QUICK START GUIDE

Wi-Fi cable modem

G34

G36

2 3

What’s in the box

Wi-Fi cable modem

G34

G36

Soware License

& Warranty card

Quick Start Guide

G34

G36

Introduction

Status indicators

Get started

Set up your Wi-Fi network connection

3.1 Connect using your mobile device

Web Manager

Power adapter

2 3

What’s in the box

Wi-Fi cable modem

G34

G36

Soware License

& Warranty card

Quick Start Guide

G34

G36

Introduction

Status indicators

Get started

Set up your Wi-Fi network connection

3.1 Connect using your mobile device

Web Manager

Power adapter

4 5

Status indicators

Front panel LEDs

Note: Detailed LED status information is available online in the G34/G36

User Guide on the ARRIS Support website, www.arris.com/selelp.

Amber (Solid) - Power is connected

Green (Blinking) - Acquiring downstream/

upstream connection

Green (Solid) - Online status in DOCSIS 3.0

mode

Blue (Solid) - Online status in DOCSIS 3.1

mode

Amber (Blinking) - Firmware download

4 5

Status indicators

Front panel LEDs

Note: Detailed LED status information is available online in the G34/G36

User Guide on the ARRIS Support website, www.arris.com/selelp.

Amber (Solid) - Power is connected

Green (Blinking) - Acquiring downstream/

upstream connection

Green (Solid) - Online status in DOCSIS 3.0

mode

Blue (Solid) - Online status in DOCSIS 3.1

mode

Amber (Blinking) - Firmware download

6 7

Get started

This SURFboard device is a combination of DOCSIS 3.1

cable modem and four-port Ethernet router withWi-Fi.

It uses DOCSIS 3.1 technology to provide ultra

high-speed Internet access on yourWi-Fi home or small

business network.

Using the connection capabilities of the Wi-Fi cable

modem, you can connect your computer and other

network-enabled devices via the four Ethernet ports

or the 2.4 GHz and 5 Ghz Wi-Fi connections.TheWi-Fi

cable modem connects to the existing coaxial cable

connection in your home.

Note: For Internet connections, you need a cable

service connection (coaxial cable line) with a cable

Internet Service Provider.The

G34/G36

will not

operate with a Digital Subscriber Line service (DSL)

or Satellite Internet service.

6 7

Get started

This SURFboard device is a combination of DOCSIS 3.1

cable modem and four-port Ethernet router withWi-Fi.

It uses DOCSIS 3.1 technology to provide ultra

high-speed Internet access on yourWi-Fi home or small

business network.

Using the connection capabilities of the Wi-Fi cable

modem, you can connect your computer and other

network-enabled devices via the four Ethernet ports

or the 2.4 GHz and 5 Ghz Wi-Fi connections.TheWi-Fi

cable modem connects to the existing coaxial cable

connection in your home.

Note: For Internet connections, you need a cable

service connection (coaxial cable line) with a cable

Internet Service Provider.The

G34/G36

will not

operate with a Digital Subscriber Line service (DSL)

or Satellite Internet service.

8 9

Connect the coaxial cable (not included) from the

cable wall outlet or RF splier (not included) to the

Cable connector on the rear of your Wi-Fi cable

modem.

Tighten the

connector by hand.

Connect an Ethernet cable (not included) to any

Ethernet port on the rear of your Wi-Fi cable modem

and the Ethernet port on your PC or laptop.

8 9

Connect the coaxial cable (not included) from the

cable wall outlet or RF splier (not included) to the

Cable connector on the rear of your Wi-Fi cable

modem.

Tighten the

connector by hand.

Connect an Ethernet cable (not included) to any

Ethernet port on the rear of your Wi-Fi cable modem

and the Ethernet port on your PC or laptop.

10 11

Connect the power adapter to the Power port on the

rear of your Wi-Fi cable modem, then plug it into an

electrical wall outlet that is not controlled by a wall

switch to power on your Wi-Fi cablemodem.

YourWi-Fi cable modem

will automatically power

ON when the power

adapter is connected.

Check the front panel LED on your Wi-Fi cable

modem. Aer a brief pause, the LED should light up

SOLID green or SOLID blue.
