Home Prev Next CM550 Cable Modem User’s Guide 1

Safety Getting Started Installation USB Drivers Usage Troubleshooting Glossary

Touchstone™ CM550 Cable Modem

User’s Guide

Get ready to experience the Internet’s express lane! Whether you’re checking out

streaming media, downloading new software, or checking your email, the Touch-

stone CM550 Cable Modem brings it all to you faster and more reliably. The high-

speed, always-on connection won’t keep you waiting.

The Touchstone Cable Modem provides an USB connection for easy hookup. The

Touchstone Cable Modem also provides an Ethernet connection for use with either

a single computer or home/office LAN. You can even hook up two separate com-

puters at the same time using both these connections.

Installation can be as simple as making three connections and restarting your com-

puter. Your cable company will provide help with any special requirements.

Follow the links below for more information and detailed instructions.

Safety Requirements

Getting Started

Installing and Connecting Your Cable Modem

Installing USB Drivers on Your PC

Using the Cable Modem

Troubleshooting

Glossary

Export Regulations

This product may not be exported outside the U.S. and Canada without U.S. Department of Commerce, Bureau of Export Administration au-

thorization. Any export or re-export by the purchaser, directly or indirectly, in contravention of U.S. Export Administration Regulation is prohib-

ited.

The information in this document is subject to change without notice. The statements, configurations, technical data, and recommendations in

this document are believed to be accurate and reliable, but are presented without express or implied warranty. Users must take full responsi-

bility for their applications of any products specified in this document. The information in this document is proprietary to ARRIS.

ARRIS, Touchstone, and the ARRIS logo are trademarks of ARRIS International, Inc. All other trademarks and registered trademarks are the

property of their respective holders.

Release 5 Standard 1.0 January 2006

Home Prev Next Touchstone CM550 Cable Modem User’s Guide 3

Safety Getting Started Installation USB Drivers Usage Troubleshooting Glossary

Safety Requirements

ARRIS complies with the applicable requirements for performance, construction, la-

beling, and information as outlined below:

•Do not use the Cable Modem near water (i.e. wet basement, bathtub, sink

or near a swimming pool, etc.). Avoid pouring or spilling liquids on the Cable

Modem.

•Avoid using and/or connecting the Cable Modem during an electrical storm.

•Do not locate the Cable Modem near a heat source (i.e. heat registers, space

heaters, fireplaces, etc.).

•To prevent overheating your Cable Modem, please do not block the ventila-

tion holes on the sides of the unit.

•Use only AC adapter and power cord included with the Cable Modem.

•Install the Cable Modem near an easily accessible AC socket-outlet.

Markings, Symbols, and Labels

Regulatory Symbols (DOCSIS modems)

Regulatory Symbols (Euro-DOCSIS modems)

Model : CM550A

P/N : TC00DA1550

Rating: 9Vdc, 0.8A

FOR HOME OR OFFICE USE

Patents, Patents Pending,

2002/95/EC

RoHS

Model : CM550B

P/N : TC00EA1550

Rating: 9Vdc, 0.8A Made in China

Patents, Patents Pending,

RoHS

2002/95/EC

Home Prev Next Touchstone CM550 Cable Modem User’s Guide 4

Safety Getting Started Installation USB Drivers Usage Troubleshooting Glossary

Functional Indicators

Radio Frequency Emissions and Immunity

United States Compliance

This device complies with part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

Product Safety

UL listed per UL60950.

Symbol Definition

Instructions: The exclamation point within a triangle alerts you to the pres-

ence of important operating and maintenance instructions.

Alternating Current: A terminal to which or from which an alternating (sine

wave) current or voltage may be applied or supplied.

Direct Current: A terminal to which or from which a direct current or voltage

may be applied or supplied.

Home Prev Next Touchstone CM550 Cable Modem User’s Guide 5

Safety Getting Started Installation USB Drivers Usage Troubleshooting Glossary

European Compliance

This product complies with the provisions of the Electromagnetic Compatibility

(EMC) Directive (89/336/EEC), the Amending Directive (92/31/EEC), the Low Volt-

age Directive (73/23/EEC), and the CE Marking Directive (93/68/EEC). As such,

this product bears the CE marking in accordance with the above applicable Direc-

tive(s).

A copy of the Declaration of Conformity may be obtained from: ARRIS Internation-

al, Inc., 3871 Lakefield Drive, Suite 300, Suwanee, GA 30024.

As indicated by the symbol below, disposal of this product or battery is governed

by Directive 2002/96/EC of the European Parliament and of the Council on waste

electrical and electronic equipment (WEEE). WEEE could potentially prove harmful

to the environment; as such, upon disposal of the Cable Modem the Directive re-

quires that this product must not be disposed as unsorted municipal waste, but

rather collected separately and disposed of in accordance with local WEEE ordinanc-

es.

