BPLANE) IOSCFGCOPY (EQPT) SD-L (STM)

AS-CMD (CE100T) KB-PASSTHR (STM) HP-DEG (VCMON-HP)

AS-CMD (CEMR) LCAS-CRC (VCTRM-HP) SSM-DUS (BITS)

AS-CMD (E1) LCAS-CRC (VCTRM-LP) SSM-DUS (E1)

AS-CMD (DS3) LCAS-RX-DNU (VCTRM-HP) SSM-DUS (STM)

AS-CMD (E3) LCAS-RX-DNU (VCTRM-LP) SSM-LNC (BITS)

AS-CMD (EQPT) LCAS-RX-FAIL (VCTRM-HP) SSM-LNC (NE-SREF)

AS-CMD (ML100T) LCAS-RX-FAIL (VCTRM-LP) SSM-LNC (STM)

AS-CMD (NE) LCAS-RX-GRP-ERR (VCTRM-HP) SSM-OFF (BITS)

AS-CMD (STM) LCAS-RX-GRP-ERR (VCTRM-LP) SSM-OFF (E1)

AS-CMD (PPM) LCAS-TX-ADD (VCTRM-HP) SSM-OFF (STM)

AS-CMD (PWR) LCAS-TX-ADD (VCTRM-LP) SSM-PRC (BITS)

AS-CMD (SHELF) LCAS-TX-DNU (VCTRM-HP) SSM-PRC (NE-SREF)

AS-MT (CE100T) LCAS-TX-DNU (VCTRM-LP) SSM-PRC (STM)

AS-MT (CEMR) LKOUTPR-S (STM) SSM-PRC (BITS)

AS-MT (E1) LOCKOUT-REQ (STM) SSM-PRC (E1)

AS-MT (DS3) LOCKOUT-REQ (VCMON-HP) SSM-PRC (NE-SREF)

AS-MT (E3) LOCKOUT-REQ (VCMON-LP) SSM-PRC (STM)

AS-MT (EQPT) LPBKCRS (VCMON-HP) SSM-RES (BITS)

AS-MT (ML100T) LPBKCRS (VCTRM-HP) SSM-RES (E1)

AS-MT (STM) LPBKDS1FE-CMD (E1) SSM-RES (NE-SREF)

AS-MT (PPM) LPBKDS3FEAC (DS3) SSM-RES (STM)

AS-MT (SHELF) LPBKDS3FEAC-CMD (DS3) SSM-SDH-TN (BITS)

AS-MT-OOG (VCTRM-HP) LPBKFACILITY (CE100T) SSM-SDH-TN (NE-SREF)

AS-MT-OOG (VCTRM-LP) LPBKFACILITY (CEMR) SSM-SDH-TN (STM)

AUD-LOG-LOSS (NE) LPBKFACILITY (E1) SSM-SETS (BITS)

AUD-LOG-LOW (NE) LPBKFACILITY (DS3) SSM-SETS (NE-SREF)

AUTOSW-LOP-SNCP (VCMON-HP) LPBKFACILITY (E3) SSM-SETS (STM)

AUTOSW-LOP-SNCP (VCMON-LP) LPBKFACILITY (STM) SSM-TNC (BITS)

AUTOSW-SDBER-SNCP (VCMON-HP) LPBKTERMINAL (CE100T) SSM-TNC (NE-SREF)

AUTOSW-SDBER-SNCP (VCMON-LP) LPBKTERMINAL (CEMR) SSM-TNC (STM)

AUTOSW-SFBER-SNCP (VCMON-HP) LPBKTERMINAL (E1) SW-MISMATCH (EQPT)

AUTOSW-SFBER-SNCP (VCMON-LP) LPBKTERMINAL (DS3) HP-DEG (VCTRM-HP)

AUTOSW-UNEQ-SNCP (VCMON-HP) INC-ISD (DS3) LP-DEG (VCMON-LP)

AUTOSW-UNEQ-SNCP (VCMON-LP) INHSWPR (EQPT) LP-DEG (VCTRM-LP)

2-5

Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0

78-18663-01

Chapter 2 Alarm Troubleshooting

Alarm Index by Default Severity

2.1.5 Not Reported (NR) Conditions

Table 2-2 alphabetically lists ONS 15310-MA SDH Major (MJ) alarms.

