Canon IXY DIGITAL Manual de instrucciones

PARTS

CATALOG

PARTS

CATALOG

IXY DIGITAL C83-1006

PowerShot S100 DIGITAL ELPH C83-1001

DIGITAL IXUS C83-1005

This page intentionally left blank

32 32

17 27

14 1

See P4

Parts List (Camera Body)

SYMBOL NEW PARTS NO. CLASS Q’TY DISCRIPTION REMARKS

1 * CD1-3101-000 F 1 COVER, BATTERY

2 * CD1-3102-000 F 1 COVER, DC COUPLER

3 * CD1-3106-000 H 1 RING, STRAP

4 * CM1-1007-000 K 1 REAR COVER UNIT

5 * CM1-1004-000 K 1 FRONT COVER UNIT DIGITAL ELPH

5 * CM1-1085-000 K 1 FRONT COVER UNIT DIGITAL IXUS

5 * CM1-1087-000 K 1 FRONT COVER UNIT IXY DIGITAL

6 * CD1-3083-000 F 1 COVER, JACK

7 * CD1-3036-000 H 1 SHEET, LENS BARREL

8 * CM1-1006-000 K 1 CENTER COVER UNIT DIGITAL ELPH

8 * CM1-1086-000 K 1 CENTER COVER UNIT DIGITAL IXUS

8 * CM1-1088-000 K 1 CENTER COVER UNIT IXY DIGITAL

9 * CD1-3107-000 F 1 COVER, CF

10 * CM1-1023-000 K 1 OPERATION KEY UNIT

11 * CM1-1019-000 M 1 PCB ASS’Y, MAIN

12 * CL1-1004-000 H 1 SHEET, SHIELD

13 * WK1-5132-000 D 1 BATTERY, LITHIUM(2ND)

14 * CS8-6151-000 C 1 SPRING, BATTERY LOCK

15 * CD1-3086-000 C 1 LOCK, BATTERY

16 * CY4-6044-000 K 1 BATTERY BOX UNIT

17 * CM1-1022-000 K 1 CF UNIT

18 * CD1-3050-000 H 1 HOLDER, LED

19 * CM1-1010-000 K 1 BACK LIGHT UNIT

20 * CY4-6049-000 M 1 PANEL, LCD

21 * CM1-1001-000 K 1 OPTICAL UNIT

22 * CM1-1002-000 K 1 FINDER UNIT

23 * CD1-3104-000 H 1 SOCKET, TRIPOD

24 * CY4-6043-000 K 1 FLASH/DC UNIT

25 * CD1-3103-000 H 1 FRAME, MAIN

26 * CY4-6050-000 Y 1 PLATE, BODY NUMBER

27 * CD1-3105-000 G 2 SCREW

28 * CD1-3108-000 G 3 SCREW

29 * CD1-3109-000 G 4 SCREW

30 * CD1-3110-000 G 2 SCREW

31 * CD1-3111-000 G 4 SCREW

32 * CD1-3112-000 G 3 SCREW

33 XA1-7140-307 G 2 SCREW

34 XA1-7170-307 G 2 SCREW

35 XA1-7170-357 G 3 SCREW

36 XA4-5170-309 G 3 SCREW

37 XA4-9140-357 G 1 SCREW

38 XA4-9170-359 G 3 SCREW

OPTICAL UNIT CM1-1001-000

FLASH/DC UNIT CY4-6043-000

* N.S. stands for No Stock

10 N.S.

N.S.

Parts List (Camera Body)

SYMBOL NEW PARTS NO. CLASS Q’TY DISCRIPTION REMARKS

1 * CD1-3042-000 H 1 PLATE, BARRIER DRIVE

2 * CD1-3040-000 H 1 BASE, BARRIER

3 * CD1-3039-000 H 2 PLATE, BARRIER

4 * CS8-5205-000 C 1 SPRING, BARRIER CLOSE

5 * CS8-5204-000 C 1 SPRING, BARRIER OPEN

6 * CD1-3041-000 H 1 RING, BARRIER DRIVE

7 * CD1-3033-000 H 1 CAP, BARREL1

8 * CD1-3034-000 H 1 CAP, FRONT

9 * CM1-1012-000 K 1 FLASH UNIT

10 * CK9-0308-000 E 1 CAPACITOR, ELECT. 330V 80UF

N.S.

Wrist Strap WS-110 Battery Changer CB-2L/CB-2LE

Battery Pack NB-1L

Compact Power Adapter CA-PS300

Video Cable VC-200

Soft Case SC-PS300

USB Interface Cable IFC-200PCU

DC Coupler DR-300

AC Cable

Case for Battery Pack NB-1L

* N.S. stands for No Stock (Product available)

Parts List (Accessories)

SYMBOL NEW PARTS NO. CLASS Q’TY DISCRIPTION REMARKS

1 * CD1-3113-000 F 1 WRIST STRAP WS-110

2 FH6-0775-000 E 1 INTERFACE CABLE IFC-200PCU

3 * CK3-0058-000 K 1 DC COUPLER DR-300

4 WT3-5063-000 E 1 AC CABLE(N)

4 WT3-5064-000 E 1 AC CABLE(E)

4 D82-0644-000 E 1 AC CABLE(B)

4 WT3-5066-000 E 1 AC CABLE(A)

4 WT3-5062-000 E 1 AC CABLE(J)

5 * CD1-3121-000 F 1 CASE FOR BATTERY PACK

6N.S.

All Weather Case AW-PS200 Waterproof seal

Silicone grease

Anti-Condesation Solution

Neck Strap

* N.S. stands for No Stock (Product available)
