Canon WEBVIEW LIVESCOPE 3.2 Manual de usuario

User's Manual

Viewer Software

Ver. 3.20

ENGLISH

Introduction

Important ....................................................................................... 4

Trademark Information ................................................................. 4

Conventions .................................................................................. 4

Overview ................................................................................... 5

Viewer Overview ....................................................................... 6

Java Viewers ................................................................................ 6

Helper Viewer ............................................................................... 7

Operating Environment ............................................................. 8

Java Viewer Ver.3.20 .................................................................... 8

Helper Viewer Ver.3.20 ................................................................. 8

Java Viewers

Preparations for Using the Java Viewer ................................. 10

Using Internet Explorer............................................................... 10

Using Netscape Navigator or Communicator ............................ 10

Starting Up the Java Viewer ................................................... 12

Using "LiveApplet" .................................................................. 13

"LiveApplet" Screens .................................................................. 13

Starting Camera Control............................................................. 15

Controlling the Camera .............................................................. 16

Changing the Camera Angle ................................................................. 16

Changing the Camera Zoom Ratio ....................................................... 17

Selecting the Camera ............................................................................ 18

Using Presets ........................................................................................ 18

Adjustment of Backlight ......................................................................... 19

Taking a Snapshot of the Video ............................................................ 20

Using "Glimpse" ...................................................................... 22

"Glimpse" Screen ....................................................................... 22

Helper Viewer

Preparations for Using the Helper Viewer .............................. 24

Difference between 2 Helper Viewers ........................................ 24

Installing the Helper Viewer ....................................................... 24

Using Browsers Other Than the Recommended

Products ...................................................................................... 26

Starting Up Helper Viewer ...................................................... 27

Starting Up from the Web Browser ............................................ 27

Starting Up Independently .......................................................... 27

Connecting to a Camera Server ............................................. 28

Specifying a Connection Target and Connecting ....................... 28

Selecting a Registered Camera Server and Connecting ........... 29

Disconnecting ............................................................................. 29

Contents

Using the Helper Viewer ......................................................... 30

"Helper Viewer" Screens ............................................................ 30

Panorama Window ................................................................................ 31

Starting Camera Control............................................................. 32

Controlling the Camera .............................................................. 33

Changing the Camera Angle ................................................................. 33

Changing the Camera Zoom Ratio ....................................................... 34

Selecting the Camera ............................................................................ 35

Using Presets ........................................................................................ 35

Changing the Video Source Size .......................................................... 36

Using Full-Screen Mode ........................................................................ 36

Adjustment of Backlight ......................................................................... 37

Stopping and Restarting Video Display ................................................ 37

Registering a camera site during connection ....................................... 38

Saving and Printing Still Pictures ............................................... 39

Saving Still Pictures to Files ................................................................. 39

Printing Still Pictures ............................................................................. 39

Displaying Information ................................................................ 40

Video Information .................................................................................. 40

Connection Information ......................................................................... 40

Camera Information ............................................................................... 40

Helper Viewer Settings

Helper Viewer Settings ........................................................... 42

Specifying the "Starting protocol" Setting ............................................. 42

"HTTP protocol" Settings ...................................................................... 43

"Performance" Setting ........................................................................... 44

"Display option" Setting ......................................................................... 45

Registering and Changing the Server .................................... 46

Registering in a Camera Site List .............................................. 46

Adding to a list ....................................................................................... 46

Changing or deleting registration details in the list .............................. 47

Registering in the Relay Server List........................................... 48

Adding a relay server to the list ............................................................ 48

Changing or deleting registration details in the list .............................. 49

Appendix

Error Messages ...................................................................... 50

Index ....................................................................................... 55

any part of the contents of this manual is forbidden.

The contents of this manual are subject to change without notice.

Every effort has been made to ensure that content of this manual is free from errors.

If you encounter any errors, omissions or apparent inaccuracies, contact the

manufacturer.

Notwithstanding above, the manufacturer accepts no liability whatsoever arising from

the results of using this product.

This manual describes how to use the WebView Livescope Ver. 3.20 Viewer software.

The two types of viewer are Java viewers and the Helper Viewer, and the video sender

can use one or the other as required. Both types provide the same basic functions for

viewing videos, but differ in terms of other features and functions.The preparations for

using the two viewer types and the required operating environment also differ

depending on the computer hardware and software used to run the viewer.