CLDRESTART (EQPT) INHSWWKG (EQPT) SF (E1)

DS3-MISM (DS3) LPBKTERMINAL (E3) SF (DS3)

ETH-LINKLOSS (NE) LPBKTERMINAL (STM) MS-EXC (E3)

FAILTOSW (STM) MAN-REQ (VCMON-HP) MS-EXC (STM)

FAILTOSW-HO (VCMON-HP) MAN-REQ (VCMON-LP) HP-EXC (VCMON-HP)

FAILTOSW-LO (VCMON-LP) MANRESET (EQPT) HP-EXC (VCTRM-HP)

FE-AIS (DS3) MANSWTOINT (NE-SREF) LP-EXC (VCMON-LP)

FE-DS3-NSA (DS3) MANSWTOPRI (EXT-SREF) LP-EXC (VCTRM-LP)

FE-DS3-SA (DS3) MANSWTOPRI (NE-SREF) SWTOPRI (EXT-SREF)

FE-EQPT-NSA (DS3) MANSWTOSEC (EXT-SREF) SWTOPRI (NE-SREF)

FE-FRCDWKSWBK-SPAN (STM) MANSWTOSEC (NE-SREF) SWTOSEC (EXT-SREF)

FE-FRCDWKSWPR-SPAN (STM) MANSWTOTHIRD (EXT-SREF) SWTOSEC (NE-SREF)

FE-IDLE (DS3) MANSWTOTHIRD (NE-SREF) SWTOTHIRD (EXT-SREF)

FE-LOCKOUTOFPR-SPAN (STM) MANUAL-REQ-SPAN (STM) SWTOTHIRD (NE-SREF)

FE-LOF (DS3) NO-CONFIG (EQPT) SYNC-FREQ (BITS)

FE-LOS (DS3) OOU-TPT (VCTRM-HP) SYNC-FREQ (E1)

FE-MANWKSWBK-SPAN (STM) OOU-TPT (VCTRM-LP) SYNC-FREQ (STM)

FE-MANWKSWPR-SPAN (STM) OPEN-SLOT (EQPT) TX-IDLE (E1)

FORCED-REQ (VCMON-HP) PORT-MISMATCH (CEMR) TX-RAI (E1)

FORCED-REQ (VCMON-LP) RAI (E1) TX-RAI (DS3)

FORCED-REQ-SPAN (STM) RAI (DS3) VCG-DEG (VCG)

FRCDSWTOINT (NE-SREF) ROLL (VCMON-HP) VCG-DOWN (VCG)

FRCDSWTOPRI (EXT-SREF) ROLL (VCTRM-HP) WKSWPR (EQPT)

FRCDSWTOPRI (NE-SREF) ROLL (VCMON-LP) WKSWPR (STM)

FRCDSWTOSEC (EXT-SREF) ROLL (VCTRM-LP) WKSWPR (VCMON-HP)

FRCDSWTOSEC (NE-SREF) ROLL-PEND (VCMON-HP) WKSWPR (VCMON-LP)

FRCDSWTOTHIRD (EXT-SREF) ROLL-PEND (VCMON-LP) WTR (EQPT)

FRCDSWTOTHIRD (NE-SREF) ROLL-PEND (VCTRM-LP) WTR (STM)

FRNGSYNC (NE-SREF) RPR-PASSTHR (RPRIF) WTR (VCMON-HP)

FSTSYNC (NE-SREF) RPRW (ML100T) WTR (VCMON-LP)

FULLPASSTHR-BI (STM) RUNCFG-SAVENEED (EQPT) —

HLDOVRSYNC (NE-SREF) SD (E1) —

Table 2-4 ONS 15310-MA SDH NA Conditions List (continued)

2-6

Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0

78-18663-01

Chapter 2 Alarm Troubleshooting

Alarms and Conditions Indexed By Alphabetical Entry

2.2 Alarms and Conditions Indexed By Alphabetical Entry

Table 2-6 alphabetically lists all ONS 15310-MA SDH alarms and conditions.

