Avalue Technology LPC-1206 Manual de usuario

Part No. E2017L560A0R

LPC-1206/1506

12.1"/15" 2nd Gen Intel® Core™ Processor i7/i5/i3 Fanless

Rugged Touch Panel PC

Quick Reference Guide

1st Ed –15 June 2016

LPC-1206/1506

2 LPC-1206/1506 Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

Notice

This guide is designed for experienced users to setup the system within the shortest time.

For detailed information, please always refer to the electronic user's manual.

No part of this document may be reproduced, copied, translated, or transmitted in any form

or by any means, electronic or mechanical, for any purpose, without the prior written

permission of the original manufacturer.

Trademark Acknowledgement

Brand and product names are trademarks or registered trademarks of their respective

owners.

Disclaimer

Avalue Technology Inc. reserves the right to make changes, without notice, to any product,

including circuits and/or software described or contained in this manual in order to improve

design and/or performance. Avalue Technology assumes no responsibility or liability for the

use of the described product(s), conveys no license or title under any patent, copyright, or

masks work rights to these products, and makes no representations or warranties that

Quick Reference Guide

LPC-1206/1506 Quick Reference Guide

these products are free from patent, copyright, or mask work right infringement, unless

otherwise specified. Applications that are described in this manual are for illustration

purposes only. Avalue Technology Inc. makes no representation or warranty that such

application will be suitable for the specified use without further testing or modification.

Life Support Policy

Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN

LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL

OF Avalue Technology Inc.

As used herein:

1. Life support devices or systems are devices or systems which, (a) are intended for

surgical implant into body, or (b) support or sustain life and whose failure to perform,

when properly used in accordance with instructions for use provided in the labeling, can

be reasonably expected to result in significant injury to the user.

2. A critical component is any component of a life support device or system whose

failure to perform can be reasonably expected to cause the failure of the life

support device or system, or to affect its safety or effectiveness.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

LPC-1206/1506

4 LPC-1206/1506 Quick Reference Guide

Content

1. Getting Started ........................................................................................................5

1.1 Safety Precautions....................................................................................................5

1.2 Packing List...............................................................................................................5

1.3 System Specifications...............................................................................................6

1.4 System Overview......................................................................................................9

1.4.1 Top View.................................................................................................................................. 9

1.4.2 Bottom View............................................................................................................................. 9

1.5 System Dimensions ................................................................................................10

1.5.1 LPC-1206 Front and Rear side.............................................................................................. 10

1.5.2 LPC-1506 Front and Rear side.............................................................................................. 11

2. Hardware Configuration .......................................................................................12

2.1 LPC-1206/1506 connector mapping........................................................................13

2.1.1 Serial port 1 connector (COM1)............................................................................................. 13

2.1.2 Serial port 2 connector (COM2)............................................................................................. 14

2.1.3 DVI connector (DVI) .............................................................................................................. 14

2.2 Installing Hard Disk & Memory (For LPC-1206/1506) ..............................................15

Quick Reference Guide

LPC-1206/1506 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x LPC-1206/1506 Panel PC

1 x DVD-ROM contains the followings:

—User’s Manual (this manual in PDF file)

—Ethernet driver and utilities

—VGA drivers and utilities

—Audio drivers and utilities

—WiFi drivers and utilities

—Touch controller drivers and utilities

—Chipset drivers and utilities

1 x Power Adapter

1 x Stand for Panel PC (optional)

LPC-1206/1506

6 LPC-1206/1506 Quick Reference Guide

1.3 System Specifications

Panel

Model

LPC-1206

LPC-1506

LCD size

12.1", 4:3

15", 4:3

Display type

XGA

Resolution

1024 x 768

Pixel pitch

0.240mm(H) x 0.240mm(V)

0.297mm(H) x 0.297mm(V)

Luminance

600 cd/m²

400 cd/m²

Contrast ratio

700

Viewing angle

70 (U), 70 (D), 80 (L), 80 (R)

Response time

16 ms

Backlight

LED

Touch type

5 Wires resistive

Touch Light

transmission

80 %

Touch interface

Onboard USB touch (PenMount)

System

Board

EPI-QM67

Processor

2nd Gen Intel® Core processor

System Chipset

Intel® QM67 Express Chipset

I/O Chipset

Nuvoton NTC6776F

System Memory

1 x 204-Pin DDR3 1333MHz SO-DIMM up to 8 GB

Watchdog Timer

H/W Reset, 1sec. ~ 65535min. and 1sec. or 1min./step

H/W Status

Monitor

Monitoring SYSTEM Temperature and Voltage with Auto Throttling Control

Expansion

1 x Mini PCIe Support mSATA

Storage

1 x 2.5" Drive Bay

I/O

USB

4 x USB 2.0

SATA

2 x SATA III

COM Port

1 x RS232

1 x RS232/422/485

Other

1 x HDMI

1 x DVI

Display

Quick Reference Guide

LPC-1206/1506 Quick Reference Guide

Chipset

Intel® QM67 Chipset Integrated Supports dual display

Resolution

DVI-D: Max. resolution 1920 x 1200 @ 60Hz

HDMI: Max. resolution 1920 x 1200 @ 60Hz

Audio

Chipset

Realtek ALC892

Audio Interface

Line out

Speaker Output

2 x 1W

Ethernet

Chipset

1 x Intel® 82574L

1 x Intel® 82579LM

Ethernet Interface

10/100/1000 Base-Tx GbE compatible

LAN Port

2 x RJ-45

Power Requiement

Power Connector

Lockable DC Jack

Power

Requirement

+12V ~ +19V

Power Type

AT/ATX (ATX is default setting)

