Asus RT-AX86S Manual de usuario

User Guide

RT-AX86SRT-AX86S

Wireless-AX5700 Dual-band Gigabit RouterWireless-AX5700 Dual-band Gigabit Router

No part of this manual, including the products and software described

in it, may be reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language in any form or by any means, except

documentation kept by the purchaser for backup purposes, without the

express written permission of ASUSTeK Computer Inc. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired,

modied or altered, unless such repair, modication of alteration is authorized

in writing by ASUS; or (2) the serial number of the product is defaced or

missing.

ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND,

EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED

WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,

EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,

OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS

AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR

PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE

FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE

AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A

COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY

FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,

INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be

registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’benet, without intent

to infringe.

E19942

First Edition

March 2022

Table of contents

1 Getting to know your wireless router

1.1 Welcome!...........................................................................................6

1.2 Package contents ...........................................................................6

1.3 Your wireless router.......................................................................7

1.4 Positioning your wireless router ...............................................9

1.5 Setup Requirements................................................................... 10

2 Getting started

2.1 Router Setup ................................................................................. 11

A. Wired connection..................................................................11

B. Wireless connection.............................................................12

2.2 Quick Internet Setup (QIS) with Auto-detection.............. 14

2.3 Connecting to your wireless network.................................. 16

3 Conguring the General settings

3.1 Logging into the Web GUI........................................................ 17

3.1.1 Setting up the wireless security settings......................19

3.1.2 Managing your network clients.......................................20

3.1.3 Monitoring your USB device.............................................21

3.2 Creating a Guest Network........................................................ 24

3.3 AiProtection................................................................................... 26

3.3.1 Network Protection ..............................................................27

3.3.2 Setting up Parental Controls.............................................31

3.4 Using the Trac Manager ........................................................ 34

3.4.1 Managing QoS (Quality of Service) Bandwidth..........34

3.5 Trac Analyzer............................................................................. 37

3.6 Game................................................................................................ 38

3.6.1 Gear Accelerator....................................................................38

3.6.2 Mobile Game Mode..............................................................39

3.6.3 Open NAT.................................................................................40

Table of contents

3.7 Using the USB Application....................................................... 41

3.7.1 Using AiDisk ............................................................................41

3.7.2 Using Servers Center............................................................43

3.7.3 3G/4G ........................................................................................48

3.8 Using AiCloud 2.0........................................................................ 50

3.8.1 Cloud Disk................................................................................51

3.8.2 Smart Access...........................................................................52

3.8.3 AiCloud Sync...........................................................................53

4 Conguring the Advanced Settings

4.1 Wireless........................................................................................... 54

4.1.1 General......................................................................................54

4.1.2 WPS ............................................................................................57

4.1.3 Bridge ........................................................................................59

4.1.4 Wireless MAC Filter ...............................................................61

4.1.5 RADIUS Setting ......................................................................62

4.1.6 Professional.............................................................................63

4.2 LAN ................................................................................................... 66

4.2.1 LAN IP ........................................................................................66

4.2.2 DHCP Server............................................................................67

4.2.3 Route .........................................................................................69

4.2.4 IPTV ............................................................................................70

4.3 WAN.................................................................................................. 71

4.3.1 Internet Connection.............................................................71

4.3.2 Dual WAN .................................................................................73

4.3.3 Port Trigger..............................................................................74

4.3.4 Virtual Server/Port Forwarding........................................76

4.3.5 DMZ............................................................................................79

4.3.6 DDNS .........................................................................................80

4.3.7 NAT Passthrough...................................................................81

Table of contents

4.4 IPv6................................................................................................... 82

4.5 Firewall ............................................................................................ 83

4.5.1 General......................................................................................83

4.5.2 URL Filter ..................................................................................83

4.5.3 Keyword lter .........................................................................84

4.5.4 Network Services Filter .......................................................85

4.6 Administration.............................................................................. 87

4.6.1 Operation Mode ....................................................................87

4.6.2 System.......................................................................................88

4.6.3 Firmware Upgrade................................................................89

4.6.4 Restore/Save/Upload Setting ...........................................89

4.7 System Log .................................................................................... 90

5 Utilities

5.1 Device Discovery ......................................................................... 91

5.2 Firmware Restoration................................................................. 92

5.3 Setting up your printer server ................................................ 93

5.3.1 ASUS EZ Printer Sharing .....................................................93

5.3.2 Using LPR to Share Printer .................................................97

5.4 Download Master......................................................................102

5.4.1 Conguring Bit Torrent download settings.............. 103

5.4.2 NZB settings......................................................................... 104

6 Troubleshooting

6.1 Basic Troubleshooting .............................................................105

6.2 Frequently Asked Questions (FAQs) ..................................108

Appendices

Service and Support..............................................................................126

1 Getting to know your wireless1 Getting to know your wireless

routerrouter

1.1 Welcome!

Thank you for purchasing an ASUS RT-AX86S Wireless Router!

The strikingly designed black chassis with gaming-inspired red

accents, RT-AX86S features a 2.4GHz and 5GHz dual bands for

an unmatched concurrent wireless HD streaming; SMB server,

UPnP AV server, and FTP server for 24/7 le sharing; a capability

to handle 300,000 sessions; and the ASUS Green Network

Technology, which provides up to 70% power-saving solution.

1.2 Package contents

RT-AX86S Wireless Router Network cable (RJ-45)

Power adapter Quick Start Guide

Warranty card

NOTES:

• If any of the items are damaged or missing, contact ASUS for

technical inquiries and support. Refer to the ASUS Support Hotline

list at the back of this user manual.

• Keep the original packaging material in case you would need future

warranty services such as repair or replacement.

1.3 Your wireless router

WPS LED

O:WPS is not processing.

On:WPS is processing.

LAN 1~4 LEDs

O: No power or no physical connection.

On: Has physical connection to a local area network (LAN).

WAN (Internet) LED

Red: No IP or no physical connection.

On: Has physical connection to a wide area network (WAN).

USB LED

O: No power or no physical connection.

On: Has physical connection to USB devices.

2.4GHz LED

O: No 2.4GHz signal.

On:Wireless system is ready.

Flashing:Transmitting or receiving data via wireless connection.

5GHz LED

O: No 5GHz signal.

On:Wireless system is ready.

Flashing:Transmitting or receiving data via wireless connection.

Power LED

O: No power.

On: Device is ready.

Flashing slow: Rescue mode.

LED On/O button

This button turns on/off the LED indicators.

Power (DCIN) port

Insert the bundled AC adapter into this port and connect your router to a power source.

Power switch

Press this button to power on or off the system.

Reset button

This button resets or restores the system to its factory default settings.

USB 2.0 port

Insert a USB 2.0 device such as a USB hard disk or a USB ﬂash drive into this port.

Insert your iPad’s USB cable into this port to charge your iPad.

USB 3.0 port

Insert a USB 3.0 device such as a USB hard disk or a USB ﬂash drive into this port.

Insert your iPad’s USB cable into this port to charge your iPad.

WAN (Internet) port

Connect a network cable into this port to establish WAN connection.

LAN 1~4 ports

Connect network cables into these ports to establish LAN connection.

WPS button

This button launches the WPS Wizard.

NOTES:

• Use only the adapter that came with your package. Using other

adapters may damage the device.

• Specications:

DC Power adapter DC Output: +12V with 3A current

+19.5V with 2.31A current

Operating Temperature 0~40oCStorage 0~70oC

Operating Humidity 50~90% Storage 20~90%

1.4 Positioning your wireless router

For optimal wireless transmission between the wireless router and

connected wireless devices, ensure that you:

• Place the wireless router in a centralized area for a maximum

wireless coverage for the network devices.

• Keep the wireless router away from metal obstructions and

away from direct sunlight.

• Keep the wireless router away from 802.11g or 20MHz only

Wi-Fi devices, 2.4GHz computer peripherals, Bluetooth devices,

cordless phones, transformers, heavy-duty motors, ﬂuorescent

lights, microwave ovens, refrigerators, and other industrial

equipment to prevent signal interference or loss.

• Always update to the latest ﬁrmware.Visit the ASUS website at

http://www.asus.com to get the latest ﬁrmware updates.

• Orient the antennas as shown in the drawing below.

90°90 °90 °

1.5 Setup Requirements

To set up your wireless network, you need a computer that meets

the following system requirements:

• Ethernet RJ-45 (LAN) port (10Base-T/100Base-

TX/1000BaseTX)

• IEEE 802.11a/b/g/n/ac/ax wireless capability

• An installed TCP/IP service

• Web browser such as Internet Explorer, Firefox, Safari, or

Google Chrome

NOTES:

• If your computer does not have built-in wireless capabilities, you may

install an IEEE 802.11a/b/g/n/ac/ax WLAN adapter to your computer

to connect to the network.

• With its dual band technology, your wireless router supports 2.4GHz

and 5GHz wireless signals simultaneously. This allows you to do

Internet-related activities such as Internet surng or reading/writing

e-mail messages using the 2.4GHz band while simultaneously

streaming high-denition audio/video les such as movies or music

using the 5GHz band.

• Some IEEE 802.11n devices that you want to connect to your network

may or may not support 5GHz band. Refer to the device's manual for

specications.

• The Ethernet RJ-45 cables that will be used to connect the network

devices should not exceed 100 meters.

IMPORTANT!

• Some wireless adapters might have connectivity issues to 802.11ax

WiFi APs.

• If you’re experiencing such issue, please ensure you update the driver

to the latest version. Check your manufacturer's ocial support site

where software drivers, updates, and other related information can

be obtained.

• Realtek: https://www.realtek.com/en/downloads

• Mediatek:https://www.mediatek.com/products/connectivity-

and-networking/broadband-wi

• Intel: https://downloadcenter.intel.com/

Otros manuales para RT-AX86S

Tabla de contenidos

Otros manuales de Enrutador de red de Asus

Asus

Asus AX5400 Manual de usuario

Asus

Asus ISDNLink INET-800 Manual de usuario

Asus

Asus 90IG06K0-MU9R10 Manual de usuario

Asus

Asus BRT-AC828 Manual de usuario

Asus

Asus DSL-AC88U Manual de usuario

Asus

Asus ROG Rapture GT-AC5300 Manual de usuario

Asus

Asus RT-AC56S Manual de usuario

Asus

Asus RT-AC88U Manual de usuario

Asus

Asus RT-N13U - Wireless Router Manual de usuario

Asus

Asus BLUE CAVE Manual de usuario

Asus

Asus RT-AC51 Manual de instrucciones

Asus

Asus 90IG04K0-BU9100 Manual de usuario

Asus

Asus DSL-AC55U Manual de usuario

Asus

Asus GX-D1051 Manual de usuario

Asus

Asus DSL-AC88U Manual de usuario

Asus

Asus RT-AC66U Manual de usuario

Asus

Asus RT-AC750 Manual de usuario

Asus

Asus BRT-AC828/M2 Manual de usuario

Asus

Asus RT-AX86U Manual de usuario

Asus

Asus ZenWiFi Pro ET12 Manual de usuario

Asus

Asus ROG Strix GS-AX5400 Manual de usuario

Asus

Asus ZenWiFi Pro ET12 Manual de usuario

Asus

Asus RT-AC1500UHP Manual de usuario

Asus

Asus FX-D1161 Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