Table 2-5 ONS 15310-MA SDH Major Alarm List

AIS (BITS) TU-AIS (VCMON-LP) HP-RFI (VCTRM-HP)

AIS (E1) TU-AIS (VCTRM-LP) LP-RFI (VCMON-LP)

AIS (DS3) AUTOSW-AIS-SNCP(VCMON-HP) LP-RFI (VCTRM-LP)

AIS (FUDC) AUTOSW-AIS-SNCP(VCMON-LP) ROLL-PEND (VCTRM-HP)

MS-AIS (E3) NON-CISCO-PPM (PPM) TX-AIS (E1)

MS-AIS (STM) MS-RFI (E3) TX-AIS (DS3)

AU-AIS (VCMON-HP) MS-RFI (STM) TX-LOF (E1)

AU-AIS (VCTRM-HP) HP-RFI (VCMON-HP) UNQUAL-PPM (PPM)

Table 2-6 ONS 15310-MA SDH Alarm and Condition Alphabetical List

AIS (BITS) FULLPASSTHR-BI (STM) PROV-MISMATCH (PPM)

AIS (E1) GFP-CSF (CE100T) PWR-FAIL-A (EQPT)

AIS (DS3) GFP-CSF (CEMR) PWR-FAIL-B (EQPT)

AIS (FUDC) GFP-CSF (ML100T) RAI (E1)

MS-AIS (E3) GFP-LFD (CE100T) ROLL (VCTRM-HP)

MS-AIS (STM) GFP-LFD (ML100T) ROLL (VCMON-LP)

AU-AIS (VCMON-HP) GFP-UP-MISMATCH (CE100T) ROLL (VCTRM-LP)

AU-AIS (VCTRM-HP) GFP-UP-MISMATCH (CEMR) ROLL-PEND (VCMON-HP)

TU-AIS (VCMON-LP) GFP-UP-MISMATCH (ML100T) ROLL-PEND (VCTRM-HP)

TU-AIS (VCTRM-LP) HELLO (STM) ROLL-PEND (VCTRM-LP)

ALS (STM) HI-LASERBIAS (STM) RPR-PASSTHR (RPRIF)

APC-END (NE) HI-LASERBIAS (PPM) RPRW (ML100T)

APSB (STM) HI-LASERTEMP (STM) RUNCFG-SAVENEED (EQPT)

APSCDFLTK (STM) HI-LASERTEMP (PPM) SD (E1)

APSCINCON (STM) HI-RXPOWER (STM) SD (DS3)

APSCM (STM) HITEMP (EQPT) SD-L (E3)

APSCNMIS (STM) HITEMP (NE) SD-L (STM)

APSIMP (STM) HI-TXPOWER (STM) HP-DEG (VCMON-HP)

AS-CMD (BPLANE) HI-TXPOWER (PPM) HP-DEG (VCTRM-HP)

AS-CMD (CE100T) HLDOVRSYNC (NE-SREF) LP-DEG (VCMON-LP)

AS-CMD (CEMR) IDLE (E1) LP-DEG (VCTRM-LP)

AS-CMD (E1) I-HITEMP (NE) SF (E1)

AS-CMD (DS3) IMPROPRMVL (EQPT) SF (DS3)

2-7

Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0

78-18663-01

Chapter 2 Alarm Troubleshooting

Alarms and Conditions Indexed By Alphabetical Entry

AS-CMD (E3) IMPROPRMVL (PPM) MS-EXC (E3)

AS-CMD (EQPT) INC-ISD (DS3) MS-EXC (STM)

AS-CMD (ML100T) INHSWPR (EQPT) HP-EXC (VCMON-HP)

AS-CMD (NE) INHSWWKG (EQPT) HP-EXC (VCTRM-HP)

AS-CMD (STM) INTRUSION-PSWD (NE) SFTWDOWN (EQPT)

AS-CMD (PPM) INVMACADR (BPLANE) LP-EXC (VCMON-LP)

