Asus RT-AC1750U Manual de usuario
Quick Start Guide
Kullanım Klavuzu
RT-AC1750U
Wireless-AC1750 Dual Band Gigabit Router
¤
Q15122 / First Edition / December 2018
2
Table of contents
Package contents ........................................................................3
A quick look at RT-AC1750U....................................................3
Position your wireless router...................................................4
Preparing your modem.............................................................5
Setting up your Router..............................................................6
A. Wired connection .............................................................................6
B. Wireless connection.........................................................................7
FAQ ...................................................................................................9
Networks Global Hotline Information .................................18
This QSG contains these languages: English, Русский.
3
English
A quick look at RT-AC1750U
Package contents
RT-AC1750U Wireless Router AC adapter
Network cable (RJ-45) Quick Start Guide
LAN 1~4 LEDs WPS button
WAN LED Power (DC-IN) port
2.4GHz LED Power button
5GHz LED USB3.0 port
Power LED WAN (Internet) port
Reset button LAN 1 ~ 4 ports
4
English
Position your wireless router
For optimal wireless transmission between the wireless router and connected
wireless devices, ensure that you:
• Placethewirelessrouterinacentralizedareaforamaximumwirelesscoverage
for the network devices.
• Keepthewirelessrouterawayfrommetalobstructionsandawayfromdirect
sunlight.
• Keepthewirelessrouterawayfrom802.11gor20MHzonlyWi-Fidevices,
2.4GHz computer peripherals, Bluetooth devices, cordless phones, transformers,
heavy-duty motors, uorescent lights, microwave ovens, refrigerators, and other
industrial equipment to prevent signal interference or loss.
• Alwaysupdatetothelatestrmware.VisittheASUSwebsiteat
http://www.asus.comtogetthelatestrmwareupdates.
• Toensurethebestwirelesssignal,orientthefourdetachableantennasasshown
in the drawing below.
NOTES:
• Useonlytheadapterthatcamewithyourpackage.Usingotheradapters
may damage the device.
• Specications:
DC Power adapter DCOutput:+12Vwith2.5Acurrent
Operating Temperature 0~40oC Storage 0~70oC
Operating Humidity 50~90% Storage 20~90%
5
English
Preparing your modem
1. Unplug the power cable/DSL modem. If it has a
battery backup, remove the battery.
NOTE: If you are using DSL for Internet, you
will need your username/password from your
Internet Service Provider (ISP) to properly
conguretherouter.
2. Connect your modem to the router with the
bundled network cable.
3. Power on your cable/DSL modem.
4. Check your cable/DSL modem LED lights to ensure
the connection is active.
Unplug
6
English
Setting up your Router
You can set up your Router via wired or wireless connection.
A. Wired connection
1. Plug your router into a power outlet and power it on. Connect the network
cable from your computer to a LAN port on your router.
2. The web GUI launches automatically when you open a web browser. If it does
not auto-launch, enter http://router.asus.com.
3. Set up a password for your router to prevent unauthorized access.
1
Internet
Modem
4
3
WAN
2
LAN
Laptop
7
English
B. Wireless connection
1. Plug your router into a power outlet and power it on.
2. Connect to the network with SSID shown on the product label on the back side
of the router. For better network security, change to a unique SSID and assign
a password.
ASUS router
2.4G Wi-Fi Name (SSID): ASUS_XX_2G
5G Wi-Fi Name (SSID): ASUS_XX_5G
* XX refers to the last two digits of 2.4GHz
MACaddress.Youcannditonthelabel
on the back of your router.
RT-AC1750U
Laptop
Tablet
Smart phone
1
Internet
Modem
3
2
WAN
8
English
3. You can choose either the web GUI or ASUS Router app to set up your router.
a. Web GUI Setup
•
Once connected, the web GUI launches automatically when you open a
web browser. If it does not auto-launch, enter http://router.asus.com.
•
Set up a password for your router to prevent unauthorized access.
b. App Setup
Download ASUS Router App to set up your router via your mobile devices.
•
Turn on Wi-Fi on your mobile devices and connect to your router’s
network.
•
Follow ASUS Router App setup instructions to complete the setup.
ASUS Router
ASUS
Router
9
English
FAQ
1. WherecanIndmoreinformationaboutthewirelessrouter?
• OnlineFAQsite:https://www.asus.com/support/faq
• Technicalsupportsite:https://www.asus.com/support
• Customerhotline:refertotheSupportHotlinesectioninthisQuickStart
Guide
• Youcangettheusermanualonlineathttps://www.asus.com/support
Remembering your wireless router settings
• Rememberyourwirelesssettingsasyoucompletetheroutersetup.
Router Name: Password:
2.4 GHz network SSID: Password:
5GHz network SSID: Password:
10
Русский
Быстрый обзор RT-AC1750U
Комплект поставки
Беспроводной роутер RT-AC1750U Блок питания
Сетевой кабель (RJ-45) Краткое руководство
Индикаторы LAN 1~4 Кнопка WPS
WAN индикатор Разъем питания (DC-In)
Индикатор 2.4 ГГц Кнопка питания
Индикатор 5 ГГц Разъем USB3.0
Индикатор питания Порт WAN (Internet)
КНОПКА СБРОСА Порты LAN 1 ~ 4
