OPERATING INSTRUCTIONS

Read the instructions carefully before installing and operating the appliance or performing

maintenance operations. Observe all the safety instructions; failure to observe the instructions may

cause accidents and/or damages. Store these instructions for future reference.

ELECTRIC CONVECTOR HEATER

WITH GLASS PANEL

IP24

V 09/16

GENERAL SAFETY INFORMATION

Use this convector only as outlined in this manual. Any other use not

recommended by the manufacturer may cause fire, electric shock or

injury to persons.

This convector is designed for domestic use. It must not be used for

commercial or industrial purposes.

Ensure that the mains voltage complies with that indicated on the

convector data plate (220-240VAC/50Hz).

This appliance can be used by children aged from 8 years and

above and people with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance in a

safe way and understand the hazards involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children

without supervision.

Remove the convector from its packaging and check that it is in good

condition before use. Keep any plastic bags away from children.

Check the cord and plug before using the convector to ensure that

they have not been damaged during transport.

This product is not a toy. Children of less than 3 years should be

kept away unless continuously supervised.

Children aged from 3 and less than 8 years shall only switch on/off

the appliance provided that it has been placed or installed in its

intended normal operating position and they have been given

instruction concerning use of the appliance in a safe way and

understand the hazards involved.

Children aged from 3 years and les than 8 years shall not plug in,

regulate and clean the appliance or perform user maintenance.

CAUTION - Some parts of this product can become very hot and

cause burns. Particular attention has to be given where children

and vulnerable people are present.

WARNING: In order to avoid hazard due to inadvertent resetting of

the thermal cut-out, this appliance must not be supplied through and

external switching device, such as a timer, or connected to a circuit

that is regularly switched on and off by the utility.

WARNING: do not use the fan heater with a controller or any

other external device that activates the appliance

automatically, as there may be a risk of fire if the fan heater is

V 09/16

covered or incorrectly positioned.

The appliance is equipped with an IP24 degree of protection

and can be used in private bathrooms in zone 2.

The convector must not be touched by people that use bath tubs

and showers.

Disconnect the mains power when the appliance is not used or for

cleaning operations.

To disconnect the convector, set the selector to 0 and remove the

plug from the socket. Pull on the plug only. Do not pull the cord.

Avoid placing fingers or foreign objects in the air inlet/outlet

grilles, as this may lead to electric shock or fire and may damage the

convector. To avoid the risk of fire, do not block the grilles or tamper

with them in any way while the convector operates.

Do not use the convector if the cord or plug is damaged. If the

power supply cord is damaged, it must be replaced by the

manufacturer, dealer or a similarly qualified person so as to avoid any

safety risks.

Do not place any objects on the cord and do not bend it. During

operation, the cord must be entirely unwound.

It is not advisable to use extension cords, as these may overheat

and cause the risk of fire. Do not use a single extension cord to

operate more than one convector.

The convector heats up significantly during operation. Risk of

burn. To avoid injury, do not allow skin to come into contact with a hot

surface. Use the handle to move the convector. Keep flammable

materials, such as furniture, cushions, blankets, paper, cloths,

curtains and suchlike at least 1 m from the front and back

Do not immerse the cord, plug or any other element of the panel

V 09/16

in water or other liquids.

Do not touch the plug or convector with wet hands.

Avoid using the convector in dusty environments or in the

presence of flammable vapours (e.g. in workshops or garages).

Do not place the convector above or near another heat source.

WARNING: AVOID COVERING THE CONVECTOR TO PREVENT IT

FROM OVERHEATING.

The symbol below signals the above warning:

The convector may cause risk of fire if, while in operation, is

covered by or comes into contact with flammable material including

curtains, drapery, blankets, etc. KEEP THE CONVECTOR AWAY

FROM THESE MATERIALS.

Do not insert and avoid accidental insertion of any external

objects into the ventilation or discharge outlets as this may lead to

electric shock, fire or damage the convector.

A convector contains parts that generate arcs or sparks. It must

not be used in potentially dangerous areas such as areas at risk of

fire or explosion, or areas loaded with chemical substances or

humidity.

Do not use the convector on soft surfaces such as beds, where

the grilles may be covered. Always stand the convector on a flat,

stable surface when in operation, in order to prevent it from

overturning. Arrange the cord in such a way that the convector and

other objects do not rest on it. Do not run the cord under carpets. Do

not cover the cord with blankets, carpets or similar materials. Place

the cord far away from busy areas, or in a place where it cannot be

accidentally pulled-out.

This convector cannot be used in bathrooms, laundry rooms, next

to a shower or swimming pool or in similar indoor environments.

Never position the convector where it may fall into a bath or other

containers of water.

Never position the convector on a wet floor.

In any case, the adjustment knobs must never be accessible by

anyone in a bath or shower.

Do not position the convector below an electric socket.

The socket must be earthed.

