Cisco Physical Security Multiservices

Platform Series User Guide

Model CPS-MSP-1RU-K9

Model CPS-MSP-2RU-K9

Text Part Number: OL-21838-03

NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED

WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.

THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT

SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE

OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.

The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public

NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS” WITH

ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT

LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF

DEALING, USAGE, OR TRADE PRACTICE.

IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING,

WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO

OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other countries. A listing of Cisco's trademarks can be found at

www.cisco.com/go/trademarks. Third party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership

relationship between Cisco and any other company. (1005R)

Cisco Physical Security Multiservices Platform Series User Guide

iii

Cisco Physical Security Multiservices Platform Series User Guide

OL-21838-03

CONTENTS

Preface v

Overview v

Organization v

Obtaining Documentation, Obtaining Support, and Security Guidelines vi

CHAPTER

1Overview 1-1

Important Safety Information 1-1

Multiservices Platform Series Products 1-1

System Interface 1-2

Control Panel Buttons and LEDs 1-2

Hard Drive Indicator LEDs 1-3

Rear Panel 1-4

CHAPTER

2Setting Up and Maintaining the Multiservices Platform Series Device 2-1

Setting up a Multiservices Platform Series Device 2-1

Unpacking the Multiservices Platform Series Device 2-2

Mounting the Multiservices Platform Series Device in a Rack 2-2

Preparing for Rack Mounting 2-3

Rack Mounting 2-4

Installing Hard Drives 2-10

Connecting to Power, the Network, and External Devices 2-11

Multiservices Platform Series Maintenance Operations 2-11

Removing the Chassis Cover 2-11

Replacing a System Fan 2-12

Replacing a Power Supply 2-13

Checking Air Flow 2-14

APPENDIX

ASystem Specifications A-1

General Specifications A-1

Power Supply Specifications A-2

APPENDIX

BRecovering from a Hard Drive Failure B-1

Replacing a Hard Drive B-3

Contents

Cisco Physical Security Multiservices Platform Series User Guide

OL-21838-03

Reimaging a Multiservices Platform Series Device that is Running VSM B-5

Reimaging a Multiservices Platform Series Device that is Running Cisco IPICS B-6

Reimaging a Multiservices Platform Series Device that is Running Cisco PAM B-7

APPENDIX

CFiber Channel Card C-1

APPENDIX

D16 x CIF / 4 x 4CIF Video Capture Card D-1

Video Inputs D-1

Power and System Requirements D-2

APPENDIX

E16 x D1 and 8 x D1 Video Capture Cards E-1

Before You Begin E-1

Overview E-2

Requirements E-3

Features E-4

Encoding Parameter Limitations E-4

Motion Detection with Low Quality Cameras E-5

Video Card Connector and LED E-6

Understanding Video Channel Numbers E-6

1-RU Multi Services Platform Series Device Channel Numbers E-6

2-RU Multi Services Platform Series Device Channel Numbers E-8

Connecting the Video Capture Card to the BNC Breakout Panel E-10

Part Numbers E-12

Specifications E-13

Configuration Instructions for Cisco Video Surveillance E-14

Configuring Camera Channel Numbers in Cisco VSM E-14

Connecting and Configuring Analog PTZ Cameras E-14

Troubleshooting PTZ Camera Controls E-19

Related Documentation E-19

APPENDIX

FUsing IPMI to Remotely Reboot a Multi Services Platform Series Device F-1

Setting Up IPMI on Multi Services Platform Device F-1

Rebooting a Multi Services Platform Series Device by using the IPMI F-2

NDEX

Cisco Physical Security Multiservices Platform Series User Guide

OL-21838-03

Preface

Overview

This document describes how to install the Cisco Multiservices Platform Series devices and how to

perform the initial set up of these devices. It provides information for the following Multiservices

Platform Series model:

• CPS-MSP-1RU-K9—1-rack unit (RU) chassis with motherboard, 300 W power supply, and CPU.

(Drives and option cards are available separately.)

• CPS-MSP-2RU-K9—2-rack unit (RU) chassis with motherboard, 900 W power supply, and CPU.

(Drives are available separately.)

This document it is intended for experienced system integrators and technicians who are installing these

devices.

