Asus 4G-AC68U Manual de usuario

User Guide

4G-AC68U

Dual-Band Wireless-AC1900 LTE Modem Router

No part of this manual, including the products and software described

in it, may be reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language in any form or by any means, except

documentation kept by the purchaser for backup purposes, without the

express written permission of ASUSTeK Computer Inc. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired,

modiﬁed or altered, unless such repair, modiﬁcation of alteration is authorized

in writing by ASUS; or (2) the serial number of the product is defaced or

missing.

ASUS PROVIDES THIS MANUAL“AS IS”WITHOUT WARRANTY OF ANY KIND,

EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED

WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,

EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,

OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS

AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR

PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE

FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE

AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A

COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY

FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,

INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be

registered trademarks or copyrights of their respective companies, and are used

only for identiﬁcation or explanation and to the owners’beneﬁt, without intent

to infringe.

E13374

First Edition

August 2017

Table of contents

1 Getting to know your wireless router

1.1 Welcome! ...........................................................................................7

1.2 Package contents............................................................................7

1.3 Your wireless router .......................................................................8

1.4 Device Properties......................................................................... 10

1.5 Positioning your router.............................................................. 11

1.6 Installing your router.................................................................. 12

1.6.1 Prepare the setup requirements......................................12

1.6.2 Set up your LTE wireless router. .......................................13

2 Getting started

2.1 Quick Internet Setup (QIS) with Auto- detection............. 15

3 Conﬁguring the General Settings

3.1 Using the Network Map ........................................................... 20

3.1.1 Setting up the wireless security settings......................21

3.1.2 System Status .........................................................................22

3.1.3 Managing your network clients.......................................23

3.1.4 Monitoring the Internet Status ........................................25

3.1.5 Monitoring your USB device.............................................26

3.2 Guest Network.............................................................................. 27

3.3 AiProtection................................................................................... 29

3.3.1 Network Protection..............................................................30

3.3.2 Setting up Parental Controls.............................................34

3.4 Adaptive QoS ................................................................................ 38

3.4.1 Bandwidth Monitor..............................................................38

3.4.2 QoS.............................................................................................39

3.4.3 Web History.............................................................................40

Table of contents

3.5 Traﬃc Analyzer ............................................................................. 41

3.6 Using the USB Application ....................................................... 42

3.6.1 Using AiDisk............................................................................42

3.6.2 Using Servers Center............................................................45

3.7 Using AiCloud 2.0 ........................................................................ 50

3.7.1 Cloud Disk................................................................................51

3.7.2 Smart Access...........................................................................52

3.7.3 Smart Sync...............................................................................53

3.7.4 Sync Server..............................................................................54

3.7.5 Settings.....................................................................................57

4 Conﬁguring the Advanced Settings

4.1 Wireless............................................................................................ 58

4.1.1 General......................................................................................58

4.1.2 WPS ............................................................................................60

4.1.3 WDS............................................................................................62

4.1.4 Wireless MAC Filter ...............................................................64

4.1.5 RADIUS Setting .....................................................................65

4.1.6 Professional ............................................................................66

4.2 LAN.................................................................................................... 69

4.2.1 LAN IP........................................................................................69

4.2.2 DHCP Server............................................................................70

4.2.3 Route .........................................................................................72

4.2.4 IPTV ............................................................................................73

4.2.5 Switch Control........................................................................73

4.3 WAN.................................................................................................. 74

4.3.1 Internet Connection.............................................................74

4.3.2 IPv6 (Internet Settings) .......................................................83

4.3.3 Dual WAN .................................................................................84

4.3.4 Port Trigger..............................................................................85

Table of contents

4.3.5 Virtual Server/Port Forwarding........................................87

4.3.6 DMZ............................................................................................90

4.3.7 DDNS .........................................................................................91

4.3.8 NAT Passthrough...................................................................92

4.4 IPv6 ................................................................................................... 93

4.5 VPN Server...................................................................................... 94

4.6 Firewall............................................................................................. 95

4.6.1 General......................................................................................95

4.6.2 URL Filter ..................................................................................95

4.6.3 Keyword ﬁlter .........................................................................96

4.6.4 Network Services Filter .......................................................96

4.6.5 IPv6 Firewall ............................................................................97

4.7 Administration.............................................................................. 98

4.7.1 Operation Mode....................................................................98

4.7.2 System.......................................................................................99

4.7.3 Firmware Upgrade............................................................. 101

4.7.4 Restore/Save/Upload Setting ........................................ 102

4.8 System Log...................................................................................103

4.9 Ethernet WAN Mobile Broadband Function Support List104

5 Utilities

5.1 Device Discovery........................................................................106

5.2 Firmware Restoration...............................................................107

5.3 Setting up your printer server...............................................108

5.3.1 ASUS EZ Printer Sharing .................................................. 108

5.3.2 Using LPR to Share Printer.............................................. 112

5.4 Download Master ......................................................................117

5.4.1 Conﬁguring Bit Torrent download settings.............. 119

5.4.2 NZB settings......................................................................... 120

5.4.3 eMule settings..................................................................... 120

6 Troubleshooting

6.1 Basic Troubleshooting..............................................................121

6.2 Frequently Asked Questions (FAQs) ...................................123

Appendices

Notices 132

ASUS Contact information..................................................................146

Networks Global Hotline Information.............................................147

1 Getting to know your wireless

router

1.1 Welcome!

Thank you for purchasing an ASUS 4G-AC68U Wireless Router!

