The AutoView®KVM switching system provides you with the added benefit of advanced

cable management with integrated access cables or server interface modules. This switching

system also includes a convenient on-screen display that allows easy system configuration

and quick server selection. The advanced cabling automatically assigns and retains unique

server names for each attached server, which simplifies installation and eases re-configuration.

With PS/2, USB, Sun and serial connectivity in one solution, the Avocent 8-port AutoView 1400

single-user, 8-port AutoView 1500 and 16-port AutoView 2000 multi-user KVM switches offer

the flexibility needed for today’s small office and mid-sized business networking environments.

AutoView solutions integrate the Avocent field-proven analog KVM switching technology with

affordable, smart cable management and a powerful on-screen display.

With AutoView KVM switches, your choices for simpler KVM switching, affordable cabling

options, and easier access to servers and other network devices have never been better.

AutoView 1400/1500/2000

KVM Switching Solutions

Simple KVM switching and smart cabling in one KVM solution.

AUTOVIEW SWITCHING

BENEFITS

• Integrated Cabling. AutoView integrated

access cables offer PS/2 or USB keyboard,

video and mouse connectivity in one, slim

CAT 5 cable, which reduces cable bulk, saves

time and reduces cost.

• Advanced Cable Management. Smart chip

interface automatically assigns and retains

unique server names for each attached server.

Smart cabling simplifies installation efforts

and eases re-configurations tasks.

• Connectivity. AutoView switches deliver

simple and convenient connectivity to all

major server platforms and VT100 serial-

based devices.

• On-Screen Display. Easily configure your

system; name and select your servers from

the convenient on-screen display (OSD).

• AutoView 8-port KVM Switches. The

AutoView 1400 switch provides a single user

with access to eight PCs and network devices.

The AutoView 1500 switch provides two

simultaneous users with access to eight PCs

and network devices.

• AutoView 16-port KVM Switch. The

AutoView 2000 16-port KVM switch provides

two simultaneous users with access to 16

PCs and network devices.

• BIOS-level Access. Gives you critical

connection to the attached servers

regardless of the health or type of the

operating system.

• Design. Space-saving 1U rack mount design.

• Flash-upgrades. Flash-upgrade firmware

for fast and easy updates for the appliances

and the server interface modules.

AutoView KVM switches offer affordable integrated access cabling and convenient KVM

control for up to two local, simultaneous users.

The Power of Being There®

AUTOVIEW SPECIFICATIONS

MECHANICAL

AutoView 1400/1500/2000

•Height - 1.75 in. (4.45 cm)

•Depth - 11.00 in. (27.94 cm)

•Width - 17.00 in. (43.18 cm)

•Weight - 8 lbs. (3.6 kg)

•Style - Rack mount

ENVIRONMENTAL / POWER

AutoView 1400/1500/2000

•Operating Temperature - 50° (10°C) to 122° (50°C)

•Storage Temperature - -4° (-20°C) to 140° (60°C)

•Operating Voltage - 100 - 240 VAC Autosensing, 50/60 Hz

•Computers - IBM PC/AT, PC and 100% compatibles

•Monitors - XGA, XGA-II with adapter,

1600 x 1280 @ 75 Hz resolution

•Peripherals - PC keyboard, PC mouse, Microsoft Explorer

mouse, Microsoft IntelliMouse family, IBM Scrollpoint, Logitech

Mouseman Wheel, Logitech Trackman Marble Wheel, Logitech

Marble FX and Kensington 4-button mouse

STANDARDS

•Approved Agency - UL FCC Class A, cUL, ICES Class A,

CE, N, GS, IRAM, GOST, VCCI, Class A, MIC Class A, C-Tick

ORDERING DETAILS

AutoView 1400/1500/2000 KVM Switches

•AV1400-001 - 8-port, single user, w/OSD and rack mount kit

•AV1500-001 - 8-port, dual user, w/OSD and rack mount kit

•AV2000-AM - 16-port, dual user, w/OSD and rack mount kit

AutoView 1400/1500/2000 Cables

•PS2IAC-7 - 7’ PS2 integrated access cable

•USBIAC-7 - 7’ USB integrated access cable

•PS2IAC-10 - 10’ PS2 integrated access cable

•USBIAC-10 - 10’ USB integrated access cable

•PS2IAC-15 - 15’ PS2 integrated access cable

•USBIAC-15 - 15’ USB integrated access cable

AutoView 1400/1500/2000 Server Interface Modules

•AVRIQ-PS2 - Server interface module forVGA PS2 keyboard

PS2 mouse

•AVRIQ-SRL - Server interface module for serial-based devices

(requires UPD-AM power supply)

•AVRIQ-USB - Server interface module forVGA USB

keyboard/mouse USB mouse

•AVRIQ-VSN - Sever interface module forVGA or 13W3, Sun

keyboard/mouse

WARRANTY

•Two Years

Corporate Address

4991 Corporate Drive, Huntsville, AL35805

TEL 866 286-2368 FAX 256 430-4030

www.avocent.com

Avocent, the Avocent logo,The Power ofBeing There and AutoView are registered

tradmarks of Avocent Corporation orits affiliates. All other marks are the property

0705-AV-TP

This AutoView switching system

also provides you with the added

benefit of advanced cable

management and a powerful

on-screen display that allows

convenient system configuration

and quick server selection.

AutoView 2000

KVM switch

USB, PS/2, Sun or

serial connectivity

to the AutoView 2000

KVM switch

Local Analog

Connection

(VGA, PS/2)

AVRIQ Server

Interface Module

CAT 5, 5E or 6

Cables

Integrated

Access Cables
