Brady BMP71 Instrucciones de operación

TUTORIAL

LABEL PRINTER

MOBILE PRINTER

8/12/09 BMP71 Tutorial YXXXXXX

Tutorial

The tutorial is divided into eight lessons, some lessons building on techniques and processes

learned in a previous lesson. For the first time user, it is important to perform the lessons in

order, from first to last.

At the beginning of every lesson, the preferred media (continuous or die cut) is listed, as well

as the part number for that media. For best results, follow the guidelines. The section of the

user’s manual addressing the techniques used in the particular lesson is also listed.

Each lesson provides step-by-step instructions on how to achieve the desired results. Some

lessons present multiple ways to accomplish a certain task. Where appropriate, a graphic

representation displays indicating how your label should look if you followed the steps

correctly.

The following lessons are contained in this tutorial.

Lesson 1. Create a 2-Line Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Lesson 2. Adding Symbols, Subscript, Frame . . . . . . . . . . . . . . . . . . . . .6

Lesson 3. Adding Serialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Lesson 4. Save and Open a File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Lesson 5. Create Multiple Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Lesson 6. Rotating Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Lesson 7. Barcodes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Lesson 8. Add Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Lesson 1. Create a 2-Line Label

BMP71 Tutorial

Lesson 1. Create a 2-Line Label

Media to use: Continuous or M71-31-423

This lesson shows you how to create a simple 2-line label, adding formatting attributes, and

previewing the label before printing. For more information on the techniques used in this

lesson, refer to the Getting Started section (starting on page 35) and the Printing section

(starting on page 79) of the user’s manual.

Entering text

1. On the first line of the label, enter: HOT.

2. To access a new line, press Enter .

3. On the second line of the label, enter: WAT E R

Changing Font Size

1. Using up/down navigation keys, place the cursor anywhere on the first line.

2. Press Font .

3. Using up/down navigation keys, choose: 20 Pt.

4. Press Enter or OK .

Highlight Text

1. Using up/down navigation keys, place the cursor on the second line.

2. Using left/right navigation keys, place the cursor at the beginning or end of the line.

3. Hold [Shift] while pressing left/right navigation keys, highlight the word: WATER.

Lesson 1. Create a 2-Line Label

BMP71 Tutorial

Bold a Word

1. Press Font .

2. Using left/right navigation keys, choose: Bold.

3. Using up/down navigation keys, choose: ON.

4. Press Enter or OK .

5. Press left or right navigation key to remove highlighting.

Custom Font Size

1. With the cursor still on the word WAT E R , press Font .

2. Using up/down navigation keys, choose: Custom.

3. Enter: 18.

4. Press Enter or OK .

Preview the Label

1. Press Print Preview .

Lesson 1. Create a 2-Line Label

BMP71 Tutorial

Depending on media used, your label should look like this:

2. Press Clear/Esc to exit Print Preview.

NoteNote

The contents of this lesson are used in Lesson 2. DO NOT CLEAR THE

CONTENTS OF THIS LESSON!

Lesson 2. Adding Symbols, Subscript, Frame

BMP71 Tutorial

Lesson 2. Adding Symbols, Subscript, Frame

Media to use: Continuous or M71-31-423

In this lesson you will learn how to add symbols (small graphics), place text in subscript form,

and add a frame around the label. For more information on the techniques used in this lesson,

refer to the Formatting section (starting on page 41) of the user’s manual.

NoteNote

This exercise uses the label created in Lesson 1. Please complete Lesson 1 before

continuing.

Add a Symbol

1. Using navigation keys, place the cursor at the beginning of line 1.

2. Press Symbol .

3. The Arrows category should already be selected. If not, use left/right navigation keys to

select category: Arrows.

4. Press Enter or OK .

5. Using navigation keys, select a left pointing arrow from the grid.

6. Press Enter or OK .

7. Using navigation keys, place the cursor at the end of line 1.

8. Press Symbol .

9. Choose category: Arrows.

10. Press Enter or OK .

11. Using navigation keys, select a right pointing arrow from the grid.

12. Press Enter or OK .

Lesson 2. Adding Symbols, Subscript, Frame

BMP71 Tutorial

Deleting Text

1. Using navigation keys, place the cursor at the end of line 2.

2. Press Backspace enough times to delete the word: WAT E R .

Turn Off Bold

Because the Bold attribute may still be turned on:

1. Press Font .

2. Using left/right navigation keys, choose: Bold.

3. Using up/down navigation keys, choose: OFF.

4. Press Enter or OK .

Text in Subscript

1. Enter the letter: H.

2. Press Subscript , then enter the number 2, followed by the letter O.

Framing a Label

1. Press Label .

2. Using left/right navigation keys, choose: Frame.

(Continually press the navigation keys until the FRAME option comes into view.)

3. Using up/down navigation keys, choose: Rect Wide.

4. Press Enter or OK .

NoteNote

The frame will not display on the editing screen, but can be viewed in Print

Preview or upon printing the label.

Lesson 2. Adding Symbols, Subscript, Frame

BMP71 Tutorial

Print the Label

1. Press Print .

Your label should look like this:

Clear Label

1. Press Clear/Esc .

2. Choose Delete All Labels.

3. Press Enter or OK .

4. Press Enter or OK again to confirm the deletion.

Lesson 3. Adding Serialization

BMP71 Tutorial

Lesson 3. Adding Serialization

Media to use: Continuous or M71-31-423

This lesson shows you how to apply serialization to labels and redefine the sequence

numbering. For more information on the techniques used in this lesson, refer to the

Formatting-Serialization section (starting on page 69) of the user’s manual.

AutoSize

Ensure that Auto sizing is on. (The status bar will display an ‘A’ in front of the font size.) If

Auto sizing is NOT on:

1. Press Font .

2. Choose Auto.

3. Press Enter or OK .

Add Serialization

1. Press Serial .

2. In Start Value field, enter: 1.

3. Press down navigation key to move to the End Value field.

4. In the End Value field, enter: 10.

5. Press down navigation key to move to the Increment field.

6. In the Increment field, enter: 3.

7. Navigate to the OK button at the bottom of the screen and press Enter or

How many labels are there? ____________ (Check the status bar.)