AS-CMD (PWR) IOSCFGCOPY (EQPT) LP-EXC (VCTRM-LP)

AS-CMD (SHELF) ISIS-ADJ-FAIL (STM) SHELF-COMM-FAIL (SHELF)

AS-MT (CE100T) KB-PASSTHR (STM) SNTP-HOST (NE)

AS-MT (CEMR) LASEREOL (STM) SQM (VCTRM-HP)

AS-MT (E1) LCAS-CRC (VCTRM-HP) SQM (VCTRM-LP)

AS-MT (DS3) LCAS-CRC (VCTRM-LP) SSM-DUS (BITS)

AS-MT (E3) LCAS-RX-DNU (VCTRM-HP) SSM-DUS (E1)

AS-MT (EQPT) LCAS-RX-DNU (VCTRM-LP) SSM-DUS (STM)

AS-MT (ML100T) LCAS-RX-FAIL (VCTRM-HP) SSM-FAIL (BITS)

GFP-LFD (CEMR) LCAS-RX-FAIL (VCTRM-LP) SSM-FAIL (E1)

AS-MT (STM) LCAS-RX-GRP-ERR (VCTRM-HP) SSM-FAIL (STM)

AS-MT (PPM) LCAS-RX-GRP-ERR (VCTRM-LP) SSM-LNC (BITS)

AS-MT (SHELF) ROLL-PEND (VCMON-LP) SSM-LNC (NE-SREF)

AS-MT-OOG (VCTRM-HP) LCAS-TX-ADD (VCTRM-HP) SSM-LNC (STM)

AS-MT-OOG (VCTRM-LP) LCAS-TX-ADD (VCTRM-LP) SSM-OFF (BITS)

AUD-LOG-LOSS (NE) LCAS-TX-DNU (VCTRM-HP) SSM-OFF (E1)

AUD-LOG-LOW (NE) LCAS-TX-DNU (VCTRM-LP) SSM-OFF (STM)

AUTOLSROFF (STM) LINK-KEEPALIVE (ML100T) SSM-PRC (BITS)

AUTORESET (EQPT) LKOUTPR-S (STM) SSM-PRC (NE-SREF)

AUTOSW-AIS-SNCP (VCMON-HP) LOA (VCG) SSM-PRC (STM)

AUTOSW-AIS-SNCP (VCMON-LP) LOCKOUT-REQ (STM) SSM-PRC (BITS)

AUTOSW-LOP-SNCP (VCMON-HP) LOCKOUT-REQ (VCMON-HP) SSM-PRC (E1)

AUTOSW-LOP-SNCP (VCMON-LP) LOCKOUT-REQ (VCMON-LP) SSM-PRC (NE-SREF)

AUTOSW-SDBER-SNCP (VCMON-HP) LOF (BITS) SSM-PRC (STM)

AUTOSW-SDBER-SNCP (VCMON-LP) LOF (E1) SSM-RES (BITS)

AUTOSW-SFBER-SNCP (VCMON-HP) LOF (DS3) SSM-RES (E1)

AUTOSW-SFBER-SNCP (VCMON-LP) LOF (E3) SSM-RES (NE-SREF)

AUTOSW-UNEQ-SNCP (VCMON-HP) LOF (STM) SSM-RES (STM)

AUTOSW-UNEQ-SNCP (VCMON-LP) LOF (VCTRM-HP) SSM-SDH-TN (BITS)

BAT-FAIL (PWR) LO-LASERBIAS (STM) SSM-SDH-TN (NE-SREF)

BKUPMEMP (EQPT) LO-LASERBIAS (PPM) SSM-SDH-TN (STM)

Table 2-6 ONS 15310-MA SDH Alarm and Condition Alphabetical List (continued)

2-8

Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0

78-18663-01

Chapter 2 Alarm Troubleshooting

Alarms and Conditions Indexed By Alphabetical Entry

BLSROSYNC (STM) LO-LASERTEMP (STM) SSM-SETS (BITS)

CARLOSS (CE100T) LO-LASERTEMP (PPM) SSM-SETS (NE-SREF)