Adapter

Input: 100 ~ 240Vac/ 50 ~ 60Hz; Output

84W Adapter (12V @ 7A Adapter)

Mechanical & Environment

System Fan

Fanless

Construction-Front

Silver Aluminum

Construction-Rear

Black

Dimension

283 x 222 x 68.8 mm

350 x 273.9 x 72.4 mm

Weight

3.9 Kgs

5 Kgs

Operating

0°C ~ 40°C (32°F ~ 104°F)

Storage

Temperature

-20°C ~ 60°C (-4°F ~ 140°F)

Operating

Humidity

0% ~ 90% Relative Humidity, Non-condensing

Vibration Test

With SSD/mSATA : 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 30min/axis

Mounting

Wall / Stand / VESA 75mm x 75mm, 100mm x 100mm

Shock Test

With CF/SSD : 10Grms, IEC 60068-2-27, Half Sine, 11ms

Certifications

Certification

Information

FCC Class B

Software Support

OS Information

Win7/Win8/Linux

LPC-1206/1506

8 LPC-1206/1506 Quick Reference Guide

Note: Specifications are subject to change without notice.

Quick Reference Guide

LPC-1206/1506 Quick Reference Guide

1.4 System Overview

1.4.1 Top View

1.4.2 Bottom View

Connectors

Label

Function

Note

POWER

Power on button

COM1

Serial port 1 connector

DB-9 male connector

Note: COM1 support RS422/485

by BIOS setting

COM2

Serial port 2 connector

DB-9 male connector

LINE OUT

Line-out audio jack

USB

4 x USB 2.0 connector

Dock USB

LAN1/2

RJ-45 Ethernet connector 1/2

HDD

HDD indicator

PWR

System power indicator

HDMI

HDMI connector

DVI

DVI connector

DC-IN

DC Power-in connector

LPC-1206/1506

10 LPC-1206/1506 Quick Reference Guide

1.5 System Dimensions

1.5.1 LPC-1206 Front and Rear side

(Unit: mm)

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Panel táctil de Avalue Technology

Avalue Technology

Avalue Technology LPC-0807 Manual de usuario

Avalue Technology

Avalue Technology EPD-42T Manual de usuario

Avalue Technology

Avalue Technology OFP-15W33 Manual de usuario

Avalue Technology

Avalue Technology BFC-15W9 Manual de usuario

Avalue Technology

Avalue Technology LPC-1503 Manual de usuario

Avalue Technology

Avalue Technology AID-156ST2 Manual de usuario

Avalue Technology

Avalue Technology LPC-1909 Series Manual de usuario

Avalue Technology

Avalue Technology ARC-1533 Manual de usuario

Avalue Technology

Avalue Technology OFT-07W33 Manual de usuario

Avalue Technology

Avalue Technology LPC-1009 Series Manual de usuario

Avalue Technology

Avalue Technology FPC-1707 Manual de usuario

Avalue Technology

Avalue Technology APC-18W5 Manual de usuario

Avalue Technology

Avalue Technology BFC-10W9 Manual de usuario

Avalue Technology

Avalue Technology BFC-1508 Manual de usuario

Avalue Technology

Avalue Technology BFC-10R1 Manual de usuario

Avalue Technology

Avalue Technology OFP-07W33 Manual de usuario

Avalue Technology

Avalue Technology AID-173S Manual de usuario

Avalue Technology

Avalue Technology SPC-1533-B1 Manual de usuario

Avalue Technology

Avalue Technology SPC-1509 Manual de usuario

Avalue Technology

Avalue Technology LPC-1507 Manual de usuario

Avalue Technology

Avalue Technology FPC 15 Series Manual de usuario

Avalue Technology

Avalue Technology FPC-10W09 Manual de usuario

Avalue Technology

Avalue Technology AID-173SHR Manual de usuario

Avalue Technology

Avalue Technology LPC-15WD510 Manual de usuario

Manuales populares de Panel táctil de otras marcas

FlowLine

FlowLine Data loop Manual de usuario

ALPEX

ALPEX AEx-8 P Series Manual de usuario

Ltech

Ltech E5S Manual de usuario

Harman

Harman AMX MODERO S MSD-701-L2 Manual de usuario

Acnodes

Acnodes PC 1150 Manual de usuario

AIS

AIS IP10IA99 series Manual de usuario

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manual de usuario

YASKAWA

YASKAWA TP 610C Manual de usuario

B&R

B&R Power Panel C Series Manual de usuario

Beijer Electronics

Beijer Electronics X2 control Manual de usuario

AXIOMTEK

AXIOMTEK GOT321W-521 Manual de usuario

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manual de usuario

Qomo

Qomo QIT1386 Manual de usuario

DFI

DFI KS104-CD Manual de usuario

AMX

AMX AXP-PPC Guía

Sartorius

Sartorius X3 PR 5410 Manual de usuario

AMX

AMX Modero X Series Manual de usuario

Advantech

Advantech TPC-30 Series Manual de usuario
