Cisco CompactFlash Adapter for Bootflash

Upgrade Installation Note

Product Numbers: WS-CF-UPG=, CF-ADAPTER=, WS-CF-UPG-1GB=

This publication describes how to replace the switch processor (SP) bootflash memory module (DIMM)

with CompactFlash on the Supervisor Engine 720. The WS-CF-UPG= and the CF-ADAPTER= support

a 512 MB CompactFlash card; the WS-CF-UPG-1GB= supports a 1 GB CompactFlash card.

Contents

This publication consists of these sections:

•Safety Overview, page 2

•Installing the SP Bootflash Memory Upgrade Kit, page 8

•Removing and Installing the CompactFlash in the CompactFlash Adapter, page 22

•Attaching Your ESD Grounding Strap, page 24

•Module Handling Guidelines, page 26

•Safety Warning Translations, page 27

•Obtaining Documentation and Submitting a Service Request, page 33

Note For translations of the warnings in this publication, see the “Safety Warning Translations” section on

page 27.

The CompactFlash adapter (see Figure 1) is a device that plugs into the SP bootflash DIMM socket on

the Supervisor Engine 720. This device expands the amount of bootflash memory that is available. The

kits contain a CompactFlash adapter with the CompactFlash installed. The CompactFlash adapter

contains a Cisco IOS image (12.2(18)SXE5 or greater). See your Cisco IOS release notes for the exact

release information.

Note The CompactFlash adapter is not supported in systems that run the Catalyst operating system.

Cisco CompactFlash Adapter for Bootflash Upgrade Installation Note

78-17277-05

Safety Overview

This upgrade is applicable only for the SP bootflash; it is independent from the SP DRAM.

Figure 1 CompactFlash Adapter

Safety Overview

Safety warnings appear throughout this publication in procedures that may harm you if performed

incorrectly. A warning symbol precedes each warning statement.

Statement 1071—Warning Definition

Cisco Systems

144401

Warning

IMPORTANT SAFETY INSTRUCTIONS

This warning symbol means danger. You are in a situation that could cause bodily injury. Before you

work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar

with standard practices for preventing accidents. Use the statement number provided at the end of

each warning to locate its translation in the translated safety warnings that accompanied this

device.

SAVE THESE INSTRUCTIONS

Waarschuwing

BELANGRIJKE VEILIGHEIDSINSTRUCTIES

Dit waarschuwingssymbool betekent gevaar. U verkeert in een situatie die lichamelijk letsel kan

veroorzaken. Voordat u aan enige apparatuur gaat werken, dient u zich bewust te zijn van de bij

elektrische schakelingen betrokken risico's en dient u op de hoogte te zijn van de standaard

praktijken om ongelukken te voorkomen. Gebruik het nummer van de verklaring onderaan de

waarschuwing als u een vertaling van de waarschuwing die bij het apparaat wordt geleverd, wilt

raadplegen.

BEWAAR DEZE INSTRUCTIES

Cisco CompactFlash Adapter for Bootflash Upgrade Installation Note

78-17277-05

Safety Overview

Varoitus

TÄRKEITÄ TURVALLISUUSOHJEITA

Tämä varoitusmerkki merkitsee vaaraa. Tilanne voi aiheuttaa ruumiillisia vammoja. Ennen kuin

käsittelet laitteistoa, huomioi sähköpiirien käsittelemiseen liittyvät riskit ja tutustu

onnettomuuksien yleisiin ehkäisytapoihin. Turvallisuusvaroitusten käännökset löytyvät laitteen

mukana toimitettujen käännettyjen turvallisuusvaroitusten joukosta varoitusten lopussa näkyvien

lausuntonumeroiden avulla.

SÄILYTÄ NÄMÄ OHJEET

Attention

IMPORTANTES INFORMATIONS DE SÉCURITÉ

Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation pouvant

entraîner des blessures ou des dommages corporels. Avant de travailler sur un équipement, soyez

conscient des dangers liés aux circuits électriques et familiarisez-vous avec les procédures

couramment utilisées pour éviter les accidents. Pour prendre connaissance des traductions des

avertissements figurant dans les consignes de sécurité traduites qui accompagnent cet appareil,

référez-vous au numéro de l'instruction situé à la fin de chaque avertissement.

CONSERVEZ CES INFORMATIONS

Warnung

WICHTIGE SICHERHEITSHINWEISE

Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen

kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und

den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder

Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten

Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.

BEWAHREN SIE DIESE HINWEISE GUT AUF.

