Avalue Technology EPC-3711 Manual de usuario
Part No. E20173711A1R
EPC-3711/CX700
Fanless VIA CN700 Eden V4 1 GHz Micro PC
Quick Reference Guide
2nd Ed – 16 August 2007
EPC-3711/CX700
2 EPC-3711/CX700 Quick Reference Guide
Contents
1. Getting Started............................................................................................................3
1.1 Safety Precautions ................................................................................................3
1.2 Packing List...........................................................................................................3
1.3 System Specifications ...........................................................................................4
1.4 System Overview...................................................................................................5
1.4.1 Front View.................................................................................................................................... 5
1.4.2 Rear View..................................................................................................................................... 6
1.5 System Dimensions...............................................................................................7
1.5.1 Top and Front .............................................................................................................................. 7
1.5.2 Bottom and Rear.......................................................................................................................... 8
2. Hardware Configuration.............................................................................................9
2.1 Jumper and Connector Setting, Driver and BIOS Installing...................................9
2.2 Installing Hard Disk & Memory ............................................................................10
Quick Reference Guide
EPC-3711/CX700 Quick Reference Guide 3
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
z1 x EPC-3711 VIA Eden Micro PC (with ECM-3711-E10 inside) or 1 x
EPC-CX700M VIA Eden Micro PC (with EPC-CX700 inside)
z1 x Quick Reference Guide
z1 x DVD-ROM contains the followings:
—User’s Manual (this manual in PDF file)
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
zOther major components include the followings:
—1 x PS/2 keyboard and mouse Y cable (6-pin, Mini-DIN)
—2 x SATA cable
—1 x AC to DC adapter
—1 x Protective Cover
EPC-3711/CX700
4 EPC-3711/CX700 Quick Reference Guide
1.3 System Specifications
System
Model EPC-3711 EPC-CX700
CPU Onboard VIA Eden V4 1 GHz
BIOS Award 512 KB Flash BIOS
System Chipset VIA CN700/VT8251 VIA CX700M
I/O Chipset VIA VT1211
System Memory One 200-pin SODIMM supports up to 1 GB DDR2 400/533 SDRAM
SSD One CompactFlash Type I/II socket with ejector
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor Monitoring system and CPU temperature, voltage, Auto throttling control when CPU
overheats
Display VIA ProSavage CN700 integrated 2D/3D
graphics engine VIA CX700M with integrated 2D and 3D
Graphics engine
Audio VIA VT1616 supports 5.1 CH Audio Realtek ALC883 supports 5.1 CH Audio
and 7.1 CH with SPDIF
Ethernet Dual Realtek RTL8111B 1000Base-T Fast
Ethernet controllers Dual Realtek RTL8101L
System Indicators 2 LED indicators show the power and HDD
External I/O Ports
COM Port 1 x RS-232, 1 x RS232/422/485, Setting by BIOS
Ethernet Port 2 x RJ-45
VGA / LCD Port 1 x DB-15
TV-out ------------- 1 x RCA jack
Audio Port Mic-in, Line-in, Line-out
USB Port 3 x USB 2.0 4 x USB 2.0
Mouse & KB 1 x PS/2 mini DIN
Power Supply Unit
Power Input 100 ~ 240 Vac / 50 ~ 60 Hz
Power Output +5 Vdc / 8 A (40W)
Environment & Mechanical
Operating Temperature 0~40°C (32~104°F)
Storage Temperature -20 to +75°C (-4~167°F)
Relative Humidity 5 to 90% @ 40°C (104°F), relative humidity, non-condensing
Dimension (W x D x H) 7.0" x 4.4" x 2.0" (178 x 112 x 50 mm)
Weight 2.65 lbs (1.2 Kgs)
Quick Reference Guide
EPC-3711/CX700 Quick Reference Guide 5
1.4 System Overview
1.4.1 Front View
Connectors
Label Function Note
POWER Power on button
LED System power indicator
USB USB 2.0 connector
EPC-3711/CX700
6 EPC-3711/CX700 Quick Reference Guide
1.4.2 Rear View
Connectors
Label Function Note
COM Serial port DB-9 male connector
CF CF Type I/II Socket with Ejector
DC-IN DC Power-in connector
HDD HDD indicator
K/B Keyboard and PS/2 mouse connector 6-pin mini DIN
LAN 2 x 10/100Base-Tx Ethernet connector RJ-45
LINE IN Line-in audio jack
LINE OUT Line-out audio jack
MIC IN Mic-in audio jack
PWR System power indicator
RESET Reset button
TV-OUT TV-Out connector (for EPC-CX700 only) RCA Jack
USB 2 x USB 2.0 connector
VGA CRT connector DB-15 female connector
Quick Reference Guide
EPC-3711/CX700 Quick Reference Guide 7
1.5 System Dimensions
1.5.1 Top and Front
(Unit: mm)
EPC-3711/CX700
8 EPC-3711/CX700 Quick Reference Guide
1.5.2 Bottom and Rear
(Unit: mm)
Quick Reference Guide
EPC-3711/CX700 Quick Reference Guide 9
2.Hardware
Configuration
2.1 Jumper and Connector Setting, Driver and BIOS
Installing
zPlease refer to ECM-3711 or ECM-CX700s’ Quick Installation Guide or
User’s Manual.
Note: If you need more information, please visit our website:
http://www.avalue.com.tw
EPC-3711/CX700
10 EPC-3711/CX700 Quick Reference Guide
2.2 Installing Hard Disk & Memory
Step 1. Unfasten 8 screws from two sides as
above, and remove the chassis
cover.
Step 4. Insert the DDR SODIMM into the
memory socket.
Step 2. Turn over the system and take off the
front/rear chassis, then unlock 4
screws of the bottom.
Step 5. Place back the bottom cover with 4
screws locked and assemble the
front/rear chassis into one piece.
Step 3. Reverse the bottom cover and fasten
3 screws with HDD as above.
Step 6. Fasten 4 screws back as the
original.