CARLOSS (CEMR) LOM (VCMON-HP) SSM-SETS (STM)

CARLOSS (EQPT) LOM (VCTRM-HP) SSM-TNC (BITS)

CARLOSS (ML100T) LOM (VCTRM-LP) SSM-TNC (NE-SREF)

CLDRESTART (EQPT) AU-LOP (VCMON-HP) SSM-TNC (STM)

COMIOXC (EQPT) AU-LOP (VCTRM-HP) SW-MISMATCH (EQPT)

CONTBUS-CLK-A (EQPT) TU-LOP (VCMON-LP) SWMTXMOD-PROT (EQPT)

CONTBUS-CLK-B (EQPT) TU-LOP (VCTRM-LP) SWMTXMOD-WORK (EQPT)

CONTBUS-DISABLED (EQPT) LO-RXPOWER (STM) SWTOPRI (EXT-SREF)

CONTBUS-IO-A (EQPT) LOS (BITS) SWTOPRI (NE-SREF)

CONTBUS-IO-B (EQPT) LOS (E1) SWTOSEC (EXT-SREF)

CTNEQPT-PBPROT (EQPT) LOS (DS3) SWTOSEC (NE-SREF)

CTNEQPT-PBWORK (EQPT) LOS (E3) SWTOTHIRD (EXT-SREF)

DATA-CRC (CE100T) LOS (FUDC) SWTOTHIRD (NE-SREF)

DATA-CRC (ML100T) LOS (STM) SYNC-FREQ (BITS)

DATAFLT (NE) LO-TXPOWER (STM) SYNC-FREQ (E1)

DS3-MISM (DS3) LO-TXPOWER (PPM) SYNC-FREQ (STM)

DUP-IPADDR (NE) LPBKCRS (VCMON-HP) SYNCPRI (EXT-SREF)

DUP-NODENAME (NE) LPBKCRS (VCTRM-HP) SYNCPRI (NE-SREF)

DUP-SHELF-ID (SHELF) LPBKDS1FE-CMD (E1) SYNCSEC (EXT-SREF)

EHIBATVG (PWR) LPBKDS3FEAC (DS3) SYNCSEC (NE-SREF)

ELWBATVG (PWR) LPBKDS3FEAC-CMD (DS3) SYNCTHIRD (EXT-SREF)

ENCAP-MISMATCH-P (VCTRM-HP) LPBKFACILITY (CE100T) SYNCTHIRD (NE-SREF)

EOC (STM) LPBKFACILITY (CEMR) SYSBOOT (NE)

MS-EOC (STM) LPBKFACILITY (E1) TIM (STM)

EQPT (EQPT) LPBKFACILITY (DS3) HP-TIM (VCMON-HP)

EQPT (PPM) LPBKFACILITY (E3) HP-TIM (VCTRM-HP)

EQPT-MISS (FAN) LPBKFACILITY (STM) RS-TIM (E3)

ERROR-CONFIG (EQPT) LPBKTERMINAL (CE100T) RS-TIM (STM)

ETH-LINKLOSS (NE) LPBKTERMINAL (CEMR) LP-TIM (VCMON-LP)

EXCCOL (EQPT) LPBKTERMINAL (E1) LP-TIM (VCTRM-LP)

EXT (ENVALRM) LPBKTERMINAL (DS3) TPTFAIL (CE100T)

FAILTOSW (STM) MAN-REQ (VCMON-HP) RAI (DS3)

FAILTOSW-HO (VCMON-HP) MAN-REQ (VCMON-LP) MS-RFI (E3)

FAILTOSW-LO (VCMON-LP) MANRESET (EQPT) MS-RFI (STM)

FAN (FAN) MANSWTOINT (NE-SREF) HP-RFI (VCMON-HP)

Table 2-6 ONS 15310-MA SDH Alarm and Condition Alphabetical List (continued)

2-9

Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0

78-18663-01

Chapter 2 Alarm Troubleshooting

Alarm Logical Objects

2.3 Alarm Logical Objects

The CTC alarm profile list organizes all alarms and conditions according to the logical objects they are

raised against. These logical objects represent physical objects such as cards, logical objects such as

circuits, or transport and signal monitoring entities such as the SDH overhead bits. One alarm can appear

in multiple entries. It can be raised against multiple objects. For example, the loss of signal (LOS) alarm

can be raised against the optical signal (STM-N) or the optical transport layer overhead (OTN) as well

as other objects. Therefore, both STM: LOS and OTN: LOS appear in the list (as well as the other

objects).

