Canon CDI-M186-010 Manual de usuario

DPUG7 IMPRIMÉ AU JAPON

Direct Print User Guide

Guide d'utilisation de l'impression directe

Guía del usuario de impresión directa

You don’t even need a computer !

Just connect your camera to your printer and print

Vous n'avez pas besoin d'ordinateur !

Imprimez en raccordant directement l'appareil photo à

l'imprimante

¡No necesita un ordenador!

Simplemente conecte la cámara a la impresora e

imprima

Direct Print User Guide

ENGLISH

Introduction

—

Confirm Your Printer Model and the Section that Applies to You

Operations differ according to your printer model.

According to the procedure below, confirm the section and page

you should read in this user guide.

Connect the camera to the printer with an appropriate cable

and confirm the icon displayed in the camera's LCD monitor.

• For instructions on camera and printer connection methods,

please refer to page 8.

• If one of the aforementioned icons does not appear, the connected printer

cannot be used.

• When the printer is ready for printing, the button lights in blue. The

button blinks during printing.

Confirming the section that applies to you

Icons displayed in the camera's LCD monitor

* Please also refer to the user guide that came with your printer.

Confirm your printer

model.

Read the page

below.

Printer model Refer to the sections

indicated

SELPHY CP

series

Page 10

" Printing with SELPHY CP

Series Printers using

PictBridge"

PIXMA/

SELPHY DS

series

Page 29

" Printing with Bubble Jet

Printers (PIXMA series/

SELPHY DS series) using

PictBridge"

Non-Canon

printers*

Page 47

" Printing with Non-Canon,

PictBridge Compliant Printers"

SELPHY CP

series

Page 48

" Printing with SELPHY CP

Series Printers using Canon

Direct Print"

Bubble Jet

printers

Page 64

" Printing with Bubble Jet

Printers using Bubble Jet

Direct"

Trademark Acknowledgements

• Names and products in this guide may be registered trademarks or

trademarks of their respective companies.

For the latest information regarding connections between Canon

printers and cameras, please refer to the following URL:

http://web.canon.jp/Imaging/BeBit-e.html

http://www.canon.com/pictbridge/

PictBridge Compliance

This camera complies with the industry standard “PictBridge”*.

This allows you to also connect your camera to non-Canon

PictBridge compliant printers and print images with simple

operations using the camera buttons.

* PictBridge: PictBridge is an industry standard for direct printing that

allows you to print images without using a computer by directly

connecting digital cameras and digital camcorders (hereafter “camera”)

to a printer, regardless of the devices’ brand and model.

Disclaimer

• No part of this guide may be reproduced, transmitted, transcribed, stored

in a retrieval system, or translated into any language in any form, by any

means, without the prior written permission of Canon.

• Canon reserves the right to change the specifications of the hardware

described herein at any time without prior notice.

• While every effort has been made to ensure that the information contained

in this guide is accurate and complete, no liability can be accepted for any

errors or omissions.

• Canon makes no warranties for damages resulting from corrupted or lost

data due to a mistaken operation or malfunction of the camera, the

software, the memory cards, personal computers, peripheral devices, or

use of non-Canon memory cards.

Table of Contents

Direct Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Allows for Printing without the Use of a Computer . . . . 6

Various Printing Operations Can Be Performed . . . . . . . 6

You Can Also Perform the Following Printing Operations . .7

Using Canon SELPHY CP Series Printers . . . . . . . . . . 7

Using Canon Printers (PIXMA series/SELPHY series)

with PictBridge. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Connecting the Camera to the Printer. . . . . . . . . . . . . . . . . 8

Disconnecting the Camera and the Printer. . . . . . . . . . . . . 9

Printing with SELPHY CP Series Printers using PictBridge . . .10

Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Easy Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Print after Changing the Print Settings . . . . . . . . . . . 11

Selecting Print Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Setting the Date and the File Number Printing Option

. 13

Setting the Print Effect . . . . . . . . . . . . . . . . . . . . . . . . 14

Setting the Number of Copies . . . . . . . . . . . . . . . . . . 14

Setting the Printing Area (Trimming) . . . . . . . . . . . . . 15

Selecting the Paper Settings . . . . . . . . . . . . . . . . . . . 17

Printing Multiple Images on a Sheet of Paper . . . 19

Printing by Specifying the Print Size

(ID Photo Print) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Printing Images in the Fixed Size . . . . . . . . . . . . . 22

Printing Movies (Movie Print) . . . . . . . . . . . . . . . . . . . 23

Printing with DPOF Print Settings . . . . . . . . . . . . . . . . . 25

List of Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Printing with Bubble Jet Printers (PIXMA series/

SELPHY DS series) using PictBridge . . . . . . . . . . . . . . . . . 29

Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Easy Print. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Print after Changing the Print Settings . . . . . . . . . . . .30

Selecting Print Settings. . . . . . . . . . . . . . . . . . . . . . . . . . .32

Setting the Date Printing Option . . . . . . . . . . . . . . . . .32

Setting the Print Effect . . . . . . . . . . . . . . . . . . . . . . . . .33

Setting the Number of Copies . . . . . . . . . . . . . . . . . . .34

Setting the Printing Area (Trimming) . . . . . . . . . . . . .34

Selecting the Paper Settings . . . . . . . . . . . . . . . . . . . .37

Printing Multiple Images on a Sheet of Paper . . . .39

Printing with DPOF Print Settings . . . . . . . . . . . . . . . . . .41

List of Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Printing with Non-Canon, PictBridge Compliant Printers

