Autodesk Inventor Simulation 2010

Getting Started

January 2009Part No. 466B1-050000-PM01A

reproduced in any form, by any method, for any purpose.

Certain materials included in this publication are reprinted with the permission of the copyright holder.

Trademarks

The following are registered trademarks or trademarks of Autodesk, Inc., in the USA and other countries: 3DEC (design/logo), 3December,

3December.com, 3ds Max, ADI, Alias, Alias (swirl design/logo), AliasStudio, Alias|Wavefront (design/logo), ATC, AUGI, AutoCAD, AutoCAD

Learning Assistance, AutoCAD LT, AutoCAD Simulator, AutoCAD SQL Extension, AutoCAD SQL Interface, Autodesk, Autodesk Envision, Autodesk

Insight, Autodesk Intent, Autodesk Inventor, Autodesk Map, Autodesk MapGuide, Autodesk Streamline, AutoLISP, AutoSnap, AutoSketch,

AutoTrack, Backdraft, Built with ObjectARX (logo), Burn, Buzzsaw, CAiCE, Can You Imagine, Character Studio, Cinestream, Civil 3D, Cleaner,

Cleaner Central, ClearScale, Colour Warper, Combustion, Communication Specification, Constructware, Content Explorer, Create>what's>Next>

(design/logo), Dancing Baby (image), DesignCenter, Design Doctor, Designer's Toolkit, DesignKids, DesignProf, DesignServer, DesignStudio,

Design|Studio (design/logo), Design Web Format, Discreet, DWF, DWG, DWG (logo), DWG Extreme, DWG TrueConvert, DWG TrueView, DXF,

Ecotect, Exposure, Extending the Design Team, Face Robot, FBX, Filmbox, Fire, Flame, Flint, FMDesktop, Freewheel, Frost, GDX Driver, Gmax,

Green Building Studio, Heads-up Design, Heidi, HumanIK, IDEA Server, i-drop, ImageModeler, iMOUT, Incinerator, Inferno, Inventor, Inventor

LT, Kaydara, Kaydara (design/logo), Kynapse, Kynogon, LandXplorer, LocationLogic, Lustre, Matchmover, Maya, Mechanical Desktop, Moonbox,

MotionBuilder, Movimento, Mudbox, NavisWorks, ObjectARX, ObjectDBX, Open Reality, Opticore, Opticore Opus, PolarSnap, PortfolioWall,

Powered with Autodesk Technology, Productstream, ProjectPoint, ProMaterials, RasterDWG, Reactor, RealDWG, Real-time Roto, REALVIZ,

Recognize, Render Queue, Retimer,Reveal, Revit, Showcase, ShowMotion, SketchBook, Smoke, Softimage, Softimage|XSI (design/logo),

SteeringWheels, Stitcher, Stone, StudioTools, Topobase, Toxik, TrustedDWG, ViewCube, Visual, Visual Construction, Visual Drainage, Visual

Landscape, Visual Survey, Visual Toolbox, Visual LISP, Voice Reality, Volo, Vtour, Wire, Wiretap, WiretapCentral, XSI, and XSI (design/logo).

The following are registered trademarks or trademarks of Autodesk Canada Co. in the USA and/or Canada and other countries:

Backburner,Multi-Master Editing, River, and Sparks.

The following are registered trademarks or trademarks of MoldflowCorp. in the USA and/or other countries: Moldflow, MPA, MPA

(design/logo),Moldflow Plastics Advisers, MPI, MPI (design/logo), Moldflow Plastics Insight,MPX, MPX (design/logo), Moldflow Plastics Xpert.

All other brand names, product names or trademarks belong to their respective holders.

Disclaimer

THIS PUBLICATION AND THE INFORMATION CONTAINED HEREIN IS MADE AVAILABLE BY AUTODESK, INC. "AS IS." AUTODESK, INC. DISCLAIMS

ALL WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR

FITNESS FOR A PARTICULAR PURPOSE REGARDING THESE MATERIALS.