Read this manual carefully before you use the viewer to ensure that you make the best

possible use of this product.

Store this manual in a safe place after you finish reading it.

Important

Introduction

Trademark Information

Canon and Canon logo are registered trademarks of Canon Inc.

Microsoft Windows, Windows NT, and Microsoft Internet Explorer are registered trademarks of the Microsoft

Corporation in the United States and other countries.

Netscape is a trademark of Netscape Communications Corporation.

All other company or product names used in this document are trademarks or registered trademarks of their

respective holders.

* In this manual, "Microsoft Windows" is abbreviated as simply "Windows".

Conventions

Indicates important notes or restrictions that must be observed when using this product. Always

read these notes.

Indicates additional information or explanations for a procedure. You should read these items.

Under copyright law, video or still images photographed by the client cannot be used for any purpose other than

personal enjoyment without prior permission from the copyright holder

Note

Tip

Introduction

Overview

■WebView Livescope is the system that allows camera control and live video distribution from a

remote location.

■The system is configured of a camera server and viewer software. The camera server distributes

live videos taken by the video camera to the Internet or an Intranet. The viewer software can

display those videos and remotely control the camera.

■The WebView Livescope system can be used in a wide range of applications such as distributing

live videos from a Web site and monitoring.

The following types of camera servers are available:

• Network Camera Server VB101

• Network Camera VB-C10/VB-C10R

• WebView Livescope camera server ver. 3.10

The following types of Viewer Software packages are available:

• WebView Livescope viewer software (This manual: provided free of charge with camera

server product)

• WebView Livescope MV ver. 2.0/LE software

WebView Livescope is an video distribution system that enables users to

actively (by performing operations by oneself) view live (showing now) video

from Web pages by allowing users to change camera angle and zoom magnification.

Video Sender Live

Active

Video Recipient

(Viewer software)

Sending the current video

Viewing by switching angle and zoom magnification

Offers an easy way

to provide live information contents.

Offers the advantage of

being able to actively select desirable

parts from live video according to

the user's purposes.

(Camera server)

VB101

VB-C10

Java Viewer

LiveApplet

Video display functions

Camera control functions

Java Viewer

Glimpse

Video display functions

Java Viewers

Viewer Overview

These are viewers written using Java. These viewers allow the camera server videos to be

viewed on any computer with a Web browser that runs Java, regardless of the platform.

Because the Java applet is downloaded when the viewer starts up, the first video takes

some time to appear, but there is no need to pre-install the viewer on your computer. The

Java Viewer provides two types of viewers: LiveApplet containing Video Display and

Camera Control functions, and Glimpse containing a Video Display function.

Panorama picture

➤

Click

There are two types of WebView Livescope Viewer Software: the Java Viewer and the Helper

Viewer.

Introduction

Helper Viewer

This is a viewer that runs as a helper application. This viewer provides video display and

camera control functions and appears in a separate window at startup. While the Helper

Viewer has to be pre-installed, it offers the advantage of displaying the first video quickly. At

present, only a Windows version of this viewer is available.

Note

●There are two types of Helper Viewers: the Helper Viewer that is packaged

with the VB101 network camera server and the VB-C10/VB-C10R network

camera, and the Helper Viewer that can be downloaded at no charge from

the WebView World Web site (see p. 24).

●Panorama pictures must be registered in advance at the camera server.

➤

Click

Panorama picture

Operating Environment

Java Viewer Ver. 3.20

Web Browser A Web browser that runs Java.

Microsoft Internet Explorer 4.01 or later recommended.

Netscape Navigator or Communicator 4.78 or later

recommended. (excluding 6.01 and 6.1)

Computer

Operating

System

IBM PC/AT Conpatible

Windows 98 Second Edition, Windows Me, Windows NT 4.0

(requires IE 4.01 or later), Windows 2000, Windows XP

Helper Viewer Ver. 3.20

Web Browser A Web browser that runs Java.

Microsoft Internet Explorer 4.01 or later recommended.

Netscape Navigator or Communicator 4.78 or later

recommended.

