CareCo Evo Guía del usuario

www.careco.co.uk

Evo

Suspension Rollator

OWNERS HANDBOOK

Product Code: WA01056

Your CareCo Evo Suspension Rollator

1. Handgrip

2. Nylon-backrest

3. Shopping bag

4. Front wheel

5. Rear wheel

6. Suspension

7. Seat

8. Handle tube

List of Parts

Thank you for purchasing the CareCo Evo

Suspension Rollator. The Evo Suspension

Rollator has been designed and manufactured

to meet our own high level of specifications

and we hope you will be delighted with your

purchase.

The Evo Suspension Rollator has been designed

as a lightweight and portable rollator to aid the

user to walk and offer stability and security to

the user. Evo Suspension Rollator is designed

for use both indoors and outdoors and will take

a maximum user weight of 150kg (23 stone).

The CareCo Evo Suspension Rollator will arrive

assembled with the exception of the height

adjustable handles.

Rollator Dimensions: 71cm (Length) x 62cm

(Width) x 87-97cm (Height)

Seat Height: 55cm

Weight: 8.9kg

Max User Weight: 150kg

Shopping Bag Max Capacity: 5.5kg

Introduction

Specification

Assembly

1. Remove all protective packaging and fold

out the rollator. Place upright with wheels on

the ground on a flat surface.

2. Insert the handle tube into the rollator frame

ensuring the cable is on the outside of the

rollator frame.

3. Select the required height and secure with

the tightening knob supplied.

4. Repeat for the other handle.

5. To adjust the height of the handles, unscrew

the tightening knob, adjust handles to desired

height and screw in the tightening knob.

For Safety:

• Ensure you adopt a comfortable posture

and can operate the brakes with ease.

• Ensure the handles are at equal heights and

securely locked in position.

• Ensure the rollator is fully folded out prior

to use.

Turn knob to

the right for

tightening.

1. To operate the brakes squeeze the lever up

to engage the brake.

2. To lock the brakes, push down on the brake

lever until it locks in place.

3. To unlock the brakes, pull up on the brake

lever until the lock is removed.

Operation

• Ensure the brakes are tested prior to use.

• Do not use on gradients greater than 7

degrees.

• Ensure the brakes are locked when using

the seat.

• When sitting, ensure the user is sat in the

centre of the seat.

Folding

For ease of storage and transportation the

Evo Suspension Rollator has an easy folding

mechanism.

Maintenance

Be sure your CareCo Evo Suspension Rollator

is in proper working order at all times. Please

contact CareCo for any repairs required.

• Ensure the rollator is kept clean. Wipe

down the rollator with a damp cloth on a

regular basis.

• Check the wheels and height adjustable

handles regularly.

• Ensure the brakes have been adjusted to

suit the wheels and user.

• Ensure all nuts, bolts and screws are

securely tightened at regular intervals.

• If the solid wheel becomes cracked or

severely worn, replace immediately.

• Check the front castor wheel swivels freely.

To fold the Evo Suspension Rollator, lift the seat

up and push the two legs of the frame together.

This will fold the rollator for easy storage and

transportation.

Your CareCo branded product is under

warranty to be free from defects in material

and workmanship for one year from date of

receipt. This warranty expresses our confidence

in the workmanship and materials used for our

products.

In the event of a defect covered by this

warranty, CareCo will, at our discretion,

replace the rollator or supply parts to remedy.

This warranty does not cover device failure

due to owner misuse or negligence, or due to

normal wear and tear. The warranty does not

extend to non-durable parts, such as rubber

accessories, castors and grips, which are subject

to normal wear and tear and require periodic

replacement.

If you have any queries please contact CareCo.

The manufacturer reserves the right to alter

without notice any weights, measurements or

other technical data shown in this manual. All

figures, measurements and capacities shown

in this manual are approximate and do not

constitute specifications.

Warranty

CareCo, Hubert Road, Brentwood,

Essex CM14 4JE

www.careco.co.uk