Do not allow the electric cord to touch the metal structure of the

V 09/16

convector when it is hot or in operation, in order to avoid the high

temperatures ruining the cord.

Do not operate the convector outdoors. Do not use the convector

in front of or near an open window.

WARNING: do not use the convector with an external controller

or any other external device that activates the convector

automatically, as there may be a risk of fire if the convector is

covered or incorrectly positioned.

Upon initial start-up, the convector may emit a slight, harmless

smell. This smell is a normal effect of the initial heating up of the

internal heating elements, and should not recur later on.

Do not attempt to repair, disassemble or modify the convector.

The convector does not contain parts that can be repaired by the

user.

Turn the switch off and unplug before carrying out any

maintenance work or moving the convector. Always unplug from the

socket when the convector is not in use.

WARNING: ALWAYS UNPLUG WHEN CARRYING OUT

MAINTENANCE WORK OR MOVING THE CONVECTOR.

Do not place anything on the convector; avoid placing wet

garments on the convector.

Turn the appliance off if unattended in order to avoid accidents.

If the convector is not used for prolonged periods, disconnect the

plug, replace the convector in its box and store it in a dry, ventilated

place.

Ensure that the air inlet /outlet are not close to walls or curtains

when the convector is in use, so as to avoid obstructing the convector

and hampering its efficiency.

Should you hear an abnormal noise or detect an unusual smell

when using the convector, cease use and unplug immediately.

Do not expose the elderly or children to a continuous flow of air.

Do not use the convector if it has been damaged or dropped.

WARNING:

THE ON/OFF SWITCH IS NOT THE ONLY MEANS TO

DISCONNECT THE POWER SUPPLY. ALWAYS PULL OUT THE

PLUG FROM THE SOCKET IN THE EVENT OF MAINTENANCE

OPERATIONS, WHEN MOVING THE PANEL OR WHEN NOT IN

USE.

V 09/16

DESCRIPTION OF PARTS

FRONT VIEW SIDE VIEW REAR VIEW

A. Delivery/intake grille

B. Feet with wheels

C. ON/OFF switch

D. Side Control panel

E. Rear holes for wall mounting

F. Rear brackets for wall mounting

HOW TO INSTALL THE APPLIANCE

The convector can be used on the floor, after assembling the feet, or alternatively it can be wall-mounted using the

specific accessories supplied.

MONTARE I PIEDINI IN DOTAZIONE

A. Floor portable using: how to assemble the feet with wheels supplied

The convector is packed without feet. These must therefore be assembled before using the appliance.

Assemble the feet as shown in the figure and put the convector in an upright position. Position the unit on a flat,

stable surface and stop the wheels with the proper wheels locks before turning it on.

1. Turn the convector upside down and

loosen the wing nuts.

2. Insert the feet. The longest part

must be positioned behind on

the rear the convector.

3. Tighten the wing nuts on the feet.

B. Wall-mounting: how to assemble the rear bracket and mount the convector onto the wall

The convector packaging contains all the accessories necessary for wall-mounting.

To wall-mount, proceed as follows:

Remove the rear bracket from the back of the unit as described in the pictures below.

V 09/16

1. Unscrew the two screws on top of the 2

vertical bars of the wall bracket.

2. Pull down the wall bracket by pressing downward on the

top of the two vertical bars of the wall bracket.

3. Remove the bracket for wall mounting from the convector completely.

4. By supporting the bracket onto the wall, mark on the

wall with a pencil the points where it is necessary to

make the holes in order to insert the Fishers. Observe

the minimum distances from the walls as pointed out

in the picture below.

5. Drill holes in the wall and insert the 4 Fishers.

Secure the bracket to the wall and insert the 4

screws supplied.

6. Place the unit upright. Insert the two lower parts of the

bracket into the holes on the rear of the convector in the

lower part.

7. Insert the two upper parts of the bracket into the

holes on the rear of the convector in the upper

part.

V 09/16

8. Tighten the screws at the top of the convector firmly.

9. Installation complete.

HOW TO USE THE CONVECTOR

Connect the power cord to a suitable electric socket (220-240V~/50Hz).

ON/OFF switch (on the right side)

Bring the on/off switch to the “ON” position.

When the appliance emits a beep this means that the convector is ready for use.

Bring the switch to the “0FF” position to switch off the convector.

LED DISPLAY

ECO mode:

750 W, reduced power to

save energy

SUPER mode: maximum

power (1500W)

COMFORT mode:

it adjusts automatically heat output and

therefore energy consumption, according to set

tem

erature.

Timer on setting/

timer set

°C

Temperature and timer

display

V 09/16

CONTROL PANEL

WARNING: THE TEMPERATURE SELECTION BUTTON IS ACTIVE ONLY IN COMFORT MODE.

The appliance is fitted with an anti tip-up device that prevents it from operating when it detects that the product is inclined.

Do not position the appliance on its side or upside down.

The remote control uses Lithium/Manganese button cells, model no. CR2032-3 V, compliant with Battery Directive no.