FANDEGRADE (FAN) MANSWTOPRI (EXT-SREF) HP-RFI (VCTRM-HP)

FE-AIS (DS3) MANSWTOPRI (NE-SREF) LP-RFI (VCMON-LP)

FE-DS3-NSA (DS3) MANSWTOSEC (EXT-SREF) LP-RFI (VCTRM-LP)

FE-DS3-SA (DS3) MANSWTOSEC (NE-SREF) ROLL (VCMON-HP)

FE-EQPT-NSA (DS3) MANSWTOTHIRD (EXT-SREF) TPTFAIL (CEMR)

FE-FRCDWKSWBK-SPAN (STM) MANSWTOTHIRD (NE-SREF) TPTFAIL (ML100T)

FE-FRCDWKSWPR-SPAN (STM) MANUAL-REQ-SPAN (STM) TX-AIS (E1)

FE-IDLE (DS3) MATECLK (EQPT) TX-AIS (DS3)

FE-LOCKOUTOFPR-SPAN (STM) MEA (EQPT) TX-IDLE (E1)

FE-LOF (DS3) MEA (FAN) TX-LOF (E1)

FE-LOS (DS3) MEA (PPM) TX-RAI (E1)

FE-MANWKSWBK-SPAN (STM) MEA (SHELF) TX-RAI (DS3)

FE-MANWKSWPR-SPAN (STM) MEM-GONE (EQPT) HP-UNEQ (VCMON-HP)

FEPRLF (STM) MEM-LOW (EQPT) HP-UNEQ (VCTRM-HP)

FORCED-REQ (VCMON-HP) MFGMEM (BPLANE) LP-UNEQ (VCMON-LP)

FORCED-REQ (VCMON-LP) MFGMEM (FAN) LP-UNEQ (VCTRM-LP)

FORCED-REQ-SPAN (STM) MFGMEM (PPM) UNQUAL-PPM (PPM)

FP-LINK-LOSS (EQPT) NO-CONFIG (EQPT) VCG-DEG (VCG)

FRCDSWTOINT (NE-SREF) NON-CISCO-PPM (PPM) VCG-DOWN (VCG)

FRCDSWTOPRI (EXT-SREF) OOU-TPT (VCTRM-HP) WKSWPR (EQPT)

FRCDSWTOPRI (NE-SREF) OOU-TPT (VCTRM-LP) WKSWPR (STM)

FRCDSWTOSEC (EXT-SREF) OPEN-SLOT (EQPT) WKSWPR (VCMON-HP)

FRCDSWTOSEC (NE-SREF) LP-PLM (VCMON-HP) WKSWPR (VCMON-LP)

FRCDSWTOTHIRD (EXT-SREF) LP-PLM (VCTRM-HP) WTR (EQPT)

FRCDSWTOTHIRD (NE-SREF) HP-PLM (VCMON-LP) WTR (STM)

FRNGSYNC (NE-SREF) HP-PLM (VCTRM-LP) WTR (VCMON-HP)

FSTSYNC (NE-SREF) PORT-MISMATCH (CEMR) WTR (VCMON-LP)

LPBKTERMINAL (E3) PRC-DUPID (STM) —

LPBKTERMINAL (STM) PROTNA (EQPT) —

Table 2-6 ONS 15310-MA SDH Alarm and Condition Alphabetical List (continued)

2-10

Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0

78-18663-01

Chapter 2 Alarm Troubleshooting

Alarm Logical Objects

Alarm profile list objects are defined in Table 2-7.

Note Alarm logical object names can appear as abbreviated versions of standard terms used in the system and

the documentation. For example, the “STM” logical object refers to the STM-N signal. Logical object

names or industry-standard terms are used within the entries as appropriate.

