Asus DSL-N55U Manual de instrucciones
U8625_DSL-N55U_QSG.indd 1
04/02/15 2:47:31 PM
Quick Start Manual
Kullanım Klavuzu
U8625_DSL-N55U_QSG.indd 3 11/4/13 2:47:31 PM
Table of contents
U8625 / First Edition / Oct. 2013
English.........................................................................................................................7
Français .......................................................................................................................12
Deutsch.......................................................................................................................17
Italiano ........................................................................................................................22
Русский.......................................................................................................................27
Български..................................................................................................................32
Čeština.........................................................................................................................37
Nederlands ................................................................................................................42
Eesti..............................................................................................................................47
Suomi...........................................................................................................................52
Ελληνικά......................................................................................................................57
Magyar ........................................................................................................................62
Latviski ........................................................................................................................67
Lietuvių .......................................................................................................................72
Polski............................................................................................................................77
Português...................................................................................................................82
Română.......................................................................................................................87
Slovensky....................................................................................................................92
Español........................................................................................................................97
Türkçe ..........................................................................................................................102
Українська.................................................................................................................107
Norsk............................................................................................................................112
Svenska .......................................................................................................................117
U8625_DSL-N55U_QSG.indd 2 11/4/13 2:47:31 PM
Note / Забележка / Poznámka /märkus / Megjegyzés/
piezīme/ Pastaba/ Uwaga/ Notă/ Примечание/ Obs/not/
Примітка/ Hinweis/NAPOMENA / BELEŠKA /OPOMBA
• For more details, refer to the user manual included in the support
CD.
•
За повече информация, вижте ръководството на потребителя,
намиращо се на помощния CD диск.
• Podrobnější informace viz uživatelská příručka na podpůrném disku
CD.
• Täpsemat teavet leiate seadmega kaasnenud tugijuhendi CD-lt.
• A további részleteket illetően tekintse meg a támogató CD-n lévő
felhasználói útmutatót.
• Detalizētāku informāciju meklējiet atbalsta CD esošajā lietotāja
rokasgrāmatā.
• Išsamiau žr. vartotojo vadovą, esantį šiame pagalbos kompaktiniame
(CD) diske.
• Dalsze szczegółowe informacje znajdują się w podręczniku
użytkownika na pomocniczym dysku CD.
• Pentru mai multe detalii, consultaţi manualul de utilizare inclus pe
CD-ul suport.
• Для получения дополнительной информации обратитесь к
руководству пользователя на компакт-диске.
• Viac podrobností nájdete v návode na obsluhu na CD s podporou.
• Daha fazla ayrıntı için destek CD'sinde bulunan kullanıcı kılavuzuna
bakın.
• Детальніше див. посібник користувача на компакт-диску
підтримки.
• Weitere Details nden Sie im Benutzerhandbuch auf der Support-
CD.
• Dodatne pojedinosti potražite u korisničkom priručniku na CD-u
podrške.
• Za više detalja, pogledajte uputstvo za korišćenje koje se nalazi na
CD-u za podršku.
• Za več podrobnosti glejte uporabniški priročnik na priloženem
CD-ju.
U8625_DSL-N55U_QSG.indd 6 11/4/13 2:47:32 PM
7
English
Hardware Features
1. Power LED 4. LAN LED
2. ADSL / WAN LED 5. 2.4GHz LED
3. Internet LED 6. 5GHz LED
Top
Rear
DSL-N55U Dual-band N600
Wireless ADSL Modem Router
ADSL
WAN
1. Reset button 5. USB 2.0 ports
2. Power (DC-In) port 6. Ethernet WAN port
3. Power switch 7. LAN 1~ 4 ports
4. WPS / WiFi button 8. DSL WAN (ADSL)
U8625_DSL-N55U_QSG.indd 7 11/4/13 2:47:34 PM
8
English
• USB External HDD/Flash disk:
• This wireless router works with most USB HDDs/Flash disks up
to 2TB and supports read-write access for FAT16, FAT32, EXT2,
EXT3, and NTFS.
