Brickcom PoE Cube CB-101Ap v2.1 Manual de usuario

Megapixel

PoE Cube Network Camera

PoE Cube Series

PS-588I

8-port 10/100M PoE Fast

Ethernet Switch

PS-7242IL-AF

24-port 10/100M PoE Web

Smart Ethernet Switch

Dimension Diagram (PoE Cube Series)

▪H.264, MPEG-4 and MJPEG Triple Codec Compression with Dual

Simultaneous Streaming

▪DI/DO for External Alarm and Sensor

▪Built-in PIR Sensor and Illumination LED(*)

▪Built-in Microphone/Speaker/ Micro SD/SDHC Memory Card Slot (*)

▪3G USB Dongle Support(*)

▪Interchangeable CS Mount Lens(CB-102A Series)

▪Power over Ethernet (PoE)

▪EasyConfig for Easy Set Up and GUI Integration

▪Unique Profile Setting for Variable Environment

H.264, MPEG-4 and MJPEG Triple Codec Compression with Dual

Simultaneous Streaming

▪Compact and Streamline Design

▪DI/DO for External Alarm and Sensor

▪Built-in PIR Sensor and Illumination LED(*)

▪Built-in Microphone and Speaker(*)

▪Built-in Micro SD/SDHC Memory Card Slot for Local Storage(*)

▪3G USB Dongle Support(*)

▪Interchangeable CS Mount Lens(CB-102A Series)

▪Built-in 802.3af Compliant Power over Ethernet (PoE)

▪EasyConfig for Easy Set Up and GUI Integration

▪Unique Profile Setting for Variable Environment

Camera Accessories

Network Equipment

CI-803A/CI-803C

Camera Bracket

GL-222

Camera Bracket

M13VM288IR (CB-102A)

2.2x Vari-focal Lens with Manual

Iris

BP-1000

UPS power pack

for camera

PoE Cube Series

Hardware System

CPU: 500 MHz

Flash: 16M

RAM: 128M DDR

Image Sensor

Sensor Type: 1/4” CMOS Megapixel

SensorSensor Resolution: 1280 x 800 pixel

Minimum Illumination :

CB-101Ap v2.1

2 Lux ( F2.0, Color)

1 Lux (F2.0, B/W)

CB-102Ae/ CB-102Ap v2.1

3 Lux ( F1.3, Color)

2Lux (F1.3, B/W)

Lens

CB-101Ap v2.1

Lens Type : Board Lens

Focal Length: f= 3.74 mm

F-number:F2.0

ViewAngle (H): 56°(V): 37°(D): 62°

CB-102Ae/ CB-102Ap v2.1

Lens Type : CS Mount Lens

Focal Length: f= 4 mm

F-number:F1.3

ViewAngle (H): 57°(V): 35°(D): 68°

Audio Streaming

CB-102Ae

1-way audio support

CB-101Ap v2.1/ CB-102Ap v2.1

2-way audio support

Audio Compression

G.711, AMR (8 kHz, Mono, PCM)

Audio Input/ Output

CB-102Ae

Build-in Microphone

CB-101Ap v2.1/ CB-102Ap v2.1

Build-in Microphone and Speaker

Video Image

Compression

H.264 / MPEG4 / MJPEG

Video Setting

Auto Exposure Control:

Sport/ Normal/ Night Vision/ User Defined

Auto Exposure Control:1X~5X

Shutter Speed : 1/8~1/20000 sec

S/N Ratio

39dB

Image Resolution

16:10

- 1280 x 800

- 640 x 400

- 320 x 192

16:9

- 1280 x 720

- 640 x 352

- 320 x 176

4:3

- 640 x 480

- 320 x 240

Frame Rate at

Max. Resolution

CB-102Ae

H.264: 15 fps

MPEG4: 15 fps

MJPEG: 30 fps

CB-101Ap v2.1/ CB-102Ap v2.1

H.264: 30 fps

MPEG4: 15 fps

MJPEG: 30 fps

Communication

Ethernet : one 10/100Mbps RJ-45

Supported Protocols : TCP/IP, UDP, ICMP,

DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP,

Samba, PPPoE, UPnP, RTP, RTSP,

RTCP

Power input

802.3af Compliant Power on Ethernet (PoE)

DC12V / 1 A (Power Supply)

LEDs

Power /Connect/Internet/ Privacy

/Firmware upgrade

Max. Power

Consumption

CB-102Ae

3.8 watts

CB-101Ap v2.1/ CB-102Ap v2.1

4.8watts

Environment

Operating Temperature :

0°C ~ 50°C (32°F ~122°F),

Operating Humidity : 10% ~ 80%

Dimension

CB-101Ap v2.1

34.8 (L) X60 (W) X 95 (H) mm

CB-102Ae/ CB-102Ap v2.1

45.86 (L) X60 (W) X 95 (H) mm(Including Lens)

Weight

CB-102Ae

116g

CB-101Ap v2.1

98g

CB-102Ap v2.1

129g

Certification

FCC, CE

Warranty

Limited 2-year warranty

Camera

Network

Communication

Ethernet : one 10/100Mbps RJ-45

Supported Protocols : TCP/IP, UDP, ICMP,

DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP,

Samba, PPPoE, UPnP, RTP, RTSP,

RTCP

Network

General

Audio

(*) These are optional features. Please refer to the Buying Guide for the full

list of optional features available for this product.

Video

Brickcom Corporation Headquarters

Address: No.1 Jen Ai Rd, Hsinchu Industrial Park, Hukou, Hsinchu, Taiwan,

R.O.C. 303 Tel: + 886-3-5982022 Fax: + 886-3-5982023

Mail: info@brickcom.com http://www.brickcom.com
