hc6620 Built-In Ceramic Hob

Manual for Installation, Use and Maintenance

Contents

Contents.............................................................................................................2

Important............................................................................................................3

Important Note.................................................................................................5

Using Your Hob ...............................................................................................5

Using the Timer ............................................................................................. 10

Efficient Use of Your Hob............................................................................13

Care and Maintenance................................................................................ 15

Troubleshooting ............................................................................................ 16

Mains Electricity Connection ......................................................................17

Fitting the Hob ............................................................................................... 19

How to Install the Hob................................................................................. 21

Important

The CDA Group Ltd cannot be held responsible for injuries or

losses caused by incorrect use or installation of this product.

Please note that CDA reserve the right to invalidate the guarantee

supplied with this product following incorrect installation or misuse

of the appliance or use in a commercial environment.

This appliance is not designed to be used by people (including

children) with reduced physical, sensorial or mental capacity, or

who lack experience or knowledge about it, unless they have had

supervision or instructions on how to use the appliance by

someone who is responsible for their safety.

Under no circumstances should any external covers be removed

for servicing or maintenance except by suitably qualified

personnel.

Appliance Information:

Please enter the details on the appliance rating plate below for

reference, to assist CDA Customer Care in the event of a fault with

your appliance and to register your appliance for guarantee

purposes.

Appliance Model

Serial Number

This appliance has been manufactured to the strictest standards

and complies with all applicable legislation, including Electrical

safety (LVD) 2006/95/EC and Electromagnetic interference

compatibility (EMC) 2004/108/EC. Parts intended to come into

contact with food conform to 89/109/EC.

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF

THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE

2002/96/EC.

At the end of its working life, the product must be taken to a

special local authority waste collection centre or to a dealer

providing appliance recycling services.

Disposing of a household appliance separately avoids possible

negative consequences for the environment and health. It also

enables the constituent materials to be recovered, saving both

energy and resources. As a reminder of the need to dispose of

household appliances separately, the product is marked with a

crossed-out wheeled dustbin.

Please Note:

•Ceramic hobs become hot and remain hot during and

immediately after use. Do not touch the hob until it has

been allowed to cool.

•Keep children away from the appliance when in use.

•Never put cooking foil or plastic materials on the ceramic

surface when the hob is hot. These materials could melt

and cause damage to the hob.

•Never use the hob top for storage.

•Pan handles should never stand out beyond the edge of

the worktop. This will ensure children cannot reach them.

•Do not use pans with rough bases (e.g. cast iron) as these

may scratch the hob surface.

•Do not switch on the zones without cookware in place.

•Do not lean over the hob when it is in use.

•Follow the cleaning instructions carefully.

•Ensure the base of the saucepan is clean and dry before

placing it on the hob.

•After use, please ensure that all the zones have been

switched off.

•This hob (Class 3) has been designed for use only as a

cooking appliance. Any other use (e.g. heating rooms)

should be considered incorrect and therefore dangerous.

•The appliance is not intended to be operated by any

means of an external timer or separate remote-control

system.

Important Note

Do not use the hob if the glass surface is cracked or damaged to

prevent risk of electric shock. Disconnect it from the power

supply.

Using Your Hob

Zones:

1. Front left 1.8 kW

2. Back left 1.2 kW

3. Back right 1.8kW

4. Front right 1.2 kW

Control Panel:

1 5 4

1 2 3

1. Heating zone selection controls

2. Power / Timer adjusting controls

3. Keylock control

4. ON/OFF control

5. Timer control

Using the Touch Controls

The controls respond to touch, so you

don’t need to apply any pressure.

Use the ball of your finger, not its tip.

You will hear a beep each time a touch is

registered.

Make sure the controls are always clean, dry, and that there is

nothing (e.g. a utensil or a cloth) covering them. Even a thin film of

water may make the controls difficult to operate.

To Switch Heating Zones On

When the mains power supply is switched on, the buzzer beeps

once and all the indicators light up for 1 second, then go out. This

indicates that the ceramic hob has entered standby mode.

Touch the ON/OFF control, all the indicators show “-“.

Place a suitable pan on the cooking zone that you wish to use

(see “Efficient Use of Your Hob” section for selection of suitable

pans).

Ensure the bottom of the pan and the surface of the cooking zone

are clean and dry.

Touch the heating zone selection control that corresponds to the

zone where the pan is placed (for example back right ).

Select a heat setting by touching the “+” or “-“ controls. You may

select any power level from “1” to “9”.

If you don’t choose a heat setting within approx. 1 minute, the

ceramic hob will automatically switch off.

You can change the heat setting at any time during cooking.

By holding down either of these controls, the power level will

adjust up or down.

To use more than one heating zone, just touch the control for the

next one you want to use, then select the power level for that (as

above).

To Switch Heating Zones Off

Touch the heating zone selection control that corresponds to the

zone you wish to switch off (for example back right ).

Turn the cooking zone off by using the “+” or “-“ controls to scroll

down to “ 0 “.

Alternatively, the zone may be switched off by touching the “+”

and “-“ controls together.

To switch all heating zones off at once it is only necessary to

touch the ON/OFF control.

Hot Hob Warning Indicators

When a heating zone is hot, the indicator

adjacent to that zone’s corresponding

selection control will show “H”

The hot hob warning indicators remain lit

(even when the hob is switched off to standby mode) until the

cooking zones cool sufficiently to touch.

Do not touch the glass plate until the indicator goes out.

Locking the Controls

You can lock the controls to prevent unintended use (for example

children accidentally turning the cooking zones on).

When the controls are locked, all the controls except the ON/OFF

control are disabled.

To Lock the Controls:

Touch the key lock control . The timer indicator will show “Lo“.

To Unlock the Controls:

Touch and hold the key lock control for approx. 2 seconds.

The controls are now unlocked and the ceramic hob is now ready

for use.

Warning:If the hob is switched off using the “ON/OFF” control

while the controls are locked, it will be necessary to unlock the

hob using the process above BEFORE the hob is next switched

on.

Over-Temperature Protection

The ceramic hob is fitted with a sensor to monitor the temperature

inside the hob. When an excessive temperature is recorded, the

ceramic hob will stop operation automatically.

Auto-Shutdown

The ceramic hob is fitted with an auto-shutdown safety feature.

If a cooking zone is accidentally left switched on for a long period

it will automatically switch off after a default shutdown time.

The default shutdown times are dependent on power setting as

shown here:

Power Level

Shutdown Time

(hours)

Using the Timer

You can use the timer in two different ways:

•You can use it as a minute minder. In this case, the timer

will not turn any cooking zone off when the set time is up.

•You can set it to turn one or more cooking zone(s) off after

the set time.

You can set the timer for up to 99 minutes.

Using the Timer as a Minute Minder

Make sure the ceramic hob is switched on.

Note: you can use the minute minder even if you’re not using any

cooking zones.

Touch the timer control , the timer indicator shows “--”

Adjust the time setting by touching the “+” or “-“ controls. The

minute minder indicator will start flashing and will show in the

timer display.

Touch the “+” or “-“ control of the timer once to increase or

decrease by 1 minute.

Touch and hold the “+” or “-“ control of the timer to decrease or

increase in 10 minute increments.

If the setting time exceeds 99 minutes the timer will automatically

return to 0 minutes.

When the timer is set, it will begin to count down immediately. The

display will show the remaining time.

When the set time is reached the buzzer beeps for up to 30