2006/66/CE (supplied with the remote control).

HOW TO INSERT / REMOVE THE REMOTE CONTROL BATTERIES (refer to the diagram below)

Open the battery cover at the rear of the remote control (press and pull the cover).

Place the battery into the cover, observing the correct polarity. Insert the cover onto the remote control.

REMOTE CONTROL

ON/OFF button

TEMPERATURE

button

Mode selection

button ECO, SUPER

or COMFORT

TIMER button

When the appliance is operating, the operating

time can be set by touching this button: the

timer display shows a flashing 0 and pressing

TIMER you can set the desired time, between

0,5 and 8 hours, with each touch

corresponding to half and hour.

The display shows the set time: wait 5” for the

setting to be confirmed. The unit will switch off

automatically at the end of the programmed time

(stand by).

In order to switch it on again press the button

ON/OFF.

If a TIMER is set the LED remains on.

ON/OFF buttons

Touching the ON/OFF button will cause the ECO

LED to light and the appliance will begin to

operate in ECO mode.

The display will show ambient temperature.

Touching the button ON/OFF once again the

LED will show room temperature.

To switch off the convector completely, place

the on/off switch in the “0FF” position.

TEMPERATURE button

When COMFORT mode has been set, touching

this button will allow you to set the

temperature: the display will show ambient

temperature and, by pressing this button, the

desired temperature can be set between 5 and

35°C. Once the desired temperature has been

set, wait 5” for the setting to be confirmed. After

5” the display will show the ambient temperature

once again.

This function is active only in COMFORT

mode.

ECO/SUPER/COMFORT selection

button

- ECO mode: 750 W, reduced power to save

energy

- SUPER mode: maximum heating power

(1500W)

- COMFORT mode: automatic adjustment of

heat emission according to set temperature

ECO is the default mode.

ON/OFF switch

V 09/16

MAINTENANCE AND STORAGE

ALWAYS UNPLUG THE APPLIANCE BEFORE CLEANING OR MAINTENANCE.

IMPORTANT: DO NOT SUBMERGE THE CONVECTOR IN WATER.

Cleaning the outside surface of the appliance

Turn the switch off and unplug before carrying out any maintenance work or moving the appliance.

Use a soft cloth to remove any dust from the convector.

If the convector is excessively dirty, use a soft cloth moistened with water and a mild detergent at a temperature lower than

50°C. Let the convector dry completely before use.

Do not use corrosive detergents or solvents such as petrol. Do not wash the appliance with water. Do not use oils, chemical

substances or other items to clean that may damage the surface.

Use a vacuum cleaner to remove dust from the air inlet/outlet grilles.

STORAGE

If the appliance is not used for prolonged periods, it must be stored together with this manual in its original packaging, in a

cool and dry place.

Information for correct disposal of the product in accordance with the European Directive 2012/19/EU

At the end of its working life this equipment must not be disposed of as an household waste. It must be taken to special local

community waste collection centres or to a dealer providing this service. Disposing of electrical and electronic equipment

separately avoids possible negative effects on the environment and human health deriving from an inappropriate disposal and

enables its components to be recovered and recycled to obtain significant savings in energy and resources. In order to

underline the duty to dispose of this equipment separately, the product is marked with a crossed-out dustbin.

Information for correct disposal of the battery in accordance with the European Directive 2006/66/EC

Please replace battery when its electricity charge is used up: please do not eliminate this battery together with normal

household waste. It must be taken to special local community waste collection centres or to a dealer providing this service.

Disposing of a battery separately avoids possible negative effects on the environment and human health deriving from an

inappropriate disposal and enables its components to be recovered and recycled to obtain significant savings in energy and

resources. In order to underline the duty to dispose of this equipment separately, the battery is marked with a crossed-out

dustbin.

www.argoclima.com

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Calentador de Argo

Manuales populares de Calentador de otras marcas

oventrop

oventrop Regucor Series Manual de usuario

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manual de usuario

ELMEKO

ELMEKO ML 150 Manual de usuario

BN Thermic

BN Thermic 830T Manual de usuario

KING

KING K Series Guía

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guía de inicio rápido

Well Straler

Well Straler RC-16B Manual de usuario

EUROM

EUROM 333299 Manual de usuario

Heylo

Heylo K 170 Manual de usuario

Eterna

Eterna TR70W Manual de usuario

Clarke

Clarke GRH15 Manual de instrucciones

IRSAP

IRSAP The Radiator Company Ovali Manual de usuario

Empire Heating Systems

Empire Heating Systems WCC65 Manual de usuario

Wetekom

Wetekom 92 86 43 Manual de usuario

Desa

Desa SPC170-F Manual de usuario

Watlow

Watlow Watrod Electric Tubular Heaters Manual de usuario

Haverland

Haverland ECO-DRY GPS Series Manual de lista de piezas

Stelpro

Stelpro ASILVC2060 Series Manual de usuario