The powerful and stylish 4G-AC68U features 2.4GHz and 5GHz

dual bands for an unmatched concurrent wireless HD streaming;

SMB server, UPnP AV server, and FTP server for 24/7 ﬁle sharing;

a capability to handle 300,000 sessions; and the ASUS Green

Network Technology, which provides up to 70% power-saving

solution.

1.2 Package contents

NOTES:

• Ifanyoftheitemsisdamagedormissing,contactyourretaileror

ASUS for technical inquiries and support, Refer to the ASUS Support

Hotline list at the back of this user manual.

• Keeptheoriginalpackagingmaterialincaseyouwouldneedfuture

warranty services such as repair or replacement.

4G-AC68U Wireless Router AC adapter

Network cable (RJ-45) Quick Start Guide

2 x 3G/4G antennas

1.3 Your wireless router

3G/4G signal strength LED

1 lit LED: Weak signal

2 lit LEDs: Normal signal

3 lit LEDs: Strong signal

Purple light for 3G connection, blue light for 4G connection

WPS LED

Oﬀ: WPS is not processing.

Flashing quick: WPS is processing.

USB 3.0 LED

Oﬀ: No power or no physical connection.

On: Has physical connection to USB 3.0 devices.

LAN LED

Oﬀ: No data activity or no physical connection.

On: Ethernet connection is established.

5GHz Wi-Fi LED

Oﬀ: No 5GHz signal.

On: 5GHz wireless is ready.

Flashing: Transmitting or receiving data via wireless connection.

2.4GHz Wi-Fi LED

Oﬀ: No 2.4GHz signal.

On: 2.4GHz wireless is ready.

Flashing: Transmitting or receiving data via wireless connection.

WAN (Internet) LED

Oﬀ: No data activity or no physical connection.

On: Has physical connection to a wide area network (WAN).

Power LED

Oﬀ: No power.

On: Device is ready.

Flashing slow: Rescue mode

Flashing quick: WPS is processing.

Reset button

This button resets or restores the system to its factory default settings.

Power on/oﬀ button

Press this button to power on or oﬀ the system.

Power (DC-In) port

Insert the bundled AC adapter into this port and connect your router to a

power source.

USB 3.0 port

Insert USB 3.0 compatible devices such as USB hard disks or USB ﬂash drives

into this port.

WAN (Internet) port

Connect a network cable into this port to establish WAN connection.

LAN (1~4) ports

Connect network cables into these ports to establish LAN connection.

WPS button

Long press the button to launch the WPS Wizard.

Wi-Fi On/Oﬀ button

Press this button to turn on /oﬀ the Wi-Fi connection.

Micro SIM/USIM card slot

Install a Micro SIM/USIM card into this slot to establish a Mobile Broadband

Internet connection.

18 Detachable LTE antennas

Fixed Wi-Fi antennas

NOTES:

• Useonlytheadapterthatcamewithyourpackage.Usingother

adapters may damage the device.

• EnsuretoinserttheMicroSIM/USIMcardintothecardslotbefore

powering on the router.

1.4 Device Properties

Power Consumption:

• Input:AC100~240V/50~60Hz,DC19V/2.37A(EU)

 Input:AC100~240V/50~60Hz,DC19V/3.42A(UK)

• Maximumpowerconsumption:25.8W

• Averagepowerconsumption:10.3W

• Theaveragepowerconsumptionwasdeterminedatroom

temperature ( 23 °C to 27 °C ) with the following load:

 • ActiveMobileBroadbandconnection

 • WirelessLANon;nodevicesareconnectedtothewireless

LAN

 • OnenetworkdeviceisconnectedtoaLANport;nodata

transfer; no network devices are connected to the other

LAN ports

Ambient conditions:

DC Power adapter DC Output: +19V with max 2.37A current ;

DC Output: +19V with max 3.42A current

Operating Temperature 0~40oCStorage Temperature 0~70oC

Operating Humidity 10~90% Storage Humidity 10~90%

Otros manuales para 4G-AC68U

Tabla de contenidos

Otros manuales de Enrutador de red de Asus

Asus

Asus DSL-N16 Manual de usuario

Asus

Asus RT-G32 - Wireless Router Manual de usuario

Asus

Asus ROG Rapture GT-BE98 Pro Manual de usuario

Asus

Asus RT-AX92U/CA Manual de usuario

Asus

Asus RT-G32 - Wireless Router Manual de usuario

Asus

Asus INET-810 Manual de usuario

Asus

Asus RT-AXE7800 Manual de usuario

Asus

Asus RT-AC2600 Manual de usuario

Asus

Asus RT-AC52U B1 Manual de usuario

Asus

Asus RT-AC57U Manual de usuario

Asus

Asus RTAXI600 Manual de usuario

Asus

Asus SuperSpeed N WL-500W Manual de usuario

Asus

Asus ZenWiFi Pro ET12 Manual de usuario

Asus

Asus RT-AC85MR Manual de usuario

Asus

Asus RT-AC55UHP Manual de usuario

Asus

Asus RT-N10U Instrucciones de funcionamiento y mantenimiento

Asus

Asus RT-BE96U Manual de usuario

Asus

Asus RT-N13U - Wireless Router Manual de usuario

Asus

Asus RT-AX86U Manual de usuario

Asus

Asus DSL-N55U Manual de instrucciones

Asus

Asus BLUE CAVE Manual de usuario

Asus

Asus WL-330NUL Manual de usuario

Asus

Asus RT-AC66U Manual de usuario

Asus

Asus ROG Rapture GT-AC2900 Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
