CDA Hn6410 Manual de referencia

IMPORTANT: PLEASE REFER TO PAGE 20 FOR INFORMATION ON

CONFIGURING THE POWER CONSUMPTION MODE CORRECTLY.

THE HOB MUST BE CONFIGURED AT FIRST SWITCH ON.

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY

T : 01949 862 012 F : 01949 862 003 E : [email protected] W : www.cda.eu

hn6410 Induction Hob

Manual for Installation, Use and Maintenance

Important

The CDA Group Ltd cannot be held responsible for injuries or losses

caused by incorrect use or installation of this product. Please note

that CDA reserve the right to invalidate the guarantee supplied with

this product following incorrect installation or misuse of the appliance

or use in a commercial environment.

This appliance is not designed to be used by people (including

children) with reduced physical, sensorial or mental capacity, or

who lack experience or knowledge about it, unless they have had

supervision or instructions on how to use the appliance by someone

who is responsible for their safety.

Under no circumstances should any external covers be removed for

servicing or maintenance except by suitably qualiﬁed personnel.

Appliance information:

Please enter the details on the appliance rating plate below for

reference, to assist CDA Customer Care in the event of a fault with

your appliance and to register your appliance for guarantee purposes.

Appliance Model

Serial Number

CE Declarations of Conformity

This appliance has been manufactured to the strictest standards and

complies with all applicable legislation, including Electrical safety (LVD)

2006/95/EC and Electromagnetic interference compatibility (EMC)

2004/108/EC. Parts intended to come into contact with food conform

to 89/109/EC.

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE

PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.

At the end of its working life, the product must be taken to a special

local authority waste collection centre or to a dealer providing

appliance recycling services.

Disposing of a household appliance separately avoids possible

negative consequences for the environment and health. It also

enables the constituent materials to be recovered, saving both energy

and resources. As a reminder of the need to dispose of household

appliances separately, the product is marked with a crossed-out

wheeled dustbin.

Please note:

•Induction hobs become hot and remain hot during and immediately

after use. Do not touch the hob until it has been allowed to cool.

•Keep children away from the appliance when in use.

•Never use the hob top for storage.

•Pan handles should never stand out beyond the edge of the

worktop. This will ensure children cannot reach them.

•Do not lean over the hob when it is in use.

•Follow the cleaning instructions carefully.

•Ensure the base of the saucepan is clean and dry before placing it

on the hob.

•Avoid hard shocks from cookware – the vitroceramic glass surface

is highly resistant but not unbreakable.

•Do not place hot lids ﬂat on the hob top. A “suction” eect could

cause damage to the hob.

•Do not drag cookware across the hob top: in the long term, this

could cause damage to the hob.

•Do not store cleaning or ﬂammable products in the unit below the

hob.

•Always use appropriate cookware.

•Do not cook unopened tins of food directly on the hob.

•Never put cooking foil or plastic materials on the ceramic surface

when the hob is hot. These materials could melt and cause

damage to the hob.

•This hob (Class 3) has been designed for use only as a cooking

appliance. Any other use should be considered incorrect and

therefore dangerous.

FOR THOSE WITH HEART PACEMAKERS OR ACTIVE IMPLANTS:

The function of this hob conforms to current electromagnetic

interference standards and thus is in total compliance with legal

requirements (2004/108/CE directives).

To avoid interference between your hob and a pacemaker, your

pacemaker must be designed and programmed in compliance with

the regulations that apply to it. As such, CDA guarantee only that our

product is compliant.

With regard to the compliance of the pacemaker or any potential

incompatibility, you should obtain information from the manufacturer

or your attending physician.

Important

•Do not use the hob if the glass surface is cracked or damaged to

prevent the risk of electric shock. Disconnect it from the power

supply.

•Ensure that the power cables of connected electrical appliances

near the hob are not in contact with the cooking zones.

Important: Please refer to page 20 for information on conguring

the power consumption mode correctly. The hob must be

congured at rst switch on.

Cooking on Induction

The principle of induction cooking is based on magnetic eect.

When you put your cookware on an induction zone and switch it on,

the electronic boards in the hob produce induced currents in the base

of the cookware and instantly raise its temperature. This heat is then

transferred to the food inside the cookware.

The best cookware to use with induction cooking has thick ﬂat bases,

as the heat will be better distributed so cooking more evenly.