Avvertenza

IMPORTANTI ISTRUZIONI SULLA SICUREZZA

Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe causare infortuni alle

persone. Prima di intervenire su qualsiasi apparecchiatura, occorre essere al corrente dei pericoli

relativi ai circuiti elettrici e conoscere le procedure standard per la prevenzione di incidenti.

Utilizzare il numero di istruzione presente alla fine di ciascuna avvertenza per individuare le

traduzioni delle avvertenze riportate in questo documento.

CONSERVARE QUESTE ISTRUZIONI

Advarsel

VIKTIGE SIKKERHETSINSTRUKSJONER

Dette advarselssymbolet betyr fare. Du er i en situasjon som kan føre til skade på person. Før du

begynner å arbeide med noe av utstyret, må du være oppmerksom på farene forbundet med

elektriske kretser, og kjenne til standardprosedyrer for å forhindre ulykker. Bruk nummeret i slutten

av hver advarsel for å finne oversettelsen i de oversatte sikkerhetsadvarslene som fulgte med denne

enheten.

TA VARE PÅ DISSE INSTRUKSJONENE

Cisco CompactFlash Adapter for Bootflash Upgrade Installation Note

78-17277-05

Safety Overview

Aviso

INSTRUÇÕES IMPORTANTES DE SEGURANÇA

Este símbolo de aviso significa perigo. Você está em uma situação que poderá ser causadora de

lesões corporais. Antes de iniciar a utilização de qualquer equipamento, tenha conhecimento dos

perigos envolvidos no manuseio de circuitos elétricos e familiarize-se com as práticas habituais de

prevenção de acidentes. Utilize o número da instrução fornecido ao final de cada aviso para

localizar sua tradução nos avisos de segurança traduzidos que acompanham este dispositivo.

GUARDE ESTAS INSTRUÇÕES

¡Advertencia!

INSTRUCCIONES IMPORTANTES DE SEGURIDAD

Este símbolo de aviso indica peligro. Existe riesgo para su integridad física. Antes de manipular

cualquier equipo, considere los riesgos de la corriente eléctrica y familiarícese con los

procedimientos estándar de prevención de accidentes. Al final de cada advertencia encontrará el

número que le ayudará a encontrar el texto traducido en el apartado de traducciones que acompaña

a este dispositivo.

GUARDE ESTAS INSTRUCCIONES

Varning!

VIKTIGA SÄKERHETSANVISNINGAR

Denna varningssignal signalerar fara. Du befinner dig i en situation som kan leda till personskada.

Innan du utför arbete på någon utrustning måste du vara medveten om farorna med elkretsar och

känna till vanliga förfaranden för att förebygga olyckor. Använd det nummer som finns i slutet av

varje varning för att hitta dess översättning i de översatta säkerhetsvarningar som medföljer denna

anordning.

SPARA DESSA ANVISNINGAR

Cisco CompactFlash Adapter for Bootflash Upgrade Installation Note

78-17277-05

Safety Overview

Aviso

INSTRUÇÕES IMPORTANTES DE SEGURANÇA

Este símbolo de aviso significa perigo. Você se encontra em uma situação em que há risco de lesões

corporais. Antes de trabalhar com qualquer equipamento, esteja ciente dos riscos que envolvem os

circuitos elétricos e familiarize-se com as práticas padrão de prevenção de acidentes. Use o

número da declaração fornecido ao final de cada aviso para localizar sua tradução nos avisos de

segurança traduzidos que acompanham o dispositivo.

GUARDE ESTAS INSTRUÇÕES

Advarsel

VIGTIGE SIKKERHEDSANVISNINGER

Dette advarselssymbol betyder fare. Du befinder dig i en situation med risiko for

legemesbeskadigelse. Før du begynder arbejde på udstyr, skal du være opmærksom på de

involverede risici, der er ved elektriske kredsløb, og du skal sætte dig ind i standardprocedurer til

undgåelse af ulykker. Brug erklæringsnummeret efter hver advarsel for at finde oversættelsen i de

oversatte advarsler, der fulgte med denne enhed.

GEM DISSE ANVISNINGER

Cisco CompactFlash Adapter for Bootflash Upgrade Installation Note

78-17277-05

Safety Overview

Cisco CompactFlash Adapter for Bootflash Upgrade Installation Note

78-17277-05

Safety Overview

Cisco CompactFlash Adapter for Bootflash Upgrade Installation Note

78-17277-05

Installing the SP Bootflash Memory Upgrade Kit

The SP memory upgrade procedure is divided into the following tasks:

•Verifying the SP ROMMON Version, page 8

•Upgrading and Verifying the SP ROMMON Image, page 8

•Removing the Supervisor Engine 720, page 10

•Installing the CompactFlash Adapter, page 13

•Reinstalling the Supervisor Engine 720, page 16

If your system has redundant supervisor engines, you need to install the SP memory upgrade on both

supervisor engines. To install the SP memory upgrade on both supervisor engines:

•Perform the SP Bootflash memory upgrade procedure on the current standby supervisor engine.

