Avalue Technology EES-CDV Manual de usuario

Part No. E2017SCDVA0R

EES-CDV

Fanless Intel® Atom™D2550 Tiny Box PC

with Intel® NM10 Express Chipset

Quick Reference Guide

1st Ed –21 June 2012

EES-CDV

2EES-CDV Quick Reference Guide

Content

1. Getting Started............................................................................................................3

1.1 Safety Precautions ................................................................................................3

1.2 Packing List...........................................................................................................3

1.3 System Specifications ...........................................................................................4

1.4 System Overview...................................................................................................6

1.4.1 Front & Rear View ................................................................................................................... 6

1.5 System Dimensions...............................................................................................7

1.5.1 Top/ Front & Side (with rubber foot) ............................................................................................ 7

1.5.2 Top/ Front & Side (with wallmount).............................................................................................. 8

2. Hardware Configuration.............................................................................................9

2.1 EES-CDV connector list ......................................................................................10

2.2 EES-CDV connector mapping.............................................................................11

2.2.1 External Serial Port 1 connector (COM1) .................................................................................. 11

2.2.2 External Serial Port 2 connector (COM2) .................................................................................. 11

2.2.3 VGA connector (VGA)................................................................................................................ 12

2.3 HDD Installation...................................................................................................13

2.4 Memory Installation .............................................................................................15

2.5 Installing Mounting Bracket (Optional).................................................................16

Quick Reference Guide

EES-CDV Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x EES-CDV (with ECM-CDV)

1 x Quick Reference Guide

1 x DVD-ROM contains the followings:

—User’s Manual (this manual in PDF file)

—Ethernet driver and utilities

—VGA drivers and utilities

—Audio drivers and utilities

Other major components include the followings:

—Screw kit for HDD/SSD fixing

—AC to DC Adapter

—Power Cord

EES-CDV

4EES-CDV Quick Reference Guide

1.3 System Specifications

System

Board

ECM-CDV

CPU

Onboard Intel® Atom™ D2550 1.86GHz CPU

BIOS

AMI 16Mbit SPI BIOS

System Chipset

Intel® NM10 Express Chipset

System Memory

One 204-pin DDR3 SODIMM Socket Supports Up to

4GB DDR3 800/ 1066 SDRAM

SSD

One CompactFlash Type I/II Socket

HDD

1 x 2.5” SATA HDD/ SSD

Watchdog Timer

Reset: 1sec. ~ 65535sec./min. and 1sec. or 1min./step

H/W Status

Monitor

Monitoring System Temperature, Voltage with Auto

Throttling Control

External I/O

COM Port

1 x RS-232,1 x RS-232/ 422/ 485 (Setting by Jumper & BIOS)

LAN Port

2 x RJ-45

Antenna

2 Knockouts for Antenna Mounting

(Options to Add WiFi & 3G)

VGA

1 x VGA

HDMI

1 x HDMI

Audio Port

Mic-in, Line-in, Line-out

USB Port

5 x USB 2.0

Expansions

1 x Mini-PCIe Socket

Display

Chipset

Intel® Cedarview Integrated Graphics

Resolution

CRT Mode: 1920 x 1200 @ 60Hz

Audio

Chipset

Realtek ALC655 supports 5.1-CH Audio

Audio Interface

Mic in, Line in, Line out

Ethernet

LAN Chip

2 x Intel® 82574L Gigabit Ethernet

Ethernet Interface

10/ 100/ 1000 Base-Tx Gigabit Ethernet Compatible

Quick Reference Guide

EES-CDV Quick Reference Guide

Environment &

Mechanical

Power Requirement

+12 ~ +26Vdc (+12V/ 5A Lockable DC Plug Adapter is

an Accessory to This System)

ACPI

Single Power ATX Support S0, S3, S4, S5

ACPI 3.0 Compliant

Power Type

AT/ ATX (ATX is The Default Setting)

Operating Temp.

0 ~ 50°C (32 ~ 122°F) (w/ CF & SSD), Ambient w/ Air Flow

0 ~ 40°C (32 ~ 104°F) (w/ HDD), Ambient w/ Air Flow

Storage Temp.

-40 ~ 75°C (-40 ~ 167°F)

Relative Humidity

0% ~ 90% Relative Humidity, Non-condensing

Vibration Protection

With CF/ SSD: 1.5Grms, IEC 60068-2-64, Random,

10 ~ 500Hz, 30min/axis

Shock Protection

With CF/ SSD: 10G, IEC 60068-2-27, Half Sine,11ms,

Z axis

Dimension (W x D x H)

8.7" x 2.8" x 5.8" (220mm x 66.1mm x 147mm)

Weight

2.7lbs (1.2kg)

Mounting

Wall Mount Kit

EES-CDV

6EES-CDV Quick Reference Guide

1.4 System Overview

1.4.1 Front & Rear View

Front View

Rear View

Quick Reference Guide

EES-CDV Quick Reference Guide

1.5 System Dimensions

1.5.1 Top/ Front & Side (with rubber foot)

(Unit: mm)

EES-CDV

8EES-CDV Quick Reference Guide

1.5.2 Top/ Front & Side (with wallmount)

(Unit: mm)

Quick Reference Guide

EES-CDV Quick Reference Guide

2.Hardware

Configuration

Please refer to ECM- CDV Quick Installation Guide or User’s Manual for

advanced information.

Note: If you need more information, please visit our website:

http://www.avalue.com.tw

EES-CDV

10 EES-CDV Quick Reference Guide

2.1 EES-CDV connector list

Connectors

Label

Function

Note

COM1

Serial port 1 connector

COM2

Serial port 2 connector

Compact Flash

Compact Flash card connector

Type I/II x 1

DC-IN

DC power-in connector

LAN1

RJ-45 Ethernet 1

LAN2

RJ-45 Ethernet 2

LINE IN

Line-in audio jack

LINE OUT

Line-out audio jack

MIC IN

Mic-in audio jack

Power

System power switch

HDD

HDD indicator

USB1~5

USB 1~5 connector

PWR

System power indicator

VGA

VGA connector

D-sub 15-pin, female

HDMI

HDMI connector