Organization

This document is organized as follows:

Chapter 1, “Overview” Provides information about the Multiservices

Platform Series features, chassis, and system

interface

Chapter 2, “Setting Up and Maintaining the

Multiservices Platform Series Device”

Describes how to perform a variety of set up and

hardware maintenance procedures for Multiservices

Platform Series devices

Appendix A, “System Specifications” Provides technical specifications for the

Multiservices Platform Series, including connection

ports, power needs and operating environment

requirements

Appendix B, “Recovering from a Hard Drive

Failure”

Describes how to replace and reimage a failed hard

disk drive

Appendix C, “Fiber Channel Card” Provides information about the optional fiber channel

card, which enables fibre channel connectivity to

external storage arrays

Cisco Physical Security Multiservices Platform Series User Guide

OL-21838-03

Preface

Obtaining Documentation, Obtaining Support, and Security

Guidelines

For information about obtaining documentation, submitting a service request, and gathering additional

information, see the monthly What’s New in Cisco Product Documentation, which also lists all new and

revised Cisco technical documentation, at:

http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html

Subscribe to the What’s New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed

and set content to be delivered directly to your desktop using a reader application. The RSS feeds are a free

service and Cisco currently supports RSS version 2.0.

Appendix D, “16 x CIF / 4 x 4CIF Video

Capture Card”

Provides information about the optional 16 x CIF / 4

x 4CIF video capture card, which enables capturing

and compressing analog video streams

Appendix E, “16 x D1 and 8 x D1 Video

Capture Cards”

Provides information about the optional 16 x D1 and

8 x D1 video capture cards, which capture and

compress standard definition analog video streams

Appendix F, “Rebooting a Multi Services

Platform Series Device by using the IPMI”

how to configure a Multiservices Platform Series

device so that it can be rebooted by using the IPMI,

and how to perform the remote reboot procedure

CHAPTER

1-1

Cisco Physical Security Multiservices Platform Series User Guide

OL-21838-03

Overview

The Cisco Multiservices Platform Series models are high-performance servers that offer choices for

deploying and managing physical security applications, including video surveillance, access control, and

flexible incident response communications. Applications include:

• Video surveillance with network digital recording and playback

• Physical access control with electronic access control using the IP network to manage doors and

locks

• Incident response systems for on-demand communications across multiple agencies

This chapter includes these sections:

• Important Safety Information, page 1-1

• Multiservices Platform Series Products, page 1-1

• System Interface, page 1-2

• Rear Panel, page 1-4

Important Safety Information

To prevent potential serious injury to yourself and others and to protect your Multiservices Platform

Series device, make sure to read and understand in the compliance, safety, statutory, and related in

formation information in Regulatory Compliance and Safety Information for the Cisco Multiservices

Platform Series before you set up, install, or operate the device.

Multiservices Platform Series Products

The Cisco Multiservices Platform Series comprises a suite of server platforms that offer choices for a

variety of Cisco physical security applications.

The Multiservices Platform Series includes the following models:

• 1-RU Multiservices Platform Series, Model CPS-MSP-1RU-K9—Supports up to four 1 TB SATA

hard drives.

• 2-RU Multiservices Platform Series, model CPS-MSP-2RU-K9—Supports six or twelve 2 TB SATA

hard drives.

1-2

Cisco Physical Security Multiservices Platform Series User Guide

OL-21838-03

Chapter 1 Overview

System Interface

Key features include:

• 300 W high-efficiency power supply on 1-RU model, and 900 W high-efficiency power supply with

redundancy option on 2-RU model

• High-performance fans with built-in redundancy for optimized cooling

• Support for fiber channel card or video encoding card (1-RU only)

• Hot-swappable SATA hard disk drives (in RAID configurations only)

System Interface

The Multiservices Platform Series device includes a variety of controls and LED indicators that help you

manage and monitor the system. The following sections describe these items in detail:

• Control Panel Buttons and LEDs, page 1-2

• Hard Drive Indicator LEDs, page 1-3

Control Panel Buttons and LEDs

Table 1-1 describes the controls and LEDs on the front panel of the Multiservices Platform Series device.

Ta b l e 1-1 Multiservices Platform Series Device Controls and LEDs

Control Description

Buttons

Reset button Press this button to reboot the Multiservices Platform Series device.

This button is recessed on 2-RU models. Use a pin or paperclip to press it on

these devices.

Power button Press this button to apply or remove power from the Multiservices Platform

Series device.

To perform a normal, graceful shutdown of the device, press and release the

button quickly. To shut down the device immediately, press and hold the button

for 4 seconds.

Turning off system power with this button removes the main power but keeps

standby power supplied to the system.