•Perform a manual supervisor engine switchover, switching the upgraded standby supervisor engine

to active and the active supervisor engine to standby.

•Perform the SP Bootflash memory upgrade procedure on the current standby supervisor engine.

•If necessary, perform a manual supervisor engine switchover to restore the original redundant

supervisor engine configuration.

Verifying the SP ROMMON Version

An SP ROMMON upgrade may be required to support the CompactFlash adapter; you must determine

what SP ROMMON release is installed on the Supervisor Engine 720 prior to performing an SP

ROMMON upgrade. The minimum SP ROMMON release required is 8.4(2). To determine the currently

running SP ROMMON release, enter the remote command switch show version | include ROM

command

If your system is running SP ROMMON Release 8.4(2) or a later release, you can continue on to

“Removing the Supervisor Engine 720” section on page 10. If your SP ROMMON release is earlier than

8.4(2), you must upgrade the SP ROMMON image. Go to the “Upgrading and Verifying the SP

ROMMON Image” section on page 8.

Upgrading and Verifying the SP ROMMON Image

In order to utilize the SP CompactFlash adapter, your Supervisor Engine 720 must have SP ROMMON

Release 8.4(2) or a later release installed on it.

Note The upgrade task description is based on the Supervisor Engine 720 installed in a 9-slot chassis currently

running ROMMON from its S (Gold) region; the ROMMON upgrade to support the CompactFlash

adapter will be done in the F1 region.

Cisco CompactFlash Adapter for Bootflash Upgrade Installation Note

78-17277-05

Installing the SP Bootflash Memory Upgrade Kit

To upgrade your SP ROMMON, perform these steps:

Step 1 Download the latest SP ROMMON (c6ksup3-rm2.srec.8.4.2) from cisco.com and copy it to any of the

following locations: sup-bootflash:, bootflash:, disk0:, or disk1: by entering this URL:

http://www.cisco.com/cgi-bin/tablebuild.pl/cat6000-rommon

Step 2 Display the SP ROMMON image status by entering the show rom-monitor slot 5 sp command

Note The system responds with a message indicating that SP is: “Currently running ROMMON from

the S (Gold) region.”

Step 3 Verify that the necessary SP ROMMON version is present by entering the dir

{sup-bootflash:|bootflash:|disk 0:|disk 1:} command.

Step 4 Upgrade the SP ROMMON image by entering the upgrade rom-monitor slot 5 sp file

{sup-bootflash:|bootflash:|disk 0:|disk 1:}c6ksup3-rm2.srec.8.4.2 command.

Note Slot 5 indicates the slot number of the supervisor engine to be upgraded; the supervisor engine

can be installed in either slot 5, slot 6, or in both slots.

Reload the switch by entering the reload command. At the prompt, type Yto confirm and press Enter.

Note Do not perform a Reset.

Step 5 Boot the Cisco IOS software from the boot device. At this point the SP ROMMON upgrade process is

complete; the next steps are used to verify that the upgrade has been completed correctly.

Step 6 Enter privileged EXEC mode by entering the enable command

Step 7 Display the SP ROMMON image status by entering the show rom-monitor slot 5 sp

Note The system responds with a message indicating that SP is “Currently running ROMMON from

F1 region.”

Step 8 Verify the SP ROMMON version by entering the remote command switch show version | include

ROM command.

Note You should see “ROM: System Bootstrap, Version 8.4(2).”

Cisco CompactFlash Adapter for Bootflash Upgrade Installation Note

78-17277-05

Installing the SP Bootflash Memory Upgrade Kit

Removing the Supervisor Engine 720

Warning

Only trained and qualified personnel should be allowed to install, replace, or service this equipment.

Statement 1030

The following tools are required to perform the bootflash upgrade kit installation:

•3/16-inch flat-blade screwdriver for the captive installation screws on the supervisor engine

•Antistatic mat or foam pad to support and protect the removed supervisor engine

•Your own ESD-prevention equipment or the disposable grounding wrist strap included with all

upgrade kits, field-replaceable units (FRUs), and spares

Warning

Blank faceplates and cover panels serve three important functions: they prevent exposure to

hazardous voltages and currents inside the chassis; they contain electromagnetic interference (EMI)

that might disrupt other equipment; and they direct the flow of cooling air through the chassis. Do not

operate the system unless all cards, faceplates, front covers, and rear covers are in place.