This product complies with directive 2002/95/EC of the European Parliament and

of the Council of 27 January 2003 on the restriction of the use of certain hazardous

substances (RoHS) in electrical and electronic equipment.

Home Prev Next Touchstone CM550 Cable Modem User’s Guide 6

Safety Getting Started Installation USB Drivers Usage Troubleshooting Glossary

Getting Started

About Your New Cable Modem

The Touchstone CM550 Cable Modem is a DOCSIS 2.0 or Euro-DOCSIS 2.0

(A-TDMA and S-CDMA) ready cable modem with the following features:

•Speed: much faster than dialup or ISDN service

•Convenience: supports USB 1.1 and Ethernet; both can be used simulta-

neously

•Compatibility: supports tiered data services (if offered by your cable

company)

What’s in the Box?

Make sure you have the following items before proceeding. Call your cable company

for assistance if anything is missing.

•Cable Modem

•AC Adapter

•Quick Installation Guide

•End User’s License Agreement

•USB Cable

•Ethernet Cable

•CD-ROM

What’s on the CD?

The CD provides the following items:

•User’s Guide

•USB Drivers (Windows 98SE/ME/2000/XP)

•USB Uninstall Utility

•Adobe Acrobat Reader

•ARRIS Contact Information

•End User License Agreement

Home Prev Next Touchstone CM550 Cable Modem User’s Guide 7

Safety Getting Started Installation USB Drivers Usage Troubleshooting Glossary

Items You Need

If you are installing the Cable Modem yourself, make sure you have the following

items on hand before continuing:

•

Cable modem package

: see What’s in the Box? for a list of items in the

package.

•

Coaxial cable (coax)

: as shown in the picture to the left, this is a thin ca-

ble with a connector on each end. It is the same kind of wire used to connect

your television for cable TV. You can buy coax from any electronics retailer

and many discount stores; make sure it has connectors on both ends.

(There are two types of connectors, slip-on and screw-on; the screw-on

connectors are best for use with your Cable Modem.) The coax should be

long enough to reach from your Cable Modem to the nearest cable outlet.

•

Splitter (optional)

: provides an extra cable connection by splitting a single

outlet into two. You may need a splitter if you have a TV already connected

to the cable outlet that you want to use. You can buy a splitter from any

electronics retailer and most discount stores; you may also need a short

piece of coaxial cable (with connectors); use it to connect the splitter to the

cable outlet and then connect the Cable Modem and TV to the splitter.

Note:

A splitter effectively cuts the signal in half and sends each half to its two

outputs. Using several splitters in a line may slow down or stop Internet

communications, or cause snowy TV pictures.

•

Information packet

: your cable company should furnish you with a packet

containing information about your service and how to set it up. Read this

information carefully and contact your cable company if you have any ques-

tions.

Coax Cable

Home Prev Next Touchstone CM550 Cable Modem User’s Guide 8

Safety Getting Started Installation USB Drivers Usage Troubleshooting Glossary

System Requirements

The Touchstone Cable Modem operates with most computers. The following de-

scribes requirements for each operating system; see the documentation for your

system for details on enabling and configuring networking.

To use the Cable Modem, you need DOCSIS high-speed Internet service from your

cable company.

Windows

Ethernet connection: Windows 95, Windows 98, Windows 98 SE (Second Edition),

Windows ME, Windows 2000, or Windows XP

USB connection: Windows 98 SE (Second Edition), Windows ME, Windows 2000, or

Windows XP

MacOS

Ethernet connection only: System 7.5 to MacOS 9.2 (Open Transport recommend-

ed) or MacOS X

Linux/other Unix

Ethernet connection only: Hardware drivers, TCP/IP, and DHCP must be enabled in

the kernel

Home Prev Next Touchstone CM550 Cable Modem User’s Guide 9

Safety Getting Started Installation USB Drivers Usage Troubleshooting Glossary

Ethernet or USB?

There are two ways to connect your computer (or other equipment) to the Cable

Modem. The following will help you decide which is best for you:

Ethernet

Ethernet is a standard method of connecting two or more computers into a Local

Area Network (LAN). Use the Ethernet connection if your PC has built-in Ethernet

hardware, or does not use Windows, or you want to share the Cable Modem con-

nection with several computers.

Note:

To connect two or more computers to the Ethernet port, you need a hub

or broadband router (available at computer retailers).

The Cable Modem package comes with a 6-foot (1.9m) Ethernet cable (the connec-

tors look like wide telephone connectors); you can purchase more cables if neces-

sary at a computer retailer. If you are connecting the Cable Modem directly to a PC,

or to an Ethernet hub or broadband router with a cross-over switch, ask for

Category 5 (CAT5) straight-through cable. If you are connecting the Cable Modem

to an Ethernet hub or broadband router without a crossover switch, ask for a Cat-

egory 5 crossover cable.