Published by:

Autodesk, Inc.

111 Mclnnis Parkway

San Rafael, CA 94903, USA

Contents

Stress Analysis . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Chapter 1 Get Started With Stress Analysis . . . . . . . . . . . . . . . . . . 3

About Autodesk Inventor Simulation . . . . . . . . . . . . . . . . . . . 3

Learn Autodesk Inventor Simulation . . . . . . . . . . . . . . . . . . . . 4

Use Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Use Stress Analysis Tools . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Understand the Value of Stress Analysis . . . . . . . . . . . . . . . . . . 6

Understand How Stress Analysis Works . . . . . . . . . . . . . . . . . . 7

Analysis Assumptions . . . . . . . . . . . . . . . . . . . . . . . . 7

Interpret Results of Stress Analysis . . . . . . . . . . . . . . . . . . . . . 9

Equivalent or Von Mises Stress . . . . . . . . . . . . . . . . . . . . 9

Maximum and Minimum Principal Stresses . . . . . . . . . . . . 10

Deformation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Safety Factor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Frequency Modes . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Chapter 2 Analyze Models . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Do a Static Stress Analysis . . . . . . . . . . . . . . . . . . . . . . . . . 13

Enter Environment and Create a Simulation . . . . . . . . . . . . 14

Exclude Components . . . . . . . . . . . . . . . . . . . . . . . . 15

Specify Material . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Add Constraints . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

iii

Add Loads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Add Contact Conditions . . . . . . . . . . . . . . . . . . . . . . 19

Generate a Mesh . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Run the Simulation . . . . . . . . . . . . . . . . . . . . . . . . . 20

Run Modal Analysis . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Chapter 3 View Results . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Use Results Visualization . . . . . . . . . . . . . . . . . . . . . . . . . 23

Edit the Color Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Read Stress Analysis Results . . . . . . . . . . . . . . . . . . . . . . . . 26

Interpret Results Contours . . . . . . . . . . . . . . . . . . . . . 26

Animate Results . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Set Results Display Options . . . . . . . . . . . . . . . . . . . . . 28

Chapter 4 Revise Models and Stress Analyses . . . . . . . . . . . . . . . . 31

Change Model Geometry . . . . . . . . . . . . . . . . . . . . . . . . . 31

Change Solution Conditions . . . . . . . . . . . . . . . . . . . . . . . 32

Update Results of Stress Analysis . . . . . . . . . . . . . . . . . . . . . 34

Chapter 5 Generate Reports . . . . . . . . . . . . . . . . . . . . . . . . . 35

Run Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Interpret Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Model Information . . . . . . . . . . . . . . . . . . . . . . . . . 36

Project Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Simulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Save and Distribute Reports . . . . . . . . . . . . . . . . . . . . . . . . 38

Saved Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Print Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Distribute Reports . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Chapter 6 Manage Stress Analysis Files . . . . . . . . . . . . . . . . . . . 39

Create and Use Analysis Files . . . . . . . . . . . . . . . . . . . . . . . 39

Understand File Relationships . . . . . . . . . . . . . . . . . . . 39

Resolve Missing Files . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Dynamic Simulation . . . . . . . . . . . . . . . . . . . . . . . . 41

Chapter 7 Get Started with Simulation . . . . . . . . . . . . . . . . . . . 43

About Autodesk Inventor Simulation . . . . . . . . . . . . . . . . . . . 43

Learning Autodesk Inventor Simulation . . . . . . . . . . . . . . . . . 44

Use Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Understand Simulation Tools . . . . . . . . . . . . . . . . . . . . . . . 45

iv | Contents

Simulation Assumptions . . . . . . . . . . . . . . . . . . . . . . . . . 45

Interpret Simulation Results . . . . . . . . . . . . . . . . . . . . . . . 45

Relative Parameters . . . . . . . . . . . . . . . . . . . . . . . . . 45

Coherent Masses and Inertia . . . . . . . . . . . . . . . . . . . . 46

Continuity of Laws . . . . . . . . . . . . . . . . . . . . . . . . . 46

Chapter 8 Simulate Motion . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Understand Degrees of Freedom . . . . . . . . . . . . . . . . . . . . . 47

Understand Constraints . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Convert Assembly Constraints . . . . . . . . . . . . . . . . . . . . . . 49

Run Simulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Chapter 9 Construct Moving Assemblies . . . . . . . . . . . . . . . . . . 55

Retain Degrees of Freedom . . . . . . . . . . . . . . . . . . . . . . . . 55

Add Joints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Impose Motion on Joints . . . . . . . . . . . . . . . . . . . . . . . . . 58

Run Simulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Chapter 10 Construct Operating Conditions . . . . . . . . . . . . . . . . . 61

Complete the Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Add Friction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Add a Sliding Joint . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Contents | v

Stress Analysis

Part 1 of this manual presents the getting started information for Stress Analysis in the Autodesk

Inventor®Simulation software. This add-on to the Autodesk Inventor assembly, part, and

sheet metal environments provides the capability to analyze the static stress and natural

frequency responses of mechanical designs.

Get Started With Stress

Analysis

Autodesk Inventor®Simulation software provides a combination of industry-specific tools

that extend the capabilities of Autodesk Inventor®for completing complex machinery and

other product designs.

Stress Analysis in Autodesk Inventor Simulation is an add-on to the Autodesk Inventor

assembly, part, and sheet metal environments.

Static Analysis provides the means to simulate stress, strain, and deformation.

Modal Analysis provides means to find natural frequencies of vibration and mode shapes of

mechanical designs.

You can visualize the affects in 3D volume plots, create reports for any results, and perform

parametric studies to refine your design.

This chapter provides basic information about the stress analysis environment and the

workflow processes necessary to analyze loads and constraints placed on a part or assembly.

About Autodesk Inventor Simulation

Built on the Autodesk Inventor application, Autodesk Inventor Simulation

includes several different modules. The first module included in this manual is

Stress Analysis. It provides functionality for Structural Static and Modal analysis

of mechanical product designs.

This manual provides basic conceptual information to help get you started and

specific examples that introduce you to the capabilities of Stress and Modal

Analysis in Autodesk Inventor Simulation.

Learn Autodesk Inventor Simulation

We assume that you have a working knowledge of the Autodesk Inventor

Simulation interface and tools. If you do not, use Help for access to online

documentation and tutorials, and complete the exercises in the Autodesk

Inventor Simulation Getting Started manual.

At a minimum, we recommend that you understand how to:

■Use the assembly, part modeling, and sketch environments and browsers.

■Edit a component in place.

■Create, constrain, and manipulate work points and work features.

■Set color styles.

Be more productive with Autodesk®software. Get trained at an Autodesk

Authorized Training Center (ATC®) with hands-on, instructor-led classes to

help you get the most from your Autodesk products. Enhance your productivity

with proven training from over 1,400 ATC sites in more than 75 countries.

For more information about training centers, contact [email protected]

or visit the online ATC locator at www.autodesk.com/atc.

We also recommend that you have a working knowledge of Microsoft®

Windows®XP or Windows Vista®. It is desirable, but not required, to have a

working knowledge of concepts for stress analysis of mechanical assembly

designs.

Use Help

As you work, you may need additional information about the task you are

performing. The Help system provides detailed concepts, procedures, and

reference information about every feature in the Autodesk Inventor Simulation

modules as well as the standard Autodesk Inventor Simulation features.

To access the Help system, use one of the following methods:

■Click Help ➤Help Topics, and then use the Table of Contents to navigate

to Stress Analysis topics.

■Press F1 for Help with the active operation.

■In any dialog box, click .

4| Chapter 1 Get Started With Stress Analysis

Otros manuales para 466B1-05A761-1304 - AutoCAD Inventor Simulation Suite...

Tabla de contenidos

Otros manuales de Software de Autodesk

Autodesk

Autodesk 057A1-05A111-1001 - AutoCAD LT 2009 Manual de usuario

Autodesk

Autodesk AUTOCAD MEP Manual de usuario

Autodesk

Autodesk AUTODESK ROBOT STRUCTURAL ANALYSIS... Manual de usuario

Autodesk

Autodesk 24000-000000-9860 - Revit Architecture - PC Manual de usuario

Autodesk

Autodesk 15606-011408-9320 - MAP R6.3 CPU MODEL-UPG 4/5 MIN 2 CPUS... Manual de usuario

Autodesk

Autodesk AUTOCAD ELECTRICAL - Manual de usuario

Autodesk

Autodesk AUTOSKETCH 8 Manual de usuario

Autodesk

Autodesk ROBOT STRUCTURAL ANALYSIS PROFESSIONAL 2010 Manual de usuario

Autodesk

Autodesk 657B1-000110-S001 - Maya - Mac Manual de usuario

Autodesk

Autodesk 15606-011408-9005 - MAP R6.3 NAMED-10U PK Instrucciones de operación

Autodesk

Autodesk AUTOSKETCH 10 - SYSTEM REQUIREMENTS Manual de usuario

Autodesk

Autodesk 15606-011408-9330 - MAPGUIDE R6.3 SITE LIC-UPG... Manual de instrucciones

Autodesk

Autodesk 256B1-05A761-1301 - AutoCAD Revit Structure Suite... Manual de usuario

Autodesk

Autodesk CAICE VISUAL SURVEY 10 Manual de usuario

Autodesk

Autodesk GREEN BUILDING STUDIO - QUESTIONS AND... Manual de usuario

Autodesk

Autodesk AUTODESK MOTIONBUILDER 2011 - SYSTEM... Manual de usuario

Autodesk

Autodesk AUTOCAR CIVIL 2010 Manual de usuario

Autodesk

Autodesk INVENTOR 2010 - Manual de usuario

Autodesk

Autodesk 225A1-05A111-1001 - AutoCAD Electrical 2009 Manual de usuario

Autodesk

Autodesk AUTOCAD RASTER DESIGN Manual de usuario

Autodesk

Autodesk 00128-051462-9340 - AutoCAD 2008 - PC Manual de usuario

Autodesk

Autodesk 240B1-05A111-1301 - Revit Architecture 2010 Manual de usuario

Autodesk

Autodesk 46304-050008-1600A - Vault R4 Essentials... Manual de usuario

Autodesk

Autodesk 237B1-05A761-1301 - AutoCAD Civil 3D 2010 Manual de servicio

Manuales populares de Software de otras marcas

COMPRO

COMPRO COMPROFM Manual de usuario

Muratec

Muratec OFFICEBRIDGE ONLINE Manual de usuario

Oracle

Oracle Contact Center Anywhere 8.1 Manual de usuario

Adobe

Adobe 65007312 - Photoshop Lightroom Manual

Avaya

Avaya NULL One-X for RIM Blackberry Manual de usuario

HP ProLiant BL420c Manual de usuario

PS Audio

PS Audio PowerPlay Manual del propietario

Brady

Brady LOCKOUT PRO 3.0 Manual de servicio

Avaya

Avaya Interaction Center Manual de usuario

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manual

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manual de usuario

Oracle

Oracle Application 9i Manual de usuario

Acer

Acer RDM Manual de usuario

Canon

Canon Vixia HF21 Manual de usuario

Canon

Canon ZR950 Manual de usuario

Samsung

Samsung Auto Backup Manual de usuario

Polycom

Polycom Vortex EF2201 Instrucciones de instalación y funcionamiento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manual de usuario