Warning

Because the device receives standby power even when it is turned

off, unplug device from its power source before servicing it.

LEDs

Power Failure LED Flashes to indicate a power failure in the power supply.

1-3

Cisco Physical Security Multiservices Platform Series User Guide

OL-21838-03

Chapter 1 Overview

System Interface

Hard Drive Indicator LEDs

The hard drive bays on the Multiservices Platform Series device include these LED indicators:

• 1-RU model:

–

Solid green—Normal drive status

–

Flashing green—Normal drive activity

–

Solid red—Drive failure

–

Flashing red—Drive rebuilding

• 2-RU model:

–

Sold blue—Normal drive status

–

Flashing blue—Normal drive activity

–

Solid red—Drive failure

Overheat/Fan Fail

LED

Flashes to indicate a fan failure. Lights continuously to indicate an overheat

condition.

An overheat condition can be caused by cables or other obstructions that

constrict the airflow in the system or by the ambient room temperature being

too warm. If this condition occurs, check the routing of the cables, make sure

that all fans are installed and operating normally, make sure that the chassis

covers are installed, and verify that the heat sinks are installed properly. For

related information, see the “Checking Air Flow” section on page 2-14.

NIC 1 LED Flashes to indicate network activity on network interface card (NIC) 1.

NIC 2 LED Flashes to indicate network activity on network interface card (NIC) 2.

HDD LED Lights to indicate hard disk drive activity.

Power LED Lights when the Multiservices Platform Series device power supply receives

power.

This LED should be lit during normal system operation.

Table 1-1 Multiservices Platform Series Device Controls and LEDs (continued)

Control Description

1-4

Cisco Physical Security Multiservices Platform Series User Guide

OL-21838-03

Chapter 1 Overview

Rear Panel

–

Flashing red—Drive rebuilding

Rear Panel

Figure 1-1 illustrates the rear panel of the Multiservices Platform Series 1-RU model.

Figure 1-1 Multiservices Platform Series 1-RU Model Rear Panel

Figure 1-2 illustrates the rear panel of the Multiservices Platform Series 2-RU model

Figure 1-2 Multiservices Platform Series 2-RU Model Rear Panel

1Power cord connector port. 5VGA (video) monitor port.

2Mouse port. 6Serial port.

3Diagnostic port, for Cisco TAC use. 7USB ports.

4RJ-45 Ports for network connection. The port

on the left is the first network port and the port

on the right is the second.

8Keyboard port.

277891

1 2

8 56

198718

1 3 4

678

1Power cord connector port. 6VGA (video) monitor port.

2(Optional) Power cord connector port on

redundant power supply.

7Serial port.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Hardware de red de Cisco

Cisco

Cisco ASA 5506-X Manual

Cisco

Cisco Aironet 340 Series Manual de usuario

Cisco

Cisco 5400 Manual de usuario

Cisco

Cisco UCS-FI-6332-16UP Manual de usuario

Cisco

Cisco RSP4+ Bootflash Memory Upgrade to 16MB... Manual del operador

Cisco

Cisco 1230AG - Aironet - Wireless Access Point Manual de usuario

Cisco

Cisco NCS 1010 Hoja de instrucciones

Cisco

Cisco Cisco ONS 15600 SDH Manual de usuario

Cisco

Cisco Firepower 4100 Series Manual de usuario

Cisco

Cisco Rack-Mount and Cable Mgmt. 7505/7010 Manual de usuario

Cisco

Cisco C7200-I - Input/Output Controller - Control... Manual de usuario

Cisco

Cisco Linksys Business Series Network Storage System... Manual de usuario

Cisco

Cisco ASR 5500 Manual de instrucciones

Cisco

Cisco Firepower 9300 Manual

Cisco

Cisco Firepower 9300 Guía de mantenimiento y servicio

Cisco

Cisco WS-CE500 - Catalyst Express 500-24PC Manual de instrucciones

Cisco

Cisco Meraki MX65W Manual de usuario

Cisco

Cisco VPN 3002 Hardware Client Manager Manual de usuario

Cisco

Cisco ONS 15454 M12 Manual de usuario

Cisco

Cisco IDS 4210 - Intrusion Detection Sys 4210... Manual de usuario

Cisco

Cisco Octal-Port DMT ATU-C Line Card Manual técnico

Cisco

Cisco ONS 15540 ESP Manual

Cisco

Cisco NCS 1002 Actualización de firmware

Cisco

Cisco Catalyst 8300 Series Manual

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario
