Asus RT-AX86U Manual de usuario

Quick Start Guide

RT-AX86SRT-AX86S

Wireless-AX5700 Dual Band RouterWireless-AX5700 Dual Band Router

U18502 / First Edition / May 2021

Table of contentsTable of contents

Package contents........................................................................3

A quick look at RT-AX86S..........................................................3

Position your wireless router...................................................4

Preparing your modem.............................................................5

Setting up your RT-AX86S........................................................6

A. Wired connection .............................................................................6

B. Wireless connection.........................................................................6

FAQ ...................................................................................................8

This QSG contains these languages:

English

Български

Čeština

Hrvatski

Dansk

Nederlands

Eesti

Français

Suomi

Deutsch

Ελληνικά

Magyar

Italiano

Lietuvių

Latviski

Norsk

Português

Polski

Română

Русский

Srpski

Slovenský

Slovenščina

Español

Svenska

Український

Türkçe

תירבע

English

A quick look at RT-AX86SA quick look at RT-AX86S

WPS LED Power (DC-IN) port

LAN 1~4 LEDs Power button

WAN (Internet) LED Reset button

USB LED USB 2.0 port

2.4GHz LED USB 3.0 port

5GHz LED WAN (Internet) port

Power LED LAN 1 ~ 4 ports

LED on/o button WPS button

Package contentsPackage contents

RT-AX86S Wireless Router AC adapter

Network cable (RJ-45) Quick Start Guide

English

Position your wireless routerPosition your wireless router

For optimal wireless transmission between the wireless router and connected

wireless devices, ensure that you:

• Place the wireless router in a centralized area for a maximum wireless coverage

for the network devices.

• Keep the wireless router away from metal obstructions and away from direct

sunlight.

• Keep the wireless router away from 802.11g or 20MHz only Wi-Fi devices,

2.4GHz computer peripherals, Bluetooth devices, cordless phones, transformers,

heavy-duty motors, uorescent lights, microwave ovens, refrigerators, and other

industrial equipment to prevent signal interference or loss.

• Always update to the latest rmware. Visit the ASUS website at

http://www.asus.com to get the latest rmware updates.

• Orient the antennas as shown in the drawing below.

NOTES:

• Use only the adapter that came with your package. Using other

adapters may damage the device.

• Specications:

DC Power adapter DC Output: +12V with 3A current

+19.5V with 2.31A current

Operating Temperature 0~40oC Storage 0~70oC

Operating Humidity 50~90% Storage 20~90%

90°90 °90 °

English

Preparing your modemPreparing your modem

1. Unplug the power cable/DSL modem. If it has a

battery backup, remove the battery.

NOTE: If you are using DSL for Internet, you

will need your username/password from your

Internet Service Provider (ISP) to properly

congure the router.

2. Connect your modem to the router with the

bundled network cable.

3. Power on your cable/DSL modem.

4. Check your cable/DSL modem LED lights to ensure

the connection is active.

Unplug

English

Setting up your RT-AX86SSetting up your RT-AX86S

You can set up your router via wired or

wireless connection.

A. Wired connection

1. Plug your router into a power outlet and

power it on. Connect the network cable from

your computer to a LAN port on your router.

2. The web GUI launches automatically when you open a web browser. If it does

not auto-launch, enter http://router.asus.com.

3. Set up a password for your router to prevent unauthorized access.

B. Wireless connection

1. Plug your router into a power outlet and

power it on.

Laptop

Tablet

Smart phone

Modem

Wall Power Outlet

LINE LAN RESET PWR

Power

WAN

RT-AX86S

LAN

Laptop

Modem

Wall Power Outlet

LINE LAN RESET PWR

Power aWAN

RT-AX86S

English

2. Connect to the network with SSID shown on the product label on the back side

of the router. For better network security, change to a unique SSID and assign

a password.

ASUS router

ASUS_XX

Wi-Fi Name (SSID): ASUS_XX

* XX refers to the last two digits of 2.4GHz

MAC address. You can nd it on the label

on the back of your router.

3. You can choose either the web GUI or ASUS Router app to set up your router.

a. Web GUI Setup

•

Once connected, the web GUI launches automatically when you open a

web browser. If it does not auto-launch, enter http://router.asus.com.

•

Set up a password for your router to prevent unauthorized access.

English

b. App Setup

Download ASUS Router App to set up your

router via your mobile devices.

•

Turn on Wi-Fi on your mobile devices

and connect to your router’s network.

•

Follow ASUS Router App setup

instructions to complete the setup.

ASUS Router

ASUS

Router

Remembering your wireless router settings

• Remember your wireless settings as you complete the router setup.

Router Name: Password:

2.4 GHz network SSID: Password:

5GHz network SSID: Password:

FAQFAQ

1. Where can I nd more information about the wireless router?

•

Online FAQ site: https://www.asus.com/support/

• Technical support site: https://www.asus.com/support

• Customer hotline: refer to the Support Hotline section in this Quick Start

Guide

• You can get the user manual online at https://www.asus.com/support

български

Бърз преглед на Вашия RT-AX86SБърз преглед на Вашия RT-AX86S

Бърз прегледБърз преглед

RT-AX86S Адаптер за променлив ток

Мрежов кабел (RJ-45) Ръководство за бърз старт

WPS индикатор Порт захранване (DC-IN)

LAN 1~4 индикатор Пpeвклюцватeл на ахранването

WAN (Internet) индикатор Бутон за нулиране

2,5GHz индикатор USB 2.0 порт

2,4GHz индикатор USB 3.0 порт

5GHz индикатор WAN (Internet) Порт

Индикатор на захранването LAN 1~4 портове

Бутон индикатор вкл./изкл. WPS бутон

български

Разположение на безжичния рутерРазположение на безжичния рутер

За постигане на максимално добро предаване на безжичните сигнали

между безжичния рутер и свързаните с него мрежови устройства трябва:

• Да поставите безжичния рутер на централно място за максимално покритие

на мрежовите устройства.

• Рутерът да е отдалечен от метални прегради и да не е изложен на слънчева

светлина.

• Рутерът да е отдалечен от Wi-Fi устройства 802.11g или 20MHz, компютърни

периферни устройства 2,4GHz, Bluetooth (блутут) устройства, безжични

телефони, трансформатори, мощни мотори, флуоресцентни лампи,

микровълнови печки, хладилници и други промишлени машини за

избягване на смущенията или загубите на сигнала.

• Винаги използвайте най-новите версии на фърмуера. Посетете сайта на

ASUS http://www.asus.com за сваляне на последните версии на фърмуера.

• Cе антени да се ориентират както е показано на схемата по-долу.

ЗАБЕЛЕЖКА:

• Да се използва само адаптерът, предоставен в комплекта. Използването

на други адаптери може да повреди устройството.

• Технически характеристики:

Адаптер за

захранване с прав ток

Изходна мощност на прав ток: +12V с макс. ток 3A

+19.5V с макс. ток 2.31A

Работна температура 0~40oC Памет 0~70oC

Влажност при работа 50~90% Памет 20~90%

90°90 °90°