Computer

Operating

System

IBM PC/AT Conpatible

Windows 98 Second Edition, Windows Me, Windows NT 4.0

(requires IE 4.01 or later), Windows 2000, Windows XP

* This viewer is installed in the camera server and automatically downloads to the client when accessed.

* Operation is unstable when used with an OS or Web browser other than those noted above.

* Must be installed in advance from the CD-ROM supplied with the camera server.

Chapter 1

Java Viewers

This chapter describes the preparations required for using the WebView

Livescope Java viewers and explains how to use the viewers.

Preparations for Using the Java Viewer

The Java Viewer is automatically downloaded from the camera server. There is no need to install it in

advance. However, depending on the type of Web browser you are using and your software settings,

you must change your Web browser settings.

Using Internet Explorer

Using Netscape Navigator or Communicator

Netscape Navigator and Netscape Communicator also have a setting that specifies

whether the use of Java is permitted.

Select "Preferences" from the "Edit" menu, click "Advanced" and then click in the

"Enable Java" checkbox.

Internet Explorer has a setting that specifies whether the use of Java is permitted.

From the "View" menu, select "Internet Options" and click the "Advanced" tab. Then

set "Java JIT compiler enabled" as the "Java VM" setting.

In Internet Explorer 5 or later, you must install the Java VM.

* For Internet Explorer 4.01

* For Netscape Navigator 6.2

The settings for the Web browser vary depending on the version used. Refer

to the settings given here and check your browser version.

Note

Tabla de contenidos

Otros manuales de Software de Canon

Canon

Canon iR Series Manual de usuario

Canon

Canon PowerShot A520 Manual de usuario

Canon

Canon EOS-1D Mark II Digial Guía de inicio rápido

Canon

Canon EOS 450D Manual de usuario

Canon

Canon PowerShot SD880 IS Digital ELPH Instrucciones de montaje

Canon

Canon DR 2580C - Document Scanner Manual de usuario

Canon

Canon Selphy CP510 Instrucciones de montaje

Canon

Canon CanoScan D646U Manual de usuario

Canon

Canon 0273B001 - Elura 90 Camcorder Manual de usuario

Canon

Canon PowerShot ELPH 100 HS IXUS 115 HS Guía de inicio rápido

Canon

Canon Powershot Pro90 IS Manual de usuario

Canon

Canon HV10 - Camcorder - 1080i Manual de usuario

Canon

Canon REALiS SX80 Mark II D Manual de instrucciones

Canon

Canon EOS-1Ds Mark III Manual de usuario

Canon

Canon EOS Rebel T3 18-55mm IS II Kit Manual de usuario

Canon

Canon 08011-41-UD2-003 Manual del operador

Canon

Canon 3508B001 - PowerShot D10 Digital Camera Guía de seguridad

Canon

Canon PowerShot A200 Instrucciones de montaje

Canon

Canon PowerShot A530 Instrucciones de montaje

Canon

Canon ZR90 Manual de usuario

Canon

Canon 70 MC - ZR70MC MiniDV Digital Camcorder Manual de usuario

Canon

Canon 0286B001 - Optura S1 Camcorder Manual de usuario

Canon

Canon 3421B001 - FS200 32GB Flash Memory Camcorder Manual de usuario

Canon

Canon imagePROGRAF W6400 Manual de usuario

Manuales populares de Software de otras marcas

COMPRO

COMPRO COMPROFM Manual de usuario

Muratec

Muratec OFFICEBRIDGE ONLINE Manual de usuario

Oracle

Oracle Contact Center Anywhere 8.1 Manual de usuario

Adobe

Adobe 65007312 - Photoshop Lightroom Manual

Avaya

Avaya NULL One-X for RIM Blackberry Manual de usuario

HP ProLiant BL420c Manual de usuario

PS Audio

PS Audio PowerPlay Manual del propietario

Brady

Brady LOCKOUT PRO 3.0 Manual de servicio

Avaya

Avaya Interaction Center Manual de usuario

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manual

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manual de usuario

Oracle

Oracle Application 9i Manual de usuario

Acer

Acer RDM Manual de usuario

Samsung

Samsung Auto Backup Manual de usuario

Polycom

Polycom Vortex EF2201 Instrucciones de instalación y funcionamiento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manual de usuario

Novell

Novell SP2 - S Manual de instrucciones

Lexmark

Lexmark Apps Manual de servicio