Most cookware is compatible with induction cooking. There are three

ways to check the suitability of your cookware:

1. Use a magnet to see if the base of the pan is magnetic: if the

magnet sticks, then the cookware is compatible.

2.Place the pan on one of the cooking zones switched on to power

level 4: If the display remains on, then the cookware is

compatible. If the display ﬂashes, the cookware cannot be used on

an induction hob.

3.Check the instructions or packaging of the pans for the symbols

indicating suitability for use with induction.

Using Your Hob

The table below oers guidance as to what each power level is for.

Power level Type of cooking

0 Switched o

1/2 Melting (butter/chocolate) or keeping food warm

2/3 Keeping food hot or to heat small quantities of liquid

3/4 Heat larger quantities of liquid (sauces etc.)

4/5 Slow boiling, e.g spaghetti, soups, stews, potatoes

6/7 Gentle frying

7/8 Browning meats, frying ﬁsh, omelettes

9 Fast frying steaks

Fig.1

Control panel:

5. Power key

6. Timer keys

7. Childlock key

8. Zone power level keys

9. Zone displays

6 7 98

Zones:

1. Front left 1.5 kW (2.0kW boost) 210 mm

2. Back left 1.2 kW (1.6kW boost) 145 mm

3. Back right 1.5 kW (2.0kW boost) 210 mm

4. Front right 1.2 kW (1.6kW boost) 145 mm

Using Your Hob

To switch the hob on

To switch the power on, touch and hold the key for approximately

two seconds. The hob will beep and all four zone displays will show

zero.

Please note: If a power level is not set within ten seconds, the hob

will switch o automatically.

To set the power level

There are power keys for each individual zone which allow you to set

the power level by touching the “+” or “-” keys for the zone required.

To increase the power level from 1 (minimum) toward 9 (maximum),

touch the “+” key.

To go straight to power level 9, touch the “-” key when the zone

display shows “0”.

To turn the power o

To switch o a single zone, touch the “+” and “-” keys together for

the zone no longer required. This will set the power level to zero.

Alternatively, touch the “-” key until the zone display shows zero.

When all the zones are at zero, the hob will switch o automatically

after approximately ten seconds.

Alternatively, to switch o the hob immediately, touch and hold the

key for approximately two seconds.

Booster

The hob is equipped with a booster function, allowing a higher power

level than the maximum for approximately ten minutes. To turn on the

booster function, touch the “+” key when the power level is already

set at 9. “P” will show in the display. To cancel the booster at any

time, touch the “-” key to return to power level 9.

Timer

The hob is equipped with a timer that allows a ﬁnish time to be set for

the end of cooking on any zone, between a minimum of one minute

and a maximum of 99 minutes. This timer can be used only one zone

at a time.

To set the timer

First switch on the hob.

Touch either the timer “+” or “-” keys. The timer display will show “00”

and the zone displays will ﬂash “t”.

Set the power level for the zone requiring the timer by touching

the “+” or “-” key for the required zone. The timer indicator LED will

illuminate on the zone to conﬁrm the timer is selected.

Set the required duration using the timer “+” or “-” keys within ﬁve

seconds. Touching the timer “-” key will go straight to the maximum

99 minutes. Touch and hold the timer “+” or “-” keys to scroll through

the duration quickly.

After approximately ﬁve seconds, the LED and the timer display will

stop ﬂashing and the countdown will start. The timer display will show

the minutes remaining until the last minute, when it will show the

seconds remaining.

At the end of the timer, the selected zone will switch o and the

timer display and the zone timer LED will ﬂash. The hob will beep for

approximately one minute. To switch o the beep and the ﬂashing

displays, touch any key.

To cancel the timer

Touch the timer “+” and “-” keys together.

Please note: Cancelling the timer will not switch o the zone. You

should switch the zone o manually if required.

Please note: the power level can be adjusted during the

countdown using the “+” or “-” keys.

Childlock

The hob is equipped with a childlock to lock the controls. This can be

used when the hob is o or during cooking.

To switch on the childlock

Touch the key for approximately two seconds until the LED above

the childlock key illuminates and the hob beeps to conﬁrm the

childlock is switched on.

To turn o the childlock

Touch the key for approximately two seconds until the LED above

the childlock key switches o and the hob beeps to conﬁrm the