. . . 47

Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

Printing with SELPHY CP Series Printers using

Canon Direct Print. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

Easy Print. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

Print after Changing the Print Settings . . . . . . . . . . . .48

Selecting Print Settings. . . . . . . . . . . . . . . . . . . . . . . . . . .50

Selecting the Number of Copies . . . . . . . . . . . . . . . . .50

Setting the Print Style (Image, Borders and Date) . . .50

Setting the Printing Area (Trimming) . . . . . . . . . . . . .52

Printing by Specifying the Print Size (ID Photo Print)

. .55

Printing Movies (Movie Print) . . . . . . . . . . . . . . . . . . . .58

Printing with DPOF Print Settings . . . . . . . . . . . . . . . . . .60

List of Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

Printing with Bubble Jet Printers using Bubble Jet Direct

. .64

Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Setting the Print Style . . . . . . . . . . . . . . . . . . . . . . . . . 65

Settings that Can Be Set with the Camera . . . . . . . . . . . . . . . . . 67

SELPHY CP Series Printers using PictBridge . . . . . . 67

Bubble Jet Printers (PIXMA series/SELPHY DS series)

using PictBridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

SELPHY CP Series Printers using Canon Direct Print

Bubble Jet Printers using Bubble Jet Direct . . . . . . . 70

Direct Print

Allows for Printing without the Use of a Computer

Connect your camera to the printer with the appropriate cable.

Image selection and printing is operated from the camera.

Various Printing Operations Can Be Performed*

Multiple pictures can be printed at once. (DPOF print setting*)

Prints to cover the entire

surface of the paper.

Or, prints with a border.

Add the date.

Specify which portion of

the image to print.

(Trimming)

03/04/2005

* Some settings may not be selectable for Non-Canon printers.

You Can Also Perform the Following Printing Operations

An image can be trimmed, laid out and printed

as ID photos. (ID photo print (p. 20 or p. 55))

Movie frames can be extracted at fairly

regular intervals and printed on a single

sheet of paper. (Movie print (p. 23 or p. 58))

Using Canon SELPHY CP Series Printers

107-J006

6"25

12"50

18"75

1"25

7"50

13"75

20"00

2"50

8"75

15"00

21"25

3"75

10"00

16"25

22"50

5"00

11"25

17"50

23"75

* Depending on the printer used, the print size may be fixed before printing.

Compositions of multiple

images you specify of the same

dimensions can be printed on a

single sheet of paper (p. 19 or

p. 39). (This function is not

available on some printers.)

Moreover, the DPOF print

setting* function allows you to

separately print different images

by specifying the number of

frames to be printed per image.

* DPOF print settings

This function allows you to preset the images and the number of

copies using the camera button controls. The settings are recorded

to a memory card.

Please refer to the Camera User Guide for instructions on setting

procedure. This guide explains how to print images with DPOF

print settings.

DPOF=Digital Print Order Format

Using Canon Printers (PIXMA series/SELPHY series)

with PictBridge

Connecting the Camera to the

Printer

Connect the camera to the printer. For instructions on printer and

camera operation methods, refer to their respective user guides.

Set one of the following into the camera.

• Compact power adapter (sold separately)

• Fully charged battery

• New batteries

Place paper, ink cassette/cartridge, etc. into the

printer.

Connect the camera to the printer with the

appropriate interface cable supplied with the camera.

Some printers require specific connection cables which differ

from the above cable. Please refer to the printer’s user guide.

Turn the printer’s power on.

Set the camera to Playback mode and turn the

power on.

Depending on the camera model, the camera’s power will

automatically turn on when the printer’s power is turned on.

The following operations are not available during a camera/printer

connection.

• Movie playback.

• Language settings that use the SET button and the MENU button.

• Resetting the camera’s settings to default.

DIGITAL terminal

This illustration shows the PowerShot SD500 DIGITAL ELPH/

DIGITAL IXUS 700 as an example.

Camera: Connect the cable to

the DIGITAL terminal.

Printer: Refer to the printer’s

user guide.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Canon

Canon

Canon PowerShot SX60 HS Manual de instrucciones

Canon

Canon DIGITAL IXUS i5 PowerShot SD20 Manual de usuario

Canon

Canon PowerShot SX200 IS Manual de usuario

Canon

Canon 0206b003 - EOS Digital Rebel XT Camera SLR Manual de usuario

Canon

Canon PowerShot D20 Manual de usuario

Canon

Canon EOS 1Ds Mark III Guía de referencia rápida

Canon

Canon MP480 series Manual de usuario

Canon

Canon CR-X500 1A Manual de usuario

Canon

Canon Digital REBEL 300D Manual del operador

Canon

Canon ELPH130IS IXUS 140 Manual de usuario

Canon

Canon Powershot SD40 Manual de usuario

Canon

Canon PowerShot G1X Mark II Manual de usuario

Canon

Canon EOS 60D Manual de usuario

Canon

Canon CR-1 Mark II Manual de usuario

Canon

Canon IXUS 220 HS Manual de usuario

Canon

Canon EOS Rebel T3 18-55mm IS II Kit Manual de usuario

Canon

Canon Powershot S2 IS Manual de instrucciones

Canon

Canon DIGITAL IXUS80 IS Manual de usuario

Canon

Canon 3632B001 - PowerShot G11 Digital Camera Manual de usuario

Canon

Canon EOS REBEL T8i Instrucciones de montaje

Canon

Canon POWERSHOT A75 Guía de instalación

Canon

Canon Power Shot SX710 HS Manual de usuario

Canon

Canon Powershot S2 IS - Powershot S2 IS 5MP Digital... Manual de usuario

Canon

Canon EOS 5D Mark II Manual de uso y cuidado

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Nikon

Nikon Coolpix 100 Manual de usuario