Statement

1029

Warning

Hazardous voltage or energy is present on the backplane when the system is operating. Use caution

when servicing.

Statement 1034

Caution Always use an ESD wrist strap when handling the Supervisor Engine 720 or coming in contact with

internal components.

To remove the supervisor engine, follow these steps:

Step 1 Power down your system.

Step 2 Disconnect any network interface cables attached to the supervisor engine.

Step 3 Attach an ESD grounding strap to your wrist and to ground. (If you are unsure about the correct way to

attach an ESD grounding strap, see the “Attaching Your ESD Grounding Strap” section on page 24 for

instructions.)

Step 4 Verify that the captive installation screws on all of the modules in the chassis are tight. This step ensures

that the space created by the removed module is maintained.

Note If the captive installation screws are loose, the EMI gaskets on the installed modules will push

the modules toward the open slot, reducing the opening size and making it difficult to reinstall

the module.

Step 5 Loosen the two captive screws on the supervisor engine that is to be removed.

Tabla de contenidos

Otros manuales de Tarjeta de red de Cisco

Cisco

Cisco Linksys USB200M Manual de usuario

Cisco

Cisco ASR 9000 Series Manual de usuario

Cisco

Cisco 7300-6T3 Manual del operador

Cisco

Cisco Linksys WMA11B Manual de usuario

Cisco

Cisco Modular Gigabit Ethernet Line Card I Instrucciones de funcionamiento y mantenimiento

Cisco

Cisco WEC600N Manual de usuario

Cisco

Cisco 6500 - Catalyst Series 10 Gigabit EN Interface Module... Manual de instalación y operación

Cisco

Cisco One-Port Serial WAN Interface Card Cable... Manual de usuario

Cisco

Cisco MGX-FRSM-2CT3 Manual de usuario

Cisco

Cisco DFC3A Manual de instalación y operación

Cisco

Cisco uBR-MC28U Manual de usuario

Cisco

Cisco Linksys WUSB54G Manual de usuario

Cisco

Cisco WUSB54GSC Manual de usuario

Cisco

Cisco VWIC-2MFT-T1 - Multiflex Trunk Voice/WAN Interface Card Expansion... Manual de usuario

Cisco

Cisco Linksys WUSB600N Manual de usuario

Cisco

Cisco WUSB100 Manual de usuario

Cisco

Cisco Catalyst 4500 Series Manual

Cisco

Cisco Linksys WUSB600N Manual de usuario

Cisco

Cisco PA-4C-E 1 Manual del operador

Cisco

Cisco Catalyst 4500 Dimensiones

Cisco

Cisco 7304 Series Instrucciones de funcionamiento y mantenimiento

Cisco

Cisco LINKSYS WUSB54GR Manual de usuario

Cisco

Cisco uBR-E-16U Manual de usuario

Cisco

Cisco Linksys RangePlus WPC100 Manual de usuario

Manuales populares de Tarjeta de red de otras marcas

FirstComm

FirstComm OBiWiFi5G Manual de usuario

Sun Microsystems

Sun Microsystems Interface Adapter Manual de usuario

TRENDnet

TRENDnet TU2-ETG Manual de usuario

YASKAWA

YASKAWA SI-EN3 Manual de usuario

Paradyne

Paradyne BitStorm 2600 IP DSLAM Manual de usuario

Belkin

Belkin F5D7050 Manual de usuario

3Com

3Com EtherLink 3C509B Manual de usuario

TRENDnet

TRENDnet TEG-PCITX Manual de usuario

Delta Electronics

Delta Electronics Braking Modules VFDB Series Manual de usuario

TwinMOS

TwinMOS Booming Manual de usuario

Dialogic

Dialogic Media Board DM/V1200BTEPEQ Manual de usuario

Buffalo

Buffalo AirStation WLI-PCM-L11GP Manual de usuario

National Instruments

National Instruments NI 9234 Manual de usuario

Hama

Hama 49276 Manual de usuario

Linksys

Linksys WCF54G - Wireless-G Compact Flash Card Manual de operación

Compaq

Compaq Wireless LAN 100 Manual de usuario

Bose

Bose PowerMatch Dante Manual de usuario

TRENDnet

TRENDnet TEG-PCITXR Manual de usuario