Table 2-7 Alarm Logical Object Type Definitions

Type Definition

BITS Building integrated timing supply (BITS) incoming references (BITS-1, BITS-2).

BPLANE The backplane.

CE100T The CE-100T-8 Ethernet card.

CEMR The CE-MR-6 Ethernet card.

E1 A E1 port on the 15310-MA SDH CTX, E1-21/DS3-E3-3, or E1-63/DS3-E3-3

card.

DS3 A DS-3 port on the 15310-MA SDH CTX, E1-21/DS3-E3-3, or E1-63/DS3-E3-3

card.

E3 A E3 port on the 15310-MA SDH CTX, E1-21/DS3-E3-3, or E1-63/DS3-E3-3

card.

ENVALRM An environmental alarm port.

EQPT A card, its physical objects, and logical objects as they are located in any of the

noncommon card slots. The EQPT object is used for alarms that refer to the

card itself and all other objects on the card including ports, lines, and VC (virtual

container).

EXT-SREF BITS outgoing references (SYNC-BITS1, SYNC-BITS2).

FAN Fan located in the ONS 15310-MA SDH shelf.

FUDC SDH F1 byte user data channel for an ONS 15310-MA SDH ML-100T-8 Ethernet

card.

ML100T The ML-100T-8 Ethernet card.

NE The entire network element.

NE-SREF The timing status of the NE.

STM An STM1 port or STM1, STM4 and STM16 port on the ONS 15310-MA SDH.

PPM Pluggable port module (PPM, also called SFP).

RPRIF Interface for Resilient Packet Ring technology as defined in IEEE 802.17b. Also

called RPR-IEEE.

PWR The node power supply.

SHELF The ONS 15310-MA SDH shelf.

VCMON-HP VC alarm detection at the monitor point (upstream from the cross-connect).

Note The network element reports alarms or conditions on ingress ports of the

card. Alarms detected at the internal ports (TERM side) will be ingress

mapped to the MON side. The alarm profile entities of VCMON-HP, if

available, should be changed to the same severity as the customized

severity for a specific VCMON-HP alarm.

Tabla de contenidos

Otros manuales de Hardware de red de Cisco

Cisco

Cisco CSS11501 - 100Mbps Ethernet Load Balancing... Manual de usuario

Cisco

Cisco ONS 15454 Manual de instrucciones

Cisco

Cisco CPS-MSP-1RU-K9 Manual de usuario

Cisco

Cisco NCS 6008 LCC Manual de instrucciones

Cisco

Cisco ASR 5000 Series Manual de usuario

Cisco

Cisco IPS-4260-K9 - IPS Sensor 4260 Manual de usuario

Cisco

Cisco ONS 15454 Series Manual

Cisco

Cisco Firepower 2130 Guía de mantenimiento y servicio

Cisco

Cisco NM-1FE-TX - Interface Module Ethernet Manual de usuario

Cisco

Cisco BR1400 Series Guía de referencia rápida

Cisco

Cisco 7606 Manual de usuario

Cisco

Cisco Meraki Catalyst 9300/X/L-M Series Manual de usuario

Cisco

Cisco ISA500 Series Manual de usuario

Cisco

Cisco CVPN3002-K9 - Fast Ethernet VPN Gateway Manual de usuario

Cisco

Cisco NSS4100 - Gigabit Storage System Manual de instrucciones

Cisco

Cisco SCE8000 GBE Manual de usuario

Cisco

Cisco OL-7822-06 Manual de usuario

Cisco

Cisco WAE-674-K9 - Wide Area Application Engine... Manual

Cisco

Cisco ON100 Network Agent Manual de usuario

Cisco

Cisco ASR 5000 Manual de instrucciones

Cisco

Cisco ASA Guía de inicio rápido

Cisco

Cisco CiscoWorks Wireless LAN Solution Engine Manual del operador

Cisco

Cisco Cisco ASA Series Manual de usuario

Cisco

Cisco AIM-VPN - DES/3DES VPN Data Encryption AIM... Manual de usuario

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario
