Features

•USB DFU boot loaders, version 1.1.0

•Same feature set as version 1.0.3

•These boot loaders do not use any general purpose fuses

•USB protocol

– Based on the USB device firmware upgrade (DFU) class

– Auto-baud (8, 12, and 16MHz crystal on Osc0)

•In-system programming (ISP)

– Configurable I/O start conditions (default is pressing the joystick on Atmel®

EVK1100 and Atmel EVK1101, SW2 button on Atmel EVK1104, PB0 button on

Atmel UC3C-EK, HBUTTON0 button on Atmel UC3-C2-Xplained board) stored in

user page. Protected by 8-bit CRC

– Can be forced by non-volatile configuration bits stored in user page. Protected by

8-bit CRC

– Read/write, on-chip flash memories

– Read device ID

– Full chip erase

– Start application command

32166A–AVR32806–06/11

Atmel UC3 32-bit

Microcontroller

AVR UC3 USB

DFU Boot

Loader, Version

1.1.0 and Higher

32166A–AVR32806–06/11

Atmel AVR32806

1. Description

Atmel AVR®UC3 devices with the USB feature are shipped with a USB boot loader.

This USB boot loader allows in-system programming (ISP) to be performed from a USB host

controller without removing the part from the system, without a preprogrammed application, and

without any external programming interface other than USB.

One boot loader is compiled for each AVR UC3 series. The default hardware I/O conditions

used to request the start of the ISP are also specific to each family.

The USB DFU boot loader, version 1.1.0, has the exact same set of features as the USB DFU

boot loader, versions 1.0.x. The difference is the implementation: Version 1.1.0 does not use

any general purpose fuse for configuration, and uses instead the last two words at the end of the

user page, while version 1.0.3 uses three general purpose fuses (GP29, GP30, and GP31) and

the last word at the end of the user page.

This document describes the USB boot loader functions and its use in various contexts.

2. Related parts

This documentation applies to the following AVR UC3 parts:

•Atmel AT32UC3C0512C, rev. D and higher

•Atmel AT32UC3C0256C, rev. D and higher

•Atmel AT32UC3C0128C, rev. D and higher

•Atmel AT32UC3C064C, rev. D and higher

•Atmel AT32UC3C1512C, rev. D and higher

•Atmel AT32UC3C1256C, rev. D and higher

•Atmel AT32UC3C1128C, rev. D and higher

•Atmel AT32UC3C164C, rev. D and higher

•Atmel AT32UC3C2512C, rev. D and higher

•Atmel AT32UC3C2256C, rev. D and higher

•Atmel AT32UC3C2128C, rev. D and higher

•Atmel AT32UC3C264C, rev. D and higher

Note: The list above is the list of AVR UC3 devices shipped with a preprogrammed USB DFU boot

loader, version 1.1.0 or higher.

Note: The Atmel AT32UC3A0/1, rev. H and higher, the Atmel AT32UC3B0/1, rev. F and higher, and

the Atmel AT32UC3A3, rev. E and higher, can operate with version 1.1.0 of the USB DFU

boot loader, but these devices are shipped preprogrammed with older versions of the boot

loader. For an accurate boot loader version per AVR UC3 devices overview, please refer to

the table of preprogrammed boot loader versions in AVR UC3 devices in Section 8.2.

The boot loader is compiled for each AVR UC3 family because of differences in the MCU periph-

eral memory map. The functionality is the same among families.

3. Related items

• Atmel AVR UC3 A0, A1 Series datasheet:

http://www.atmel.com/dyn/resources/prod_documents/doc32058.pdf

• Atmel AVR UC3 B0, B1 Series datasheet:

http://www.atmel.com/dyn/resources/prod_documents/doc32059.pdf

32166A–AVR32806–06/11

Atmel AVR32806

• Atmel AVR UC3 A3 Series datasheet:

http://www.atmel.com/dyn/resources/prod_documents/doc32072.pdf

• Atmel AVR UC3 C0, C1, C2 Series datasheet:

http://www.atmel.com/dyn/resources/prod_documents/doc32117.pdf

• Atmel AVR UC3 A0, A1, A3, B0, B1 DFU boot loader up to version 1.0.3:

http://www.atmel.com/dyn/resources/prod_documents/doc7745.pdf

• Atmel AVR Software Framework:

http://www.atmel.com/asf

• Atmel FLIP 3:

http://www.atmel.com/dyn/products/tools_card.asp?tool_id=3886

• Atmel AVR32 Studio 2.7:

http://www.atmel.no/beta_ware/

32166A–AVR32806–06/11

Atmel AVR32806

4. Abbreviations

• ISP: In-system programming

• BOD: Brown-out detector

• USB: Universal serial bus

• DFU: Device firmware upgrade

• avr32program: AVR 32-bit part programmer used with hardware debuggers

• FLIP: Flexible in-system programmer

5. Boot loader environment

The boot loader manages the USB communication protocol and performs read/write operations

from/to the on-chip memories.

The boot loader is located at the beginning of the on-chip flash array, where an area of up to

64KB can be configured to be write protected by the internal flash controller. The boot loader

protected size must be at least the size of the boot loader. On Atmel AT32UC3xxxxx devices, it

is configured to 8KB.

Figure 5-1. Physical environment.

BatchISP is a PC tool that allows a part to be programmed using the Atmel AVR UC3 USB DFU

boot loader. It is compatible with both Windows®and Linux®. It is integrated into Atmel AVR32

Studio by use of a plug-in.

Note that all GCC make files of the Atmel AVR UC3 Software Framework have programming

goals using BatchISP.

32166A–AVR32806–06/11

Atmel AVR32806

6. Inner workings

6.1 Memory layout

An Atmel AVR UC3 part with the preprogrammed boot loader resets as any other part, at

80000000h. Boot loader execution begins here. The boot loader first performs the boot process

to know whether it should start the USB DFU ISP or the application. If the tested conditions indi-

cate that the USB DFU ISP should be started, then execution continues in the boot loader area

between 80000000h and 80002000h; else the boot loader launches the application at

80002000h.

The conditions tested by the boot process are configured by two 32-bit configuration words

located at the end of the flash user page.

Figure 6-1. The Atmel AT32UC3C0512C non-volatile memory layout with USB DFU boot

loader.

6.2 Configuration

The boot loader configuration is non-volatile and determines the behavior of the boot process

and the ISP. This configuration is stored in the 32 general purpose fuse bits and in the flash user

page (see Figure 6-1).

See the AVR UC3 datasheets for further information about the general purpose fuse bits and the

flash user page.

Application

Bootloader

Reset vector is

@ 80000000h

Application is

@ 80002000h

Flash User Page

Free Flash Space

User page is

@ 80800000h

32-bit bootloader

configuration word1 is

@ 808001FCh &

configuration word2 is

@ 808001F8h

32 GP Fuse

Bits

MCU Address Space

256kB

-Flash

Array

248 kB

8 kB

512 B

32166A–AVR32806–06/11

Atmel AVR32806

6.2.1 General purpose fuse bits

Atmel AVR UC3 series devices have 32 general purpose fuse bits. When these bits are erased,

they are set to logical 1.

AVR UC3 devices are shipped with their fuses set as follows:

• For Atmel AVR UC3 C series: The general purpose fuses are set to F877FFFFh

•

That is, BOD is enabled, and the boot loader area is set to 8192 bytes.

The general purpose fuse bits can be changed in one of the following ways:

• With a hardware debugger, use the avr32program writefuses command (see avr32program

help writefuses), or execute “Program Fuses...” on the chosen hardware debugger Atmel

AVR32 target in Atmel AVR32 Studio

• With ISP, use the CONFIGURATION memory with BatchISP (see Section 7.4.2), or execute

“Program Fuses...” on the appropriate ISP AVR 32-bit target in AVR32 Studio (see Section

7.5.2)

• From the running embedded application, use the WGPB, EGPB, PGPFB, and EAGPF

FLASHC commands. See the AVR UC3 datasheets for further information, and be careful of

the lock errors that can occur with these commands

6.2.2 Flash user page

6.2.2.1 Description

The boot loader uses two words in the flash user page to store its configuration:

• Configuration Word1 at address 808001FCh is read first at boot time to know if the ISP

process should start unconditionally, and whether it should use Configuration Word2, where

further configuration is stored (see Table 6-1.)

• Configuration Word2 at address 808001F8h stores the I/O conditions that determine

whether the USB DFU ISP or the application is started at the end of the boot process (see

Table 6-2.)

32166A–AVR32806–06/11

Atmel AVR32806

See Section 6.2.2.2 for the default preprogrammed value of this configuration word.

Table 6-1. Boot loader flash user page Configuration Word1.

Config

Word1 @

808001FCh Name Description

7:0 ISP_CRC8_1 CRC8 of the boot loader Configuration Word1

usingthe polynomial:

P(X) = X8+X2+X+1.

This CRC is used to check the validity of

Configuration Word1.

8 ISP_IO_COND_EN When at 1, tells the boot process to use the user

page Configuration Word2 to determine the I/O

conditions to test to know whetherto start the USB

DFU ISP or the application. Refer to Table 6-2 for a

description of the user page Configuration Word2.

Setting this bit to 0 allows the application to save a

GPIO pin and to free the penultimate word of the

user page, but the ISP will then be unreachable until

the ISP_FORCE bit is set to 1. This behavior can be

useful when extending the Atmel default boot loader

with an applicative boot loader (see Section 7.6.3.3).

9 ISP_FORCE When at 1, tells the boot process to start the USB

DFU ISP process without testing any other

conditions.

15:10 Reserved Reserved. Set to 3Fh.

31:16 ISP_BOOT_KEY_1 Boot key=E11Eh. This key is used to identify this

word as meaningful for the boot loader.

32166A–AVR32806–06/11

Atmel AVR32806

See Section 6.2.2.2 for the default preprogrammed value of this configuration word.

6.2.2.2 Flash user page configuration words preprogrammed values

The default value of the boot loader flash user page Configuration Word1 is E11EFFD7h (that is,

ISP_FORCE is enabled) for all Atmel AVR UC3 C and D series devices.

The default value of the boot loader flash user page Configuration Word2 is:

• 929E0E62h for the AVR UC3 C0-1 series,

• 929E7504h for the AVR UC3 C2 series,

•

That is, the ISP will be activated when

• the PB0 button onthe UC3C-EK kit is pressed at reset,

• the HBUTTON0 button on the UC3-C2-Xplained kit is pressed at reset,

•

Refer to Section 7.3 for a description of how to customize and program the two configuration

words.

Table 6-2. Boot loader flash user page Configuration Word2.

Config

Word2 @

808001F8h Name Description

7:0 ISP_CRC8_2 CRC8 of the boot loader user page Configuration

Word2 usingthe polynomial:

P(X) = X8+X2+X+1.

This CRC is used to check the validity of

Configuration Word2.

15:8 ISP_IO_COND_PIN The GPIO pin number to test during the boot

process to know whehterto start the USB DFU ISP

or the application. For example, to select PB10 (that

is, QFP144 pin 16 and GPIO pin 42) on the Atmel

AT32UC3A3256, this bit field must be set to 42.

Possible values are:

- 0 to 109 for Atmel AVR UC3 A0 144-pin packages

- 0 to 69 for Atmel AVR UC3 A1 100-pin packages

- 0 to 109 for Atmel AVR UC3 A3 144-pin packages

- 0 to 43 for Atmel AVR UC3 B0 64-pin packages

- 0 to 27 for Atmel AVR UC3 B1 48-pin packages

- 0 to 125 for Atmel AVR UC3 C 144-pin packages

- 0 to 83 for Atmel AVR UC3 C 100-pin packages

- 0 to 47 for Atmel AVR UC3 C 64-pin packages

16 ISP_IO_COND_LEVEL Active level of ISP_IO_COND_PIN that the boot

loader will consider as a request for starting the USB

DFU ISP: 0 for GPIO low level, 1 for GPIO high level

31:17 ISP_BOOT_KEY_2 Boot key = 494Fh. This key is used to identify the

word as meaningful for the boot loader

32166A–AVR32806–06/11

Atmel AVR32806

6.3 Boot process

After reset, the boot process starts at 80000000h:

• If the ISP_FORCE configuration bit is 1 (see Table 6-1), the USB DFU ISP is immediately

started

• If the ISP_FORCE configuration bit is 0:

– If external events (power-on reset, external reset, OCD reset, JTAG reset, or JTAG

hardware reset) are among the reset causes, the boot process checks if the

ISP_IO_COND_EN configuration bit is 1, and if so, launches either the USB DFU

ISP or the application according to the ISP I/O configuration specified by the user

page Configuration Word2. If ISP_IO_COND_EN is 0, the application is launched.

– If the watchdog timer (WDT) is one of the reset causes, the boot process launches

the application. The watchdog timer is not stopped if the application was running

before reset.

– If an error (BOD or CPU error) is one of the reset causes, the boot process launches

either the USB DFU ISP or the application according to which one was running

before the reset.

32166A–AVR32806–06/11

Atmel AVR32806

Figure 6-2. Boot process.

Note:

• The ISP_FORCE configuration bit in the user page Configuration Word1 is set to 1 by the

ISP on each ISP command received, and it is set to 0 by the ISP when a request to start the

application is received. That means that after a command has been sent using BatchISP, the

ISP_FORCE=1?

Yes

Customer Application

(@ 80002000h)

Note:

ISP_IO_COND_EN and ISP_FORCE are

respectively bit 8 and bit 9 of the user

page configuration word1.

ISP_IO_COND_EN=1?

Reset Vector

(@ 80000000h)

Bootloader

(@ 80000000h)

ISP_FORCE=1 on DFU

Reset Cause:

POR or EXT or OCD or

JTAG or JTAG HW?

Disable WDT

Set ISP RAM Key

ISP RAM Key

Set?

Disable WDT

Clear ISP RAM Key

Yes

SW Reset CPU Regs

Reset Cause:

WDT?

No Yes

ISP RAM Key

Set?

Yes

ISP User Page Cfg

Word2 OK?

(CRC8, Boot Key, Pin)

Yes

ISP I/O Condition Active?

Yes

NoYes

ISP_FORCE=0

Start Customer

Application?

Yes

Reset

Requested?

NoYes

Jump

WDT Reset

ISP User page

configuration Word1 OK

(CRC8, Boot key)?

Yes

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Microcontrolador de Atmel

Atmel

Atmel SAM4L Xplained Pro Manual de usuario

Atmel

Atmel STK200 Manual de usuario

Atmel

Atmel develer DevelBoard Blue Guía rápida de usuario

Atmel

Atmel AVR 1908 Manual de usuario

Atmel

Atmel ATmega645 Instrucciones de instalación y funcionamiento

Atmel

Atmel megaAVR Manual de usuario

Atmel

Atmel AVR2103 Manual de usuario

Atmel

Atmel AVR AVR350 Instrucciones de instalación y funcionamiento

Atmel

Atmel STK512 Manual de usuario

Atmel

Atmel AT88CK109STK3 Manual de instalación

Atmel

Atmel AVR ATtiny22 Manual de instrucciones

Atmel

Atmel AT90PWM2 Manual de usuario

Atmel

Atmel ATtiny104 Xplained Nano Manual de usuario

Atmel

Atmel ATF15 DK3-U Series Manual de usuario

Atmel

Atmel AT32UC3A3256S Manual de usuario

Atmel

Atmel AT97SC3205T-SDK2 Manual de usuario

Atmel

Atmel ATSAMB11 BluSDK SMART Manual de usuario

Atmel

Atmel AVR461 Manual de usuario

Atmel

Atmel AVR XMEGA AU series Manual de usuario

Atmel

Atmel AVR042 Instrucciones de instalación y funcionamiento

Atmel

Atmel AT89C51 Guía del usuario

Atmel

Atmel AVR1921 Instrucciones de instalación y funcionamiento

Atmel

Atmel AT89RFD-10/EVLB002 Manual de usuario

Atmel

Atmel AVR AT90S2323 Manual de usuario

Manuales populares de Microcontrolador de otras marcas

AMS

AMS AS7261 Demo Kit Manual de usuario

Novatek

Novatek NT6861 Manual de usuario

Espressif Systems

Espressif Systems ESP8266 SDK Guía de configuración

Nuvoton

Nuvoton ISD61S00 ChipCorder Guía

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manual de usuario

Texas Instruments

Texas Instruments Chipcon CC2420DK Manual de usuario

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manual de usuario

NEC

NEC 78GK0S/K 1+ Series Instrucciones de instalación y funcionamiento

Mikroe

Mikroe SEMITECH N-PLC Click Instrucciones de instalación y funcionamiento

Intel

Intel Agilex Manual de usuario

Cypress

Cypress CY4607 HX2VL Manual de usuario

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manual de usuario

Texas Instruments

Texas Instruments TMS320F2837 D Series Manual de usuario

CYPRES

CYPRES CY14NVSRAMKIT-001 Manual de usuario

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manual de usuario

Espressif Systems

Espressif Systems ESP8266EX Instrucciones de funcionamiento

Abov

Abov AC33M8128L Manual de usuario

Laird

Laird BL654PA Manual de usuario