USB

USB (Universal Serial Bus) is meant for connecting a variety of accessories, such

as keyboards, mice, printers, and communications devices (including cable mo-

dems) to a single PC. Use the USB connection if you have only one computer, and

the computer is using a Windows operating system (Windows 98 Second Edition or

later), and has no built-in Ethernet hardware.

The Cable Modem package comes with a 5-foot (1.6m) USB cable; you can pur-

chase a longer cable—up to 14-foot (4.25m)—at a computer retailer. Ask for a

USB

A/B cable

—it has a long narrow connector on one end (to connect to the PC) and

a square connector on the other end (to connect to the Cable Modem).

Both

If you have two or more computers, you can connect one computer to the Cable

Modem’s USB port and one or more to the Ethernet port. To connect two or more

computers to the Ethernet port, you need a hub or broadband router (available at

computer retailers).

For more information about connecting two or more computers, contact your cable

service provider.

Ethernet Cable

USB Cable

Home Prev Next Touchstone CM550 Cable Modem User’s Guide 10

Safety Getting Started Installation USB Drivers Usage Troubleshooting Glossary

What About Security?

Having a high-speed, always-on connection to the Internet requires a certain

amount of responsibility to other Internet users—including the need to maintain a

reasonably secure system. While no system is 100% secure, you can use the fol-

lowing tips to enhance your system’s security:

•Keep your operating system updated with the latest security patches. Run

the system update utility at least weekly.

•Keep your email program updated with the latest security patches. In addi-

tion, avoid opening email containing attachments, or opening files sent

through chat rooms, whenever possible.

•Install a virus checker and keep it updated.

•Avoid providing web or file-sharing services over your Cable Modem. Be-

sides certain vulnerability problems, most cable companies prohibit running

servers on consumer-level accounts and may suspend your account for vi-

olating your terms of service.

•Use the cable company’s mail servers for sending email.

•Avoidusing proxy software unless you are certain that it is not open for

abuse by other Internet users (some are shipped open by default). Crimi-

nals can take advantage of open proxies to hide their identity when breaking

into other computers or sending spam. If you have an open proxy, your ca-

ble company may suspend your account to protect the rest of the network.

•If you connect your Cable Modem to a wireless LAN, make sure you enable

security and encryption on the wireless hub (for the same reason that you

should run only secured proxies). Consult the documentation and technical

support of the wireless equipment provider for help.

Otros manuales para Touchstone CM550

Tabla de contenidos

Otros manuales de Módem de Arris

Arris

Arris WBM750 Manual de usuario

Arris

Arris Touchstone TM702 Manual de usuario

Arris

Arris SURFboard SB6183 Manual de usuario

Arris

Arris Touchstone TM1602G Manual de usuario

Arris

Arris SURFboard SBG8300 Manual de usuario

Arris

Arris SURFboard SBV2402 Manual de usuario

Arris

Arris Touchstone TM608 Manual de usuario

Arris

Arris Touchstone SBG6700-AC Manual de usuario

Arris

Arris SURFboard SBV3202 Manual de usuario

Arris

Arris Touchstone CM900 Manual de usuario

Arris

Arris SURFboard SBG6950AC2 Manual de usuario

Arris

Arris SURFboard SBG7580-AC QSG Manual de usuario

Arris

Arris SURFboard SBG8300 Manual de usuario

Arris

Arris TG3452A Manual de usuario

Arris

Arris Surfboard G34 Manual de usuario

Arris

Arris SurfBoard SVG2482AC Manual de usuario

Arris

Arris Touchstone TM822G Manual de usuario

Arris

Arris SURFboard T25 Manual de usuario

Arris

Arris Touchstone TM502 Manual de usuario

Arris

Arris DOCSIS SURFboard S33 Manual de usuario

Arris

Arris SURFboard SBG6950AC2 Manual de usuario

Arris

Arris Touchstone TG2472 Manual de usuario

Arris

Arris Touchstone CM8200 Manual de usuario

Arris

Arris Touchstone DG860 Instrucciones de uso

Manuales populares de Módem de otras marcas

Davicom

Davicom DM562AP Manual de usuario

EpiValley

EpiValley TATA indicom SXC-1080 Manual de usuario

Zte

Zte WiMAX Manual de usuario

Intelimax

Intelimax MA-2060 Manual de usuario

SMC Networks

SMC Networks D3CM1604V Manual de uso y cuidado

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manual de usuario

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manual de usuario

Samsung

Samsung AceLink SAM-335A Manual de usuario

Enfora

Enfora Enabler-G Guía de configuración rápida

iRZ

iRZ ATM2-232 Manual de usuario

Zhone

Zhone 6310 Manual de usuario

Paradyne

Paradyne Hotwire 7976 Manual de usuario

US Robotics

US Robotics 3453C Manual de usuario

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manual de usuario

Zte

Zte MF823 Manual de usuario

Four-Faith

Four-Faith F1403 Manual de usuario

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manual de usuario

Gemtek

Gemtek WiMAX WIXFBR-103 Manual de usuario
