CDA HN6411 Guía de inicio rápido
Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu
IMPORTANT: PLEASE REFER TO PAGE 20 FOR
INFORMATION ON CONFIGURING THE POWER
CONSUMPTION MODE CORRECTLY.
THE HOB MUST BE CONFIGURED AT FIRST
SWITCH ON.
Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
HN6411
Induction Hob
Installation, Use and Maintenance
2
Important
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance
or use in a commercial environment.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
EU Declarations of Conformity
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
2014/35/EU and Electromagnetic interference compatibility (EMC)
3
2014/30/EU. Parts intended to come into contact with food conform to
1935/2004/EC.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both energy
and resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin.
Please note:
•Induction hobs become hot and remain hot during and immediately
after use. Do not touch the hob until it has been allowed to cool.
•Keep children away from the appliance when in use.
•Never use the hob top for storage.
•Pan handles should never stand out beyond the edge of the
worktop. This will ensure children cannot reach them.
•Do not lean over the hob when it is in use.
•Follow the cleaning instructions carefully.
•Ensure the base of the saucepan is clean and dry before placing it
on the hob.
•Avoid hard shocks from cookware – the vitroceramic glass surface
is highly resistant but not unbreakable.
4
•Do not place hot lids flat on the hob top. A “suction” eect could
cause damage to the hob.
•Do not drag cookware across the hob top: in the long term, this
could cause damage to the hob.
•Do not store cleaning or flammable products in the unit below the
hob.
•Always use appropriate cookware.
•Do not cook unopened tins of food directly on the hob.
•Never put cooking foil or plastic materials on the ceramic surface
when the hob is hot. These materials could melt and cause
damage to the hob.
•This hob (Class 3) has been designed for use only as a cooking
appliance. Any other use should be considered incorrect and
therefore dangerous.
FOR THOSE WITH HEART PACEMAKERS OR ACTIVE IMPLANTS:
The function of this hob conforms to current electromagnetic
interference standards and thus is in total compliance with legal
requirements (2004/108/CE directives).
To avoid interference between your hob and a pacemaker, your
pacemaker must be designed and programmed in compliance with
the regulations that apply to it. As such, CDA guarantee only that our
product is compliant.
With regard to the compliance of the pacemaker or any potential
incompatibility, you should obtain information from the manufacturer
or your attending physician.
5
Important
•Do not use the hob if the glass surface is cracked or damaged to
prevent the risk of electric shock. Disconnect it from the power
supply.
•Ensure that the power cables of connected electrical appliances
near the hob are not in contact with the cooking zones.
Important: Please refer to page 20 for information on configuring
the power consumption mode correctly. The hob must be
configured at first switch on.
6
Cooking on induction
The principle of induction cooking is based on magnetic eect.
When you put your cookware on an induction zone and switch it on,
the electronic boards in the hob produce induced currents in the base
of the cookware and instantly raise its temperature. This heat is then
transferred to the food inside the cookware.
The best cookware to use with induction cooking has thick flat bases,
as the heat will be better distributed so cooking more evenly.
Most cookware is compatible with induction cooking. There are three
ways to check the suitability of your cookware:
1. Use a magnet to see if the base of the pan is magnetic: if the
magnet sticks, then the cookware is compatible.
2.Place the pan on one of the cooking zones switched on to power
level 4: If the display remains on, then the cookware is
compatible. If the display flashes, the cookware cannot be used on
an induction hob.
3.Check the instructions or packaging of the pans for the symbols
indicating suitability for use with induction.
7
Control panel
The table below oers guidance as to what each power level is for.
Power level Type of cooking
0 Switched o
1/2 Melting (butter/chocolate) or keeping food warm
2/3 Keeping food hot or to heat small quantities of liquid
3/4 Heat larger quantities of liquid (sauces etc.)
4/5 Slow boiling, e.g spaghetti, soups, stews, potatoes
6/7 Gentle frying
7/8 Browning meats, frying fish, omelettes
9 Fast frying steaks
Fig.1
5
Control panel:
5. Power key
6. Timer keys
7. Safety key lock sensor
8. Zone power level keys
9. Zone displays
6 7 98
Zones:
1. Front left 1.5 kW (2.0kW boost) 210 mm
2. Back left 1.2 kW (1.6kW boost) 145 mm
3. Back right 1.5 kW (2.0kW boost) 210 mm
4. Front right 1.2 kW (1.6kW boost) 145 mm
2
1
3
4
8
Using your hob
To switch the hob on
To switch the power on, touch and hold the key for approximately
two seconds. The hob will beep and all four zone displays will show
zero.
Please note: If a power level is not set within ten seconds, the hob
will switch o automatically.
To set the power level
There are power keys for each individual zone which allow you to set
the power level by touching the “+” or “-” keys for the zone required.
To increase the power level from 1 (minimum) toward 9 (maximum),
touch the “+” key.
To go straight to power level 9, touch the “-” key when the zone
display shows “0”.
To turn the power o
To switch o a single zone, touch the “+” and “-” keys together for
the zone no longer required. This will set the power level to zero.
Alternatively, touch the “-” key until the zone display shows zero.
When all the zones are at zero, the hob will switch o automatically
after approximately ten seconds.
Alternatively, to switch o the hob immediately, touch and hold the
key for approximately two seconds.
9
Booster
The hob is equipped with a booster function, allowing a higher power
level than the maximum for approximately ten minutes. To turn on the
booster function, touch the “+” key when the power level is already
set at 9. “P” will show in the display. To cancel the booster at any
time, touch the “-” key to return to power level 9.
Timer
The hob is equipped with a timer that allows a finish time to be set for
the end of cooking on any zone, between a minimum of one minute
and a maximum of 99 minutes. This timer can be used only one zone
at a time.
To set the timer
First switch on the hob.
Touch either the timer “+” or “-” keys. The timer display will show “00”
and the zone displays will flash “t”.
Set the power level for the zone requiring the timer by touching
the “+” or “-” key for the required zone. The timer indicator LED will
illuminate on the zone to confirm the timer is selected.
Set the required duration using the timer “+” or “-” keys within five
seconds. Touching the timer “-” key will go straight to the maximum
99 minutes. Touch and hold the timer “+” or “-” keys to scroll through
the duration quickly.
After approximately five seconds, the LED and the timer display will
stop flashing and the countdown will start. The timer display will show
the minutes remaining until the last minute, when it will show the
seconds remaining.
10
At the end of the timer, the selected zone will switch o and the
timer display and the zone timer LED will flash. The hob will beep for
approximately one minute. To switch o the beep and the flashing
displays, touch any key.
To cancel the timer
Touch the timer “+” and “-” keys together.
Please note: Cancelling the timer will not switch o the zone. You
should switch the zone o manually if required.
Please note: the power level can be adjusted during the
countdown using the “+” or “-” keys.
Safety key lock
The hob is equipped with a safety key lock to lock the controls. This
can be used when the hob is o or during cooking.
To switch on the safety key lock
Touch the key for approximately two seconds until the LED above
the safety key lock sensor illuminates and the hob beeps to confirm
the safety key lock is switched on.
To turn o the childlock
Touch the key for approximately two seconds until the LED above
the safety key lock sensor switches o and the hob beeps to confirm
the safety key lock is switched o.