• To safely remove the USB disk, launch the web GUI
(http://192.168.1.1 or http://router.asus.com), click the USB
icon on the Network Map page and click Eject USB disk.
• Incorrect removal of the USB disk, such as during video/music
• wireless router supports, visit:
http://event.asus.com/networks/disksupport
• For the list of printers that the wireless router supports, visit:
http://event.asus.com/2009/networks/printersupport
Package contents
If any of the items is damaged or missing, contact your
retailer.
DSL-N55U wireless modem router
Network cable (RJ-45)
AC adapter
Phone cable
Support CD (User Manual/utilities)
Quick Start Guide
• USB External HDD/Flash disk:
• This wireless router works with most USB HDDs/Flash disks up
to 2TB and supports read-write access for FAT16, FAT32, EXT2,
EXT3, and NTFS.
• To safely remove the USB disk, launch the web GUI
(http://192.168.1.1 or http://router.asus.com), click the USB
icon on the Network Map page and click Eject USB disk.
• Incorrect removal of the USB disk, such as during video/music
• wireless router supports, visit:
http://event.asus.com/networks/disksupport
• For the list of printers that the wireless router supports, visit:
http://event.asus.com/2009/networks/printersupport
Package contents
If any of the items is damaged or missing, contact your
retailer.
Network cable (RJ-45)
AC adapter
Phone cable
Support CD (User Manual/utilities)
Quick Start Guide
U8625_DSL-N55U_QSG.indd 8
11/4/13 2:47:35 PM
9
English
Positioning your wireless router
For the best wireless signal transmission between the wireless router
and the network devices connected to it, ensure that you:
• Place the wireless router at the center of your network for maximum
wireless coverage.
• Keep the device away from metal obstructions and away from direct
sunlight.
• Keep the device away from 802.11g or 20MHz only Wi-Fi devices,
2.4GHz computer peripherals, Bluetooth devices, cordless phones,
transformers, heavy-duty motors, uorescent lights, microwave
ovens, refrigerators, and other industrial equipment to prevent
signal interference or loss.
• For optimum performance, adjust the internal cooling system. Refer
to the user manual for details.
• Always update to the latest rmware. Visit the ASUS website at
http://www.asus.com to get the latest rmware updates.
45°45°
90°
ADSL
WAN
U8625_DSL-N55U_QSG.indd 9 11/4/13 2:47:36 PM
10
English
Before you proceed
1. Connect your devices.
Client
Wall power outlet
Splitter
Phone
DSL
2. Before setting up your network, ensure that the DSL LED
indicator is a solid light.
U8625_DSL-N55U_QSG.indd 10 11/4/13 2:47:37 PM
11
English
3. Launch a web browser and follow the Quick Internet Setup
(QIS) steps.
DSL-N55U-C1 is set up with these Internet and wireless settings.
If the QIS web page does not appear after you launched
the web browser, disable the proxy settings on the web
browser.
4. Setup complete.
U8625_DSL-N55U_QSG.indd 11 11/4/13 2:47:39 PM
12
Français
Caractéristiques matérielles
1. Voyant d’alimentation 4. Voyant LAN
2. Voyant ADSL / WAN 5. Voyant 2.4GHz
3. Voyant Internet 6. Voyant 5GHz
Vue d’en haut
Rear
DSL-N55U Dual-band N600
Wireless ADSL Modem Router
ADSL
WAN
1. Bouton de réinitialisation 5. Ports USB 2.0
2. Prise d’alimentation (CC) 6. Port réseau étendu
(WAN)
3. Bouton d’alimentation 7. Ports réseau local
(LAN) 1 à 4
4. Bouton WPS/Wi-Fi 8. DSL WAN (ADSL)
U8625_DSL-N55U_QSG.indd 12 11/4/13 2:47:41 PM
